TEQ 20-7211WIR TRACO POWER
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 20W; Uin: 43÷160VDC; Uout: 5VDC; Iout: 4A; 330kHz
Type of converter: DC/DC
Power: 20W
Input voltage: 43...160V DC
Output voltage: 5V DC
Output current: 4A
Mounting: for building in
Manufacturer series: TEQ 20WIR
Body dimensions: 103x57.2x26.1mm
Efficiency: 86%
Operating temperature: -40...93°C
Switching frequency: 330kHz
Protection: anti-overvoltage OVP; overheating OTP; short circuit protection SCP
Insulation voltage: 2.25kV
Number of outputs: 1
Application: railway industry
Conform to the norm: EN 50155
Produktrezensionen
Produktbewertung abgeben
Technische Details TEQ 20-7211WIR TRACO POWER
Category: DC/DC Converters, Description: Converter: DC/DC; 20W; Uin: 43÷160VDC; Uout: 5VDC; Iout: 4A; 330kHz, Type of converter: DC/DC, Power: 20W, Input voltage: 43...160V DC, Output voltage: 5V DC, Output current: 4A, Mounting: for building in, Manufacturer series: TEQ 20WIR, Body dimensions: 103x57.2x26.1mm, Efficiency: 86%, Operating temperature: -40...93°C, Switching frequency: 330kHz, Protection: anti-overvoltage OVP; overheating OTP; short circuit protection SCP, Insulation voltage: 2.25kV, Number of outputs: 1, Application: railway industry, Conform to the norm: EN 50155.
Weitere Produktangebote TEQ 20-7211WIR nach Preis ab 240.63 EUR bis 277.51 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TEQ 20-7211WIR | Traco Power |
Description: DC/DC CONVERTER 5V 20W Voltage - Isolation: 2.25 kV Number of Outputs: 1 Part Status: Active Voltage - Output 1: 5V Voltage - Input (Min): 43V Current - Output (Max): 4A Efficiency: 86% Voltage - Input (Max): 160V Applications: ITE (Commercial), Railway Operating Temperature: -40°C ~ 93°C (With Derating) Type: Enclosed Mounting Type: Chassis Mount Size / Dimension: 4.06" L x 2.25" W x 1.03" H (103.1mm x 57.2mm x 26.2mm) Power (Watts): 20W Packaging: Box |
auf Bestellung 2 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
 |
TEQ 20-7211WIR | TRACO Power |
Isolated DC/DC Converters - Chassis Mount 43-160Vin 5V 4000mA 20W Iso railway |
auf Bestellung 1 Stücke: Lieferzeit 10-14 Tag (e) |
|
| TEQ 20-7211WIR |
|
Hersteller: Traco Power
Description: DC/DC CONVERTER 5V 20W
Voltage - Isolation: 2.25 kV
Number of Outputs: 1
Part Status: Active
Voltage - Output 1: 5V
Voltage - Input (Min): 43V
Current - Output (Max): 4A
Efficiency: 86%
Voltage - Input (Max): 160V
Applications: ITE (Commercial), Railway
Operating Temperature: -40°C ~ 93°C (With Derating)
Type: Enclosed
Mounting Type: Chassis Mount
Size / Dimension: 4.06" L x 2.25" W x 1.03" H (103.1mm x 57.2mm x 26.2mm)
Power (Watts): 20W
Packaging: Box
Description: DC/DC CONVERTER 5V 20W
Voltage - Isolation: 2.25 kV
Number of Outputs: 1
Part Status: Active
Voltage - Output 1: 5V
Voltage - Input (Min): 43V
Current - Output (Max): 4A
Efficiency: 86%
Voltage - Input (Max): 160V
Applications: ITE (Commercial), Railway
Operating Temperature: -40°C ~ 93°C (With Derating)
Type: Enclosed
Mounting Type: Chassis Mount
Size / Dimension: 4.06" L x 2.25" W x 1.03" H (103.1mm x 57.2mm x 26.2mm)
Power (Watts): 20W
Packaging: Box
auf Bestellung 2 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 266.82 EUR |
| TEQ 20-7211WIR |
|
Hersteller: TRACO Power
Isolated DC/DC Converters - Chassis Mount 43-160Vin 5V 4000mA 20W Iso railway
Isolated DC/DC Converters - Chassis Mount 43-160Vin 5V 4000mA 20W Iso railway
auf Bestellung 1 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 277.51 EUR |
| 10+ | 262.82 EUR |
| 25+ | 257.17 EUR |
| 50+ | 253.01 EUR |
| 100+ | 240.63 EUR |
