Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
EEC0251B3-000U-A99 EEC0251B3-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C4E9C729C188F1A704005056AB0C4F&compId=EEC0251B3-A99.pdf?ci_sign=3378c529cdb87bcd5ec7048e05de31579aefce34 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 120x120x25mm
Power consumption: 1.9W
Current rating: 0.161A
Fan efficiency: 127.42m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.06mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 6...13.8V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 629 Stücke:
Lieferzeit 7-14 Tag (e)
7+10.77 EUR
10+9.3 EUR
20+8.37 EUR
40+8.05 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0251B3-000U-G99 EEC0251B3-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=E1C04371B0D878F1A6F5005056AB5A8F&compId=(d12017030g-00)-0.pdf?ci_sign=96acebe48f92451413f2c54453a9a526191892c5 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x25mm; 127.5m3/h; 34dBA; ball; 24AWG
Operating voltage: 6...13.8V DC
Leads: leads x3
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.17A
Supply voltage: 12V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 127.5m3/h
Static pressure: 4.06mm H2O
Noise level: 34dBA
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1473 Stücke:
Lieferzeit 7-14 Tag (e)
6+11.93 EUR
10+10.28 EUR
20+9.47 EUR
40+8.65 EUR
240+8.07 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-A99 EEC0252B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D87FF1A6F5005056AB5A8F&compId=(d12016680g-00)-0.pdf?ci_sign=1b9bb3ad5f8131436ca72d9ca68893266eae4700 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.33m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 7.11mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3200 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.01 EUR
10+9.51 EUR
20+8.57 EUR
40+7.64 EUR
240+6.96 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-F99 EEC0252B1-000U-F99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D886F1A6F5005056AB5A8F&compId=(d12016690g-00)-0.pdf?ci_sign=b6d4a8619e3d8f2e03b0a708b4d363d624fd8773 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 7.11mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: R type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 41 Stücke:
Lieferzeit 7-14 Tag (e)
4+22.95 EUR
10+20.25 EUR
40+16.17 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-G99 EEC0252B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=E1D7CE090B0B2BF1A704005056AB0C4F&compId=EEC0252B1-G99.pdf?ci_sign=7b19d0ff57e49898ad3bff7069e8d6fcb155e812 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.83m3/h; 44.5dBA; ball
Operating temperature: -10...70°C
Current rating: 0.207A
Supply voltage: 24V DC
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 183.83m3/h
Noise level: 44.5dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 5W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 53 Stücke:
Lieferzeit 7-14 Tag (e)
6+13.44 EUR
10+12.1 EUR
40+11.55 EUR
240+10.74 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B2-000U-A99 EEC0252B2-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA48049DFFC31C0D3&compId=EEC0252B2-A99.pdf?ci_sign=0586a1c9d43c0d491d56f22a07526be266faa7e0 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 158m3/h; 40.5dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Fan dimensions: 120x120x25mm
Power consumption: 3.5W
Current rating: 0.146A
Fan efficiency: 158m3/h
Noise level: 40.5dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Leads: leads x2
Lead length: 0.33m
Operating temperature: -10...70°C
Fan motor: brushless DC
Enclosure material: thermoplastic
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 610 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.43 EUR
10+10.74 EUR
40+10.47 EUR
200+10.22 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B3-000U-A99 EEC0252B3-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED131D6BFE8135&compId=EEC0252B3-A99.pdf?ci_sign=2b75788df5d99bf649d777ff2026892302f31d4f Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 2W
Current rating: 84mA
Fan efficiency: 127.42m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.06mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2985 Stücke:
Lieferzeit 7-14 Tag (e)
7+10.7 EUR
10+9.21 EUR
20+8.45 EUR
40+7.68 EUR
240+7.51 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B3-000U-G99 EEC0252B3-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D88DF1A6F5005056AB5A8F&compId=(d12016780g-00)-0.pdf?ci_sign=7665e873ec74a30a1053bf478ff8ae9993213acf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 127.5m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 2W
Current rating: 84mA
Fan efficiency: 127.5m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.07mm H2O
Operating voltage: 10...27.6V DC
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Insulation class: A
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
3+23.84 EUR
10+9.78 EUR
40+9.38 EUR
200+9.11 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B1-000U-A99 EEC0254B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=E1DA1D8597D97CF1A704005056AB0C4F&compId=EEC0254B1-A99.pdf?ci_sign=75e865b6bdd691f084336d305c1f3ec3c1491a7a pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 183.83m3/h; 44.5dBA; ball
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.7W
Current rating: 0.119A
Fan efficiency: 183.83m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Static pressure: 7.11mm H2O
Operating voltage: 24...56V DC
Fan motor: brushless DC
Flammability rating: UL94V-0
Insulation class: A
Current and power consumption tolerance: ±15%
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Anzahl je Verpackung: 1 Stücke
auf Bestellung 941 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.16 EUR
10+14.81 EUR
40+12.1 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B2-000U-A99 EEC0254B2-000U-A99 SUNON (D12015490G-01)-1.pdf Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 158m3/h; 40.5dBA; ball; 24AWG
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 79mA
Supply voltage: 48V DC
Leads: leads x2
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 158m3/h
Static pressure: 5.58mm H2O
Noise level: 40.5dBA
Rotational rate/speed: 2700 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 3.8W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 518 Stücke:
Lieferzeit 7-14 Tag (e)
5+17.66 EUR
10+15.36 EUR
40+13.76 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B3-000U-A99 EEC0254B3-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED6851FD9F4135&compId=EEC0254B3-A99.pdf?ci_sign=44a8e42fed00a1e5a100ddfae74547459c720acb Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Operating voltage: 24...56V DC
Leads: leads x2
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 54mA
Supply voltage: 48V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 127.42m3/h
Static pressure: 4.06mm H2O
Noise level: 34dBA
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2.6W
Wire size: 24AWG
Lead length: 0.13m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 297 Stücke:
Lieferzeit 7-14 Tag (e)
5+17.52 EUR
10+16.17 EUR
40+14.81 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B1-000U-A99 EEC0381B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D894F1A6F5005056AB5A8F&compId=(D12017220G-00)-0.pdf?ci_sign=11f840a869391e669e20741e7c34f99c7cb92a65 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 234.4m3/h
Static pressure: 9.14mm H2O
Noise level: 48dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.6W
Wire size: 24AWG
Lead length: 0.31m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.8A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 6...13.8V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1026 Stücke:
Lieferzeit 7-14 Tag (e)
6+11.94 EUR
10+10.3 EUR
20+9.3 EUR
40+8.27 EUR
240+7.52 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B1-000U-G99 EEC0381B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049AFF1A6F5005056AB5A8F&compId=(D12017230G-00)-0.pdf?ci_sign=f1767038c37bcf27eb55889b78a6de4d4f0a435e Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.6W
Current rating: 0.8A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Lead length: 0.33m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
Signal output: F type
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B2-000U-A99 EEC0381B2-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FE4F1A6F5005056AB5A8F&compId=EEC0381B2-A99(D12017250G-00)-0.pdf?ci_sign=e67cc591ad6ff86e660a34e08cbeb91e0ae47696 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.1W
Current rating: 0.421A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.3m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 6...13.8V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3753 Stücke:
Lieferzeit 7-14 Tag (e)
7+10.94 EUR
10+9.41 EUR
20+8.59 EUR
40+8.05 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B3-000U-A99 EEC0381B3-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049B6F1A6F5005056AB5A8F&compId=(D12017280G-00)-0.pdf?ci_sign=6ff615a94f5b83e9765169f3638eb915772e5411 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 158m3/h; 37dBA; ball; 4.57mmH2O
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.255A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 6...13.8V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 158m3/h
Static pressure: 4.57mm H2O
Noise level: 37dBA
Rotational rate/speed: 2100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2.9W
Wire size: 28AWG
Lead length: 0.31m
Additional functions: autorestart
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 329 Stücke:
Lieferzeit 7-14 Tag (e)
6+12.08 EUR
10+11.55 EUR
40+11.14 EUR
200+10.78 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-A99 EEC0382B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049BDF1A6F5005056AB5A8F&compId=(d12016480g-00)-0.pdf?ci_sign=a17c3bf63c2474118d99d15351ac16053d8e88c8 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.2W
Current rating: 0.4A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2069 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.54 EUR
10+9.94 EUR
20+8.98 EUR
40+8.02 EUR
240+7.34 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-A99 + CABLE 550MM + IP56 SUNON EEC0382B1-A99-OZ DC24V Fans
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-F99 EEC0382B1-000U-F99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049C4F1A6F5005056AB5A8F&compId=(d12016510g-00)-0.pdf?ci_sign=144ef31b6e9a0cbd47b14cd9caadd0a71f228711 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.2W
Current rating: 0.4A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: R type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2328 Stücke:
Lieferzeit 7-14 Tag (e)
6+14.26 EUR
10+12.1 EUR
40+10.74 EUR
200+8.02 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-G99 EEC0382B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FEBF1A6F5005056AB5A8F&compId=eec0382b1-0000-g99(d12012680g-00).pdf?ci_sign=1963f7da4e046611b6e5481bfe999451410b4731 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.4A
Supply voltage: 24V DC
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 234.4m3/h
Static pressure: 9.14mm H2O
Noise level: 48dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.2W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3697 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.15 EUR
10+9.62 EUR
20+9.09 EUR
40+8.55 EUR
240+8.17 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-A99 EEC0382B2-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FF2F1A6F5005056AB5A8F&compId=EEC0382B2-A99(D12016520G-00)-0.pdf?ci_sign=e3561314bdc562a669a0b641ad5c131a53bedca7 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.4W
Current rating: 0.224A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 637 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.61 EUR
10+10.01 EUR
20+9.04 EUR
40+8.04 EUR
240+7.34 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-F99 EEC0382B2-000U-F99 SUNON Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197m3/h; 44dBA; ball; 2600rpm
Supply voltage: 24V DC
Operating temperature: -10...70°C
Additional functions: autorestart
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 5.4W
Lead length: 0.33m
Signal output: R type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.224A
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 197m3/h
Noise level: 44dBA
Anzahl je Verpackung: 1 Stücke
auf Bestellung 835 Stücke:
Lieferzeit 7-14 Tag (e)
4+21.05 EUR
10+19.16 EUR
40+18.08 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-G99 EEC0382B2-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049CBF1A6F5005056AB5A8F&compId=(D12016530G-00)-0.pdf?ci_sign=10c62ef7f4e983393ce1daa1f9129e2bfa7f24dc Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.4W
Current rating: 0.224A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 588 Stücke:
Lieferzeit 7-14 Tag (e)
5+14.8 EUR
10+10.74 EUR
40+9.48 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B3-000U-A99 EEC0382B3-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED9F7BDD520135&compId=EEC0382B3-A99.pdf?ci_sign=27a6073d9f0222c585880cb94149799714f78399 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 158m3/h; 37dBA; ball; 4.57mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 3.1W
Current rating: 0.13A
Fan efficiency: 158m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 2100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.57mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 297 Stücke:
Lieferzeit 7-14 Tag (e)
7+11.54 EUR
10+10.74 EUR
40+10.2 EUR
200+9.38 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0384B1-000U-A99 EEC0384B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049D2F1A6F5005056AB5A8F&compId=(d12017420g-00)-0.pdf?ci_sign=48496e9fc05fc2998d38f3f646916b70c1061159 Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.7W
Current rating: 0.203A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.31m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 24...56V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1164 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.86 EUR
10+14.54 EUR
20+12.91 EUR
40+11.25 EUR
240+10.1 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0384B1-000U-G99 EEC0384B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE9000F1A6F5005056AB5A8F&compId=EEC0384B1-G99(D12017430G-00)-0.pdf?ci_sign=cac8aec6baf458936b4040325f31da2923953676 Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x38mm; 234.6m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.7W
Current rating: 0.203A
Fan efficiency: 234.6m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Fan motor: brushless DC
Operating voltage: 24...56V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 259 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.97 EUR
10+14.63 EUR
20+14.31 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF40101B1-1000U-A99 EF40101B1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F37A0C4&compId=EF40101B1-A99-A.pdf?ci_sign=87c1c83d892160214819a651436997ed78f30f09 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 13.59m3/h; 27.3dBA; ball; 7000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 1.01W
Current rating: 82mA
Fan efficiency: 13.59m3/h
Noise level: 27.3dBA
Kind of Bearing: ball
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 4.82mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 433 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.82 EUR
10+7.61 EUR
50+7.05 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF40101B2-1000U-A99 EF40101B2-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F38E0C4&compId=EF40101B2-A99-A.pdf?ci_sign=1a44e2da2122513116ced8482f2128035f484f13 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9.35m3/h; 17.7dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 0.45W
Current rating: 37mA
Fan efficiency: 9.35m3/h
Noise level: 17.7dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 2.53mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 425 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.74 EUR
50+6.79 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF40101BX-1000U-A99 EF40101BX-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3A20C4&compId=EF40101BX-A99-A.pdf?ci_sign=ffddb0b7854d79224fb10e2050395c1e89729a33 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 16.99m3/h; 33.7dBA; ball; 9000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 1.47W
Current rating: 0.122A
Fan efficiency: 16.99m3/h
Noise level: 33.7dBA
Kind of Bearing: ball
Rotational rate/speed: 9000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 6.85mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 134 Stücke:
Lieferzeit 7-14 Tag (e)
7+10.72 EUR
10+9.24 EUR
50+8.42 EUR
200+8.02 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-000U-A99 EF40201B1-000U-A99 SUNON pVersion=0046&contRep=ZT&docId=E2B2F6EC306F81F19A99005056AB752F&compId=EF40201B1-A99.pdf?ci_sign=f254060f99a09245c2df245f8037f3d75a6e96f9 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.12m3/h; 26.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.56W
Current rating: 46mA
Fan efficiency: 15.12m3/h
Noise level: 26.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6300 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2182 Stücke:
Lieferzeit 7-14 Tag (e)
11+6.79 EUR
14+5.31 EUR
50+4.62 EUR
200+4.48 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-1000U-A99 EF40201B1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.2m3/h; 24.5dBA; ball; 7200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.66W
Current rating: 55mA
Fan efficiency: 15.2m3/h
Noise level: 24.5dBA
Kind of Bearing: ball
Rotational rate/speed: 7200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart; protection against reverse connection of power supply
Fan motor: brushless DC
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 919 Stücke:
Lieferzeit 7-14 Tag (e)
8+10.18 EUR
10+9.38 EUR
50+8.02 EUR
150+7.81 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-000U-G99 EF40201B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1ED6BB88205ADE77FE28&compId=EF40201B1-G99_DTE.pdf?ci_sign=0c1391c4e335740808617d18912847f4fc174b58 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.12m3/h; 26.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.56W
Current rating: 46mA
Fan efficiency: 15.12m3/h
Noise level: 26.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6300 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
Lead length: 0.305m
Signal output: F type
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2557 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.19 EUR
11+6.66 EUR
50+6.12 EUR
200+5.71 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B2-1000U-A99 EF40201B2-1000U-A99 SUNON (D04158940G-00)-0.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 13.08m3/h; 27.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.65W
Current rating: 54mA
Fan efficiency: 13.08m3/h
Noise level: 27.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6200 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 3.05mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 991 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.84 EUR
25+6.91 EUR
50+6.51 EUR
75+6.26 EUR
150+6.12 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B3-1000U-A99 EF40201B3-1000U-A99 SUNON (D04159100G-00)-1.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 7.99m3/h; 22.1dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.58W
Current rating: 48mA
Fan efficiency: 7.99m3/h
Noise level: 22.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 2.29mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 619 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.84 EUR
11+7.09 EUR
50+6.91 EUR
100+6.51 EUR
150+6.12 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201BX-1000U-A99 EF40201BX-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB281E1EDF9D985FBD42BB00D6&compId=EF40201BX-1000U-A99.pdf?ci_sign=8d40a031c9e3f9abf17d873f0a47bba122860863 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 18.7m3/h; 28.5dBA; ball; 8200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.78W
Current rating: 65mA
Fan efficiency: 18.7m3/h
Noise level: 28.5dBA
Kind of Bearing: ball
Rotational rate/speed: 8200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart; protection against reverse connection of power supply
Fan motor: brushless DC
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 216 Stücke:
Lieferzeit 7-14 Tag (e)
8+8.97 EUR
10+7.48 EUR
50+6.25 EUR
150+5.71 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF45101S1-1000U-999 EF45101S1-1000U-999 SUNON Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 45x45x10mm; 15.8m3/h; 33dBA; slide; 3.05mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 45x45x10mm
Power consumption: 1.18W
Current rating: 98mA
Fan efficiency: 15.8m3/h
Noise level: 33dBA
Kind of Bearing: slide
Rotational rate/speed: 5700 (±10%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Static pressure: 3.05mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1116 Stücke:
Lieferzeit 7-14 Tag (e)
22+3.39 EUR
23+3.13 EUR
50+2.86 EUR
200+2.45 EUR
Mindestbestellmenge: 22
Im Einkaufswagen  Stück im Wert von  UAH
EF45101S2-1000U-999 EF45101S2-1000U-999 SUNON (D04166920G-00)-1.pdf Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 45x45x10mm; 13.93m3/h; 29.3dBA; slide; 26AWG
Enclosure material: thermoplastic
Current rating: 78mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 45x45x10mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 13.93m3/h
Static pressure: 2.29mm H2O
Noise level: 29.3dBA
Rotational rate/speed: 5000 (±10%)rpm
Power consumption: 0.94W
Wire size: 26AWG
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1130 Stücke:
Lieferzeit 7-14 Tag (e)
22+3.39 EUR
23+3.13 EUR
50+2.86 EUR
200+2.59 EUR
Mindestbestellmenge: 22
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B1-1B00U-A99 EF50151B1-1B00U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B460C7&compId=Product%2022.pdf?ci_sign=c6852293cc844d69b6b4831e62b56fcadf507f47 Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 7.64m3/h; 41dBA; ball
Power consumption: 1.28W
Enclosure material: thermoplastic
Current rating: 106mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 7.64m3/h
Noise level: 41dBA
Rotational rate/speed: 5200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1156 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.3 EUR
10+14.27 EUR
50+12.91 EUR
156+11.55 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B2-1B00U-A99 EF50151B2-1B00U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA789610A6890A0C7&compId=Product%2026.pdf?ci_sign=920c521048c42f92d5e2bf2dcfe89fabdfa5552a Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; ball
Power consumption: 0.64W
Enclosure material: thermoplastic
Current rating: 54mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 5.94m3/h
Noise level: 34dBA
Rotational rate/speed: 4200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 242 Stücke:
Lieferzeit 7-14 Tag (e)
6+14.26 EUR
10+12.91 EUR
50+12.1 EUR
156+11.81 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B3-1B00U-A99 EF50151B3-1B00U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B1E0C7&compId=Product%2020.pdf?ci_sign=c809c6d26b03eccb771b7d7c69b772c087a6b3ef Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 4.41m3/h; 26dBA; ball
Power consumption: 0.6W
Enclosure material: thermoplastic
Current rating: 36mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 4.41m3/h
Noise level: 26dBA
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 730 Stücke:
Lieferzeit 7-14 Tag (e)
6+14.26 EUR
10+13.46 EUR
50+12.91 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EF50151BX-1B00U-A99 EF50151BX-1B00U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960C2933660C7&compId=Product%2011.pdf?ci_sign=809b2ed67f97b20df0d8e4cef9e98e065ea96499 Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 9.17m3/h; 45.8dBA; ball
Power consumption: 1.8W
Enclosure material: thermoplastic
Current rating: 0.15A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 9.17m3/h
Noise level: 45.8dBA
Rotational rate/speed: 6200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 10 Stücke:
Lieferzeit 7-14 Tag (e)
5+16.43 EUR
10+15.63 EUR
50+14.41 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF60202B1-000U-G99 EF60202B1-000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1ED6BB8883FB319CBE28&compId=EF60202B1-G99_DTE.pdf?ci_sign=e0e053190c81bd117f55a75c219d654db3aedd78 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 39.07m3/h; 34.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 8...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 39.07m3/h
Noise level: 34.5dBA
Kind of Bearing: ball
Rotational rate/speed: 4500 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 4.57mm H2O
Wire size: 26AWG
Current and power consumption tolerance: ±15%
Related items: BUB-72H
Lead length: 0.3m
Signal output: F type
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B1-1000U-A99 EF60251B1-1000U-A99 SUNON Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 39.93m3/h; 35.1dBA; ball; 5200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 0.99W
Current rating: 82mA
Fan efficiency: 39.93m3/h
Noise level: 35.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.29m
Anzahl je Verpackung: 1 Stücke
auf Bestellung 818 Stücke:
Lieferzeit 7-14 Tag (e)
8+10.12 EUR
50+7.85 EUR
100+6.71 EUR
200+6.32 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B2-1000U-A99 EF60251B2-1000U-A99 SUNON Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 32.76m3/h; 27dBA; ball; 4500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 0.84W
Current rating: 58mA
Fan efficiency: 32.76m3/h
Noise level: 27dBA
Kind of Bearing: ball
Rotational rate/speed: 4500rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.29m
Anzahl je Verpackung: 1 Stücke
auf Bestellung 904 Stücke:
Lieferzeit 7-14 Tag (e)
8+10.12 EUR
50+7.85 EUR
100+6.71 EUR
200+6.32 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B3-1000U-A99 EF60251B3-1000U-A99 SUNON Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; ball
Type of fan: DC
Kind of fan: axial
Fan dimensions: 60x60x25mm
Kind of Bearing: ball
Min. insulation resistance: 10MΩ
Leads: leads x2
Operating temperature: -10...70°C
Fan motor: brushless DC
Additional functions: autorestart
Enclosure material: thermoplastic
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Anzahl je Verpackung: 1 Stücke
auf Bestellung 983 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.84 EUR
10+8.01 EUR
50+7.16 EUR
200+6.54 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF60252B1-1000U-A99 EF60252B1-1000U-A99 SUNON Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x25mm; 39.93m3/h; 35.1dBA; ball; 5200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Fan dimensions: 60x60x25mm
Power consumption: 1.08W
Current rating: 45mA
Fan efficiency: 39.93m3/h
Noise level: 35.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.29m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1008 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.84 EUR
10+8.01 EUR
50+7.16 EUR
200+6.54 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF60252S1-1000U-A99 EF60252S1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3CA0C4&compId=EF60252S1-A99.pdf?ci_sign=7d5ae0d1fab98b134c86f3b17f37b740072a9bee Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x25mm; 39.93m3/h; 27dBA; slide; 4500rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 39.93m3/h
Noise level: 27dBA
Rotational rate/speed: 4500rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.25W
Wire size: 26AWG
Related items: SRF4-30
Lead length: 0.29m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 50mA
Supply voltage: 24V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 60x60x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
2+35.75 EUR
10+7.15 EUR
40+3.13 EUR
160+2.6 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B1-1000U-A99 EF80251B1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3DE0C4&compId=EF80251B1-A99-A.pdf?ci_sign=78c8977168b93967acd27f7402c62fe213548d39 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.5m3/h; 33dBA; ball; 3200rpm
Current rating: 65mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 69.5m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Power consumption: 1.56W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B1-1000U-G99 EF80251B1-1000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 70m3/h; 33dBA; ball; Out: F type
Current rating: 0.125A
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 70m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Power consumption: 1.5W
Lead length: 0.315m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x3
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B2-1000U-A99 EF80251B2-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3F20C4&compId=EF80251B2-A99-A.pdf?ci_sign=67ff2d4345fec6c678d45216cf524b487a2eccf1 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Current rating: 90mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.08W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2014 Stücke:
Lieferzeit 7-14 Tag (e)
11+6.52 EUR
14+5.31 EUR
50+4.35 EUR
200+4.08 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B3-1000U-A99 EF80251B3-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F4060C4&compId=EF80251B3-A99-A.pdf?ci_sign=949583447a887ab7cec6feb076c385d1c6373b46 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 56.05m3/h; 28dBA; ball; 2600rpm
Current rating: 65mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 56.05m3/h
Noise level: 28dBA
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 0.78W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 537 Stücke:
Lieferzeit 7-14 Tag (e)
11+6.65 EUR
14+5.16 EUR
50+4.35 EUR
200+4.2 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF80251BX-1000U-A99 EF80251BX-1000U-A99 SUNON Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 76.43m3/h; 36.1dBA; ball; 3600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.47...1.7W
Current rating: 0.122A
Fan efficiency: 76.43m3/h
Noise level: 36.1dBA
Kind of Bearing: ball
Rotational rate/speed: 3600rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 4.5...13.8V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 641 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.55 EUR
10+7.61 EUR
50+7.38 EUR
200+6.99 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S1-1000U-A99 EF80251S1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1ED7ACFEA7A7B44C2A13&compId=EF80251S1-1000U-A99%20D08062910G-00.pdf?ci_sign=c34cbb73ff09730178097adab6515b3371313dd7 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.29m3/h; 33dBA; slide; 24AWG
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.29m3/h
Static pressure: 4.57mm H2O
Noise level: 33dBA
Rotational rate/speed: 3200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.66W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.12A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
3+23.84 EUR
25+2.86 EUR
50+2.33 EUR
250+2.14 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S1-1000U-G99 EF80251S1-1000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB752F1ED7ACFEB6E583D06A13&compId=EF80251S1-1000U-G99%20%20D08062930G-00.pdf?ci_sign=242b69eef9bdf660fcc88633100f2dd20f844f56 Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.29m3/h; 33dBA; slide; 24AWG
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.12A
Supply voltage: 12V DC
Leads: leads x3
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.29m3/h
Static pressure: 4.57mm H2O
Noise level: 33dBA
Rotational rate/speed: 3200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.66W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2810 Stücke:
Lieferzeit 7-14 Tag (e)
19+3.93 EUR
22+3.4 EUR
50+2.72 EUR
250+2.59 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S2-1000U-A99 SUNON (D08070900G-00)-1.pdf EF80251S2-A99-A DC12V Fans
auf Bestellung 383 Stücke:
Lieferzeit 7-14 Tag (e)
15+4.86 EUR
50+4 EUR
Mindestbestellmenge: 15
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S3-1000U-A99 EF80251S3-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1B4AFF400C4&compId=EF80251S3-A99-A.pdf?ci_sign=49f16fe3ace70dfa2a9ba522eb7e14f610aa331d Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 56.06m3/h; 28dBA; slide; 2600rpm
Leads: leads x2
Insulation class: A
Current rating: 70mA
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: slide
Fan efficiency: 56.06m3/h
Noise level: 28dBA
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 0.84W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 102 Stücke:
Lieferzeit 7-14 Tag (e)
12+6.11 EUR
14+5.31 EUR
50+4.76 EUR
200+3.95 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B1-1000U-A99 EF80252B1-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1B4AFF540C4&compId=EF80252B1-A99-A.pdf?ci_sign=9f4c764d2d851ffb0947fd0561a1bc5122056b42 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.66m3/h; 33dBA; ball; 3200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 65mA
Fan efficiency: 69.66m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1410 Stücke:
Lieferzeit 7-14 Tag (e)
12+6.38 EUR
15+5.03 EUR
50+4.22 EUR
200+3.95 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B1-1000U-G99 EF80252B1-1000U-G99 SUNON pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.5m3/h; 33dBA; ball; Out: F type
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 65mA
Fan efficiency: 69.5m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Signal output: F type
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 82 Stücke:
Lieferzeit 7-14 Tag (e)
9+8.82 EUR
10+8.15 EUR
50+7.48 EUR
200+6.66 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B2-1000U-A99 EF80252B2-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1309BFC20C4&compId=EF80252B2-A99-A.pdf?ci_sign=d8a1f8316b35ccdf93ddc286be43d7ec8d81ee10 Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.16W
Current rating: 48mA
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 778 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.46 EUR
11+6.66 EUR
50+6.25 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B2-1000U-G99 SUNON SUNON%20DC%20Brushless%20Fan%20&%20Blower(255-E).pdf Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 8...27.6V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.16W
Current rating: 48mA
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.315m
Signal output: F type
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B3-1000U-A99 EF80252B3-1000U-A99 SUNON pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1309BFD60C4&compId=EF80252B3-A99-A.pdf?ci_sign=bd11c7d2df23ac5597be9af79ec59ac983b8042d Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 56.06m3/h; 28dBA; ball; 2600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 0.89W
Current rating: 36mA
Fan efficiency: 56.06m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 111 Stücke:
Lieferzeit 7-14 Tag (e)
10+7.46 EUR
11+7.06 EUR
50+6.79 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EEC0251B3-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C4E9C729C188F1A704005056AB0C4F&compId=EEC0251B3-A99.pdf?ci_sign=3378c529cdb87bcd5ec7048e05de31579aefce34
EEC0251B3-000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 120x120x25mm
Power consumption: 1.9W
Current rating: 0.161A
Fan efficiency: 127.42m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.06mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 6...13.8V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 629 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+10.77 EUR
10+9.3 EUR
20+8.37 EUR
40+8.05 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0251B3-000U-G99 pVersion=0046&contRep=ZT&docId=E1C04371B0D878F1A6F5005056AB5A8F&compId=(d12017030g-00)-0.pdf?ci_sign=96acebe48f92451413f2c54453a9a526191892c5 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b
EEC0251B3-000U-G99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x25mm; 127.5m3/h; 34dBA; ball; 24AWG
Operating voltage: 6...13.8V DC
Leads: leads x3
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.17A
Supply voltage: 12V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 127.5m3/h
Static pressure: 4.06mm H2O
Noise level: 34dBA
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1473 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+11.93 EUR
10+10.28 EUR
20+9.47 EUR
40+8.65 EUR
240+8.07 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D87FF1A6F5005056AB5A8F&compId=(d12016680g-00)-0.pdf?ci_sign=1b9bb3ad5f8131436ca72d9ca68893266eae4700
EEC0252B1-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Lead length: 0.33m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 7.11mm H2O
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3200 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.01 EUR
10+9.51 EUR
20+8.57 EUR
40+7.64 EUR
240+6.96 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-F99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D886F1A6F5005056AB5A8F&compId=(d12016690g-00)-0.pdf?ci_sign=b6d4a8619e3d8f2e03b0a708b4d363d624fd8773
EEC0252B1-000U-F99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.8m3/h; 44.5dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.3W
Current rating: 0.445A
Fan efficiency: 183.8m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 7.11mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: R type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 41 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
4+22.95 EUR
10+20.25 EUR
40+16.17 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B1-000U-G99 pVersion=0046&contRep=ZT&docId=E1D7CE090B0B2BF1A704005056AB0C4F&compId=EEC0252B1-G99.pdf?ci_sign=7b19d0ff57e49898ad3bff7069e8d6fcb155e812 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b
EEC0252B1-000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 183.83m3/h; 44.5dBA; ball
Operating temperature: -10...70°C
Current rating: 0.207A
Supply voltage: 24V DC
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 183.83m3/h
Noise level: 44.5dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 5W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 53 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+13.44 EUR
10+12.1 EUR
40+11.55 EUR
240+10.74 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B2-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA48049DFFC31C0D3&compId=EEC0252B2-A99.pdf?ci_sign=0586a1c9d43c0d491d56f22a07526be266faa7e0
EEC0252B2-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 158m3/h; 40.5dBA; ball; 2700rpm
Type of fan: DC
Kind of fan: axial
Fan dimensions: 120x120x25mm
Power consumption: 3.5W
Current rating: 0.146A
Fan efficiency: 158m3/h
Noise level: 40.5dBA
Kind of Bearing: ball
Rotational rate/speed: 2700rpm
Min. insulation resistance: 10MΩ
Leads: leads x2
Lead length: 0.33m
Operating temperature: -10...70°C
Fan motor: brushless DC
Enclosure material: thermoplastic
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 610 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.43 EUR
10+10.74 EUR
40+10.47 EUR
200+10.22 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B3-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED131D6BFE8135&compId=EEC0252B3-A99.pdf?ci_sign=2b75788df5d99bf649d777ff2026892302f31d4f
EEC0252B3-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 2W
Current rating: 84mA
Fan efficiency: 127.42m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.06mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2985 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+10.7 EUR
10+9.21 EUR
20+8.45 EUR
40+7.68 EUR
240+7.51 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0252B3-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D88DF1A6F5005056AB5A8F&compId=(d12016780g-00)-0.pdf?ci_sign=7665e873ec74a30a1053bf478ff8ae9993213acf
EEC0252B3-000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x25mm; 127.5m3/h; 34dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x25mm
Power consumption: 2W
Current rating: 84mA
Fan efficiency: 127.5m3/h
Noise level: 34dBA
Kind of Bearing: ball
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.07mm H2O
Operating voltage: 10...27.6V DC
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Insulation class: A
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
3+23.84 EUR
10+9.78 EUR
40+9.38 EUR
200+9.11 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B1-000U-A99 pVersion=0046&contRep=ZT&docId=E1DA1D8597D97CF1A704005056AB0C4F&compId=EEC0254B1-A99.pdf?ci_sign=75e865b6bdd691f084336d305c1f3ec3c1491a7a pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b
EEC0254B1-000U-A99
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 183.83m3/h; 44.5dBA; ball
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x25mm
Power consumption: 5.7W
Current rating: 0.119A
Fan efficiency: 183.83m3/h
Noise level: 44.5dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Static pressure: 7.11mm H2O
Operating voltage: 24...56V DC
Fan motor: brushless DC
Flammability rating: UL94V-0
Insulation class: A
Current and power consumption tolerance: ±15%
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Anzahl je Verpackung: 1 Stücke
auf Bestellung 941 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.16 EUR
10+14.81 EUR
40+12.1 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B2-000U-A99 (D12015490G-01)-1.pdf
EEC0254B2-000U-A99
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 158m3/h; 40.5dBA; ball; 24AWG
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 79mA
Supply voltage: 48V DC
Leads: leads x2
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 158m3/h
Static pressure: 5.58mm H2O
Noise level: 40.5dBA
Rotational rate/speed: 2700 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 3.8W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 518 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+17.66 EUR
10+15.36 EUR
40+13.76 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0254B3-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED6851FD9F4135&compId=EEC0254B3-A99.pdf?ci_sign=44a8e42fed00a1e5a100ddfae74547459c720acb
EEC0254B3-000U-A99
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x25mm; 127.42m3/h; 34dBA; ball; 24AWG
Operating voltage: 24...56V DC
Leads: leads x2
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 54mA
Supply voltage: 48V DC
Type of fan: DC
Fan dimensions: 120x120x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 127.42m3/h
Static pressure: 4.06mm H2O
Noise level: 34dBA
Rotational rate/speed: 2200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2.6W
Wire size: 24AWG
Lead length: 0.13m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 297 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+17.52 EUR
10+16.17 EUR
40+14.81 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B1-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04371B0D894F1A6F5005056AB5A8F&compId=(D12017220G-00)-0.pdf?ci_sign=11f840a869391e669e20741e7c34f99c7cb92a65
EEC0381B1-000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 234.4m3/h
Static pressure: 9.14mm H2O
Noise level: 48dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.6W
Wire size: 24AWG
Lead length: 0.31m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.8A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 6...13.8V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1026 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+11.94 EUR
10+10.3 EUR
20+9.3 EUR
40+8.27 EUR
240+7.52 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B1-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049AFF1A6F5005056AB5A8F&compId=(D12017230G-00)-0.pdf?ci_sign=f1767038c37bcf27eb55889b78a6de4d4f0a435e
EEC0381B1-000U-G99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.6W
Current rating: 0.8A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Lead length: 0.33m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 9.14mm H2O
Wire size: 24AWG
Signal output: F type
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B2-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FE4F1A6F5005056AB5A8F&compId=EEC0381B2-A99(D12017250G-00)-0.pdf?ci_sign=e67cc591ad6ff86e660a34e08cbeb91e0ae47696
EEC0381B2-000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.1W
Current rating: 0.421A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.3m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 6...13.8V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3753 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+10.94 EUR
10+9.41 EUR
20+8.59 EUR
40+8.05 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0381B3-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049B6F1A6F5005056AB5A8F&compId=(D12017280G-00)-0.pdf?ci_sign=6ff615a94f5b83e9765169f3638eb915772e5411
EEC0381B3-000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 120x120x38mm; 158m3/h; 37dBA; ball; 4.57mmH2O
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.255A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 6...13.8V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 158m3/h
Static pressure: 4.57mm H2O
Noise level: 37dBA
Rotational rate/speed: 2100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 2.9W
Wire size: 28AWG
Lead length: 0.31m
Additional functions: autorestart
Kind of fan: axial
Anzahl je Verpackung: 1 Stücke
auf Bestellung 329 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+12.08 EUR
10+11.55 EUR
40+11.14 EUR
200+10.78 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049BDF1A6F5005056AB5A8F&compId=(d12016480g-00)-0.pdf?ci_sign=a17c3bf63c2474118d99d15351ac16053d8e88c8
EEC0382B1-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.2W
Current rating: 0.4A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2069 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.54 EUR
10+9.94 EUR
20+8.98 EUR
40+8.02 EUR
240+7.34 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-A99 + CABLE 550MM + IP56
Hersteller: SUNON
EEC0382B1-A99-OZ DC24V Fans
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-F99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049C4F1A6F5005056AB5A8F&compId=(d12016510g-00)-0.pdf?ci_sign=144ef31b6e9a0cbd47b14cd9caadd0a71f228711
EEC0382B1-000U-F99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.2W
Current rating: 0.4A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: R type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2328 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+14.26 EUR
10+12.1 EUR
40+10.74 EUR
200+8.02 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B1-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FEBF1A6F5005056AB5A8F&compId=eec0382b1-0000-g99(d12012680g-00).pdf?ci_sign=1963f7da4e046611b6e5481bfe999451410b4731
EEC0382B1-000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.4A
Supply voltage: 24V DC
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 234.4m3/h
Static pressure: 9.14mm H2O
Noise level: 48dBA
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 9.2W
Wire size: 24AWG
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3697 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.15 EUR
10+9.62 EUR
20+9.09 EUR
40+8.55 EUR
240+8.17 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE8FF2F1A6F5005056AB5A8F&compId=EEC0382B2-A99(D12016520G-00)-0.pdf?ci_sign=e3561314bdc562a669a0b641ad5c131a53bedca7
EEC0382B2-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.4W
Current rating: 0.224A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 637 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.61 EUR
10+10.01 EUR
20+9.04 EUR
40+8.04 EUR
240+7.34 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-F99
EEC0382B2-000U-F99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197m3/h; 44dBA; ball; 2600rpm
Supply voltage: 24V DC
Operating temperature: -10...70°C
Additional functions: autorestart
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 5.4W
Lead length: 0.33m
Signal output: R type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.224A
Leads: leads x3
Operating voltage: 10...27.6V DC
Type of fan: DC
Fan dimensions: 120x120x38mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 197m3/h
Noise level: 44dBA
Anzahl je Verpackung: 1 Stücke
auf Bestellung 835 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
4+21.05 EUR
10+19.16 EUR
40+18.08 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B2-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049CBF1A6F5005056AB5A8F&compId=(D12016530G-00)-0.pdf?ci_sign=10c62ef7f4e983393ce1daa1f9129e2bfa7f24dc
EEC0382B2-000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 197.2m3/h; 44dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 5.4W
Current rating: 0.224A
Fan efficiency: 197.2m3/h
Noise level: 44dBA
Kind of Bearing: ball
Rotational rate/speed: 2600 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 6.6mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 588 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+14.8 EUR
10+10.74 EUR
40+9.48 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0382B3-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE2B3ED9F7BDD520135&compId=EEC0382B3-A99.pdf?ci_sign=27a6073d9f0222c585880cb94149799714f78399
EEC0382B3-000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 120x120x38mm; 158m3/h; 37dBA; ball; 4.57mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 120x120x38mm
Power consumption: 3.1W
Current rating: 0.13A
Fan efficiency: 158m3/h
Noise level: 37dBA
Kind of Bearing: ball
Rotational rate/speed: 2100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 4.57mm H2O
Lead length: 0.33m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 10...27.6V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 297 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+11.54 EUR
10+10.74 EUR
40+10.2 EUR
200+9.38 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EEC0384B1-000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04377B049D2F1A6F5005056AB5A8F&compId=(d12017420g-00)-0.pdf?ci_sign=48496e9fc05fc2998d38f3f646916b70c1061159
EEC0384B1-000U-A99
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x38mm; 234.4m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.7W
Current rating: 0.203A
Fan efficiency: 234.4m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.31m
Additional functions: autorestart
Fan motor: brushless DC
Operating voltage: 24...56V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1164 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.86 EUR
10+14.54 EUR
20+12.91 EUR
40+11.25 EUR
240+10.1 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EEC0384B1-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1EE69BCFD9F3F6A6CFA8&compId=Sunon%20DC%20Brushless%20Fan%20%26%20Blower.pdf?ci_sign=a0c7d956948f5b35d6b13385113d437006f0ea7b pVersion=0046&contRep=ZT&docId=E1C04B6FAE9000F1A6F5005056AB5A8F&compId=EEC0384B1-G99(D12017430G-00)-0.pdf?ci_sign=cac8aec6baf458936b4040325f31da2923953676
EEC0384B1-000U-G99
Hersteller: SUNON
Category: DC48V Fans
Description: Fan: DC; axial; 48VDC; 120x120x38mm; 234.6m3/h; 48dBA; ball; 24AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 48V DC
Fan dimensions: 120x120x38mm
Power consumption: 9.7W
Current rating: 0.203A
Fan efficiency: 234.6m3/h
Noise level: 48dBA
Kind of Bearing: ball
Rotational rate/speed: 3100 (±10%)rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Static pressure: 9.14mm H2O
Lead length: 0.33m
Additional functions: autorestart
Signal output: F type
Fan motor: brushless DC
Operating voltage: 24...56V DC
Insulation class: A
Wire size: 24AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 259 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.97 EUR
10+14.63 EUR
20+14.31 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF40101B1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F37A0C4&compId=EF40101B1-A99-A.pdf?ci_sign=87c1c83d892160214819a651436997ed78f30f09
EF40101B1-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 13.59m3/h; 27.3dBA; ball; 7000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 1.01W
Current rating: 82mA
Fan efficiency: 13.59m3/h
Noise level: 27.3dBA
Kind of Bearing: ball
Rotational rate/speed: 7000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 4.82mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 433 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.82 EUR
10+7.61 EUR
50+7.05 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF40101B2-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F38E0C4&compId=EF40101B2-A99-A.pdf?ci_sign=1a44e2da2122513116ced8482f2128035f484f13
EF40101B2-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 9.35m3/h; 17.7dBA; ball; 5000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 0.45W
Current rating: 37mA
Fan efficiency: 9.35m3/h
Noise level: 17.7dBA
Kind of Bearing: ball
Rotational rate/speed: 5000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 2.53mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 425 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.74 EUR
50+6.79 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF40101BX-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3A20C4&compId=EF40101BX-A99-A.pdf?ci_sign=ffddb0b7854d79224fb10e2050395c1e89729a33
EF40101BX-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x10mm; 16.99m3/h; 33.7dBA; ball; 9000rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x10mm
Power consumption: 1.47W
Current rating: 0.122A
Fan efficiency: 16.99m3/h
Noise level: 33.7dBA
Kind of Bearing: ball
Rotational rate/speed: 9000rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 6.85mm H2O
Lead length: 0.3m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 134 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
7+10.72 EUR
10+9.24 EUR
50+8.42 EUR
200+8.02 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-000U-A99 pVersion=0046&contRep=ZT&docId=E2B2F6EC306F81F19A99005056AB752F&compId=EF40201B1-A99.pdf?ci_sign=f254060f99a09245c2df245f8037f3d75a6e96f9
EF40201B1-000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.12m3/h; 26.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.56W
Current rating: 46mA
Fan efficiency: 15.12m3/h
Noise level: 26.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6300 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2182 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
11+6.79 EUR
14+5.31 EUR
50+4.62 EUR
200+4.48 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211
EF40201B1-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.2m3/h; 24.5dBA; ball; 7200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.66W
Current rating: 55mA
Fan efficiency: 15.2m3/h
Noise level: 24.5dBA
Kind of Bearing: ball
Rotational rate/speed: 7200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart; protection against reverse connection of power supply
Fan motor: brushless DC
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 919 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
8+10.18 EUR
10+9.38 EUR
50+8.02 EUR
150+7.81 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B1-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1ED6BB88205ADE77FE28&compId=EF40201B1-G99_DTE.pdf?ci_sign=0c1391c4e335740808617d18912847f4fc174b58
EF40201B1-000U-G99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 15.12m3/h; 26.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.56W
Current rating: 46mA
Fan efficiency: 15.12m3/h
Noise level: 26.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6300 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 5.59mm H2O
Wire size: 26AWG
Lead length: 0.305m
Signal output: F type
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2557 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.19 EUR
11+6.66 EUR
50+6.12 EUR
200+5.71 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B2-1000U-A99 (D04158940G-00)-0.pdf
EF40201B2-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 13.08m3/h; 27.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.65W
Current rating: 54mA
Fan efficiency: 13.08m3/h
Noise level: 27.5dBA
Kind of Bearing: ball
Rotational rate/speed: 6200 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 3.05mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 991 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.84 EUR
25+6.91 EUR
50+6.51 EUR
75+6.26 EUR
150+6.12 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201B3-1000U-A99 (D04159100G-00)-1.pdf
EF40201B3-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 7.99m3/h; 22.1dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.58W
Current rating: 48mA
Fan efficiency: 7.99m3/h
Noise level: 22.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 2.29mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 619 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.84 EUR
11+7.09 EUR
50+6.91 EUR
100+6.51 EUR
150+6.12 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF40201BX-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB281E1EDF9D985FBD42BB00D6&compId=EF40201BX-1000U-A99.pdf?ci_sign=8d40a031c9e3f9abf17d873f0a47bba122860863
EF40201BX-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 40x40x20mm; 18.7m3/h; 28.5dBA; ball; 8200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 6...13.8V DC
Fan dimensions: 40x40x20mm
Power consumption: 0.78W
Current rating: 65mA
Fan efficiency: 18.7m3/h
Noise level: 28.5dBA
Kind of Bearing: ball
Rotational rate/speed: 8200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart; protection against reverse connection of power supply
Fan motor: brushless DC
Lead length: 0.305m
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
auf Bestellung 216 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
8+8.97 EUR
10+7.48 EUR
50+6.25 EUR
150+5.71 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF45101S1-1000U-999
EF45101S1-1000U-999
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 45x45x10mm; 15.8m3/h; 33dBA; slide; 3.05mmH2O
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 45x45x10mm
Power consumption: 1.18W
Current rating: 98mA
Fan efficiency: 15.8m3/h
Noise level: 33dBA
Kind of Bearing: slide
Rotational rate/speed: 5700 (±10%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Static pressure: 3.05mm H2O
Wire size: 26AWG
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1116 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
22+3.39 EUR
23+3.13 EUR
50+2.86 EUR
200+2.45 EUR
Mindestbestellmenge: 22
Im Einkaufswagen  Stück im Wert von  UAH
EF45101S2-1000U-999 (D04166920G-00)-1.pdf
EF45101S2-1000U-999
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 45x45x10mm; 13.93m3/h; 29.3dBA; slide; 26AWG
Enclosure material: thermoplastic
Current rating: 78mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 45x45x10mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 13.93m3/h
Static pressure: 2.29mm H2O
Noise level: 29.3dBA
Rotational rate/speed: 5000 (±10%)rpm
Power consumption: 0.94W
Wire size: 26AWG
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1130 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
22+3.39 EUR
23+3.13 EUR
50+2.86 EUR
200+2.59 EUR
Mindestbestellmenge: 22
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B1-1B00U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B460C7&compId=Product%2022.pdf?ci_sign=c6852293cc844d69b6b4831e62b56fcadf507f47
EF50151B1-1B00U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 7.64m3/h; 41dBA; ball
Power consumption: 1.28W
Enclosure material: thermoplastic
Current rating: 106mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 7.64m3/h
Noise level: 41dBA
Rotational rate/speed: 5200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1156 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.3 EUR
10+14.27 EUR
50+12.91 EUR
156+11.55 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B2-1B00U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA789610A6890A0C7&compId=Product%2026.pdf?ci_sign=920c521048c42f92d5e2bf2dcfe89fabdfa5552a
EF50151B2-1B00U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 5.94m3/h; 34dBA; ball
Power consumption: 0.64W
Enclosure material: thermoplastic
Current rating: 54mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 5.94m3/h
Noise level: 34dBA
Rotational rate/speed: 4200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 242 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+14.26 EUR
10+12.91 EUR
50+12.1 EUR
156+11.81 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EF50151B3-1B00U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960ED33B1E0C7&compId=Product%2020.pdf?ci_sign=c809c6d26b03eccb771b7d7c69b772c087a6b3ef
EF50151B3-1B00U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 4.41m3/h; 26dBA; ball
Power consumption: 0.6W
Enclosure material: thermoplastic
Current rating: 36mA
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 4.41m3/h
Noise level: 26dBA
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 730 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
6+14.26 EUR
10+13.46 EUR
50+12.91 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
EF50151BX-1B00U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDBA78960C2933660C7&compId=Product%2011.pdf?ci_sign=809b2ed67f97b20df0d8e4cef9e98e065ea96499
EF50151BX-1B00U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; blower; 12VDC; 51.6x51.7x15mm; 9.17m3/h; 45.8dBA; ball
Power consumption: 1.8W
Enclosure material: thermoplastic
Current rating: 0.15A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 51.6x51.7x15mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 9.17m3/h
Noise level: 45.8dBA
Rotational rate/speed: 6200rpm
Current and power consumption tolerance: ±15%
Lead length: 0.305m
Additional functions: autorestart
Kind of fan: blower
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Anzahl je Verpackung: 1 Stücke
auf Bestellung 10 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
5+16.43 EUR
10+15.63 EUR
50+14.41 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
EF60202B1-000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1ED6BB8883FB319CBE28&compId=EF60202B1-G99_DTE.pdf?ci_sign=e0e053190c81bd117f55a75c219d654db3aedd78
EF60202B1-000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x20mm; 39.07m3/h; 34.5dBA; ball; 26AWG
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 8...27.6V DC
Fan dimensions: 60x60x20mm
Power consumption: 1.44W
Current rating: 60mA
Fan efficiency: 39.07m3/h
Noise level: 34.5dBA
Kind of Bearing: ball
Rotational rate/speed: 4500 (±15%)rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Static pressure: 4.57mm H2O
Wire size: 26AWG
Current and power consumption tolerance: ±15%
Related items: BUB-72H
Lead length: 0.3m
Signal output: F type
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B1-1000U-A99
EF60251B1-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 39.93m3/h; 35.1dBA; ball; 5200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 0.99W
Current rating: 82mA
Fan efficiency: 39.93m3/h
Noise level: 35.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.29m
Anzahl je Verpackung: 1 Stücke
auf Bestellung 818 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
8+10.12 EUR
50+7.85 EUR
100+6.71 EUR
200+6.32 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B2-1000U-A99
EF60251B2-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; 32.76m3/h; 27dBA; ball; 4500rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Fan dimensions: 60x60x25mm
Power consumption: 0.84W
Current rating: 58mA
Fan efficiency: 32.76m3/h
Noise level: 27dBA
Kind of Bearing: ball
Rotational rate/speed: 4500rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.29m
Anzahl je Verpackung: 1 Stücke
auf Bestellung 904 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
8+10.12 EUR
50+7.85 EUR
100+6.71 EUR
200+6.32 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
EF60251B3-1000U-A99
EF60251B3-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 60x60x25mm; ball
Type of fan: DC
Kind of fan: axial
Fan dimensions: 60x60x25mm
Kind of Bearing: ball
Min. insulation resistance: 10MΩ
Leads: leads x2
Operating temperature: -10...70°C
Fan motor: brushless DC
Additional functions: autorestart
Enclosure material: thermoplastic
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Anzahl je Verpackung: 1 Stücke
auf Bestellung 983 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.84 EUR
10+8.01 EUR
50+7.16 EUR
200+6.54 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF60252B1-1000U-A99
EF60252B1-1000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x25mm; 39.93m3/h; 35.1dBA; ball; 5200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 10...27.6V DC
Fan dimensions: 60x60x25mm
Power consumption: 1.08W
Current rating: 45mA
Fan efficiency: 39.93m3/h
Noise level: 35.1dBA
Kind of Bearing: ball
Rotational rate/speed: 5200rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.29m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1008 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.84 EUR
10+8.01 EUR
50+7.16 EUR
200+6.54 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF60252S1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3CA0C4&compId=EF60252S1-A99.pdf?ci_sign=7d5ae0d1fab98b134c86f3b17f37b740072a9bee
EF60252S1-1000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 60x60x25mm; 39.93m3/h; 27dBA; slide; 4500rpm
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 39.93m3/h
Noise level: 27dBA
Rotational rate/speed: 4500rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.25W
Wire size: 26AWG
Related items: SRF4-30
Lead length: 0.29m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 50mA
Supply voltage: 24V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 60x60x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
2+35.75 EUR
10+7.15 EUR
40+3.13 EUR
160+2.6 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3DE0C4&compId=EF80251B1-A99-A.pdf?ci_sign=78c8977168b93967acd27f7402c62fe213548d39
EF80251B1-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.5m3/h; 33dBA; ball; 3200rpm
Current rating: 65mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 69.5m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Power consumption: 1.56W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 8...27.6V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B1-1000U-G99 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211
EF80251B1-1000U-G99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 70m3/h; 33dBA; ball; Out: F type
Current rating: 0.125A
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: ball
Fan efficiency: 70m3/h
Noise level: 33dBA
Rotational rate/speed: 3200rpm
Power consumption: 1.5W
Lead length: 0.315m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x3
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B2-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F3F20C4&compId=EF80251B2-A99-A.pdf?ci_sign=67ff2d4345fec6c678d45216cf524b487a2eccf1
EF80251B2-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Current rating: 90mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.08W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2014 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
11+6.52 EUR
14+5.31 EUR
50+4.35 EUR
200+4.08 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF80251B3-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1634F4060C4&compId=EF80251B3-A99-A.pdf?ci_sign=949583447a887ab7cec6feb076c385d1c6373b46
EF80251B3-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 56.05m3/h; 28dBA; ball; 2600rpm
Current rating: 65mA
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: ball
Fan efficiency: 56.05m3/h
Noise level: 28dBA
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 0.78W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 537 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
11+6.65 EUR
14+5.16 EUR
50+4.35 EUR
200+4.2 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
EF80251BX-1000U-A99
EF80251BX-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 76.43m3/h; 36.1dBA; ball; 3600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 12V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.47...1.7W
Current rating: 0.122A
Fan efficiency: 76.43m3/h
Noise level: 36.1dBA
Kind of Bearing: ball
Rotational rate/speed: 3600rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 4.5...13.8V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 641 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.55 EUR
10+7.61 EUR
50+7.38 EUR
200+6.99 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB752F1ED7ACFEA7A7B44C2A13&compId=EF80251S1-1000U-A99%20D08062910G-00.pdf?ci_sign=c34cbb73ff09730178097adab6515b3371313dd7
EF80251S1-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.29m3/h; 33dBA; slide; 24AWG
Operating temperature: -10...70°C
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.29m3/h
Static pressure: 4.57mm H2O
Noise level: 33dBA
Rotational rate/speed: 3200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.66W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Enclosure material: thermoplastic
Current rating: 0.12A
Supply voltage: 12V DC
Leads: leads x2
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
3+23.84 EUR
25+2.86 EUR
50+2.33 EUR
250+2.14 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S1-1000U-G99 pVersion=0046&contRep=ZT&docId=005056AB752F1ED7ACFEB6E583D06A13&compId=EF80251S1-1000U-G99%20%20D08062930G-00.pdf?ci_sign=242b69eef9bdf660fcc88633100f2dd20f844f56
EF80251S1-1000U-G99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 69.29m3/h; 33dBA; slide; 24AWG
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Current rating: 0.12A
Supply voltage: 12V DC
Leads: leads x3
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Insulation class: A
Kind of Bearing: slide
Fan efficiency: 69.29m3/h
Static pressure: 4.57mm H2O
Noise level: 33dBA
Rotational rate/speed: 3200 (±10%)rpm
Current and power consumption tolerance: ±15%
Power consumption: 1.66W
Wire size: 24AWG
Lead length: 0.315m
Additional functions: autorestart
Signal output: F type
Kind of fan: axial
Min. insulation resistance: 10MΩ
Anzahl je Verpackung: 1 Stücke
auf Bestellung 2810 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
19+3.93 EUR
22+3.4 EUR
50+2.72 EUR
250+2.59 EUR
Mindestbestellmenge: 19
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S2-1000U-A99 (D08070900G-00)-1.pdf
Hersteller: SUNON
EF80251S2-A99-A DC12V Fans
auf Bestellung 383 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
15+4.86 EUR
50+4 EUR
Mindestbestellmenge: 15
Im Einkaufswagen  Stück im Wert von  UAH
EF80251S3-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1B4AFF400C4&compId=EF80251S3-A99-A.pdf?ci_sign=49f16fe3ace70dfa2a9ba522eb7e14f610aa331d
EF80251S3-1000U-A99
Hersteller: SUNON
Category: DC12V Fans
Description: Fan: DC; axial; 12VDC; 80x80x25mm; 56.06m3/h; 28dBA; slide; 2600rpm
Leads: leads x2
Insulation class: A
Current rating: 70mA
Supply voltage: 12V DC
Operating voltage: 4.5...13.8V DC
Type of fan: DC
Fan dimensions: 80x80x25mm
Fan motor: brushless DC
Impeller material: thermoplastic
Flammability rating: UL94V-0
Kind of Bearing: slide
Fan efficiency: 56.06m3/h
Noise level: 28dBA
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Power consumption: 0.84W
Lead length: 0.315m
Additional functions: autorestart
Kind of fan: axial
Min. insulation resistance: 10MΩ
Operating temperature: -10...70°C
Enclosure material: thermoplastic
Anzahl je Verpackung: 1 Stücke
auf Bestellung 102 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
12+6.11 EUR
14+5.31 EUR
50+4.76 EUR
200+3.95 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B1-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1B4AFF540C4&compId=EF80252B1-A99-A.pdf?ci_sign=9f4c764d2d851ffb0947fd0561a1bc5122056b42
EF80252B1-1000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.66m3/h; 33dBA; ball; 3200rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 65mA
Fan efficiency: 69.66m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 1410 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
12+6.38 EUR
15+5.03 EUR
50+4.22 EUR
200+3.95 EUR
Mindestbestellmenge: 12
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B1-1000U-G99 pVersion=0046&contRep=ZT&docId=005056AB281E1EDDA480685F949B20D3&compId=sunon2.pdf?ci_sign=4349dd8df21299cc839a5ff85190e2036a875211
EF80252B1-1000U-G99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 69.5m3/h; 33dBA; ball; Out: F type
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.56W
Current rating: 65mA
Fan efficiency: 69.5m3/h
Noise level: 33dBA
Kind of Bearing: ball
Rotational rate/speed: 3200rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x3
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Signal output: F type
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 82 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
9+8.82 EUR
10+8.15 EUR
50+7.48 EUR
200+6.66 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B2-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1309BFC20C4&compId=EF80252B2-A99-A.pdf?ci_sign=d8a1f8316b35ccdf93ddc286be43d7ec8d81ee10
EF80252B2-1000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.16W
Current rating: 48mA
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 778 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.46 EUR
11+6.66 EUR
50+6.25 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B2-1000U-G99 SUNON%20DC%20Brushless%20Fan%20&%20Blower(255-E).pdf
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 62.86m3/h; 30dBA; ball; 2900rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Operating voltage: 8...27.6V DC
Fan dimensions: 80x80x25mm
Power consumption: 1.16W
Current rating: 48mA
Fan efficiency: 62.86m3/h
Noise level: 30dBA
Kind of Bearing: ball
Rotational rate/speed: 2900rpm
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Insulation class: A
Leads: leads x3
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Additional functions: autorestart
Fan motor: brushless DC
Lead length: 0.315m
Signal output: F type
Current and power consumption tolerance: ±15%
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
EF80252B3-1000U-A99 pVersion=0046&contRep=ZT&docId=005056AB90B41EDA9EE0B1309BFD60C4&compId=EF80252B3-A99-A.pdf?ci_sign=bd11c7d2df23ac5597be9af79ec59ac983b8042d
EF80252B3-1000U-A99
Hersteller: SUNON
Category: DC24V Fans
Description: Fan: DC; axial; 24VDC; 80x80x25mm; 56.06m3/h; 28dBA; ball; 2600rpm
Type of fan: DC
Kind of fan: axial
Supply voltage: 24V DC
Fan dimensions: 80x80x25mm
Power consumption: 0.89W
Current rating: 36mA
Fan efficiency: 56.06m3/h
Noise level: 28dBA
Kind of Bearing: ball
Rotational rate/speed: 2600rpm
Current and power consumption tolerance: ±15%
Min. insulation resistance: 10MΩ
Impeller material: thermoplastic
Enclosure material: thermoplastic
Leads: leads x2
Lead length: 0.315m
Operating temperature: -10...70°C
Flammability rating: UL94V-0
Fan motor: brushless DC
Operating voltage: 8...27.6V DC
Additional functions: autorestart
Insulation class: A
Anzahl je Verpackung: 1 Stücke
auf Bestellung 111 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl Preis
10+7.46 EUR
11+7.06 EUR
50+6.79 EUR
Mindestbestellmenge: 10
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 9 18 27 36 45 52 53 54 55 56 57 58 59 60 61 62 63 72 81 90 92  [ Nächste Seite >> ]
