TVN 3-2422 TRACO Power
Hersteller: TRACO Power
Isolated DC/DC Converters - Through Hole 3W 18-36Vin SIP-8 +/-12Vout +/-125mA
| Anzahl | Privatkunde |
|---|---|
| 1+ | 73.99 EUR |
| 5+ | 73.68 EUR |
| 10+ | 72.84 EUR |
| 20+ | 71.71 EUR |
| 50+ | 62.61 EUR |
| 100+ | 61.45 EUR |
| 200+ | 60.55 EUR |
Artikel auf Bestellung
Nicht an unserem Lager — wir beziehen ihn nach Ihrer Bestellung vom Lieferantenlager.
Lieferzeit:
10-14 Tag (e)
Produktrezensionen
Produktbewertung abgeben
Technische Details TVN 3-2422 TRACO Power
Description: DC DC CONVERTER +/-12V 3W, Features: Remote On/Off, SCP, Packaging: Tube, Package / Case: 8-SIP Module, 7 Leads, Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm), Mounting Type: Through Hole, Type: Isolated Module, Operating Temperature: -40°C ~ 90°C (With Derating), Applications: ITE (Commercial), Voltage - Input (Max): 36V, Efficiency: 84%, Current - Output (Max): 125mA, 125mA, Voltage - Input (Min): 18V, Voltage - Output 1: 12V, Voltage - Output 2: -12V, Part Status: Active, Power (Watts): 3 W, Number of Outputs: 2, Voltage - Isolation: 1.6 kV.
Weitere Produktangebote TVN 3-2422 nach Preis ab 82.12 EUR bis 83.4 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||
|---|---|---|---|---|---|---|---|---|---|
 |
TVN 3-2422 | Traco Power |
Description: DC DC CONVERTER +/-12V 3W Features: Remote On/Off, SCP Packaging: Tube Package / Case: 8-SIP Module, 7 Leads Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm) Mounting Type: Through Hole Type: Isolated Module Operating Temperature: -40°C ~ 90°C (With Derating) Applications: ITE (Commercial) Voltage - Input (Max): 36V Efficiency: 84% Current - Output (Max): 125mA, 125mA Voltage - Input (Min): 18V Voltage - Output 1: 12V Voltage - Output 2: -12V Part Status: Active Power (Watts): 3 W Number of Outputs: 2 Voltage - Isolation: 1.6 kV |
auf Bestellung 15 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||
 |
TVN 3-2422 | TRACO POWER |
Category: DC/DC Converters Description: Converter: DC/DC; 3W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC; SIP8 Type of converter: DC/DC Power: 3W Input voltage: 18...36V DC Output voltage: 12V DC Output current: 0.125A Mounting: THT Body dimensions: 21.8x11.2x9.6mm Efficiency: 84% Operating temperature: -40...90°C Switching frequency: 100kHz Protection: short circuit protection SCP Insulation voltage: 1.6kV Number of outputs: 2 Case: SIP8 Output voltage 2: -12V DC Manufacturer series: TVN 3 Output current 2: 125mA |
auf Bestellung 94 Stücke: Lieferzeit 14-21 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH |
| TVN 3-2422 |
|
Hersteller: Traco Power
Description: DC DC CONVERTER +/-12V 3W
Features: Remote On/Off, SCP
Packaging: Tube
Package / Case: 8-SIP Module, 7 Leads
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 90°C (With Derating)
Applications: ITE (Commercial)
Voltage - Input (Max): 36V
Efficiency: 84%
Current - Output (Max): 125mA, 125mA
Voltage - Input (Min): 18V
Voltage - Output 1: 12V
Voltage - Output 2: -12V
Part Status: Active
Power (Watts): 3 W
Number of Outputs: 2
Voltage - Isolation: 1.6 kV
Description: DC DC CONVERTER +/-12V 3W
Features: Remote On/Off, SCP
Packaging: Tube
Package / Case: 8-SIP Module, 7 Leads
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Mounting Type: Through Hole
Type: Isolated Module
Operating Temperature: -40°C ~ 90°C (With Derating)
Applications: ITE (Commercial)
Voltage - Input (Max): 36V
Efficiency: 84%
Current - Output (Max): 125mA, 125mA
Voltage - Input (Min): 18V
Voltage - Output 1: 12V
Voltage - Output 2: -12V
Part Status: Active
Power (Watts): 3 W
Number of Outputs: 2
Voltage - Isolation: 1.6 kV
auf Bestellung 15 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 1+ | 83.4 EUR |
| 10+ | 82.12 EUR |
| TVN 3-2422 |
|
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC; SIP8
Type of converter: DC/DC
Power: 3W
Input voltage: 18...36V DC
Output voltage: 12V DC
Output current: 0.125A
Mounting: THT
Body dimensions: 21.8x11.2x9.6mm
Efficiency: 84%
Operating temperature: -40...90°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Case: SIP8
Output voltage 2: -12V DC
Manufacturer series: TVN 3
Output current 2: 125mA
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC; SIP8
Type of converter: DC/DC
Power: 3W
Input voltage: 18...36V DC
Output voltage: 12V DC
Output current: 0.125A
Mounting: THT
Body dimensions: 21.8x11.2x9.6mm
Efficiency: 84%
Operating temperature: -40...90°C
Switching frequency: 100kHz
Protection: short circuit protection SCP
Insulation voltage: 1.6kV
Number of outputs: 2
Case: SIP8
Output voltage 2: -12V DC
Manufacturer series: TVN 3
Output current 2: 125mA
auf Bestellung 94 Stücke:
Lieferzeit 14-21 Tag (e)
