D3V-16-3C5

Hersteller: OMRON Electronic Components
Category: Microswitches SNAP ACTION
Description: Microswitch SNAP ACTION; 16A/250VAC; without lever; SPST-NO
Type of switch: microswitch SNAP ACTION
AC contacts rating @R: 16A / 250V AC
Switches features: without lever
Contacts configuration: SPST-NO
Switching method: OFF-(ON)
Number of positions: 2
Manufacturer series: D3V
Stable positions number: 1
IP rating: IP40
Leads: quick connect terminal
Body dimensions: 27.8x10.3x15.9mm
Operating temperature: -25...105°C
Operating Force: 1.96N
Lever length: 0m
Terminal pitch: 7.7mm
Contact material: silver
Button shape: convex; rectangular

Hersteller: Omron Electronics
Basic / Snap Action Switches MINIATURE

Hersteller: Omron Electronics Inc-EMC Div
Description: SWITCH SNAP ACT SPST-NO 16A 250V
Packaging: Bulk
Current Rating (Amps): 16A (AC), 600mA (DC)
Mounting Type: Chassis Mount
Circuit: SPST-NO
Switch Function: Off-Mom
Operating Temperature: -25°C ~ 105°C
Termination Style: Quick Connect - 0.250" (6.3mm)
Actuator Type: Round (Pin Plunger)
Operating Force: 200gf
Ingress Protection: IP40
Release Force: 50gf
Pretravel: 0.047" (1.2mm)
Differential Travel: 0.016" (0.4mm)
Overtravel: 0.040" (1.0mm)
Part Status: Active
Voltage Rating - AC: 250 V
Voltage Rating - DC: 125 V
Operating Position: 0.579" (14.7mm)
Mechanical Life: 10,000,000 Cycles
Electrical Life: 100,000 Cycles

Hersteller: OMRON ELECTRONIC COMPONENTS
Description: OMRON ELECTRONIC COMPONENTS - D3V-16-3C5 - Mikroschalter, Miniatur, Stiftstößel, SPST-NO, Steckanschluss, 16 A, 250 V
tariffCode: 85365007
euEccn: NLR
rohsCompliant: YES
Schalteranschlüsse: Steckanschluss
Mikroschalter-Betätiger: Stiftstößel
hazardous: false
rohsPhthalatesCompliant: YES
Kontaktstrom, max.: 16A
isCanonical: Y
AC-Kontaktspannung, nom.: 250V
SVHC: No SVHC (15-Jan-2019)
DC-Kontaktspannung, nom.: 250V
Produktpalette: D3V Series
productTraceability: No
Betätigungskraft, max.: 1.96N
usEccn: EAR99
Kontaktkonfiguration: SPST-NO
Mikroschaltertyp: Miniatur
