WTB26P-1H161120A00 SICK, Inc.
Hersteller: SICK, Inc.
Description: SENSOR RETROREFL 18M NPN/PNP
Cable Length: 10.630" (270.00mm)
Ingress Protection: IP66, IP67
Response Time: 500µs
Voltage - Supply: 10V ~ 30V
Output Configuration: Push-Pull, NPN/PNP
Operating Temperature: -40°C ~ 60°C
Sensing Method: Retroreflective
Sensing Distance: 0' ~ 59.10' (0 ~ 18m)
Adjustment Type: Adjustable
Packaging: Box
Connection Method: Cable with Connector
Light Source: Red (635nm)
Produktrezensionen
Produktbewertung abgeben
Technische Details WTB26P-1H161120A00 SICK, Inc.
Category: Standard Photoelectric Sensors, Description: Sensor: photoelectric; Range: 0.01÷1.6m; PNP/NPN/push pull; 100mA, Type of sensor: photoelectric, Range: 0.01...1.6m, Output configuration: PNP/NPN/push pull, Operation modes: DARK-ON; LIGHT-ON, Operation mode: diffuse-reflective, Supply voltage: 10...30V DC, Connection: cables, IP rating: IP67, Max. operating current: 0.1A, Switching frequency max: 1kHz, Operating temperature: -40...60°C, Body material: vistal, Body dimensions: 24.6x82.5x53.3mm, Lead length: 2m, Additional functions: BluePilot; IO-Link; Teach-in, Sensors features: programmable.
Weitere Produktangebote WTB26P-1H161120A00
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
|---|---|---|---|---|---|
 |
WTB26P-1H161120A00 | Hersteller : SICK |
Category: Standard Photoelectric Sensors Description: Sensor: photoelectric; Range: 0.01÷1.6m; PNP/NPN/push pull; 100mA Type of sensor: photoelectric Range: 0.01...1.6m Output configuration: PNP/NPN/push pull Operation modes: DARK-ON; LIGHT-ON Operation mode: diffuse-reflective Supply voltage: 10...30V DC Connection: cables IP rating: IP67 Max. operating current: 0.1A Switching frequency max: 1kHz Operating temperature: -40...60°C Body material: vistal Body dimensions: 24.6x82.5x53.3mm Lead length: 2m Additional functions: BluePilot; IO-Link; Teach-in Sensors features: programmable |
Produkt ist nicht verfügbar |
