TLP705A(TP,F)

Hersteller: Toshiba Semiconductor and Storage
Description: OPTOISO 5KV 1CH GATE DVR 6SDIP
Voltage - Output Supply: 10V ~ 30V
Current - DC Forward (If) (Max): 25 mA
Number of Channels: 1
Part Status: Last Time Buy
Pulse Width Distortion (Max): 50ns
Propagation Delay tpLH / tpHL (Max): 200ns, 200ns
Common Mode Transient Immunity (Min): 20kV/µs
Rise / Fall Time (Typ): 35ns, 15ns
Supplier Device Package: 6-SDIP
Approval Agency: cUR, UR, VDE
Voltage - Isolation: 5000Vrms
Current - Output High, Low: 400mA, 400mA
Technology: Optical Coupling
Voltage - Forward (Vf) (Typ): 1.57V
Operating Temperature: -40°C ~ 100°C
Mounting Type: Surface Mount
Package / Case: 6-SOIC (0.268", 6.80mm Width)
Packaging: Tape & Reel (TR)
Current - Peak Output: 600mA

Hersteller: Toshiba
Optically Isolated Gate Drivers Photocoupler
