PI84-024AC-M91G-TS-2012 RELPOL
Hersteller: RELPOLCategory: Electromagnetic Relays - Sets
Description: Relay: interface; DPDT; Ucoil: 24VAC; 8A; 8A/230VAC; 8A/24VDC; 100mΩ
Type of relay: interface
Contacts configuration: DPDT
Rated coil voltage: 24V AC
AC contacts rating @R: 8A / 230V AC
DC contacts rating @R: 8A / 24V DC
Switched voltage: max. 300V DC; max. 400V AC
Relay variant: Relay set
Mounting: for DIN rail mounting; on panel
Relay series: PI84
Operating temperature: -40...70°C
Body dimensions: 75.5x15.5x67mm
Operate time: 7ms
Release time: 3ms
Contact resistance: 100mΩ
Contact material: AgNi
Leads: screw terminals
Switching capacity: 2kVA
Max. operating current: 8A
OEM number: 851988
Kit contents: ejector; holder; indication module; label; RM84 relay
Anzahl je Verpackung: 1 Stücke
Produkt ist nicht verfügbar
Produktrezensionen
Produktbewertung abgeben
Technische Details PI84-024AC-M91G-TS-2012 RELPOL
Category: Electromagnetic Relays - Sets, Description: Relay: interface; DPDT; Ucoil: 24VAC; 8A; 8A/230VAC; 8A/24VDC; 100mΩ, Type of relay: interface, Contacts configuration: DPDT, Rated coil voltage: 24V AC, AC contacts rating @R: 8A / 230V AC, DC contacts rating @R: 8A / 24V DC, Switched voltage: max. 300V DC; max. 400V AC, Relay variant: Relay set, Mounting: for DIN rail mounting; on panel, Relay series: PI84, Operating temperature: -40...70°C, Body dimensions: 75.5x15.5x67mm, Operate time: 7ms, Release time: 3ms, Contact resistance: 100mΩ, Contact material: AgNi, Leads: screw terminals, Switching capacity: 2kVA, Max. operating current: 8A, OEM number: 851988, Kit contents: ejector; holder; indication module; label; RM84 relay, Anzahl je Verpackung: 1 Stücke.
