Produkte > Steckverbinder, Reihenklemmen > Steckverbindungen Interface (außer USB, SATA) > 09185106904-Harting
09185106904-Harting
Produktcode: 77596
zu Favoriten hinzufügen
Lieblingsprodukt
Hersteller: HARTING
Beschreibung: Typ Steckverbinder IDC, "Mannchen", Anzahl Ausgange 10, 2 Reihen, mit Extraktor
Stecker oder Steckdose: Stecker
Anzahl, Kontakte: 10
Produktrezensionen
Produktbewertung abgeben
Weitere Produktangebote 09185106904-Harting nach Preis ab 1.3 EUR bis 3.12 EUR
| Foto | Bezeichnung | Hersteller | Beschreibung | Verfügbarkeit | Preis |
||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
09185106904 | HARTING |
Category: IDC connectors Description: Connector: IDC; socket; male; PIN: 10; SEK; straight; 1A; THT; 2.54mm Type of connector: IDC Connector: socket Kind of connector: male Number of pins: 10 Spatial orientation: straight Electrical mounting: THT Contacts pitch: 2.54mm Connector pinout layout: 2x5 Engineering PN: SEK-18 SV MA STD STR29 RLG 10P PL2 Lead length: 2.9mm Current rating: 1A Mechanical durability: 250 cycles Contact material: copper alloy Body colour: grey Connector variant: with ejector Body material: PBT Manufacturer series: SEK Flammability rating: UL94V-0 Operating temperature: -55...125°C |
auf Bestellung 668 Stücke: Lieferzeit 14-21 Tag (e) |
|
||||||||||||||||
 |
09185106904 | HARTING |
Description: CONN HEADER VERT 10POS 2.54MM Features: Keying Slot, Mounting Flange Packaging: Tray Connector Type: Header Mounting Type: Through Hole Number of Positions: 10 Number of Rows: 2 Style: Board to Cable/Wire Operating Temperature: -55°C ~ 125°C Contact Type: Male Pin Fastening Type: Latch Lock/Eject Hooks, Long Number of Positions Loaded: All Termination: Solder Material Flammability Rating: UL94 V-0 Contact Material: Copper Alloy Insulation Color: Gray Pitch - Mating: 0.100" (2.54mm) Contact Finish - Mating: Gold Contact Finish - Post: Tin Part Status: Active Contact Shape: Square Contact Length - Post: 0.114" (2.90mm) Insulation Height: 0.681" (17.30mm) Shrouding: Shrouded - 4 Wall Overall Contact Length: 0.650" (16.51mm) Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled Row Spacing - Mating: 0.100" (2.54mm) Contact Length - Mating: 0.228" (5.80mm) |
auf Bestellung 886 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||||
 |
09185106904 | HARTING |
Headers & Wire Housings 10P MALE STRT IDC LONG LEVERS |
auf Bestellung 941 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||||
 |
09 18 510 6904 | HARTING |
Description: HARTING - 09 18 510 6904 - Stiftleiste, gerade, Wire-to-Board, 2.54 mm, 2 Reihe(n), 10 Kontakt(e), Durchsteckmontage tariffCode: 85366930 euEccn: NLR rohsCompliant: YES Kontaktüberzug: Vergoldete Kontakte hazardous: false rohsPhthalatesCompliant: YES Kontaktmaterial: Messing isCanonical: Y Steckverbinderkragen: Mit Kragen Anzahl der Kontakte: 10Kontakt(e) SVHC: No SVHC (25-Jun-2025) Steckverbindersysteme: Wire-to-Board Steckverbinder: PCB-Stiftleiste Produktpalette: SEK 18 Series productTraceability: No Kontaktanschluss: Durchsteckmontage usEccn: EAR99 Anzahl der Reihen: 2Reihe(n) Rastermaß: 2.54mm |
auf Bestellung 659 Stücke: Lieferzeit 14-21 Tag (e) |
Im Einkaufswagen Stück im Wert von UAH | ||||||||||||||||
| 09 18 510 6904 | Harting |
Разъём серии IDC, вилка, 10конт.... Роз'єми Корпус: DIP Од. вим: шт Anzahl je Verpackung: 100 Stücke |
verfügbar 7 Stücke: |
Mindestbestellmenge: 7 Stücke Im Einkaufswagen Stück im Wert von UAH |
| 09185106904 |
|
Hersteller: HARTING
Category: IDC connectors
Description: Connector: IDC; socket; male; PIN: 10; SEK; straight; 1A; THT; 2.54mm
Type of connector: IDC
Connector: socket
Kind of connector: male
Number of pins: 10
Spatial orientation: straight
Electrical mounting: THT
Contacts pitch: 2.54mm
Connector pinout layout: 2x5
Engineering PN: SEK-18 SV MA STD STR29 RLG 10P PL2
Lead length: 2.9mm
Current rating: 1A
Mechanical durability: 250 cycles
Contact material: copper alloy
Body colour: grey
Connector variant: with ejector
Body material: PBT
Manufacturer series: SEK
Flammability rating: UL94V-0
Operating temperature: -55...125°C
Category: IDC connectors
Description: Connector: IDC; socket; male; PIN: 10; SEK; straight; 1A; THT; 2.54mm
Type of connector: IDC
Connector: socket
Kind of connector: male
Number of pins: 10
Spatial orientation: straight
Electrical mounting: THT
Contacts pitch: 2.54mm
Connector pinout layout: 2x5
Engineering PN: SEK-18 SV MA STD STR29 RLG 10P PL2
Lead length: 2.9mm
Current rating: 1A
Mechanical durability: 250 cycles
Contact material: copper alloy
Body colour: grey
Connector variant: with ejector
Body material: PBT
Manufacturer series: SEK
Flammability rating: UL94V-0
Operating temperature: -55...125°C
auf Bestellung 668 Stücke:
Lieferzeit 14-21 Tag (e)
| Anzahl | Preis |
|---|---|
| 37+ | 1.96 EUR |
| 41+ | 1.74 EUR |
| 43+ | 1.67 EUR |
| 46+ | 1.59 EUR |
| 100+ | 1.5 EUR |
| 200+ | 1.42 EUR |
| 300+ | 1.36 EUR |
| 500+ | 1.3 EUR |
| 09185106904 |
|
Hersteller: HARTING
Description: CONN HEADER VERT 10POS 2.54MM
Features: Keying Slot, Mounting Flange
Packaging: Tray
Connector Type: Header
Mounting Type: Through Hole
Number of Positions: 10
Number of Rows: 2
Style: Board to Cable/Wire
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock/Eject Hooks, Long
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Copper Alloy
Insulation Color: Gray
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.114" (2.90mm)
Insulation Height: 0.681" (17.30mm)
Shrouding: Shrouded - 4 Wall
Overall Contact Length: 0.650" (16.51mm)
Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
Row Spacing - Mating: 0.100" (2.54mm)
Contact Length - Mating: 0.228" (5.80mm)
Description: CONN HEADER VERT 10POS 2.54MM
Features: Keying Slot, Mounting Flange
Packaging: Tray
Connector Type: Header
Mounting Type: Through Hole
Number of Positions: 10
Number of Rows: 2
Style: Board to Cable/Wire
Operating Temperature: -55°C ~ 125°C
Contact Type: Male Pin
Fastening Type: Latch Lock/Eject Hooks, Long
Number of Positions Loaded: All
Termination: Solder
Material Flammability Rating: UL94 V-0
Contact Material: Copper Alloy
Insulation Color: Gray
Pitch - Mating: 0.100" (2.54mm)
Contact Finish - Mating: Gold
Contact Finish - Post: Tin
Part Status: Active
Contact Shape: Square
Contact Length - Post: 0.114" (2.90mm)
Insulation Height: 0.681" (17.30mm)
Shrouding: Shrouded - 4 Wall
Overall Contact Length: 0.650" (16.51mm)
Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
Row Spacing - Mating: 0.100" (2.54mm)
Contact Length - Mating: 0.228" (5.80mm)
auf Bestellung 886 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 7+ | 2.92 EUR |
| 10+ | 2.47 EUR |
| 100+ | 2.1 EUR |
| 500+ | 1.88 EUR |
| 09185106904 |
|
Hersteller: HARTING
Headers & Wire Housings 10P MALE STRT IDC LONG LEVERS
Headers & Wire Housings 10P MALE STRT IDC LONG LEVERS
auf Bestellung 941 Stücke:
Lieferzeit 10-14 Tag (e)
| Anzahl | Preis |
|---|---|
| 1+ | 3.12 EUR |
| 10+ | 2.59 EUR |
| 100+ | 2.53 EUR |
| 300+ | 2.29 EUR |
| 500+ | 2.11 EUR |
| 1000+ | 1.81 EUR |
| 2500+ | 1.74 EUR |
| 09 18 510 6904 |
|
Hersteller: HARTING
Description: HARTING - 09 18 510 6904 - Stiftleiste, gerade, Wire-to-Board, 2.54 mm, 2 Reihe(n), 10 Kontakt(e), Durchsteckmontage
tariffCode: 85366930
euEccn: NLR
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Messing
isCanonical: Y
Steckverbinderkragen: Mit Kragen
Anzahl der Kontakte: 10Kontakt(e)
SVHC: No SVHC (25-Jun-2025)
Steckverbindersysteme: Wire-to-Board
Steckverbinder: PCB-Stiftleiste
Produktpalette: SEK 18 Series
productTraceability: No
Kontaktanschluss: Durchsteckmontage
usEccn: EAR99
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 2.54mm
Description: HARTING - 09 18 510 6904 - Stiftleiste, gerade, Wire-to-Board, 2.54 mm, 2 Reihe(n), 10 Kontakt(e), Durchsteckmontage
tariffCode: 85366930
euEccn: NLR
rohsCompliant: YES
Kontaktüberzug: Vergoldete Kontakte
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktmaterial: Messing
isCanonical: Y
Steckverbinderkragen: Mit Kragen
Anzahl der Kontakte: 10Kontakt(e)
SVHC: No SVHC (25-Jun-2025)
Steckverbindersysteme: Wire-to-Board
Steckverbinder: PCB-Stiftleiste
Produktpalette: SEK 18 Series
productTraceability: No
Kontaktanschluss: Durchsteckmontage
usEccn: EAR99
Anzahl der Reihen: 2Reihe(n)
Rastermaß: 2.54mm
auf Bestellung 659 Stücke:
Lieferzeit 14-21 Tag (e)
| 09 18 510 6904 |
|
Hersteller: Harting
Разъём серии IDC, вилка, 10конт.... Роз'єми Корпус: DIP Од. вим: шт
Anzahl je Verpackung: 100 Stücke
Разъём серии IDC, вилка, 10конт.... Роз'єми Корпус: DIP Од. вим: шт
Anzahl je Verpackung: 100 Stücke
verfügbar 7 Stücke:
