THP 3-2422 TRACO Power
Hersteller: TRACO Power
Isolated DC/DC Converters - Through Hole Product Type: DC/DC; Package Style: DIP-24; Output Power (W): 3; Input Voltage: 9-40 VDC; Output 1 (Vdc): 12; Output 2 (Vdc): -12; Output 3 (Vdc): N/A
| Anzahl | Privatkunde |
|---|---|
| 1+ | 124.47 EUR |
| 10+ | 112.87 EUR |
| 20+ | 109.13 EUR |
| 50+ | 104.26 EUR |
| 100+ | 100.92 EUR |
| 200+ | 94.85 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details THP 3-2422 TRACO Power
Description: DC DC CONVERTER +/-12V 3W, Features: SCP, Packaging: Tube, Package / Case: 24-DIP Module, 5 Leads, Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm), Mounting Type: Through Hole, Type: Isolated Module, Operating Temperature: -40°C ~ 85°C (With Derating), Applications: ITE (Commercial), Medical, Voltage - Input (Max): 40V, Efficiency: 83%, Current - Output (Max): 125mA, 125mA, Voltage - Input (Min): 9V, Voltage - Output 1: 12V, Voltage - Output 2: -12V, Part Status: Active, Power (Watts): 3 W, Number of Outputs: 2, Voltage - Isolation: 3 kV.
Weitere Produktangebote THP 3-2422 nach Preis ab 99.76 EUR bis 127.76 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
THP 3-2422 | Traco Power |
Description: DC DC CONVERTER +/-12V 3W Features: SCP Packaging: Tube Package / Case: 24-DIP Module, 5 Leads Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm) Mounting Type: Through Hole Type: Isolated Module Operating Temperature: -40°C ~ 85°C (With Derating) Applications: ITE (Commercial), Medical Voltage - Input (Max): 40V Efficiency: 83% Current - Output (Max): 125mA, 125mA Voltage - Input (Min): 9V Voltage - Output 1: 12V Voltage - Output 2: -12V Part Status: Active Power (Watts): 3 W Number of Outputs: 2 Voltage - Isolation: 3 kV |
auf Bestellung 213 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||
| THP3-2422 |
auf Bestellung 6316 Stücke: Lieferzeit 21-28 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH |
| THP 3-2422 |
|
Hersteller: Traco Power
Description: DC DC CONVERTER +/-12V 3W
Features: SCP
Packaging: Tube
Package / Case: 24-DIP Module, 5 Leads
Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 85°C (With Derating)
Applications: ITE (Commercial), Medical
Voltage - Input (Max): 40V
Efficiency: 83%
Current - Output (Max): 125mA, 125mA
Voltage - Input (Min): 9V
Voltage - Output 1: 12V
Voltage - Output 2: -12V
Part Status: Active
Power (Watts): 3 W
Number of Outputs: 2
Voltage - Isolation: 3 kV
Description: DC DC CONVERTER +/-12V 3W
Features: SCP
Packaging: Tube
Package / Case: 24-DIP Module, 5 Leads
Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 85°C (With Derating)
Applications: ITE (Commercial), Medical
Voltage - Input (Max): 40V
Efficiency: 83%
Current - Output (Max): 125mA, 125mA
Voltage - Input (Min): 9V
Voltage - Output 1: 12V
Voltage - Output 2: -12V
Part Status: Active
Power (Watts): 3 W
Number of Outputs: 2
Voltage - Isolation: 3 kV
auf Bestellung 213 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 127.76 EUR |
| 10+ | 116.38 EUR |
| 25+ | 112.68 EUR |
| 50+ | 107.15 EUR |
| 100+ | 99.76 EUR |
| THP3-2422 |
auf Bestellung 6316 Stücke:
Lieferzeit 21-28 Tag (e)
