UT890D+ (UNI-T) Uni-Trend (Uni-T)
Produktcode: 121225
zu Favoriten hinzufügen
Lieblingsprodukt
Hersteller: Uni-Trend (Uni-T)
Gruppe: Multimeter
Beschreibung: Digital-Multimeter. Messung: Spannung, Strom, Widerstand, Kapazität, Frequenz, Diodentest, Transistortest. Datenhaltung, automatische Abschaltung. Stromversorgung: 6F22. Abmessungen: 186x91x39mm
Frequenzmessung: 10 Гц...10 МГц
Spannungs- und Strommessung: 600 mV...1000 V / 6 mA...20 A
Widerstandsmessung: 600 Ом...60 МОм
Induktivitätsmessung: keine
Kapazitätsmessung: 10 нФ...100 мФ
Transistortest: ja
Produktrezensionen
Produktbewertung abgeben
Weitere Produktangebote UT890D+ (UNI-T) nach Preis ab 27.33 EUR bis 29.16 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Privatkunde | ||||
|---|---|---|---|---|---|---|---|---|---|
     |
UT890D+ | UNI-T |
 Category: Portable digital multimetersDescription: Digital multimeter; LCD; (6000); VDC: 600mV,6V,60V,600V,1kV Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; transistors' gain hFE Display parameters: (6000) AC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF; 100mF Battery/ rechargeable battery: battery AAA 1,5V x2 Capacitance measuring accuracy: ±(3%+ 10 digit) Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator; MIN/MAX function; overflow indicator; REL function Power supply: battery AAA 1,5V x2 DC voltage measuring accuracy: ±(0.5% + 2 digit) Standard equipment: test leads DC current measuring accuracy: ±(0.8% + 8 digit) Operating temperature: 0...40°C Kind of display used: LCD Continuity test: acoustic indication; <10Ω True effective value measurement: True RMS DC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV AC current measuring accuracy: ±(1% + 12 digit) Diode test: 0...3V Frequency measuring range: 10...10MHz AC voltage measuring range: 6V; 60V; 600V; 750V Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ Frequency measuring accuracy: ±(1%+5 digit) Dimensions (W x H x D): 88x183x56mm Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010 Resistance measuring accuracy: ±(0.8%+3 digit) Illumination: yes AC voltage measuring accuracy: ±(0.8% + 3 digit) Type of meter: digital multimeter |
auf Bestellung 156 Stücke: Lieferzeit 14-21 Tag (e) |
|
| UT890D+ |
|
Hersteller: UNI-T
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); VDC: 600mV,6V,60V,600V,1kV
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; transistors' gain hFE
Display parameters: (6000)
AC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF; 100mF
Battery/ rechargeable battery: battery AAA 1,5V x2
Capacitance measuring accuracy: ±(3%+ 10 digit)
Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator; MIN/MAX function; overflow indicator; REL function
Power supply: battery AAA 1,5V x2
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Standard equipment: test leads
DC current measuring accuracy: ±(0.8% + 8 digit)
Operating temperature: 0...40°C
Kind of display used: LCD
Continuity test: acoustic indication; <10Ω
True effective value measurement: True RMS
DC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC current measuring accuracy: ±(1% + 12 digit)
Diode test: 0...3V
Frequency measuring range: 10...10MHz
AC voltage measuring range: 6V; 60V; 600V; 750V
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Frequency measuring accuracy: ±(1%+5 digit)
Dimensions (W x H x D): 88x183x56mm
Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010
Resistance measuring accuracy: ±(0.8%+3 digit)
Illumination: yes
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Type of meter: digital multimeter
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); VDC: 600mV,6V,60V,600V,1kV
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; transistors' gain hFE
Display parameters: (6000)
AC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF; 100mF
Battery/ rechargeable battery: battery AAA 1,5V x2
Capacitance measuring accuracy: ±(3%+ 10 digit)
Measuring instrument features: automatic power-off; contactless voltage detector; HOLD function; low battery indicator; MIN/MAX function; overflow indicator; REL function
Power supply: battery AAA 1,5V x2
DC voltage measuring accuracy: ±(0.5% + 2 digit)
Standard equipment: test leads
DC current measuring accuracy: ±(0.8% + 8 digit)
Operating temperature: 0...40°C
Kind of display used: LCD
Continuity test: acoustic indication; <10Ω
True effective value measurement: True RMS
DC current measuring range: 60µA; 600µA; 6mA; 60mA; 600mA; 20A
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC current measuring accuracy: ±(1% + 12 digit)
Diode test: 0...3V
Frequency measuring range: 10...10MHz
AC voltage measuring range: 6V; 60V; 600V; 750V
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Frequency measuring accuracy: ±(1%+5 digit)
Dimensions (W x H x D): 88x183x56mm
Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010
Resistance measuring accuracy: ±(0.8%+3 digit)
Illumination: yes
AC voltage measuring accuracy: ±(0.8% + 3 digit)
Type of meter: digital multimeter
auf Bestellung 156 Stücke:
Lieferzeit 14-21 Tag (e)
| Anzahl | Privatkunde |
|---|---|
| 3+ | 29.16 EUR |
| 4+ | 27.33 EUR |
