TVN 3-0922 TRACO POWER
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 4.5÷13.2V; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 3W
Input voltage: 4.5...13.2V
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.125A
Output current 2: 125mA
Case: SIP8
Body dimensions: 21.8x11.2x9.6mm
Efficiency: 82%
Operating temperature: -40...90°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Manufacturer series: TVN 3
Number of outputs: 2
Anzahl je Verpackung: 1 Stücke
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 4.5÷13.2V; Uout: 12VDC; Uout2: -12VDC
Type of converter: DC/DC
Power: 3W
Input voltage: 4.5...13.2V
Output voltage: 12V DC
Output voltage 2: -12V DC
Output current: 0.125A
Output current 2: 125mA
Case: SIP8
Body dimensions: 21.8x11.2x9.6mm
Efficiency: 82%
Operating temperature: -40...90°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Manufacturer series: TVN 3
Number of outputs: 2
Anzahl je Verpackung: 1 Stücke
auf Bestellung 5 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
2+ | 42.54 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details TVN 3-0922 TRACO POWER
Description: DC DC CONVERTER +/-12V 3W, Features: Remote On/Off, SCP, Packaging: Tube, Package / Case: 8-SIP Module, 7 Leads, Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm), Mounting Type: Through Hole, Type: Isolated Module, Operating Temperature: -40°C ~ 90°C (With Derating), Applications: ITE (Commercial), Voltage - Input (Max): 13.2V, Efficiency: 82%, Current - Output (Max): 125mA, 125mA, Voltage - Input (Min): 4.5V, Voltage - Output 1: 12V, Voltage - Output 2: -12V, Part Status: Active, Power (Watts): 3 W, Number of Outputs: 2, Voltage - Isolation: 1.6 kV.
Weitere Produktangebote TVN 3-0922 nach Preis ab 42.54 EUR bis 96.23 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TVN 3-0922 | Hersteller : TRACO POWER |
Category: DC/DC Converters Description: Converter: DC/DC; 3W; Uin: 4.5÷13.2V; Uout: 12VDC; Uout2: -12VDC Type of converter: DC/DC Power: 3W Input voltage: 4.5...13.2V Output voltage: 12V DC Output voltage 2: -12V DC Output current: 0.125A Output current 2: 125mA Case: SIP8 Body dimensions: 21.8x11.2x9.6mm Efficiency: 82% Operating temperature: -40...90°C Switching frequency: 100kHz Protection: short circuit protection SCP Insulation voltage: 1.6kV Manufacturer series: TVN 3 Number of outputs: 2 |
auf Bestellung 5 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||||||||||
TVN 3-0922 | Hersteller : Traco Power |
Description: DC DC CONVERTER +/-12V 3W Features: Remote On/Off, SCP Packaging: Tube Package / Case: 8-SIP Module, 7 Leads Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm) Mounting Type: Through Hole Type: Isolated Module Operating Temperature: -40°C ~ 90°C (With Derating) Applications: ITE (Commercial) Voltage - Input (Max): 13.2V Efficiency: 82% Current - Output (Max): 125mA, 125mA Voltage - Input (Min): 4.5V Voltage - Output 1: 12V Voltage - Output 2: -12V Part Status: Active Power (Watts): 3 W Number of Outputs: 2 Voltage - Isolation: 1.6 kV |
auf Bestellung 11 Stücke: Lieferzeit 10-14 Tag (e) |
|
|||||||||||||||||
TVN 3-0922 | Hersteller : TRACO Power | Isolated DC/DC Converters - Through Hole 3W 4.5-13.2Vin SIP-8 +/-12Vout +/-125mA |
auf Bestellung 19 Stücke: Lieferzeit 14-28 Tag (e) |
|
