UPO1104 UNI-T
Hersteller: UNI-TCategory: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 2Gsps; 56Mpts; LCD TFT 7"
Type of oscilloscope: digital
Number of channels: 4
Band: 100MHz
Sampling: 2Gsps
Memory record length: 56Mpts
Kind of display used: LCD TFT 7"
Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; video signal; with delay
Time base: 1n...1ks/div
Max. input voltage: 400V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Interface: AUX; EXT Trig; LAN; USB device; USB Host
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Standard equipment: mains cable; oscilloscope probe; USB cable
Supply voltage: 100...240V AC
Display resolution: 800x480
Dimensions: 306x138x107mm
auf Bestellung 6 Stücke:
Lieferzeit 14-21 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 539.8 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details UPO1104 UNI-T
Category: Digital Oscilloscopes, Description: Oscilloscope: digital; Ch: 4; 100MHz; 2Gsps; 56Mpts; LCD TFT 7", Type of oscilloscope: digital, Number of channels: 4, Band: 100MHz, Sampling: 2Gsps, Memory record length: 56Mpts, Kind of display used: LCD TFT 7", Trigger: falling-edge; impulse width; Nth Edge; pattern; rising-edge; runt; slope; video signal; with delay, Time base: 1n...1ks/div, Max. input voltage: 400V, Vertical resolution: 8bit, Input coupling: AC, DC, GND, Interface: AUX; EXT Trig; LAN; USB device; USB Host, Rise time: ≤3.5ns, Input impedance: 1MΩ/16pF, Standard equipment: mains cable; oscilloscope probe; USB cable, Supply voltage: 100...240V AC, Display resolution: 800x480, Dimensions: 306x138x107mm.
