PVA6LRE21141 E-SWITCH
Hersteller: E-SWITCHCategory: Push Button Switches
Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-ON
Mounting: on panel
Operating temperature: -20...70°C
Switching method: OFF-ON
Contact material: silver
Contacts configuration: SPST-NO
Type of switch: vandal resistant
Panel thickness: 1...6mm
Key stroke: 2.3mm
Leads dimensions: 2.75x0.5mm
Mounting hole diameter: Ø16mm
Body dimensions: Ø18.5x21.8mm
Max. contact resistance:: 50mΩ
Stable positions number: 2
Number of positions: 2
DC contacts rating @R: 2A / 36V DC
Illumination voltage: 3V DC
Operating Force: 4.51N
Electrical life: 100000 cycles
Mechanical durability: 100000 cycles
Min. insulation resistance: 1GΩ
Manufacturer series: PVA6
Actuator colour: black
Body colour: black
Backlight colour: blue
Leads: for soldering
Button shape: convex; round
Contact plating: gold-plated
IP rating: IP67
Illumination: LED; ring
Anzahl je Verpackung: 1 Stücke
auf Bestellung 67 Stücke:
Lieferzeit 7-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 5+ | 15.13 EUR |
| 35+ | 13.5 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PVA6LRE21141 E-SWITCH
Category: Push Button Switches, Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-ON, Mounting: on panel, Operating temperature: -20...70°C, Switching method: OFF-ON, Contact material: silver, Contacts configuration: SPST-NO, Type of switch: vandal resistant, Panel thickness: 1...6mm, Key stroke: 2.3mm, Leads dimensions: 2.75x0.5mm, Mounting hole diameter: Ø16mm, Body dimensions: Ø18.5x21.8mm, Max. contact resistance:: 50mΩ, Stable positions number: 2, Number of positions: 2, DC contacts rating @R: 2A / 36V DC, Illumination voltage: 3V DC, Operating Force: 4.51N, Electrical life: 100000 cycles, Mechanical durability: 100000 cycles, Min. insulation resistance: 1GΩ, Manufacturer series: PVA6, Actuator colour: black, Body colour: black, Backlight colour: blue, Leads: for soldering, Button shape: convex; round, Contact plating: gold-plated, IP rating: IP67, Illumination: LED; ring, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote PVA6LRE21141 nach Preis ab 13.5 EUR bis 25.84 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
PVA6LRE21141 | Hersteller : E-SWITCH |
Category: Push Button Switches Description: Switch: vandal resistant; Pos: 2; SPST-NO; 2A/36VDC; IP67; OFF-ON Mounting: on panel Operating temperature: -20...70°C Switching method: OFF-ON Contact material: silver Contacts configuration: SPST-NO Type of switch: vandal resistant Panel thickness: 1...6mm Key stroke: 2.3mm Leads dimensions: 2.75x0.5mm Mounting hole diameter: Ø16mm Body dimensions: Ø18.5x21.8mm Max. contact resistance:: 50mΩ Stable positions number: 2 Number of positions: 2 DC contacts rating @R: 2A / 36V DC Illumination voltage: 3V DC Operating Force: 4.51N Electrical life: 100000 cycles Mechanical durability: 100000 cycles Min. insulation resistance: 1GΩ Manufacturer series: PVA6 Actuator colour: black Body colour: black Backlight colour: blue Leads: for soldering Button shape: convex; round Contact plating: gold-plated IP rating: IP67 Illumination: LED; ring |
auf Bestellung 67 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||||
 |
PVA6LRE21141 | Hersteller : E-Switch |
Description: SWITCH PUSHBUTTON SPST 2A 36V Packaging: Tray Features: Fixed LED Ring Current Rating (Amps): 2A (DC) Mounting Type: Panel Mount, Front Circuit: SPST Type: Anti-Vandal, Illuminated Switch Function: Off-On Operating Temperature: -20°C ~ 70°C Termination Style: Solder Lug Illumination Type, Color: LED, Blue Illumination Voltage (Nominal): 2.8 ~ 3.7 VDC Actuator Type: Round, Button, Domed Ingress Protection: IP67 - Dust Tight, Waterproof Panel Cutout Dimensions: Circular - 16.00mm Dia Color - Actuator/Cap: Black Actuator Marking: No Marking Voltage Rating - DC: 36 V |
auf Bestellung 526 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||||
 |
PVA6LRE21141 | Hersteller : E-Switch |
Pushbutton Switches 2A 36VDC Off-On Blk Blu LED SLDR |
auf Bestellung 566 Stücke: Lieferzeit 148-152 Tag (e) |
|
||||||||||||||||
 |
PVA6LRE21141 | Hersteller : E-SWITCH |
Description: E-SWITCH - PVA6LRE21141 - Vandalensicherer Schalter, PVA6 Series, 16 mm, SPST-NO-DM, Aus-Ein, Rund, Schwarz, eloxiert tariffCode: 85365019 rohsCompliant: YES Schalteranschlüsse: Lötfahne Betätiger-/Kappenfarbe: Schwarz, eloxiert hazardous: false rohsPhthalatesCompliant: YES Plattenausschnitt (H x B): - Schalterfunktion: Aus-Ein isCanonical: Y IP-Schutzart: IP67 usEccn: EAR99 AC-Kontaktstrom, max.: - euEccn: NLR DC-Kontaktstrom, max.: 2A Kontaktspannung V DC: 36V Farbe der Beleuchtung: Blau Durchmesser des Frontplattenausschnitts: 16mm Schaltermontage: Panelmontage Produktpalette: PVA6 Series productTraceability: No Druckknopf-Betätiger: Rund Kontaktkonfiguration: SPST-NO-DM Kontaktspannung V AC: - SVHC: No SVHC (27-Jun-2018) |
auf Bestellung 1 Stücke: Lieferzeit 14-21 Tag (e) |
