RM96-3011-35-1012 RELPOL
Hersteller: RELPOL
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC
Mounting: PCB
Body dimensions: 30x10x16.2mm
Number of pins: 5
Operating temperature: -40...80°C
Terminal pitch: 3.2mm
Contact material: AgSnO2
Coil resistance: 660Ω
Contacts configuration: SPDT
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Type of relay: electromagnetic
Relay variant: miniature
Relay series: RM96-1P
Rated coil voltage: 12V DC
Coil voltage min.: 8.4V DC
Coil voltage max.: 29.5V DC
Coil power consumption: 300mW
Operate time: 10ms
Release time: 5ms
Switched voltage: max. 120V DC; max. 440V AC
Contact current max.: 8A
Contact resistance: 100mΩ
OEM number: 852843
Mechanical durability: 20000000 cycles
IP rating: IP67
Height: 16.2mm
Anzahl je Verpackung: 1 Stücke
Category: Miniature Electromagnetic Relays
Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC
Mounting: PCB
Body dimensions: 30x10x16.2mm
Number of pins: 5
Operating temperature: -40...80°C
Terminal pitch: 3.2mm
Contact material: AgSnO2
Coil resistance: 660Ω
Contacts configuration: SPDT
AC contacts rating @R: 8A / 250V AC
DC contacts rating @R: 8A / 24V DC
Type of relay: electromagnetic
Relay variant: miniature
Relay series: RM96-1P
Rated coil voltage: 12V DC
Coil voltage min.: 8.4V DC
Coil voltage max.: 29.5V DC
Coil power consumption: 300mW
Operate time: 10ms
Release time: 5ms
Switched voltage: max. 120V DC; max. 440V AC
Contact current max.: 8A
Contact resistance: 100mΩ
OEM number: 852843
Mechanical durability: 20000000 cycles
IP rating: IP67
Height: 16.2mm
Anzahl je Verpackung: 1 Stücke
auf Bestellung 3621 Stücke:
Lieferzeit 7-14 Tag (e)
Anzahl | Preis ohne MwSt |
---|---|
27+ | 2.75 EUR |
44+ | 1.66 EUR |
46+ | 1.56 EUR |
Produktrezensionen
Produktbewertung abgeben
Technische Details RM96-3011-35-1012 RELPOL
Category: Miniature Electromagnetic Relays, Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC, Mounting: PCB, Body dimensions: 30x10x16.2mm, Number of pins: 5, Operating temperature: -40...80°C, Terminal pitch: 3.2mm, Contact material: AgSnO2, Coil resistance: 660Ω, Contacts configuration: SPDT, AC contacts rating @R: 8A / 250V AC, DC contacts rating @R: 8A / 24V DC, Type of relay: electromagnetic, Relay variant: miniature, Relay series: RM96-1P, Rated coil voltage: 12V DC, Coil voltage min.: 8.4V DC, Coil voltage max.: 29.5V DC, Coil power consumption: 300mW, Operate time: 10ms, Release time: 5ms, Switched voltage: max. 120V DC; max. 440V AC, Contact current max.: 8A, Contact resistance: 100mΩ, OEM number: 852843, Mechanical durability: 20000000 cycles, IP rating: IP67, Height: 16.2mm, Anzahl je Verpackung: 1 Stücke.
Weitere Produktangebote RM96-3011-35-1012 nach Preis ab 1.56 EUR bis 5.2 EUR
Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis ohne MwSt | ||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
RM96-3011-35-1012 | Hersteller : RELPOL |
Category: Miniature Electromagnetic Relays Description: Relay: electromagnetic; SPDT; Ucoil: 12VDC; 8A; 8A/250VAC; 8A/24VDC Mounting: PCB Body dimensions: 30x10x16.2mm Number of pins: 5 Operating temperature: -40...80°C Terminal pitch: 3.2mm Contact material: AgSnO2 Coil resistance: 660Ω Contacts configuration: SPDT AC contacts rating @R: 8A / 250V AC DC contacts rating @R: 8A / 24V DC Type of relay: electromagnetic Relay variant: miniature Relay series: RM96-1P Rated coil voltage: 12V DC Coil voltage min.: 8.4V DC Coil voltage max.: 29.5V DC Coil power consumption: 300mW Operate time: 10ms Release time: 5ms Switched voltage: max. 120V DC; max. 440V AC Contact current max.: 8A Contact resistance: 100mΩ OEM number: 852843 Mechanical durability: 20000000 cycles IP rating: IP67 Height: 16.2mm |
auf Bestellung 3621 Stücke: Lieferzeit 14-21 Tag (e) |
|
|||||||||
RM96-3011-35-1012 | Hersteller : RELPOL |
8A; 12V; SPDT; coil power 300mW; 30,0 x 10,0 x 16,2mm; IP67 SMT, for sockets equivalent: AZ6961P, HF118F, G6RN RM96-3011-35-1012 miniature relay P RM96p012-10w Anzahl je Verpackung: 50 Stücke |
auf Bestellung 1 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||
RM96-3011-35-1012 | Hersteller : RELPOL |
8A; 12V; SPDT; coil power 300mW; 30,0 x 10,0 x 16,2mm; IP67 SMT, for sockets equivalent: AZ6961P, HF118F, G6RN RM96-3011-35-1012 miniature relay P RM96p012-10w Anzahl je Verpackung: 50 Stücke |
auf Bestellung 11 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||
RM96-3011-35-1012 | Hersteller : RELPOL |
8A; 12V; SPDT; coil power 300mW; 30,0 x 10,0 x 16,2mm; IP67 SMT, for sockets equivalent: AZ6961P, HF118F, G6RN RM96-3011-35-1012 miniature relay P RM96p012-10w Anzahl je Verpackung: 50 Stücke |
auf Bestellung 693 Stücke: Lieferzeit 7-14 Tag (e) |
|
|||||||||
RM96-3011-35-1012 Produktcode: 131519 |
Relais |
Produkt ist nicht verfügbar
|
