PIR2-230AC-M93G-PS-2012 RELPOL
Hersteller: RELPOL
Category: Electromagnetic Relays - Sets
Description: Relay: interface; DPDT; Ucoil: 230VAC; 12A; 12A/250VAC; 12A/24VDC
Manufacturer series: R2
Relay variant: Relay set
DC contacts rating @R: 12A / 24V DC
AC contacts rating @R: 12A / 250V AC
Body dimensions: 97x75.8x31mm
Operating temperature: -40...55°C
Contacts configuration: DPDT
Leads: spring clamps
Kit contents: ejector; holder; indication module; label; R2N relay
Switched voltage: max. 250V AC; max. 250V DC
Max. operating current: 12A
Rated coil voltage: 230V AC
Contact resistance: 100mΩ
Type of relay: interface
Mounting: for DIN rail mounting; on panel
Coil resistance: 16.1kΩ
Contact material: AgNi
| Anzahl | Privatkunde |
|---|---|
| 3+ | 32.64 EUR |
| 5+ | 29.76 EUR |
| 20+ | 26.16 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details PIR2-230AC-M93G-PS-2012 RELPOL
Category: Electromagnetic Relays - Sets, Description: Relay: interface; DPDT; Ucoil: 230VAC; 12A; 12A/250VAC; 12A/24VDC, Manufacturer series: R2, Relay variant: Relay set, DC contacts rating @R: 12A / 24V DC, AC contacts rating @R: 12A / 250V AC, Body dimensions: 97x75.8x31mm, Operating temperature: -40...55°C, Contacts configuration: DPDT, Leads: spring clamps, Kit contents: ejector; holder; indication module; label; R2N relay, Switched voltage: max. 250V AC; max. 250V DC, Max. operating current: 12A, Rated coil voltage: 230V AC, Contact resistance: 100mΩ, Type of relay: interface, Mounting: for DIN rail mounting; on panel, Coil resistance: 16.1kΩ, Contact material: AgNi.
