TVN 3-4819 TRACO POWER
Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 36÷75VDC; Uout: 9VDC; Iout: 333mA; SIP8
Output voltage: 9V DC
Power: 3W
Body dimensions: 21.8x11.2x9.6mm
Protection: short circuit protection SCP
Efficiency: 80%
Manufacturer series: TVN 3
Operating temperature: -40...90°C
Case: SIP8
Mounting: THT
Output current: 0.333A
Number of outputs: 1
Input voltage: 36...75V DC
Insulation voltage: 1.6kV
Switching frequency: 100kHz
Type of converter: DC/DC
Produktrezensionen
Produktbewertung abgeben
Technische Details TVN 3-4819 TRACO POWER
Description: DC DC CONVERTER 9V 3W, Voltage - Isolation: 1.6 kV, Number of Outputs: 1, Power (Watts): 3 W, Part Status: Active, Voltage - Output 1: 9V, Voltage - Input (Min): 36V, Current - Output (Max): 333mA, Efficiency: 80%, Voltage - Input (Max): 75V, Applications: ITE (Commercial), Operating Temperature: -40°C ~ 90°C (With Derating), Type: Isolated Module, Mounting Type: Through Hole, Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm), Package / Case: 8-SIP Module, 7 Leads, Features: Remote On/Off, SCP, Packaging: Tube.
Weitere Produktangebote TVN 3-4819 nach Preis ab 58.3 EUR bis 59.22 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis |
||||
|---|---|---|---|---|---|---|---|---|---|
 |
TVN 3-4819 | Traco Power |
Description: DC DC CONVERTER 9V 3W Voltage - Isolation: 1.6 kV Number of Outputs: 1 Power (Watts): 3 W Part Status: Active Voltage - Output 1: 9V Voltage - Input (Min): 36V Current - Output (Max): 333mA Efficiency: 80% Voltage - Input (Max): 75V Applications: ITE (Commercial) Operating Temperature: -40°C ~ 90°C (With Derating) Type: Isolated Module Mounting Type: Through Hole Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm) Package / Case: 8-SIP Module, 7 Leads Features: Remote On/Off, SCP Packaging: Tube |
auf Bestellung 10 Stücke: Lieferzeit 10-14 Tag (e) |
|
| TVN 3-4819 |
|
Hersteller: Traco Power
Description: DC DC CONVERTER 9V 3W
Voltage - Isolation: 1.6 kV
Number of Outputs: 1
Power (Watts): 3 W
Part Status: Active
Voltage - Output 1: 9V
Voltage - Input (Min): 36V
Current - Output (Max): 333mA
Efficiency: 80%
Voltage - Input (Max): 75V
Applications: ITE (Commercial)
Operating Temperature: -40°C ~ 90°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Package / Case: 8-SIP Module, 7 Leads
Features: Remote On/Off, SCP
Packaging: Tube
Description: DC DC CONVERTER 9V 3W
Voltage - Isolation: 1.6 kV
Number of Outputs: 1
Power (Watts): 3 W
Part Status: Active
Voltage - Output 1: 9V
Voltage - Input (Min): 36V
Current - Output (Max): 333mA
Efficiency: 80%
Voltage - Input (Max): 75V
Applications: ITE (Commercial)
Operating Temperature: -40°C ~ 90°C (With Derating)
Type: Isolated Module
Mounting Type: Through Hole
Size / Dimension: 0.86" L x 0.38" W x 0.44" H (21.8mm x 9.6mm x 11.2mm)
Package / Case: 8-SIP Module, 7 Leads
Features: Remote On/Off, SCP
Packaging: Tube
auf Bestellung 10 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 59.22 EUR |
| 10+ | 58.3 EUR |
