THD 12-2409 Traco Power

Category: DC/DC Converters, Description: Converter: DC/DC; 12W; Uin: 18÷36VDC; Uout: 2.5VDC; Iout: 3.5A; DIL, Type of converter: DC/DC, Power: 12W, Input voltage: 18...36V DC, Output voltage: 2.5V DC, Output current: 3.5A, Output current 2: 3.5A, Case: DIL, Mounting: THT, Manufacturer series: THD 12, Body dimensions: 31.8x20.32x10.22mm, Efficiency: 83%, Operating temperature: -40...85°C, Protection: over current OCP; short circuit protection SCP; undervoltage-lockout UVLO, Insulation voltage: 1.5kV DC, Number of outputs: 1, Application: industry; telecommunication, Additional functions: disturbance filter; remote ON/OFF control, Conform to the norm: cURus; EN 60950-1, Output ripple: 85Vpp.
