THP 3-7223
Produktcode: 25465
zu Favoriten hinzufügen
Lieblingsprodukt
Hersteller:
Netzteile und Ladegeräte > Blocks DC_DC Wandler
Produktrezensionen
Produktbewertung abgeben
Technische Details THP 3-7223
- CONVERTER, DC/DC, 3W, +/-15V/0.1A
- DC / DC Converter O/P Type:Dual
- No. of Outputs:2
- Output Current:100mA
- Output Current 2:100mA
- Power Rating:3W
- Supply Voltage:72V
- Approval Bodies:CB / CSA / EN / IEC / UL
- Mounting Type:THT
- External Depth:20mm
- External Length / Height:10mm
- External Width:32mm
- Approval Category:cUL/UL 60950, IEC/EN 60950, EN 50124-1&2, IEC/EN/UL 60601-1, CSA C22.2
- Efficiency:83%
- Flammability Rating:UL94V-0
- Isolation voltage:4000V ac
- Line Regulation:0.5%
- Load Regulation:1.0%
- Max Input Voltage:160V dc
- Max Operating Temperature:+85`C
- Max Output Current +:100mA
- Max Output Current -:100mA
- Min Input Voltage:36V dc
- Min Temperature Operating:-40`C
- Output Ripple and Noise Voltage, pk-pk:100mV
- Output Voltage +:15V dc
- Output Voltage -:15V dc
- Output Voltage Tolerance +:1%
- Output Voltage Tolerance -:1%
- Weight:16.2g
Weitere Produktangebote THP 3-7223 nach Preis ab 110.07 EUR bis 115.14 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis |
||||
|---|---|---|---|---|---|---|---|---|---|
 |
THP 3-7223 | Traco Power |
 Description: DC DC CONVERTER +/-15V 3WSize / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm) Package / Case: 24-DIP Module, 5 Leads Features: SCP Packaging: Tube Power (Watts): 3 W Part Status: Active Voltage - Output 2: -15V Voltage - Output 1: 15V Voltage - Input (Min): 36V Current - Output (Max): 100mA, 100mA Efficiency: 83% Voltage - Input (Max): 160V Applications: ITE (Commercial), Medical Operating Temperature: -40°C ~ 85°C (With Derating) Type: Isolated Module Mounting Type: Through Hole Voltage - Isolation: 3 kV Number of Outputs: 2 |
auf Bestellung 10 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||
 |
THP 3-7223 | TRACO Power |
Isolated DC/DC Converters Product Type: DC/DC; Package Style: DIP- |
auf Bestellung 30 Stücke: Lieferzeit 10-14 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH | ||||
| THP3-7223 |
auf Bestellung 6316 Stücke: Lieferzeit 21-28 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH |
| THP 3-7223 |
|
Hersteller: Traco Power
Description: DC DC CONVERTER +/-15V 3W
Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm)
Package / Case: 24-DIP Module, 5 Leads
Features: SCP
Packaging: Tube
Power (Watts): 3 W
Part Status: Active
Voltage - Output 2: -15V
Voltage - Output 1: 15V
Voltage - Input (Min): 36V
Current - Output (Max): 100mA, 100mA
Efficiency: 83%
Voltage - Input (Max): 160V
Applications: ITE (Commercial), Medical
Operating Temperature: -40°C ~ 85°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Voltage - Isolation: 3 kV
Number of Outputs: 2
Description: DC DC CONVERTER +/-15V 3W
Size / Dimension: 1.25" L x 0.80" W x 0.41" H (31.8mm x 20.3mm x 10.5mm)
Package / Case: 24-DIP Module, 5 Leads
Features: SCP
Packaging: Tube
Power (Watts): 3 W
Part Status: Active
Voltage - Output 2: -15V
Voltage - Output 1: 15V
Voltage - Input (Min): 36V
Current - Output (Max): 100mA, 100mA
Efficiency: 83%
Voltage - Input (Max): 160V
Applications: ITE (Commercial), Medical
Operating Temperature: -40°C ~ 85°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Voltage - Isolation: 3 kV
Number of Outputs: 2
auf Bestellung 10 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 115.14 EUR |
| 10+ | 110.07 EUR |
| THP 3-7223 |
|
Hersteller: TRACO Power
Isolated DC/DC Converters Product Type: DC/DC; Package Style: DIP-
Isolated DC/DC Converters Product Type: DC/DC; Package Style: DIP-
auf Bestellung 30 Stücke:
Lieferzeit 10-14 Tag (e)
| THP3-7223 |
auf Bestellung 6316 Stücke:
Lieferzeit 21-28 Tag (e)
