Produkte > DIOTEC SEMICONDUCTOR > Alle Produkte des Herstellers DIOTEC SEMICONDUCTOR (31546) > Seite 49 nach 526

Wählen Sie Seite:   [  << Vorherige Seite ]  1 44 45 46 47 48 49 50 51 52 53 54 104 156 208 260 312 364 416 468 520 526  [ Nächste Seite >> ]
Foto Bezeichnung Hersteller Beschreibung Verfügbarkeit
Preis
ohne MwSt
SM4004 SM4004 Diotec Semiconductor sm4001.pdf Description: DIODE GEN PURP 400V 1A MELF
Packaging: Tape & Reel (TR)
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 1.5 µs
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-213AB (MELF)
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 400 V
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
5000+0.07 EUR
10000+ 0.058 EUR
Mindestbestellmenge: 5000
SICW20C120 SICW20C120 Diotec Semiconductor sicw20c120.pdf Description: DIODE ARR SIC SCHOT 1200V TO247
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Diode Configuration: 1 Pair Common Cathode
Current - Average Rectified (Io) (per Diode): 10A
Supplier Device Package: TO-247
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 1200 V
Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 10 A
Current - Reverse Leakage @ Vr: 100 µA @ 1200 V
auf Bestellung 450 Stücke:
Lieferzeit 10-14 Tag (e)
1+22.39 EUR
10+ 19.73 EUR
100+ 17.07 EUR
ESD5Z5V0-AQ ESD5Z5V0-AQ Diotec Semiconductor esd5z2v5.pdf Description: ESD SOD523 5V UNIDIR AECQ101
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Voltage - Reverse Standoff (Typ): 5V
Supplier Device Package: SOD-523
Voltage - Breakdown (Min): 6.2V
Power - Peak Pulse: 174W
Produkt ist nicht verfügbar
ESD5Z5V0-AQ ESD5Z5V0-AQ Diotec Semiconductor esd5z2v5.pdf Description: ESD SOD523 5V UNIDIR AECQ101
Packaging: Cut Tape (CT)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Voltage - Reverse Standoff (Typ): 5V
Supplier Device Package: SOD-523
Voltage - Breakdown (Min): 6.2V
Power - Peak Pulse: 174W
auf Bestellung 3900 Stücke:
Lieferzeit 10-14 Tag (e)
29+0.62 EUR
42+ 0.43 EUR
100+ 0.21 EUR
500+ 0.17 EUR
1000+ 0.12 EUR
2000+ 0.1 EUR
Mindestbestellmenge: 29
BZT52C18 BZT52C18 Diotec Semiconductor bzt52c2v4.pdf Description: DIODE ZENER 18V 500MW SOD123F
Tolerance: ±5%
Packaging: Tape & Reel (TR)
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 18 V
Impedance (Max) (Zzt): 45 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 13 V
Produkt ist nicht verfügbar
BZT52C18 BZT52C18 Diotec Semiconductor bzt52c2v4.pdf Description: DIODE ZENER 18V 500MW SOD123F
Tolerance: ±5%
Packaging: Cut Tape (CT)
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 18 V
Impedance (Max) (Zzt): 45 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 13 V
auf Bestellung 2307 Stücke:
Lieferzeit 10-14 Tag (e)
72+0.25 EUR
98+ 0.18 EUR
179+ 0.098 EUR
500+ 0.077 EUR
1000+ 0.054 EUR
Mindestbestellmenge: 72
DI035N10PT DI035N10PT Diotec Semiconductor di035n10pt.pdf Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Produkt ist nicht verfügbar
DI035N10PT DI035N10PT Diotec Semiconductor di035n10pt.pdf Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
auf Bestellung 4900 Stücke:
Lieferzeit 10-14 Tag (e)
11+1.62 EUR
18+ 1.01 EUR
100+ 0.66 EUR
500+ 0.51 EUR
1000+ 0.46 EUR
2000+ 0.42 EUR
Mindestbestellmenge: 11
DI035N10PT-AQ DI035N10PT-AQ Diotec Semiconductor di035n10pt.pdf Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Qualification: AEC-Q101
Produkt ist nicht verfügbar
DI035N10PT-AQ DI035N10PT-AQ Diotec Semiconductor di035n10pt.pdf Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Qualification: AEC-Q101
auf Bestellung 4950 Stücke:
Lieferzeit 10-14 Tag (e)
11+1.62 EUR
18+ 1.01 EUR
100+ 0.66 EUR
500+ 0.51 EUR
1000+ 0.46 EUR
2000+ 0.42 EUR
Mindestbestellmenge: 11
BC856C BC856C Diotec Semiconductor bc856.pdf Description: TRANS PNP 65V 0.1A SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 65 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
BC856C BC856C Diotec Semiconductor bc856.pdf Description: TRANS PNP 65V 0.1A SOT23-3
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 65 V
Power - Max: 250 mW
auf Bestellung 2126 Stücke:
Lieferzeit 10-14 Tag (e)
112+0.16 EUR
164+ 0.11 EUR
304+ 0.058 EUR
500+ 0.046 EUR
1000+ 0.032 EUR
Mindestbestellmenge: 112
6.6SM8Z33A-AQ 6.6SM8Z33A-AQ Diotec Semiconductor 6.6sm8z10a.pdf Description: TVS DO218AB 33V UNIDIR AECQ101
Packaging: Tape & Reel (TR)
Package / Case: DO-218AB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 175°C (TJ)
Current - Peak Pulse (10/1000µs): 124A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-218AB
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 6600W (6.6kW)
Power Line Protection: No
Grade: Automotive
auf Bestellung 750 Stücke:
Lieferzeit 10-14 Tag (e)
750+1.97 EUR
Mindestbestellmenge: 750
6.6SM8Z33A-AQ 6.6SM8Z33A-AQ Diotec Semiconductor 6.6sm8z10a.pdf Description: TVS DO218AB 33V UNIDIR AECQ101
Packaging: Cut Tape (CT)
Package / Case: DO-218AB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 175°C (TJ)
Current - Peak Pulse (10/1000µs): 124A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-218AB
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 6600W (6.6kW)
Power Line Protection: No
Grade: Automotive
auf Bestellung 750 Stücke:
Lieferzeit 10-14 Tag (e)
5+3.69 EUR
10+ 3.51 EUR
50+ 2.83 EUR
100+ 2.4 EUR
250+ 2.34 EUR
Mindestbestellmenge: 5
MMBT2907A MMBT2907A Diotec Semiconductor mmbt2907.pdf Description: BJT SOT-23 60V 600MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max): 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 10V
Frequency - Transition: 200MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 60 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
MMBTA06 MMBTA06 Diotec Semiconductor mmbta06.pdf Description: BJT SOT-23 80V 500MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 250 mW
auf Bestellung 6000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.064 EUR
6000+ 0.059 EUR
Mindestbestellmenge: 3000
LS4148 LS4148 Diotec Semiconductor ls4148.pdf Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Tape & Reel (TR)
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -55°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 7500 Stücke:
Lieferzeit 10-14 Tag (e)
2500+0.028 EUR
5000+ 0.024 EUR
7500+ 0.023 EUR
Mindestbestellmenge: 2500
LS4148 LS4148 Diotec Semiconductor ls4148.pdf Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Cut Tape (CT)
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -55°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 7500 Stücke:
Lieferzeit 10-14 Tag (e)
112+0.16 EUR
205+ 0.086 EUR
332+ 0.053 EUR
500+ 0.038 EUR
1000+ 0.033 EUR
Mindestbestellmenge: 112
P6SMBJ170A P6SMBJ170A Diotec Semiconductor p6smbj65.pdf Description: TVS SMB 170V 600W UNI
Packaging: Tape & Reel (TR)
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 2.2A
Voltage - Reverse Standoff (Typ): 170V
Supplier Device Package: DO-214AA (SMB)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 189V
Voltage - Clamping (Max) @ Ipp: 275V
Power - Peak Pulse: 600W
Power Line Protection: No
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.089 EUR
Mindestbestellmenge: 3000
BC850C BC850C Diotec Semiconductor bc846.pdf Description: BJT SOT-23 45V 100MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 300MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 45 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
BAT46W BAT46W Diotec Semiconductor bat46w.pdf Description: DIODE SCHOTTKY 100V 0.15A SOD123
Packaging: Tape & Reel (TR)
Package / Case: SOD-123
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Technology: Schottky
Capacitance @ Vr, F: 20pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-123
Operating Temperature - Junction: -55°C ~ 125°C
Voltage - DC Reverse (Vr) (Max): 100 V
Voltage - Forward (Vf) (Max) @ If: 450 mV @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 9000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.047 EUR
6000+ 0.045 EUR
9000+ 0.038 EUR
Mindestbestellmenge: 3000
MMBT3906 MMBT3906 Diotec Semiconductor mmbt3906.pdf Description: BJT SOT-23 40V 200MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 400mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 50nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 10mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 200 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 250 mW
auf Bestellung 6000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.027 EUR
6000+ 0.026 EUR
Mindestbestellmenge: 3000
BZT52C15 BZT52C15 Diotec Semiconductor bzt52c2v4.pdf Description: DIODE ZENER 15V 500MW SOD123F
Packaging: Tape & Reel (TR)
Tolerance: ±5%
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 15 V
Impedance (Max) (Zzt): 40 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 11 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.044 EUR
Mindestbestellmenge: 3000
BZT52C15 BZT52C15 Diotec Semiconductor bzt52c2v4.pdf Description: DIODE ZENER 15V 500MW SOD123F
Packaging: Cut Tape (CT)
Tolerance: ±5%
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 15 V
Impedance (Max) (Zzt): 40 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 11 V
auf Bestellung 5728 Stücke:
Lieferzeit 10-14 Tag (e)
72+0.25 EUR
98+ 0.18 EUR
179+ 0.098 EUR
500+ 0.077 EUR
1000+ 0.054 EUR
Mindestbestellmenge: 72
DI150N04PQ DI150N04PQ Diotec Semiconductor di150n04pq.pdf Description: MOSFET PWRQFN 5X6 40V 0.0014OHM
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 150A (Tc)
Rds On (Max) @ Id, Vgs: 1.45mOhm @ 75A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 40 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3950 pF @ 20 V
Qualification: AEC-Q101
auf Bestellung 5000 Stücke:
Lieferzeit 10-14 Tag (e)
5000+1.24 EUR
Mindestbestellmenge: 5000
DI150N04PQ DI150N04PQ Diotec Semiconductor di150n04pq.pdf Description: MOSFET PWRQFN 5X6 40V 0.0014OHM
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 150A (Tc)
Rds On (Max) @ Id, Vgs: 1.45mOhm @ 75A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 40 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3950 pF @ 20 V
Qualification: AEC-Q101
auf Bestellung 5000 Stücke:
Lieferzeit 10-14 Tag (e)
7+2.87 EUR
10+ 2.38 EUR
100+ 1.9 EUR
500+ 1.6 EUR
1000+ 1.36 EUR
2000+ 1.29 EUR
Mindestbestellmenge: 7
ES3JSMB ES3JSMB Diotec Semiconductor es3asmb.pdf Description: DIODE GEN PURP 600V 3A DO214AA
Packaging: Bulk
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 30 ns
Technology: Standard
Current - Average Rectified (Io): 3A
Supplier Device Package: DO-214AA (SMB)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 3 A
Current - Reverse Leakage @ Vr: 5 µA @ 600 V
Produkt ist nicht verfügbar
DI79L06DAB Diotec Semiconductor di79l00dab.pdf Description: IC
Packaging: Bulk
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -20V
Number of Regulators: 1
Supplier Device Package: 8-SO
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L06UAB DI79L06UAB Diotec Semiconductor di79l00uab.pdf Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -20V
Number of Regulators: 1
Supplier Device Package: SOT-89
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L06ZAB DI79L06ZAB Diotec Semiconductor di79l00zab.pdf Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Output Type: Fixed
Mounting Type: Through Hole
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -30V
Number of Regulators: 1
Supplier Device Package: TO-92
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Voltage Dropout (Max): 1.7V @ 40mA
Protection Features: Over Temperature, Short Circuit
Produkt ist nicht verfügbar
ZMY75B ZMY75B Diotec Semiconductor zmy1-2p.pdf Description: IC
Packaging: Bulk
Tolerance: ±2%
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 175°C (TJ)
Voltage - Zener (Nom) (Vz): 75 V
Impedance (Max) (Zzt): 30 Ohms
Supplier Device Package: DO-213AB (MELF)
Power - Max: 1.3 W
Current - Reverse Leakage @ Vr: 1 µA @ 60 V
Produkt ist nicht verfügbar
ZMY75 ZMY75 Diotec Semiconductor zmy1.pdf Description: IC
Packaging: Bulk
Tolerance: ±5%
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 75 V
Impedance (Max) (Zzt): 30 Ohms
Supplier Device Package: DO-213AB (MELF)
Power - Max: 1.3 W
Current - Reverse Leakage @ Vr: 1 µA @ 34 V
Produkt ist nicht verfügbar
P4SMAJ28A P4SMAJ28A Diotec Semiconductor p4smaj65.pdf Description: TVS SMA 28V 400W UNIDIR
Packaging: Tape & Reel (TR)
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 8.8A
Voltage - Reverse Standoff (Typ): 28V
Supplier Device Package: DO-214AC (SMA)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 31.1V
Voltage - Clamping (Max) @ Ipp: 45.4V
Power - Peak Pulse: 400W
Power Line Protection: No
Produkt ist nicht verfügbar
P4SMAJ28A P4SMAJ28A Diotec Semiconductor p4smaj65.pdf Description: TVS SMA 28V 400W UNIDIR
Packaging: Cut Tape (CT)
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 8.8A
Voltage - Reverse Standoff (Typ): 28V
Supplier Device Package: DO-214AC (SMA)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 31.1V
Voltage - Clamping (Max) @ Ipp: 45.4V
Power - Peak Pulse: 400W
Power Line Protection: No
auf Bestellung 7225 Stücke:
Lieferzeit 10-14 Tag (e)
100+0.18 EUR
105+ 0.17 EUR
110+ 0.16 EUR
123+ 0.14 EUR
133+ 0.13 EUR
250+ 0.12 EUR
500+ 0.099 EUR
1000+ 0.094 EUR
Mindestbestellmenge: 100
MMBT4403-AQ MMBT4403-AQ Diotec Semiconductor mmbt4403.pdf Description: IC
Packaging: Bulk
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 2V
Frequency - Transition: 200MHz
Supplier Device Package: SOT-23-3 (TO-236)
Grade: Automotive
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 250 mW
Qualification: AEC-Q101
Produkt ist nicht verfügbar
DI79L08UAB DI79L08UAB Diotec Semiconductor di79l00uab.pdf Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -23V
Number of Regulators: 1
Supplier Device Package: SOT-89
Voltage - Output (Min/Fixed): -8V
PSRR: 46dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L08DAB Diotec Semiconductor di79l00dab.pdf Description: IC
Packaging: Bulk
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -23V
Number of Regulators: 1
Supplier Device Package: 8-SO
Voltage - Output (Min/Fixed): -8V
PSRR: 46dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
P6SMBJ33A-AQ P6SMBJ33A-AQ Diotec Semiconductor p6smbj65.pdf Description: IC
Packaging: Bulk
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Current - Peak Pulse (10/1000µs): 11.3A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-214AA (SMB)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 600W
Power Line Protection: No
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
BAV199 BAV199 Diotec Semiconductor bav99.pdf Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 45000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.034 EUR
6000+ 0.032 EUR
9000+ 0.027 EUR
30000+ 0.025 EUR
Mindestbestellmenge: 3000
BAV199-AQ BAV199-AQ Diotec Semiconductor bav99.pdf Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.054 EUR
Mindestbestellmenge: 3000
BAV199-AQ BAV199-AQ Diotec Semiconductor bav99.pdf Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
56+0.32 EUR
80+ 0.22 EUR
149+ 0.12 EUR
500+ 0.093 EUR
1000+ 0.065 EUR
Mindestbestellmenge: 56
LL4448R13 LL4448R13 Diotec Semiconductor ll4148.pdf Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Bulk
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
Produkt ist nicht verfügbar
DIW012N65 Diotec Semiconductor diw012n65.pdf Description: IC
Packaging: Bulk
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 12A (Tc)
Rds On (Max) @ Id, Vgs: 190mOhm @ 40A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-247
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 650 V
Gate Charge (Qg) (Max) @ Vgs: 45 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1479 pF @ 34 V
Produkt ist nicht verfügbar
BCX56-10 Diotec Semiconductor bcx56.pdf Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 63 @ 150mA, 2V
Frequency - Transition: 130MHz
Supplier Device Package: SOT-89
Current - Collector (Ic) (Max): 1 A
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 500 mW
Produkt ist nicht verfügbar
ES1A ES1A Diotec Semiconductor es1a.pdf Description: DIODE GEN PURP 50V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 15 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 50 V
Voltage - Forward (Vf) (Max) @ If: 920 mV @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 50 V
Produkt ist nicht verfügbar
US1A US1A Diotec Semiconductor us1a.pdf Description: DIODE GEN PURP 50V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 50 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 50 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 50 V
auf Bestellung 7498 Stücke:
Lieferzeit 10-14 Tag (e)
38+0.48 EUR
46+ 0.39 EUR
55+ 0.33 EUR
100+ 0.21 EUR
250+ 0.16 EUR
500+ 0.14 EUR
1000+ 0.092 EUR
2500+ 0.083 EUR
5000+ 0.072 EUR
Mindestbestellmenge: 38
MM5Z4V3 MM5Z4V3 Diotec Semiconductor mm5z2v4.pdf Description: ZENER SOD-523 4.3V 0.3W 5%
Packaging: Tape & Reel (TR)
Tolerance: ±5%
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 4.3 V
Impedance (Max) (Zzt): 80 Ohms
Supplier Device Package: SOD-523
Power - Max: 200 mW
Current - Reverse Leakage @ Vr: 3 µA @ 1 V
auf Bestellung 4000 Stücke:
Lieferzeit 10-14 Tag (e)
1000+0.47 EUR
2000+ 0.25 EUR
4000+ 0.14 EUR
Mindestbestellmenge: 1000
SB560-3G SB560-3G Diotec Semiconductor sb560-3g.pdf Description: DIODE SCHOTTKY 60V 5A DO201
Packaging: Bulk
Package / Case: DO-201AA, DO-27, Axial
Mounting Type: Through Hole
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Technology: Schottky
Current - Average Rectified (Io): 5A
Supplier Device Package: DO-201
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 60 V
Voltage - Forward (Vf) (Max) @ If: 670 mV @ 5 A
Current - Reverse Leakage @ Vr: 50 µA @ 60 V
auf Bestellung 1700 Stücke:
Lieferzeit 10-14 Tag (e)
22+0.83 EUR
27+ 0.67 EUR
29+ 0.61 EUR
100+ 0.46 EUR
250+ 0.41 EUR
500+ 0.34 EUR
1700+ 0.26 EUR
Mindestbestellmenge: 22
MPSA56BK MPSA56BK Diotec Semiconductor mpsa56.pdf Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Frequency - Transition: 50MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 625 mW
auf Bestellung 4825 Stücke:
Lieferzeit 10-14 Tag (e)
48+0.37 EUR
59+ 0.3 EUR
71+ 0.25 EUR
112+ 0.16 EUR
250+ 0.12 EUR
500+ 0.1 EUR
1000+ 0.071 EUR
2500+ 0.064 EUR
Mindestbestellmenge: 48
MPSA06BK MPSA06BK Diotec Semiconductor mpsa06.pdf Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 625 mW
Produkt ist nicht verfügbar
mmbt4401 mmbt4401 Diotec Semiconductor mmbt4401.pdf Description: BJT SOT-23 40V 600MA NPN 0.25W 1
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 300 mW
Produkt ist nicht verfügbar
mmbt4401 mmbt4401 Diotec Semiconductor mmbt4401.pdf Description: BJT SOT-23 40V 600MA NPN 0.25W 1
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 300 mW
auf Bestellung 1497 Stücke:
Lieferzeit 10-14 Tag (e)
84+0.21 EUR
148+ 0.12 EUR
238+ 0.074 EUR
500+ 0.054 EUR
1000+ 0.047 EUR
Mindestbestellmenge: 84
BC549CBK BC549CBK Diotec Semiconductor bc546bk.pdf Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 300MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 30 V
Power - Max: 500 mW
auf Bestellung 4815 Stücke:
Lieferzeit 10-14 Tag (e)
84+0.21 EUR
95+ 0.19 EUR
100+ 0.18 EUR
174+ 0.1 EUR
250+ 0.075 EUR
500+ 0.063 EUR
1000+ 0.043 EUR
2500+ 0.036 EUR
Mindestbestellmenge: 84
DI060N06PQ DI060N06PQ Diotec Semiconductor di060n06pq.pdf Description: IC
Packaging: Bulk
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 60A (Tc)
Rds On (Max) @ Id, Vgs: 7mOhm @ 20A, 10V
Power Dissipation (Max): 70W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 27 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1700 pF @ 30 V
Produkt ist nicht verfügbar
NUP2105L NUP2105L Diotec Semiconductor nup2105l.pdf Description: ESD SOT23 0.1UA 24V UNIDIR
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Capacitance @ Frequency: 30pF @ 1MHz
Current - Peak Pulse (10/1000µs): 8A (8/20µs)
Voltage - Reverse Standoff (Typ): 24V
Supplier Device Package: SOT-23-3 (TO-236)
Bidirectional Channels: 2
Voltage - Breakdown (Min): 26.2V
Voltage - Clamping (Max) @ Ipp: 44V
Power - Peak Pulse: 350W
Power Line Protection: No
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.09 EUR
Mindestbestellmenge: 3000
NUP2105L NUP2105L Diotec Semiconductor nup2105l.pdf Description: ESD SOT23 0.1UA 24V UNIDIR
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Capacitance @ Frequency: 30pF @ 1MHz
Current - Peak Pulse (10/1000µs): 8A (8/20µs)
Voltage - Reverse Standoff (Typ): 24V
Supplier Device Package: SOT-23-3 (TO-236)
Bidirectional Channels: 2
Voltage - Breakdown (Min): 26.2V
Voltage - Clamping (Max) @ Ipp: 44V
Power - Peak Pulse: 350W
Power Line Protection: No
auf Bestellung 4988 Stücke:
Lieferzeit 10-14 Tag (e)
91+0.19 EUR
98+ 0.18 EUR
109+ 0.16 EUR
117+ 0.15 EUR
250+ 0.13 EUR
500+ 0.11 EUR
Mindestbestellmenge: 91
MMBT5401-AQ Diotec Semiconductor mmbt5401.pdf Description: IC
Packaging: Bulk
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Supplier Device Package: SOT-23-3 (TO-236)
Transistor Type: PNP
Operating Temperature: -65°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 500mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 10mA, 1V
Frequency - Transition: 300MHz
Grade: Automotive
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 150 V
Power - Max: 250 mW
Qualification: AEC-Q101
Produkt ist nicht verfügbar
MPSA44BK MPSA44BK Diotec Semiconductor mpsa42.pdf Description: BJT TO92BK 400V 300MA NPN 0.625W
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 50 @ 10mA, 10V
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 300 mA
Voltage - Collector Emitter Breakdown (Max): 400 V
Power - Max: 625 mW
auf Bestellung 4960 Stücke:
Lieferzeit 10-14 Tag (e)
39+0.46 EUR
47+ 0.38 EUR
56+ 0.31 EUR
100+ 0.2 EUR
250+ 0.15 EUR
500+ 0.13 EUR
1000+ 0.089 EUR
2500+ 0.08 EUR
Mindestbestellmenge: 39
BC558B Diotec Semiconductor bc556.pdf Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 2mA, 5V
Frequency - Transition: 150MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 30 V
Power - Max: 500 mW
auf Bestellung 3698 Stücke:
Lieferzeit 10-14 Tag (e)
84+0.21 EUR
95+ 0.19 EUR
100+ 0.18 EUR
174+ 0.1 EUR
250+ 0.075 EUR
500+ 0.063 EUR
1000+ 0.043 EUR
Mindestbestellmenge: 84
US1G-AQ US1G-AQ Diotec Semiconductor us1a.pdf Description: DIODE GEN PURP 400V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 50 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Grade: Automotive
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 400 V
Qualification: AEC-Q101
Produkt ist nicht verfügbar
SM4004 sm4001.pdf
SM4004
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 400V 1A MELF
Packaging: Tape & Reel (TR)
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 1.5 µs
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-213AB (MELF)
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 400 V
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
5000+0.07 EUR
10000+ 0.058 EUR
Mindestbestellmenge: 5000
SICW20C120 sicw20c120.pdf
SICW20C120
Hersteller: Diotec Semiconductor
Description: DIODE ARR SIC SCHOT 1200V TO247
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Diode Configuration: 1 Pair Common Cathode
Current - Average Rectified (Io) (per Diode): 10A
Supplier Device Package: TO-247
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 1200 V
Voltage - Forward (Vf) (Max) @ If: 1.8 V @ 10 A
Current - Reverse Leakage @ Vr: 100 µA @ 1200 V
auf Bestellung 450 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1+22.39 EUR
10+ 19.73 EUR
100+ 17.07 EUR
ESD5Z5V0-AQ esd5z2v5.pdf
ESD5Z5V0-AQ
Hersteller: Diotec Semiconductor
Description: ESD SOD523 5V UNIDIR AECQ101
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Voltage - Reverse Standoff (Typ): 5V
Supplier Device Package: SOD-523
Voltage - Breakdown (Min): 6.2V
Power - Peak Pulse: 174W
Produkt ist nicht verfügbar
ESD5Z5V0-AQ esd5z2v5.pdf
ESD5Z5V0-AQ
Hersteller: Diotec Semiconductor
Description: ESD SOD523 5V UNIDIR AECQ101
Packaging: Cut Tape (CT)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Voltage - Reverse Standoff (Typ): 5V
Supplier Device Package: SOD-523
Voltage - Breakdown (Min): 6.2V
Power - Peak Pulse: 174W
auf Bestellung 3900 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
29+0.62 EUR
42+ 0.43 EUR
100+ 0.21 EUR
500+ 0.17 EUR
1000+ 0.12 EUR
2000+ 0.1 EUR
Mindestbestellmenge: 29
BZT52C18 bzt52c2v4.pdf
BZT52C18
Hersteller: Diotec Semiconductor
Description: DIODE ZENER 18V 500MW SOD123F
Tolerance: ±5%
Packaging: Tape & Reel (TR)
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 18 V
Impedance (Max) (Zzt): 45 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 13 V
Produkt ist nicht verfügbar
BZT52C18 bzt52c2v4.pdf
BZT52C18
Hersteller: Diotec Semiconductor
Description: DIODE ZENER 18V 500MW SOD123F
Tolerance: ±5%
Packaging: Cut Tape (CT)
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 18 V
Impedance (Max) (Zzt): 45 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 13 V
auf Bestellung 2307 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
72+0.25 EUR
98+ 0.18 EUR
179+ 0.098 EUR
500+ 0.077 EUR
1000+ 0.054 EUR
Mindestbestellmenge: 72
DI035N10PT di035n10pt.pdf
DI035N10PT
Hersteller: Diotec Semiconductor
Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Produkt ist nicht verfügbar
DI035N10PT di035n10pt.pdf
DI035N10PT
Hersteller: Diotec Semiconductor
Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
auf Bestellung 4900 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
11+1.62 EUR
18+ 1.01 EUR
100+ 0.66 EUR
500+ 0.51 EUR
1000+ 0.46 EUR
2000+ 0.42 EUR
Mindestbestellmenge: 11
DI035N10PT-AQ di035n10pt.pdf
DI035N10PT-AQ
Hersteller: Diotec Semiconductor
Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Qualification: AEC-Q101
Produkt ist nicht verfügbar
DI035N10PT-AQ di035n10pt.pdf
DI035N10PT-AQ
Hersteller: Diotec Semiconductor
Description: MOSFET POWERQFN 3X3 N 100V 35A 0
Packaging: Cut Tape (CT)
Package / Case: 8-PowerWDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 35A (Tc)
Rds On (Max) @ Id, Vgs: 18mOhm @ 7A, 10V
Power Dissipation (Max): 25W (Tc)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: 8-QFN (3x3)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 22 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 15 V
Qualification: AEC-Q101
auf Bestellung 4950 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
11+1.62 EUR
18+ 1.01 EUR
100+ 0.66 EUR
500+ 0.51 EUR
1000+ 0.46 EUR
2000+ 0.42 EUR
Mindestbestellmenge: 11
BC856C bc856.pdf
BC856C
Hersteller: Diotec Semiconductor
Description: TRANS PNP 65V 0.1A SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 65 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
BC856C bc856.pdf
BC856C
Hersteller: Diotec Semiconductor
Description: TRANS PNP 65V 0.1A SOT23-3
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 65 V
Power - Max: 250 mW
auf Bestellung 2126 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
112+0.16 EUR
164+ 0.11 EUR
304+ 0.058 EUR
500+ 0.046 EUR
1000+ 0.032 EUR
Mindestbestellmenge: 112
6.6SM8Z33A-AQ 6.6sm8z10a.pdf
6.6SM8Z33A-AQ
Hersteller: Diotec Semiconductor
Description: TVS DO218AB 33V UNIDIR AECQ101
Packaging: Tape & Reel (TR)
Package / Case: DO-218AB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 175°C (TJ)
Current - Peak Pulse (10/1000µs): 124A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-218AB
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 6600W (6.6kW)
Power Line Protection: No
Grade: Automotive
auf Bestellung 750 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
750+1.97 EUR
Mindestbestellmenge: 750
6.6SM8Z33A-AQ 6.6sm8z10a.pdf
6.6SM8Z33A-AQ
Hersteller: Diotec Semiconductor
Description: TVS DO218AB 33V UNIDIR AECQ101
Packaging: Cut Tape (CT)
Package / Case: DO-218AB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 175°C (TJ)
Current - Peak Pulse (10/1000µs): 124A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-218AB
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 6600W (6.6kW)
Power Line Protection: No
Grade: Automotive
auf Bestellung 750 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
5+3.69 EUR
10+ 3.51 EUR
50+ 2.83 EUR
100+ 2.4 EUR
250+ 2.34 EUR
Mindestbestellmenge: 5
MMBT2907A mmbt2907.pdf
MMBT2907A
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 60V 600MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 1.6V @ 50mA, 500mA
Current - Collector Cutoff (Max): 10nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 10V
Frequency - Transition: 200MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 60 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
MMBTA06 mmbta06.pdf
MMBTA06
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 80V 500MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Frequency - Transition: 100MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 250 mW
auf Bestellung 6000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.064 EUR
6000+ 0.059 EUR
Mindestbestellmenge: 3000
LS4148 ls4148.pdf
LS4148
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Tape & Reel (TR)
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -55°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 7500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
2500+0.028 EUR
5000+ 0.024 EUR
7500+ 0.023 EUR
Mindestbestellmenge: 2500
LS4148 ls4148.pdf
LS4148
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Cut Tape (CT)
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -55°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 7500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
112+0.16 EUR
205+ 0.086 EUR
332+ 0.053 EUR
500+ 0.038 EUR
1000+ 0.033 EUR
Mindestbestellmenge: 112
P6SMBJ170A p6smbj65.pdf
P6SMBJ170A
Hersteller: Diotec Semiconductor
Description: TVS SMB 170V 600W UNI
Packaging: Tape & Reel (TR)
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 2.2A
Voltage - Reverse Standoff (Typ): 170V
Supplier Device Package: DO-214AA (SMB)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 189V
Voltage - Clamping (Max) @ Ipp: 275V
Power - Peak Pulse: 600W
Power Line Protection: No
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.089 EUR
Mindestbestellmenge: 3000
BC850C bc846.pdf
BC850C
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 45V 100MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 300MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 45 V
Power - Max: 250 mW
Produkt ist nicht verfügbar
BAT46W bat46w.pdf
BAT46W
Hersteller: Diotec Semiconductor
Description: DIODE SCHOTTKY 100V 0.15A SOD123
Packaging: Tape & Reel (TR)
Package / Case: SOD-123
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Technology: Schottky
Capacitance @ Vr, F: 20pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-123
Operating Temperature - Junction: -55°C ~ 125°C
Voltage - DC Reverse (Vr) (Max): 100 V
Voltage - Forward (Vf) (Max) @ If: 450 mV @ 10 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
auf Bestellung 9000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.047 EUR
6000+ 0.045 EUR
9000+ 0.038 EUR
Mindestbestellmenge: 3000
MMBT3906 mmbt3906.pdf
MMBT3906
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 40V 200MA
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 400mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 50nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 10mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 200 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 250 mW
auf Bestellung 6000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.027 EUR
6000+ 0.026 EUR
Mindestbestellmenge: 3000
BZT52C15 bzt52c2v4.pdf
BZT52C15
Hersteller: Diotec Semiconductor
Description: DIODE ZENER 15V 500MW SOD123F
Packaging: Tape & Reel (TR)
Tolerance: ±5%
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 15 V
Impedance (Max) (Zzt): 40 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 11 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.044 EUR
Mindestbestellmenge: 3000
BZT52C15 bzt52c2v4.pdf
BZT52C15
Hersteller: Diotec Semiconductor
Description: DIODE ZENER 15V 500MW SOD123F
Packaging: Cut Tape (CT)
Tolerance: ±5%
Package / Case: SOD-123F
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 15 V
Impedance (Max) (Zzt): 40 Ohms
Supplier Device Package: SOD-123F
Power - Max: 500 mW
Current - Reverse Leakage @ Vr: 100 nA @ 11 V
auf Bestellung 5728 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
72+0.25 EUR
98+ 0.18 EUR
179+ 0.098 EUR
500+ 0.077 EUR
1000+ 0.054 EUR
Mindestbestellmenge: 72
DI150N04PQ di150n04pq.pdf
DI150N04PQ
Hersteller: Diotec Semiconductor
Description: MOSFET PWRQFN 5X6 40V 0.0014OHM
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 150A (Tc)
Rds On (Max) @ Id, Vgs: 1.45mOhm @ 75A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 40 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3950 pF @ 20 V
Qualification: AEC-Q101
auf Bestellung 5000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
5000+1.24 EUR
Mindestbestellmenge: 5000
DI150N04PQ di150n04pq.pdf
DI150N04PQ
Hersteller: Diotec Semiconductor
Description: MOSFET PWRQFN 5X6 40V 0.0014OHM
Packaging: Cut Tape (CT)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 150A (Tc)
Rds On (Max) @ Id, Vgs: 1.45mOhm @ 75A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Grade: Automotive
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 40 V
Gate Charge (Qg) (Max) @ Vgs: 61 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 3950 pF @ 20 V
Qualification: AEC-Q101
auf Bestellung 5000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
7+2.87 EUR
10+ 2.38 EUR
100+ 1.9 EUR
500+ 1.6 EUR
1000+ 1.36 EUR
2000+ 1.29 EUR
Mindestbestellmenge: 7
ES3JSMB es3asmb.pdf
ES3JSMB
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 600V 3A DO214AA
Packaging: Bulk
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 30 ns
Technology: Standard
Current - Average Rectified (Io): 3A
Supplier Device Package: DO-214AA (SMB)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 3 A
Current - Reverse Leakage @ Vr: 5 µA @ 600 V
Produkt ist nicht verfügbar
DI79L06DAB di79l00dab.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -20V
Number of Regulators: 1
Supplier Device Package: 8-SO
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L06UAB di79l00uab.pdf
DI79L06UAB
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -20V
Number of Regulators: 1
Supplier Device Package: SOT-89
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L06ZAB di79l00zab.pdf
DI79L06ZAB
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Output Type: Fixed
Mounting Type: Through Hole
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -30V
Number of Regulators: 1
Supplier Device Package: TO-92
Voltage - Output (Min/Fixed): -6V
PSRR: 48dB (120Hz)
Voltage Dropout (Max): 1.7V @ 40mA
Protection Features: Over Temperature, Short Circuit
Produkt ist nicht verfügbar
ZMY75B zmy1-2p.pdf
ZMY75B
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Tolerance: ±2%
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 175°C (TJ)
Voltage - Zener (Nom) (Vz): 75 V
Impedance (Max) (Zzt): 30 Ohms
Supplier Device Package: DO-213AB (MELF)
Power - Max: 1.3 W
Current - Reverse Leakage @ Vr: 1 µA @ 60 V
Produkt ist nicht verfügbar
ZMY75 zmy1.pdf
ZMY75
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Tolerance: ±5%
Package / Case: DO-213AB, MELF
Mounting Type: Surface Mount
Operating Temperature: -50°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 75 V
Impedance (Max) (Zzt): 30 Ohms
Supplier Device Package: DO-213AB (MELF)
Power - Max: 1.3 W
Current - Reverse Leakage @ Vr: 1 µA @ 34 V
Produkt ist nicht verfügbar
P4SMAJ28A p4smaj65.pdf
P4SMAJ28A
Hersteller: Diotec Semiconductor
Description: TVS SMA 28V 400W UNIDIR
Packaging: Tape & Reel (TR)
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 8.8A
Voltage - Reverse Standoff (Typ): 28V
Supplier Device Package: DO-214AC (SMA)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 31.1V
Voltage - Clamping (Max) @ Ipp: 45.4V
Power - Peak Pulse: 400W
Power Line Protection: No
Produkt ist nicht verfügbar
P4SMAJ28A p4smaj65.pdf
P4SMAJ28A
Hersteller: Diotec Semiconductor
Description: TVS SMA 28V 400W UNIDIR
Packaging: Cut Tape (CT)
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Applications: General Purpose
Current - Peak Pulse (10/1000µs): 8.8A
Voltage - Reverse Standoff (Typ): 28V
Supplier Device Package: DO-214AC (SMA)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 31.1V
Voltage - Clamping (Max) @ Ipp: 45.4V
Power - Peak Pulse: 400W
Power Line Protection: No
auf Bestellung 7225 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
100+0.18 EUR
105+ 0.17 EUR
110+ 0.16 EUR
123+ 0.14 EUR
133+ 0.13 EUR
250+ 0.12 EUR
500+ 0.099 EUR
1000+ 0.094 EUR
Mindestbestellmenge: 100
MMBT4403-AQ mmbt4403.pdf
MMBT4403-AQ
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 2V
Frequency - Transition: 200MHz
Supplier Device Package: SOT-23-3 (TO-236)
Grade: Automotive
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 250 mW
Qualification: AEC-Q101
Produkt ist nicht verfügbar
DI79L08UAB di79l00uab.pdf
DI79L08UAB
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -23V
Number of Regulators: 1
Supplier Device Package: SOT-89
Voltage - Output (Min/Fixed): -8V
PSRR: 46dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
DI79L08DAB di79l00dab.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 100mA
Operating Temperature: -40°C ~ 125°C (TJ)
Output Configuration: Negative
Current - Quiescent (Iq): 6 mA
Voltage - Input (Max): -23V
Number of Regulators: 1
Supplier Device Package: 8-SO
Voltage - Output (Min/Fixed): -8V
PSRR: 46dB (120Hz)
Protection Features: Over Current, Over Temperature, Short Circuit
Produkt ist nicht verfügbar
P6SMBJ33A-AQ p6smbj65.pdf
P6SMBJ33A-AQ
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: DO-214AA, SMB
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -50°C ~ 150°C (TJ)
Current - Peak Pulse (10/1000µs): 11.3A
Voltage - Reverse Standoff (Typ): 33V
Supplier Device Package: DO-214AA (SMB)
Unidirectional Channels: 1
Voltage - Breakdown (Min): 36.7V
Voltage - Clamping (Max) @ Ipp: 53.3V
Power - Peak Pulse: 600W
Power Line Protection: No
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
BAV199 bav99.pdf
BAV199
Hersteller: Diotec Semiconductor
Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 45000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.034 EUR
6000+ 0.032 EUR
9000+ 0.027 EUR
30000+ 0.025 EUR
Mindestbestellmenge: 3000
BAV199-AQ bav99.pdf
BAV199-AQ
Hersteller: Diotec Semiconductor
Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.054 EUR
Mindestbestellmenge: 3000
BAV199-AQ bav99.pdf
BAV199-AQ
Hersteller: Diotec Semiconductor
Description: DIODE ARRAY GP 75V 215MA SOT23-3
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr): 3 µs
Technology: Standard
Diode Configuration: 1 Pair Series Connection
Current - Average Rectified (Io) (per Diode): 215mA
Supplier Device Package: SOT-23-3 (TO-236)
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 150 mA
Current - Reverse Leakage @ Vr: 5 nA @ 75 V
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
56+0.32 EUR
80+ 0.22 EUR
149+ 0.12 EUR
500+ 0.093 EUR
1000+ 0.065 EUR
Mindestbestellmenge: 56
LL4448R13 ll4148.pdf
LL4448R13
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 75V 0.15A SOD80C
Packaging: Bulk
Package / Case: DO-213AC, MINI-MELF, SOD-80
Mounting Type: Surface Mount
Speed: Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr): 4 ns
Technology: Standard
Capacitance @ Vr, F: 4pF @ 0V, 1MHz
Current - Average Rectified (Io): 150mA
Supplier Device Package: SOD-80C
Operating Temperature - Junction: -50°C ~ 175°C
Voltage - DC Reverse (Vr) (Max): 75 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 100 mA
Current - Reverse Leakage @ Vr: 5 µA @ 75 V
Produkt ist nicht verfügbar
DIW012N65 diw012n65.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 12A (Tc)
Rds On (Max) @ Id, Vgs: 190mOhm @ 40A, 10V
Power Dissipation (Max): 125W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: TO-247
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±30V
Drain to Source Voltage (Vdss): 650 V
Gate Charge (Qg) (Max) @ Vgs: 45 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1479 pF @ 34 V
Produkt ist nicht verfügbar
BCX56-10 bcx56.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-243AA
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 500mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 63 @ 150mA, 2V
Frequency - Transition: 130MHz
Supplier Device Package: SOT-89
Current - Collector (Ic) (Max): 1 A
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 500 mW
Produkt ist nicht verfügbar
ES1A es1a.pdf
ES1A
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 50V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 15 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 50 V
Voltage - Forward (Vf) (Max) @ If: 920 mV @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 50 V
Produkt ist nicht verfügbar
US1A us1a.pdf
US1A
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 50V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 50 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 50 V
Voltage - Forward (Vf) (Max) @ If: 1 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 50 V
auf Bestellung 7498 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
38+0.48 EUR
46+ 0.39 EUR
55+ 0.33 EUR
100+ 0.21 EUR
250+ 0.16 EUR
500+ 0.14 EUR
1000+ 0.092 EUR
2500+ 0.083 EUR
5000+ 0.072 EUR
Mindestbestellmenge: 38
MM5Z4V3 mm5z2v4.pdf
MM5Z4V3
Hersteller: Diotec Semiconductor
Description: ZENER SOD-523 4.3V 0.3W 5%
Packaging: Tape & Reel (TR)
Tolerance: ±5%
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C (TJ)
Voltage - Zener (Nom) (Vz): 4.3 V
Impedance (Max) (Zzt): 80 Ohms
Supplier Device Package: SOD-523
Power - Max: 200 mW
Current - Reverse Leakage @ Vr: 3 µA @ 1 V
auf Bestellung 4000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
1000+0.47 EUR
2000+ 0.25 EUR
4000+ 0.14 EUR
Mindestbestellmenge: 1000
SB560-3G sb560-3g.pdf
SB560-3G
Hersteller: Diotec Semiconductor
Description: DIODE SCHOTTKY 60V 5A DO201
Packaging: Bulk
Package / Case: DO-201AA, DO-27, Axial
Mounting Type: Through Hole
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Technology: Schottky
Current - Average Rectified (Io): 5A
Supplier Device Package: DO-201
Operating Temperature - Junction: -50°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 60 V
Voltage - Forward (Vf) (Max) @ If: 670 mV @ 5 A
Current - Reverse Leakage @ Vr: 50 µA @ 60 V
auf Bestellung 1700 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
22+0.83 EUR
27+ 0.67 EUR
29+ 0.61 EUR
100+ 0.46 EUR
250+ 0.41 EUR
500+ 0.34 EUR
1700+ 0.26 EUR
Mindestbestellmenge: 22
MPSA56BK mpsa56.pdf
MPSA56BK
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Frequency - Transition: 50MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 625 mW
auf Bestellung 4825 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
48+0.37 EUR
59+ 0.3 EUR
71+ 0.25 EUR
112+ 0.16 EUR
250+ 0.12 EUR
500+ 0.1 EUR
1000+ 0.071 EUR
2500+ 0.064 EUR
Mindestbestellmenge: 48
MPSA06BK mpsa06.pdf
MPSA06BK
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 250mV @ 10mA, 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 100mA, 1V
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 500 mA
Voltage - Collector Emitter Breakdown (Max): 80 V
Power - Max: 625 mW
Produkt ist nicht verfügbar
mmbt4401 mmbt4401.pdf
mmbt4401
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 40V 600MA NPN 0.25W 1
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 300 mW
Produkt ist nicht verfügbar
mmbt4401 mmbt4401.pdf
mmbt4401
Hersteller: Diotec Semiconductor
Description: BJT SOT-23 40V 600MA NPN 0.25W 1
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 50mA, 500mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 100 @ 150mA, 1V
Frequency - Transition: 250MHz
Supplier Device Package: SOT-23-3 (TO-236)
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 40 V
Power - Max: 300 mW
auf Bestellung 1497 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
84+0.21 EUR
148+ 0.12 EUR
238+ 0.074 EUR
500+ 0.054 EUR
1000+ 0.047 EUR
Mindestbestellmenge: 84
BC549CBK bc546bk.pdf
BC549CBK
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 600mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 420 @ 2mA, 5V
Frequency - Transition: 300MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 30 V
Power - Max: 500 mW
auf Bestellung 4815 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
84+0.21 EUR
95+ 0.19 EUR
100+ 0.18 EUR
174+ 0.1 EUR
250+ 0.075 EUR
500+ 0.063 EUR
1000+ 0.043 EUR
2500+ 0.036 EUR
Mindestbestellmenge: 84
DI060N06PQ di060n06pq.pdf
DI060N06PQ
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 60A (Tc)
Rds On (Max) @ Id, Vgs: 7mOhm @ 20A, 10V
Power Dissipation (Max): 70W (Tc)
Vgs(th) (Max) @ Id: 4V @ 250µA
Supplier Device Package: 8-QFN (5x6)
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 27 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1700 pF @ 30 V
Produkt ist nicht verfügbar
NUP2105L nup2105l.pdf
NUP2105L
Hersteller: Diotec Semiconductor
Description: ESD SOT23 0.1UA 24V UNIDIR
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Capacitance @ Frequency: 30pF @ 1MHz
Current - Peak Pulse (10/1000µs): 8A (8/20µs)
Voltage - Reverse Standoff (Typ): 24V
Supplier Device Package: SOT-23-3 (TO-236)
Bidirectional Channels: 2
Voltage - Breakdown (Min): 26.2V
Voltage - Clamping (Max) @ Ipp: 44V
Power - Peak Pulse: 350W
Power Line Protection: No
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
3000+0.09 EUR
Mindestbestellmenge: 3000
NUP2105L nup2105l.pdf
NUP2105L
Hersteller: Diotec Semiconductor
Description: ESD SOT23 0.1UA 24V UNIDIR
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 150°C (TJ)
Applications: General Purpose
Capacitance @ Frequency: 30pF @ 1MHz
Current - Peak Pulse (10/1000µs): 8A (8/20µs)
Voltage - Reverse Standoff (Typ): 24V
Supplier Device Package: SOT-23-3 (TO-236)
Bidirectional Channels: 2
Voltage - Breakdown (Min): 26.2V
Voltage - Clamping (Max) @ Ipp: 44V
Power - Peak Pulse: 350W
Power Line Protection: No
auf Bestellung 4988 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
91+0.19 EUR
98+ 0.18 EUR
109+ 0.16 EUR
117+ 0.15 EUR
250+ 0.13 EUR
500+ 0.11 EUR
Mindestbestellmenge: 91
MMBT5401-AQ mmbt5401.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Supplier Device Package: SOT-23-3 (TO-236)
Transistor Type: PNP
Operating Temperature: -65°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 500mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 50nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 60 @ 10mA, 1V
Frequency - Transition: 300MHz
Grade: Automotive
Current - Collector (Ic) (Max): 600 mA
Voltage - Collector Emitter Breakdown (Max): 150 V
Power - Max: 250 mW
Qualification: AEC-Q101
Produkt ist nicht verfügbar
MPSA44BK mpsa42.pdf
MPSA44BK
Hersteller: Diotec Semiconductor
Description: BJT TO92BK 400V 300MA NPN 0.625W
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: NPN
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 750mV @ 5mA, 50mA
Current - Collector Cutoff (Max): 100nA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 50 @ 10mA, 10V
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 300 mA
Voltage - Collector Emitter Breakdown (Max): 400 V
Power - Max: 625 mW
auf Bestellung 4960 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
39+0.46 EUR
47+ 0.38 EUR
56+ 0.31 EUR
100+ 0.2 EUR
250+ 0.15 EUR
500+ 0.13 EUR
1000+ 0.089 EUR
2500+ 0.08 EUR
Mindestbestellmenge: 39
BC558B bc556.pdf
Hersteller: Diotec Semiconductor
Description: IC
Packaging: Bulk
Package / Case: TO-226-3, TO-92-3 (TO-226AA)
Mounting Type: Through Hole
Transistor Type: PNP
Operating Temperature: -55°C ~ 150°C (TJ)
Vce Saturation (Max) @ Ib, Ic: 650mV @ 5mA, 100mA
Current - Collector Cutoff (Max): 15nA
DC Current Gain (hFE) (Min) @ Ic, Vce: 200 @ 2mA, 5V
Frequency - Transition: 150MHz
Supplier Device Package: TO-92
Current - Collector (Ic) (Max): 100 mA
Voltage - Collector Emitter Breakdown (Max): 30 V
Power - Max: 500 mW
auf Bestellung 3698 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis ohne MwSt
84+0.21 EUR
95+ 0.19 EUR
100+ 0.18 EUR
174+ 0.1 EUR
250+ 0.075 EUR
500+ 0.063 EUR
1000+ 0.043 EUR
Mindestbestellmenge: 84
US1G-AQ us1a.pdf
US1G-AQ
Hersteller: Diotec Semiconductor
Description: DIODE GEN PURP 400V 1A SMA
Packaging: Bulk
Package / Case: DO-214AC, SMA
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr): 50 ns
Technology: Standard
Current - Average Rectified (Io): 1A
Supplier Device Package: DO-214AC (SMA)
Operating Temperature - Junction: -50°C ~ 150°C
Grade: Automotive
Voltage - DC Reverse (Vr) (Max): 400 V
Voltage - Forward (Vf) (Max) @ If: 1.25 V @ 1 A
Current - Reverse Leakage @ Vr: 5 µA @ 400 V
Qualification: AEC-Q101
Produkt ist nicht verfügbar
Wählen Sie Seite:   [  << Vorherige Seite ]  1 44 45 46 47 48 49 50 51 52 53 54 104 156 208 260 312 364 416 468 520 526  [ Nächste Seite >> ]
