Produkte > SUNON > SF11580AT1082HBL.GN
SF11580AT1082HBL.GN

SF11580AT1082HBL.GN SUNON


sf11580at201082hblgn(a08000550g-00).pdf Sunon AC Axial Fan & Blower.pdf Hersteller: SUNON
Category: AC115V Fans
Description: Fan: AC; axial; 115VAC; 80x80x25mm; 37m3/h(±5%); 34.5dBA; ball
Lead length: 0.33m
Enclosure material: aluminium
Current rating: 0.1A
Supply voltage: 115V AC
Leads: leads x2
Frequency: 60Hz
Type of fan: AC
Fan dimensions: 80x80x25mm
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 37m3/h (±5%)
Static pressure: 4.82mm H2O
Noise level: 34.5dBA
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Power consumption: 11W
Wire size: 24AWG
Kind of fan: axial
Min. insulation resistance: 500MΩ
Operating temperature: -10...70°C
auf Bestellung 1125 Stücke:

Lieferzeit 14-21 Tag (e)
Anzahl Preis
6+14.26 EUR
10+12.91 EUR
50+11.55 EUR
200+10.74 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
Produktrezensionen
Produktbewertung abgeben

Technische Details SF11580AT1082HBL.GN SUNON

Category: AC115V Fans, Description: Fan: AC; axial; 115VAC; 80x80x25mm; 37m3/h(±5%); 34.5dBA; ball, Lead length: 0.33m, Enclosure material: aluminium, Current rating: 0.1A, Supply voltage: 115V AC, Leads: leads x2, Frequency: 60Hz, Type of fan: AC, Fan dimensions: 80x80x25mm, Impeller material: thermoplastic, Flammability rating: UL94V-0, Kind of Bearing: ball, Fan efficiency: 37m3/h (±5%), Static pressure: 4.82mm H2O, Noise level: 34.5dBA, Rotational rate/speed: 2900rpm, Current and power consumption tolerance: ±15%, Power consumption: 11W, Wire size: 24AWG, Kind of fan: axial, Min. insulation resistance: 500MΩ, Operating temperature: -10...70°C, Anzahl je Verpackung: 1 Stücke.

Weitere Produktangebote SF11580AT1082HBL.GN nach Preis ab 10.74 EUR bis 42.86 EUR

Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
SF11580AT1082HBL.GN SF11580AT1082HBL.GN Hersteller : SUNON sf11580at201082hblgn(a08000550g-00).pdf Sunon AC Axial Fan & Blower.pdf Category: AC115V Fans
Description: Fan: AC; axial; 115VAC; 80x80x25mm; 37m3/h(±5%); 34.5dBA; ball
Lead length: 0.33m
Enclosure material: aluminium
Current rating: 0.1A
Supply voltage: 115V AC
Leads: leads x2
Frequency: 60Hz
Type of fan: AC
Fan dimensions: 80x80x25mm
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 37m3/h (±5%)
Static pressure: 4.82mm H2O
Noise level: 34.5dBA
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Power consumption: 11W
Wire size: 24AWG
Kind of fan: axial
Min. insulation resistance: 500MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1125 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+14.26 EUR
10+12.91 EUR
50+11.55 EUR
200+10.74 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
SF11580AT-1082HBL.GN SF11580AT-1082HBL.GN Hersteller : Sunon (A08000550G-00)-1.pdf AC Fans Axial Fan, 80x80x25mm, 115VAC, 18/22CFM, 0.13/0.19"H2O, Ball, Wire
auf Bestellung 283 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+38.91 EUR
10+33.63 EUR
Im Einkaufswagen  Stück im Wert von  UAH
SF11580AT-1082HBL.GN SF11580AT-1082HBL.GN Hersteller : Sunon Fans (A08000550G-00)-1.pdf Description: FAN AXIAL 80X25.5MM 115VAC WIRE
Power (Watts): 11.00W
Packaging: Bulk
Voltage - Rated: 115VAC
Size / Dimension: Square - 80mm L x 80mm H
Bearing Type: Ball
RPM: 2900 RPM
Air Flow: 22.0 CFM (0.616m³/min)
Width: 25.50mm
Weight: 0.573 lb (260.00 g)
Termination: 2 Wire Leads
Approval Agency: CE, CUR, TUV, UL
Fan Type: Tubeaxial
Noise: 34.5dB(A)
Static Pressure: 0.190 in H2O (47.3 Pa)
Part Status: Active
auf Bestellung 323 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+42.86 EUR
10+35.04 EUR
25+32.11 EUR
50+30.00 EUR
100+29.92 EUR
Im Einkaufswagen  Stück im Wert von  UAH
SF11580AT/1082HBL.GN SF11580AT/1082HBL.GN Hersteller : MULTICOMP Description: MULTICOMP - SF11580AT/1082HBL.GN - AC-Axiallüfter, 115V, Quadratisch, 80 mm, 25 mm, Kugellager, 22 cu.ft/min
tariffCode: 84145925
Stromanschluss: 2 Anschlussdrähte
rohsCompliant: YES
hazardous: false
rohsPhthalatesCompliant: YES
Art des Lagers: Kugellager
Nennleistung: -W
IP-Schutzart: -
usEccn: EAR99
Luftstrom - m3/min: 0.61m³/min
Nennstrom: 120mA
AC-Nennspannung: 115V
Außentiefe: 25mm
Geräuschentwicklung: 34.5dBA
euEccn: NLR
Luftstrom - CFM: 22cu.ft/min
Lüfterrahmen: Quadratisch
Produktpalette: Slimline
productTraceability: No
Rahmengröße: 80mm
Nenndrehzahl: 2900rpm
SVHC: No SVHC (27-Jun-2024)
auf Bestellung 137 Stücke:
Lieferzeit 14-21 Tag (e)
Im Einkaufswagen  Stück im Wert von  UAH
SF11580AT1082HBL.GN Hersteller : Sunon AC Fan Axial Ball Bearing 115V 18CFM/22CFM 30dB/34.5dB 80 X 80 X 25mm High Speed
auf Bestellung 78 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
7+23.31 EUR
10+21.98 EUR
50+20.71 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
SF11580AT1082HBL.GN Hersteller : Sunon AC Fan Axial Ball Bearing 115V 18CFM/22CFM 30dB/34.5dB 80 X 80 X 25mm High Speed
auf Bestellung 200 Stücke:
Lieferzeit 14-21 Tag (e)
Anzahl Preis
4+42.60 EUR
5+34.63 EUR
25+32.63 EUR
50+25.16 EUR
100+23.71 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
