SFM-110-02-S-D-A-P-TR Samtec Inc.
Hersteller: Samtec Inc.
Description: CONN RCPT 20POS 0.05 GOLD SMD
Packaging: Tape & Reel (TR)
Features: Board Guide, Pick and Place
Connector Type: Receptacle
Voltage Rating: 250VAC
Current Rating (Amps): 3.2A per Contact
Mounting Type: Surface Mount
Number of Positions: 20
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 6.15mm, 6.30mm, 7.92mm, 8.08mm, 9.70mm, 9.86mm, 11.61mm, 11.76mm
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.185" (4.70mm)
Row Spacing - Mating: 0.050" (1.27mm)
Number of Rows: 2
Produktrezensionen
Produktbewertung abgeben
Technische Details SFM-110-02-S-D-A-P-TR Samtec Inc.
Description: CONN RCPT 20POS 0.05 GOLD SMD, Packaging: Tape & Reel (TR), Features: Board Guide, Pick and Place, Connector Type: Receptacle, Voltage Rating: 250VAC, Current Rating (Amps): 3.2A per Contact, Mounting Type: Surface Mount, Number of Positions: 20, Style: Board to Board or Cable, Operating Temperature: -55°C ~ 125°C, Contact Type: Female Socket, Fastening Type: Push-Pull, Number of Positions Loaded: All, Termination: Solder, Material Flammability Rating: UL94 V-0, Mated Stacking Heights: 6.15mm, 6.30mm, 7.92mm, 8.08mm, 9.70mm, 9.86mm, 11.61mm, 11.76mm, Insulation Color: Black, Pitch - Mating: 0.050" (1.27mm), Contact Finish - Mating: Gold, Contact Finish Thickness - Mating: 30.0µin (0.76µm), Contact Finish - Post: Tin, Part Status: Active, Insulation Height: 0.185" (4.70mm), Row Spacing - Mating: 0.050" (1.27mm), Number of Rows: 2.
Weitere Produktangebote SFM-110-02-S-D-A-P-TR nach Preis ab 4.17 EUR bis 7.06 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
SFM-110-02-S-D-A-P-TR | Samtec Inc. |
Description: CONN RCPT 20POS 0.05 GOLD SMD Features: Board Guide, Pick and Place Packaging: Cut Tape (CT) Connector Type: Receptacle Voltage Rating: 250VAC Current Rating (Amps): 3.2A per Contact Mounting Type: Surface Mount Number of Positions: 20 Style: Board to Board or Cable Operating Temperature: -55°C ~ 125°C Contact Type: Female Socket Fastening Type: Push-Pull Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Mated Stacking Heights: 6.15mm, 6.30mm, 7.92mm, 8.08mm, 9.70mm, 9.86mm, 11.61mm, 11.76mm Insulation Color: Black Pitch - Mating: 0.050" (1.27mm) Contact Finish - Mating: Gold Contact Finish Thickness - Mating: 30.0µin (0.76µm) Contact Finish - Post: Tin Part Status: Active Insulation Height: 0.185" (4.70mm) Row Spacing - Mating: 0.050" (1.27mm) Number of Rows: 2 |
auf Bestellung 1118 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
SFM-110-02-S-D-A-P-TR | Samtec |
Headers & Wire Housings 1.27MM TIGER EYE BTB WTB REC |
auf Bestellung 1996 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
SFM-110-02-S-D-A-P-TR | SAMTEC |
Description: SAMTEC - SFM-110-02-S-D-A-P-TR - Printbuchse, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Reihe(n), 20 Kontakt(e) tariffCode: 85366930 rohsCompliant: YES Kontaktüberzug: Vergoldete Kontakte hazardous: false rohsPhthalatesCompliant: YES Kontaktmaterial: Berylliumkupfer isCanonical: Y Steckverbindermontage: Oberflächenmontage usEccn: EAR99 Anzahl der Kontakte: 20Kontakt(e) euEccn: NLR Steckverbindersysteme: Board-to-Board, Wire-to-Board Produktpalette: SFM Series productTraceability: No Anzahl der Reihen: 2Reihe(n) Rastermaß: 1.27mm SVHC: No SVHC (04-Feb-2026) |
auf Bestellung 59 Stücke: Lieferzeit 14-21 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH |
| SFM-110-02-S-D-A-P-TR |
|
Hersteller: Samtec Inc.
Description: CONN RCPT 20POS 0.05 GOLD SMD
Features: Board Guide, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Receptacle
Voltage Rating: 250VAC
Current Rating (Amps): 3.2A per Contact
Mounting Type: Surface Mount
Number of Positions: 20
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 6.15mm, 6.30mm, 7.92mm, 8.08mm, 9.70mm, 9.86mm, 11.61mm, 11.76mm
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.185" (4.70mm)
Row Spacing - Mating: 0.050" (1.27mm)
Number of Rows: 2
Description: CONN RCPT 20POS 0.05 GOLD SMD
Features: Board Guide, Pick and Place
Packaging: Cut Tape (CT)
Connector Type: Receptacle
Voltage Rating: 250VAC
Current Rating (Amps): 3.2A per Contact
Mounting Type: Surface Mount
Number of Positions: 20
Style: Board to Board or Cable
Operating Temperature: -55°C ~ 125°C
Contact Type: Female Socket
Fastening Type: Push-Pull
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Mated Stacking Heights: 6.15mm, 6.30mm, 7.92mm, 8.08mm, 9.70mm, 9.86mm, 11.61mm, 11.76mm
Insulation Color: Black
Pitch - Mating: 0.050" (1.27mm)
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Part Status: Active
Insulation Height: 0.185" (4.70mm)
Row Spacing - Mating: 0.050" (1.27mm)
Number of Rows: 2
auf Bestellung 1118 Stücke:
Lieferzeit 10-14 Tag (e)| Anzahl | Preis |
|---|---|
| 3+ | 6.95 EUR |
| 10+ | 6.25 EUR |
| 25+ | 5.64 EUR |
| 50+ | 5.1 EUR |
| 100+ | 4.64 EUR |
| SFM-110-02-S-D-A-P-TR |
|
Hersteller: Samtec
Headers & Wire Housings 1.27MM TIGER EYE BTB WTB REC
Headers & Wire Housings 1.27MM TIGER EYE BTB WTB REC
auf Bestellung 1996 Stücke:
Lieferzeit 10-14 Tag (e)| Anzahl | Preis |
|---|---|
| 1+ | 7.06 EUR |
| 10+ | 6.46 EUR |
| 25+ | 5.9 EUR |
| 50+ | 5.28 EUR |
| 100+ | 4.8 EUR |
| 575+ | 4.36 EUR |
| 1150+ | 4.17 EUR |
| SFM-110-02-S-D-A-P-TR |
|
Hersteller: SAMTEC
Description: SAMTEC - SFM-110-02-S-D-A-P-TR - Printbuchse, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Reihe(n), 20 Kontakt(e)
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Berylliumkupfer
isCanonical: Y
Steckverbindermontage: Oberflächenmontage
usEccn: EAR99
Anzahl der Kontakte: 20Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board, Wire-to-Board
Produktpalette: SFM Series
productTraceability: No
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 1.27mm
SVHC: No SVHC (04-Feb-2026)
Description: SAMTEC - SFM-110-02-S-D-A-P-TR - Printbuchse, Board-to-Board, Wire-to-Board, 1.27 mm, 2 Reihe(n), 20 Kontakt(e)
tariffCode: 85366930
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Berylliumkupfer
isCanonical: Y
Steckverbindermontage: Oberflächenmontage
usEccn: EAR99
Anzahl der Kontakte: 20Kontakt(e)
euEccn: NLR
Steckverbindersysteme: Board-to-Board, Wire-to-Board
Produktpalette: SFM Series
productTraceability: No
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 1.27mm
SVHC: No SVHC (04-Feb-2026)
auf Bestellung 59 Stücke:
Lieferzeit 14-21 Tag (e)Im Einkaufswagen Stück im Wert von UAH
