UCC2800D Texas Instruments
Hersteller: Texas Instruments
Description: IC REG CTRLR MULT TOPOLOGY 8SOIC
Packaging: Tube
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Transistor Driver
Mounting Type: Surface Mount
Function: Step-Up, Step-Up/Step-Down
Operating Temperature: -40°C ~ 125°C (TA)
Output Configuration: Positive
Frequency - Switching: 46kHz
Topology: Boost, Flyback, Forward Converter
Voltage - Supply (Vcc/Vdd): 6.9V ~ 12V
Supplier Device Package: 8-SOIC
Synchronous Rectifier: No
Control Features: Frequency Control
Output Phases: 1
Duty Cycle (Max): 99%
Clock Sync: No
Part Status: Active
Number of Outputs: 1
Applications: PWM Controller
Current - Supply: 500 µA
Voltage - Input: -0.3V ~ 6.3V
Voltage - Supply: 6.9V ~ 11V
| Anzahl | Preis |
|---|---|
| 5+ | 4.28 EUR |
| 10+ | 3.18 EUR |
| 75+ | 2.66 EUR |
| 150+ | 2.54 EUR |
| 300+ | 2.44 EUR |
| 525+ | 2.37 EUR |
| 1050+ | 2.3 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details UCC2800D Texas Instruments
Description: IC REG CTRLR MULT TOPOLOGY 8SOIC, Packaging: Tube, Package / Case: 8-SOIC (0.154", 3.90mm Width), Output Type: Transistor Driver, Mounting Type: Surface Mount, Function: Step-Up, Step-Up/Step-Down, Operating Temperature: -40°C ~ 125°C (TA), Output Configuration: Positive, Frequency - Switching: 46kHz, Topology: Boost, Flyback, Forward Converter, Voltage - Supply (Vcc/Vdd): 6.9V ~ 12V, Supplier Device Package: 8-SOIC, Synchronous Rectifier: No, Control Features: Frequency Control, Output Phases: 1, Duty Cycle (Max): 99%, Clock Sync: No, Part Status: Active, Number of Outputs: 1, Applications: PWM Controller, Current - Supply: 500 µA, Voltage - Input: -0.3V ~ 6.3V, Voltage - Supply: 6.9V ~ 11V.
Weitere Produktangebote UCC2800D
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
|---|---|---|---|---|---|
 |
UCC2800D Produktcode: 71834
zu Favoriten hinzufügen
Lieblingsprodukt
|
Hersteller : Fairchild |
IC > IC Netzteile Gehäuse: TO-3P-5L Eigenschaften: Power Switch(SPS) Fosc, kHz: 20 |
Produkt ist nicht verfügbar
|
|
 |
UCC2800D | Hersteller : Texas Instruments |
Current Mode PWM Controller -0.1V to 11V 1000kHz 8-Pin SOIC Tube |
Produkt ist nicht verfügbar |
|
|
|
UCC2800D | Hersteller : Texas Instruments |
Current Mode PWM Controller -0.1V to 11V 1000kHz 8-Pin SOIC Tube |
Produkt ist nicht verfügbar |
|
|
|
UCC2800D | Hersteller : Texas Instruments |
Current Mode PWM Controller -0.1V to 11V 1000kHz 8-Pin SOIC Tube |
Produkt ist nicht verfügbar |
|
| UCC2800D | Hersteller : Texas Instruments |
IC REG CTRLR MULT TOPOLOGY 8SOIC Група товару: Мікросхеми електроживлення Од. вим: шт |
Produkt ist nicht verfügbar |
||
 |
UCC2800D | Hersteller : Texas Instruments |
Switching Controllers Low-Power BiCMOS Current-Mode PWM |
Produkt ist nicht verfügbar |
|
 |
UCC2800D | Hersteller : TEXAS INSTRUMENTS |
Category: Voltage regulators - PWM circuits Description: IC: PMIC; PWM controller; 1A; 46kHz÷1MHz; SO8; Uin: 2.44÷2.56V; tube Type of integrated circuit: PMIC Kind of integrated circuit: PWM controller Case: SO8 Mounting: SMD Operating temperature: -40...125°C Frequency: 46kHz...1MHz Supply voltage: 7.2...13.5V Kind of package: tube Application: SMPS Output current: 1A Topology: boost; flyback; forward Duty cycle factor: 0...99% Integrated circuit features: soft-start function Operating voltage: 6.9...13.5V DC Input voltage: 2.44...2.56V |
Produkt ist nicht verfügbar |
