TMR 3-2423WIR TRACO POWER
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; SIP8
Type of converter: DC/DC
Power: 3W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output voltage 2: -15V DC
Output current: 0.1A
Output current 2: 0.1A
Mounting: SMT
Manufacturer series: TMR 3WIR
Body dimensions: 21.8x11.2x9.6mm
Efficiency: 82%
Operating temperature: -40...90°C
Switching frequency: 400kHz
Protection: anti-overload OPP; short circuit protection SCP
Insulation voltage: 3kV
Number of outputs: 2
Case: SIP8
Application: railway industry
Conform to the norm: EN 50155
Produktrezensionen
Produktbewertung abgeben
Technische Details TMR 3-2423WIR TRACO POWER
Category: DC/DC Converters, Description: Converter: DC/DC; 3W; Uin: 9÷36VDC; Uout: 15VDC; Uout2: -15VDC; SIP8, Type of converter: DC/DC, Power: 3W, Input voltage: 9...36V DC, Output voltage: 15V DC, Output voltage 2: -15V DC, Output current: 0.1A, Output current 2: 0.1A, Mounting: SMT, Manufacturer series: TMR 3WIR, Body dimensions: 21.8x11.2x9.6mm, Efficiency: 82%, Operating temperature: -40...90°C, Switching frequency: 400kHz, Protection: anti-overload OPP; short circuit protection SCP, Insulation voltage: 3kV, Number of outputs: 2, Case: SIP8, Application: railway industry, Conform to the norm: EN 50155.
Weitere Produktangebote TMR 3-2423WIR nach Preis ab 32.72 EUR bis 48.37 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TMR 3-2423WIR | TRACO Power |
DC/DC Converters - SMD 3W 9-36Vin +/-15V +/-100mA SIP Iso Reg |
auf Bestellung 4 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
TMR 3-2423WIR | Traco Power |
Description: DC DC CONVERTER +/-15V 3W Power (Watts): 3 W Part Status: Active Voltage - Output 2: -15V Voltage - Output 1: 15V Voltage - Input (Min): 9V Current - Output (Max): 100mA, 100mA Efficiency: 82% Voltage - Input (Max): 36V Applications: ITE (Commercial), Railway Operating Temperature: -40°C ~ 90°C (With Derating) Type: Isolated Module Mounting Type: Through Hole Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm) Package / Case: 8-SIP Module Features: Remote On/Off, SCP Packaging: Tube Voltage - Isolation: 3 kV Number of Outputs: 2 |
auf Bestellung 236 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
 |
TMR 3-2423WIR | Traco Power |
Module DC-DC 24VIN 2-OUT -15V/15V 0.1A/0.1A 3W 8-Pin SIP Module |
auf Bestellung 10 Stücke: Lieferzeit 14-21 Tag (e) |
|
| TMR 3-2423WIR |
|
Hersteller: TRACO Power
DC/DC Converters - SMD 3W 9-36Vin +/-15V +/-100mA SIP Iso Reg
DC/DC Converters - SMD 3W 9-36Vin +/-15V +/-100mA SIP Iso Reg
auf Bestellung 4 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 42.38 EUR |
| 10+ | 40.67 EUR |
| 20+ | 40.04 EUR |
| 50+ | 38.12 EUR |
| 100+ | 34.95 EUR |
| 200+ | 34.32 EUR |
| 500+ | 32.72 EUR |
| TMR 3-2423WIR |
|
Hersteller: Traco Power
Description: DC DC CONVERTER +/-15V 3W
Power (Watts): 3 W
Part Status: Active
Voltage - Output 2: -15V
Voltage - Output 1: 15V
Voltage - Input (Min): 9V
Current - Output (Max): 100mA, 100mA
Efficiency: 82%
Voltage - Input (Max): 36V
Applications: ITE (Commercial), Railway
Operating Temperature: -40°C ~ 90°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Package / Case: 8-SIP Module
Features: Remote On/Off, SCP
Packaging: Tube
Voltage - Isolation: 3 kV
Number of Outputs: 2
Description: DC DC CONVERTER +/-15V 3W
Power (Watts): 3 W
Part Status: Active
Voltage - Output 2: -15V
Voltage - Output 1: 15V
Voltage - Input (Min): 9V
Current - Output (Max): 100mA, 100mA
Efficiency: 82%
Voltage - Input (Max): 36V
Applications: ITE (Commercial), Railway
Operating Temperature: -40°C ~ 90°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Package / Case: 8-SIP Module
Features: Remote On/Off, SCP
Packaging: Tube
Voltage - Isolation: 3 kV
Number of Outputs: 2
auf Bestellung 236 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 45.81 EUR |
| 10+ | 42.85 EUR |
| 25+ | 41.44 EUR |
| 50+ | 40.4 EUR |
| 100+ | 39.38 EUR |
| TMR 3-2423WIR |
|
Hersteller: Traco Power
Module DC-DC 24VIN 2-OUT -15V/15V 0.1A/0.1A 3W 8-Pin SIP Module
Module DC-DC 24VIN 2-OUT -15V/15V 0.1A/0.1A 3W 8-Pin SIP Module
auf Bestellung 10 Stücke:
Lieferzeit 14-21 Tag (e)
| Anzahl | Preis |
|---|---|
| 4+ | 48.37 EUR |
