Produkte > TRACO POWER > Alle Produkte des Herstellers TRACO POWER (24138) > Seite 403 nach 403

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 9W; Uin: 36÷75VDC; Uout: 9VDC; Iout: 1000mA; SIP8
Output voltage: 9V DC
Power: 9W
Body dimensions: 21.8x11.2x9.6mm
Protection: anti-overload OPP; short circuit protection SCP
Efficiency: 88%
Operating temperature: -40...85°C
Insulation voltage: 1.6kV
Case: SIP8
Number of outputs: 1
Mounting: THT
Manufacturer series: TMR9
Input voltage: 36...75V DC
Switching frequency: 400kHz
Output current: 1A
Type of converter: DC/DC

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; Uin: 12÷36VDC; Uout: 9VDC; Iout: 1A; SMT; TSR 1SM
Output voltage: 9V DC
Body dimensions: 15.2x9.3x7.6mm
Protection: short circuit protection SCP
Efficiency: 95%
Operating temperature: -40...85°C
Number of outputs: 1
Mounting: SMT
Manufacturer series: TSR 1SM
Input voltage: 12...36V DC
Switching frequency: 500kHz
Output current: 1A
Type of converter: DC/DC

Hersteller: TRACO POWER
Category: Din Rail Mounting Power Supplies
Description: Power supply: UPS; for DIN rail; 600W; 48VDC; 12.5A; 110x54x110mm
Type of power supply: UPS
Kind of power supply: for DIN rail
Power: 600W
Output voltage: 48V DC
Output current: 12.5A
Number of outputs: 1
Body dimensions: 110x54x110mm
Manufacturer series: TSP-BCM
Operating temperature: -25...70°C
Electrical connection: terminal block
Additional functions: battery discharge signalling
Output voltage range: 48...56V DC
Mounting: for DIN rail mounting

Hersteller: TRACO POWER
Category: Built-in Power Supplies
Description: Power supply: switching; for building in; 50W; 5VDC; 10A; OUT: 1
Type of power supply: switching
Kind of power supply: for building in
Power: 50W
Output voltage: 5V DC
Output current: 10A
Number of outputs: 1
Body dimensions: 82x30x99mm
Manufacturer series: TXN
Operating temperature: -30...70°C
Electrical connection: screw terminals
Protection: anti-overload OLP; anti-overvoltage OVP; short circuit protection SCP
Efficiency: 83%
Supply voltage: 90...264V AC; 140...340V DC
Caution!: rated parameters obtained at full load
Output voltage range: 4.5...5.5V DC
Insulation voltage: 3kV
Power consumption without load: <1W

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 1W; Uin: 10.8÷13.2VDC; Uout: 15VDC; Iout: 65mA; SIP
Mounting: THT
Case: SIP
Operating temperature: -40...85°C
Input voltage: 10.8...13.2V DC
Manufacturer series: TMA
Switching frequency: 100kHz
Output current: 65mA
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 19.5x10.2x6.1mm
Efficiency: 80%
Insulation voltage: 1kV
Power: 1W
Output voltage: 15V DC
Number of outputs: 1

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 18÷36VDC; Uout: 24VDC; Iout: 83mA; DIP16
Mounting: THT
Case: DIP16
Manufacturer series: TIM 2
Output current: 83mA
Type of converter: DC/DC
Protection: anti-overvoltage OVP; short circuit protection SCP
Body dimensions: 24.3x14.4x10.2mm
Operating temperature: -40...95°C
Efficiency: 81%
Application: medical applications
Insulation voltage: 5kV
Power: 2W
Output voltage: 24V DC
Number of outputs: 1
Input voltage: 18...36V DC
Switching frequency: 100kHz

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 9÷18VDC; Uout: 24VDC; Iout: 83mA; SMT
Mounting: SMT
Manufacturer series: TRS 2
Output current: 83mA
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 12.1x11.9x8mm
Operating temperature: -40...90°C
Efficiency: 83%
Insulation voltage: 1.6kV DC
Power: 2W
Output voltage: 24V DC
Number of outputs: 1
Input voltage: 9...18V DC
Switching frequency: 100kHz

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 9÷18VDC; Uout: 24VDC; Iout: 83mA; DIP16
Mounting: THT
Case: DIP16
Manufacturer series: TIM 2
Output current: 83mA
Type of converter: DC/DC
Protection: anti-overvoltage OVP; short circuit protection SCP
Body dimensions: 24.3x14.4x10.2mm
Operating temperature: -40...95°C
Efficiency: 81%
Application: medical applications
Insulation voltage: 5kV
Power: 2W
Output voltage: 24V DC
Number of outputs: 1
Input voltage: 9...18V DC
Switching frequency: 100kHz

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 2W; Uin: 18÷36VDC; Uout: 5VDC; Iout: 400mA; SIP8
Type of converter: DC/DC
Power: 2W
Input voltage: 18...36V DC
Output voltage: 5V DC
Output current: 0.4A
Case: SIP8
Mounting: THT
Manufacturer series: TMR2
Body dimensions: 21.8x11.1x9.2mm
Efficiency: 74%
Operating temperature: -40...85°C
Switching frequency: 650kHz
Protection: short circuit protection SCP
Insulation voltage: 1kV
Number of outputs: 1

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 5W; Uin: 18÷36VDC; Uout: 12VDC; Uout2: -12VDC; THT
Mounting: THT
Case: DIP24
Operating temperature: -40...85°C
Manufacturer series: TEL5
Input voltage: 18...36V DC
Output current 2: 0.25A
Switching frequency: 300kHz
Output current: 0.25A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 32x20x10.2mm
Efficiency: 86%
Insulation voltage: 1.5kV
Power: 5W
Output voltage: 12V DC
Number of outputs: 2
Output voltage 2: -12V DC

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 10W; Uin: 9÷18VDC; Uout: 5.1VDC; Iout: 1.6A; THT
Manufacturer series: THB 10
Mounting: THT
Input voltage: 9...18V DC
Switching frequency: 150kHz
Output current: 1.6A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 50.8x25.4x12mm
Operating temperature: -40...75°C
Efficiency: 75%
Insulation voltage: 4kV
Dimensions: 2"x1"
Power: 10W
Output voltage: 5.1V DC
Number of outputs: 1

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 10W; Uin: 9÷18VDC; Uout: 12VDC; Iout: 835mA; THT
Manufacturer series: THB 10
Mounting: THT
Input voltage: 9...18V DC
Switching frequency: 150kHz
Output current: 0.835A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 50.8x25.4x12mm
Operating temperature: -40...75°C
Efficiency: 80%
Insulation voltage: 4kV
Dimensions: 2"x1"
Power: 10W
Output voltage: 12V DC
Number of outputs: 1

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 10W; Uin: 9÷18VDC; Uout: 12VDC; Uout2: -12VDC; THT
Manufacturer series: THB 10
Mounting: THT
Input voltage: 9...18V DC
Output current 2: 417mA
Switching frequency: 150kHz
Output current: 0.417A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 50.8x25.4x12mm
Operating temperature: -40...75°C
Efficiency: 80%
Insulation voltage: 4kV
Dimensions: 2"x1"
Power: 10W
Output voltage: 12V DC
Number of outputs: 2
Output voltage 2: -12V DC

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 10W; Uin: 9÷18VDC; Uout: 15VDC; Uout2: -15VDC; THT
Manufacturer series: THB 10
Mounting: THT
Input voltage: 9...18V DC
Output current 2: 333mA
Switching frequency: 150kHz
Output current: 0.333A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 50.8x25.4x12mm
Operating temperature: -40...75°C
Efficiency: 81%
Insulation voltage: 4kV
Dimensions: 2"x1"
Power: 10W
Output voltage: 15V DC
Number of outputs: 2
Output voltage 2: -15V DC

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 20W; Uin: 18÷75VDC; Uout: 12VDC; Iout: 1670mA; THT
Type of converter: DC/DC
Power: 20W
Input voltage: 18...75V DC
Output voltage: 12V DC
Output current: 1.67A
Mounting: THT
Manufacturer series: THN 20WIR
Body dimensions: 25.4x25.4x9.9mm
Efficiency: 89%
Operating temperature: -40...65°C
Switching frequency: 330kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 3kV DC
Number of outputs: 1
Dimensions: 1"x1"

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 20W; Uin: 18÷36VDC; Uout: 3.3VDC; Iout: 4500mA; THT
Type of converter: DC/DC
Power: 20W
Input voltage: 18...36V DC
Output voltage: 3.3V DC
Output current: 4.5A
Mounting: THT
Manufacturer series: THN20
Body dimensions: 25.4x25.4x9.9mm
Efficiency: 86%
Operating temperature: -40...75°C
Switching frequency: 330kHz
Protection: anti-overload OPP; anti-overvoltage OVP; short circuit protection SCP
Insulation voltage: 1.5kV DC
Number of outputs: 1
Dimensions: 1"x1"

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 6W; Uin: 9÷36VDC; Uout: 15VDC; Iout: 400mA; DIP; THT
Type of converter: DC/DC
Power: 6W
Input voltage: 9...36V DC
Output voltage: 15V DC
Output current: 0.4A
Case: DIP
Mounting: THT
Manufacturer series: TEN 6WIN
Body dimensions: 31.8x20.3x10.2mm
Efficiency: 84%
Operating temperature: -40...85°C
Protection: over current OCP; short circuit protection SCP
Insulation voltage: 3kV DC
Number of outputs: 1
Additional functions: disturbance filter
Output current 2: 0.4A
Output ripple: 80Vpp
Application: industry
Conform to the norm: cURus

Hersteller: TRACO POWER
Category: DC/DC Converters
Description: Converter: DC/DC; 3W; Uin: 4.5÷9VDC; Uout: 12VDC; Uout2: -12VDC; THT
Mounting: THT
Case: DIP24
Operating temperature: -40...85°C
Manufacturer series: TEL3
Input voltage: 4.5...9V DC
Output current 2: 125mA
Switching frequency: 300kHz
Output current: 0.125A
Type of converter: DC/DC
Protection: short circuit protection SCP
Body dimensions: 32x20x10.2mm
Efficiency: 74%
Insulation voltage: 1.5kV
Power: 3W
Output voltage: 12V DC
Number of outputs: 2
Output voltage 2: -12V DC
