SL 5 315 25 Z Fischer Elektronik
Hersteller: Fischer Elektronik
Description: ONE ROW, 0.635 MM STRO
Contact Length - Mating: 0.236" (6.00mm)
Insulation Material: Polyamide (PA46), Nylon 4/6, Glass Filled
Overall Contact Length: 1.606" (40.80mm)
Shrouding: Unshrouded
Insulation Height: 0.110" (2.79mm)
Contact Length - Post: 0.130" (3.30mm)
Contact Shape: Square
Contact Finish - Post: Tin
Contact Finish Thickness - Mating: 7.87µin (0.200µm)
Contact Finish - Mating: Gold
Pitch - Mating: 0.100" (2.54mm)
Insulation Color: Black
Contact Material: Copper Tin
Material Flammability Rating: UL94 V-0
Termination: Solder
Number of Positions Loaded: All
Fastening Type: Push-Pull
Contact Type: Male Pin
Operating Temperature: -40°C ~ 163°C
Style: Board to Board or Cable
Number of Rows: 1
Number of Positions: 25
Mounting Type: Through Hole
Current Rating (Amps): 3A
Voltage Rating: 250VAC
Connector Type: Header
Packaging: Bulk
Produktrezensionen
Produktbewertung abgeben
Technische Details SL 5 315 25 Z Fischer Elektronik
Description: ONE ROW, 0.635 MM STRO, Contact Length - Mating: 0.236" (6.00mm), Insulation Material: Polyamide (PA46), Nylon 4/6, Glass Filled, Overall Contact Length: 1.606" (40.80mm), Shrouding: Unshrouded, Insulation Height: 0.110" (2.79mm), Contact Length - Post: 0.130" (3.30mm), Contact Shape: Square, Contact Finish - Post: Tin, Contact Finish Thickness - Mating: 7.87µin (0.200µm), Contact Finish - Mating: Gold, Pitch - Mating: 0.100" (2.54mm), Insulation Color: Black, Contact Material: Copper Tin, Material Flammability Rating: UL94 V-0, Termination: Solder, Number of Positions Loaded: All, Fastening Type: Push-Pull, Contact Type: Male Pin, Operating Temperature: -40°C ~ 163°C, Style: Board to Board or Cable, Number of Rows: 1, Number of Positions: 25, Mounting Type: Through Hole, Current Rating (Amps): 3A, Voltage Rating: 250VAC, Connector Type: Header, Packaging: Bulk.
Weitere Produktangebote SL 5 315 25 Z
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde |
|---|---|---|---|---|---|
 |
SL531525Z | FISCHER ELEKTRONIK |
Category: Pin headers Description: Connector: pin strips; pin header; male; PIN: 25; THT; 3A; 250V; SL 5 Type of connector: pin strips Manufacturer series: SL 5 Current rating: 3A Rated voltage: 0.25kV Electrical mounting: THT Contact material: bronze Contact plating: tinned Body material: polyamide 46 Contacts pitch: 2.54mm Body colour: black Connector: pin header Number of pins: 25 Spatial orientation: straight Flammability rating: UL94V-0 Operating temperature: -40...163°C Overall length: 40.8mm Connector pinout layout: 1x25 Kind of package: bulk Kind of connector: male |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH |
| SL531525Z |
Hersteller: FISCHER ELEKTRONIK
Category: Pin headers
Description: Connector: pin strips; pin header; male; PIN: 25; THT; 3A; 250V; SL 5
Type of connector: pin strips
Manufacturer series: SL 5
Current rating: 3A
Rated voltage: 0.25kV
Electrical mounting: THT
Contact material: bronze
Contact plating: tinned
Body material: polyamide 46
Contacts pitch: 2.54mm
Body colour: black
Connector: pin header
Number of pins: 25
Spatial orientation: straight
Flammability rating: UL94V-0
Operating temperature: -40...163°C
Overall length: 40.8mm
Connector pinout layout: 1x25
Kind of package: bulk
Kind of connector: male
Category: Pin headers
Description: Connector: pin strips; pin header; male; PIN: 25; THT; 3A; 250V; SL 5
Type of connector: pin strips
Manufacturer series: SL 5
Current rating: 3A
Rated voltage: 0.25kV
Electrical mounting: THT
Contact material: bronze
Contact plating: tinned
Body material: polyamide 46
Contacts pitch: 2.54mm
Body colour: black
Connector: pin header
Number of pins: 25
Spatial orientation: straight
Flammability rating: UL94V-0
Operating temperature: -40...163°C
Overall length: 40.8mm
Connector pinout layout: 1x25
Kind of package: bulk
Kind of connector: male
