Produkte > CHAUVIN ARNOUX > Alle Produkte des Herstellers CHAUVIN ARNOUX (784) > Seite 1 nach 14

Hersteller: CHAUVIN ARNOUX
CA-3P-EARTHTEST100 Accessories - Others

Hersteller: CHAUVIN ARNOUX
CA-3P-EARTHTEST50 Accessories - Others

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 120mm; I AC: 100mA÷10kA; Len: 3m
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Cable length: 3m
Type of test accessories: AC current clamp adapter
Related items: CA-8220; CA-8336; CA-PEL103
Max. diameter of measured cable: 120mm
Probe length: 450mm
AC current measuring range: 100mA...10kA

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 170mm; I AC: 100mA÷10kA; Len: 3m
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Cable length: 3m
Type of test accessories: AC current clamp adapter
Related items: CA-8220; CA-8336; CA-PEL103
Max. diameter of measured cable: 170mm
Probe length: 800mm
AC current measuring range: 100mA...10kA

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 120mm; I AC: 100mA÷10kA; Len: 3m
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Cable length: 3m
Type of test accessories: AC current clamp adapter
Related items: CA-8220; CA-8336; CA-PEL103
Max. diameter of measured cable: 120mm
Probe length: 450mm
AC current measuring range: 100mA...10kA
Anzahl je Verpackung: 1 Stücke

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 170mm; I AC: 100mA÷10kA; Len: 3m
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Cable length: 3m
Type of test accessories: AC current clamp adapter
Related items: CA-8220; CA-8336; CA-PEL103
Max. diameter of measured cable: 170mm
Probe length: 800mm
AC current measuring range: 100mA...10kA
Anzahl je Verpackung: 1 Stücke

Hersteller: CHAUVIN ARNOUX
CA-P01120550 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-P01120551 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-A110-120 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-A110-45 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-A110-80 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-A130-80 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
CA-A196A-610 Meters and AC Clamp Probes

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 112mm; Len: 1.5m; IP40
Type of test accessories: AC current clamp adapter
Max. diameter of measured cable: 112mm
AC current measuring range: 500µA...4A; 500mA...400A
Output signal: 1mV/1A; 1mV/1mA
Cable length: 1.5m
IP rating: IP40
Dimensions: 285x175x43mm
Measurement: AC current
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Kind of connector: banana 4mm plug x2
Battery/ rechargeable battery: none

Hersteller: CHAUVIN ARNOUX
Category: Meters and AC Clamp Probes
Description: AC current clamp adapter; Øcable: 112mm; Len: 1.5m; IP40
Type of test accessories: AC current clamp adapter
Max. diameter of measured cable: 112mm
AC current measuring range: 500µA...4A; 500mA...400A
Output signal: 1mV/1A; 1mV/1mA
Cable length: 1.5m
IP rating: IP40
Dimensions: 285x175x43mm
Measurement: AC current
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Kind of connector: banana 4mm plug x2
Battery/ rechargeable battery: none
Anzahl je Verpackung: 1 Stücke

Hersteller: CHAUVIN ARNOUX
Category: Gas Meters and Loggers
Description: Meter: CO2, temperature and humidity; Range: 0÷5000ppm,5÷95%
Type of meter: CO2, temperature and humidity
Power supply: battery LR6 AA 1,5V x2
Measurement: CO₂; humidity; temperature
Interface: Bluetooth; USB
Software: compatible Android; compatible Windows 7; compatible Windows 8.1; compatible Windows 10; Data Logger Transfer
Humidity measuring accuracy: ±2% RH
Measuring resolution: 0,1%; 0,1°C; 1ppm
Temperature measuring range: -10...60°C
Event memory: 1M
Temperature measurement accuracy: ±0.5°C
Kind of display used: LCD
IP rating: IP40
Body dimensions: 125x65.5x32mm
Illumination: yes
Measuring range: 0...5000ppm; 5...95%
Measurement accuracy: ± (50 ppm + 3% of the value measured)
Standard equipment: USB adapter; USB/USB Micro cable; user's manual
Measuring instrument features: alarm activated on limit values exceeding

Hersteller: CHAUVIN ARNOUX
Category: Tachometers
Description: Tachometer; LCD; 60÷100000rpm; 216x72x47mm; IP51; Interface: USB
Type of meter: tachometer
Kind of display used: LCD
Measuring range: 60...100000rpm
Body dimensions: 216x72x47mm
Power supply: battery 9V x1
Measuring instrument features: MIN/MAX function; programmable alarm thresholds
Standard equipment: FRB F adapter; hard case; reflective tape; user's manual
Measurement: rpm velocity (mechanical); rpm velocity (optical)
IP rating: IP51
Interface: USB
Battery/ rechargeable battery: battery 9V x1
Measurement memory: 4000
Software: Tachograph
Illumination: yes
Bargraph: yes; 42 segm.

Hersteller: CHAUVIN ARNOUX
Category: Temperature and Humidity Loggers
Description: Data logger; temperature; IP54; Display: LCD; ±(0.4%+0.3°C); Ch: 1
Type of meter: data logger
Measurement: temperature
IP rating: IP54
Kind of display used: LCD
Temperature measurement accuracy: ±(0.4% + 0.3°C)
Temperature measuring range: -100...400°C
Standard equipment: case; USB cable
Interface: Bluetooth; USB
Power supply: battery LR6 AA 1,5V x3
Dimensions: 150x72x32mm
Kind of temperature sensor: Pt100; Pt1000
Operating temperature: -10...60°C
Number of channels: 1
Producer guarantee (months): 24
Measuring instrument features: automatic power-off; HOLD function; long operating time up to 3 years (at 15-minute measurement interval); MIN/MAX function; programmable alarm thresholds
Battery/ rechargeable battery: battery LR6 AA 1,5V x3
Measurement memory: 100000
Software: dedicated mobile app
Supported formats: EXCEL
Illumination: yes

Hersteller: CHAUVIN ARNOUX
Category: Infrared Cameras - Others
Description: Infrared camera; LCD 2,8"; 80x80; 9Hz; -20÷250°C; Focus: automatic
Type of meter: infrared camera
Kind of display used: LCD 2,8"
Camera resolution: 80x80
Refresh rate: 9Hz
Temperature measuring range: -20...250°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 20° horizontal x 20° vertical
Body dimensions: 225x125x83mm
Power supply: rechargeable battery Ni-MH x4
Standard equipment: Bluetooth earphones; hard case; mains battery charger; microSDHC memory card; USB cable; user's manual
Thermal sensitivity (NETD): ≤0.08 @ 30°C
Emissivity value: 0,05...1
Interface: Bluetooth; USB
Battery/ rechargeable battery: rechargeable battery Ni-MH x4
Resistance to: fall from 2m height
Related items: CA-F407; CA-F607
Measuring instrument features: Bluetooth communication with clamp meters and multimeters; socket for mounting on a stand; temperature markers (min, max); thermal or real image; voice annotation
Weight with battery: 700g
Three-dimensional resolution: 4.4mrad
Focusing: automatic
Software: included
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Infrared Cameras - Others
Description: Infrared camera; LCD 2,8"; 160x120; 9Hz; -20÷250°C; IP54; 4.1mrad
Type of meter: infrared camera
Kind of display used: LCD 2,8"
Camera resolution: 160x120
Refresh rate: 9Hz
Temperature measuring range: -20...250°C
Temperature measurement accuracy: ±2%; ±2°C
Field of observation: 38° horizontal x 28° vertical
Body dimensions: 225x125x83mm
Power supply: rechargeable battery Ni-MH x4
Standard equipment: Bluetooth earphones; hard case; mains battery charger; microSDHC memory card; USB cable; user's manual
Thermal sensitivity (NETD): ≤0.08 @ 30°C
Emissivity value: 0,05...1
Interface: Bluetooth; USB
Battery/ rechargeable battery: rechargeable battery Ni-MH x4
Resistance to: fall from 2m height
Related items: CA-F407; CA-F607
Measuring instrument features: Bluetooth communication with clamp meters and multimeters; socket for mounting on a stand; temperature markers (min, max); thermal or real image; voice annotation
Weight with battery: 700g
Three-dimensional resolution: 4.1mrad
Focusing: focus free
Software: included
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Analog Multimeters
Description: Analogue multimeter; Features: blown fuse indicator; IP40
Standard equipment: test leads; test probes
Measuring instrument features: blown fuse indicator
Type of meter: analogue multimeter
Input impedance for DC voltage measurement: 20kΩ/V
Input impedance for AC voltage: 6.32kΩ/V
Continuity test: acoustic indication; <50Ω
Producer guarantee (months): 36
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
AC current measuring range: 5mA; 50mA; 0.5A; 5A
Resistance measuring range: 5...1MΩ
DC current measuring range: 50µA; 5mA; 50mA; 500mA; 5A
DC voltage measuring range: 100mV; 1V; 3V; 10V; 30V; 100V; 300V; 1kV
AC voltage measuring range: 10V; 30V; 100V; 300V; 1kV
Battery/ rechargeable battery: battery LR6 AA 1,5V x1
AC current measuring accuracy: ±2.5%
DC voltage measuring accuracy: ±1.5%
DC current measuring accuracy: ±2.5%
AC voltage measuring accuracy: ±2.5%
Resistance measuring accuracy: ±10%
Power supply: battery LR6 AA 1,5V x1
IP rating: IP40
Body dimensions: 56x105x160mm
Conform to the norm: CAT III 600V; EN 61010

Hersteller: CHAUVIN ARNOUX
Category: Analog Multimeters
Description: Analogue multimeter; VDC: 100mV,1V,3V,10V,30V,100V,300V,1kV
IP rating: IP53
Body dimensions: 56x105x160mm
Conform to the norm: CAT III 600V; EN 61010
Standard equipment: test leads; test probes
Measuring instrument features: automatic calibration; blown fuse indicator
Type of meter: analogue multimeter
Input impedance for DC voltage measurement: 20kΩ/V
Input impedance for AC voltage: 6.32kΩ/V
Continuity test: acoustic indication; <50Ω
Producer guarantee (months): 36
Measurement: AC current; AC voltage; DC current; DC voltage; resistance
AC current measuring range: 1.5mA; 15mA; 150mA; 1.5A; 15A
Resistance measuring range: 5...1MΩ
DC current measuring range: 50µA; 150µA; 1.5mA; 15mA; 150mA; 1.5A; 15A
DC voltage measuring range: 100mV; 1V; 3V; 10V; 30V; 100V; 300V; 1kV
AC voltage measuring range: 10V; 30V; 100V; 300V; 1kV
Battery/ rechargeable battery: battery 6F22 9V x1
AC current measuring accuracy: ±2.5%
DC voltage measuring accuracy: ±1.5%
DC current measuring accuracy: ±2.5%
AC voltage measuring accuracy: ±2.5%
Resistance measuring accuracy: ±10%
Power supply: battery 6F22 9V x1

Hersteller: CHAUVIN ARNOUX
Category: Analog Multimeters
Description: Analogue multimeter; VDC: 100mV,1V,3V,10V,30V,100V,300V,1kV
Standard equipment: CA-MN89 - current clamp; holster; test leads
Measuring instrument features: automatic calibration; blown fuse indicator
Type of meter: analogue multimeter
Input impedance for DC voltage measurement: 20kΩ/V
Input impedance for AC voltage: 6.32kΩ/V
Continuity test: acoustic indication; <50Ω
Producer guarantee (months): 36
Measurement: AC current (with current clamps); AC voltage; DC current; DC voltage; resistance
AC current measuring range: 3A; 10A; 30A; 100A; 240A
Resistance measuring range: 5...1MΩ
DC current measuring range: 50µA; 1mA; 10mA; 100mA; 1A; 10A
DC voltage measuring range: 100mV; 1V; 3V; 10V; 30V; 100V; 300V; 1kV
AC voltage measuring range: 10V; 30V; 100V; 300V; 1kV
AC current measuring accuracy: ±2.5%
DC voltage measuring accuracy: ±1.5%
DC current measuring accuracy: ±2.5%
AC voltage measuring accuracy: ±2.5%
Resistance measuring accuracy: ±10%
Power supply: battery 6F22 9V x1
IP rating: IP53
Body dimensions: 56x105x160mm
Conform to the norm: CAT III 600V; EN 61010

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); Bargraph: 61segm; 3x/s; True RMS
Type of meter: digital multimeter
Measurement: AC current (with current clamps); AC voltage; continuity; DC current (with current clamps); DC voltage; resistance
Kind of display used: LCD
Display parameters: (6000)
Bargraph: 61 segm.
Sampling: 3x/s
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.2% + 2 digit)
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring accuracy: ±(2% + 3 digit)
Bandwidth for AC voltage measurements: 45...60Hz; 60Hz...1kHz
True effective value measurement: True RMS
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Resistance measuring accuracy: ±(0.3%+4 digit)
Test: diodes
Continuity test: acoustic indication
IP rating: IP54
Power supply: battery 6LR61 9V x1
Standard equipment: CA-MINI-03 - current clamp; test leads
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Resistance to: fall from 1m height
Dimensions (W x H x D): 75x155x75mm
Producer guarantee (months): 12
Measuring instrument features: auto and manual ranging; automatic power-off; contactless voltage detector; HOLD function; low battery indicator; low input impedance function (LoZ)
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); Bargraph: 61segm; 3x/s; True RMS
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Kind of display used: LCD
Display parameters: (6000)
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.2% + 2 digit)
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring accuracy: ±(2% + 3 digit)
DC current measuring range: 6A; 10A; 15A < 60s
DC current measuring accuracy: ±(1.5% + 3 digit)
AC current measuring range: 6A; 10A; (15A <60s)
AC current measuring accuracy: ±(2% + 3 digit)
True effective value measurement: True RMS
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 40nF; 400nF; 4µF; 40µF; 400µF; 1mF
Capacitance measuring accuracy: ±(3.5%+ 4 digit)
Frequency measuring range: 10...3000Hz
Frequency measuring accuracy: ±0.5%
Resistance measuring accuracy: ±(0.3%+4 digit)
Continuity test: acoustic indication
Power supply: battery 6LR61 9V x1
Standard equipment: banana plug - K plug adapter; drop-like K-type probe; test leads
Conform to the norm: CAT III 600V; CAT IV 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Dimensions (W x H x D): 75x155x75mm
Measuring instrument features: auto and manual ranging; automatic power-off; contactless voltage detector; HOLD function; low battery indicator; low input impedance function (LoZ); MIN/MAX/REL function
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes
Bandwidth for AC current measurements: 40Hz...1kHz
Temperature measurement accuracy: ±(2% + 5°C)
Producer guarantee (months): 12
IP rating: IP54
Resistance to: fall from 1m height
Test: diodes
Sampling: 3x/s
Duty cycle factor: 0.1...99.9%
Temperature measuring range (with K-type thermocouple): -20...760°C
Bargraph: 61 segm.
Bandwidth for AC voltage measurements: 45...60Hz; 60Hz...1kHz

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); Bargraph: 61segm; 5x/s; True RMS
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Kind of display used: LCD
Display parameters: (6000)
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.2% + 2 digit)
AC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring accuracy: ±(1.2% + 3 digit)
DC current measuring range: 6A; 10A; 20A < 30s
DC current measuring accuracy: ±(0.8% + 2 digit)
AC current measuring range: 6A; 10A
AC current measuring accuracy: ±(1% + 3 digit)
True effective value measurement: True RMS
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF
Capacitance measuring accuracy: ±(1%+ 5 digit)
Frequency measuring range: 100mHz...600Hz; 6kHz; 60kHz
Frequency measuring accuracy: ±(0.1%+2 digit)
Resistance measuring accuracy: ±(1%+2 digit)
Continuity test: acoustic indication
Power supply: battery 6F22 9V x1
Standard equipment: drop-like K-type probe; test leads; test probes
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Dimensions (W x H x D): 90x190x45mm
Measuring instrument features: auto and manual ranging; automatic calibration; automatic power-off; HOLD function; low input impedance function (LoZ); low-pass filter; MIN/MAX function
Battery/ rechargeable battery: battery 6F22 9V x1
Illumination: yes
Temperature measuring range (with K-type thermocouple): -59.6...1200°C
Bargraph: 61 segm.
Producer guarantee (months): 36
Bandwidth for AC voltage measurements: 40...400Hz; 400Hz...3kHz
Bandwidth for AC current measurements: 40Hz...1kHz
Resistance to: fall from 1m height
IP rating: IP54
Temperature measurement accuracy: ±(0.5% + 2°C)
Test: diodes
Sampling: 5x/s

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (6000); Bargraph: 61segm; 5x/s; True RMS
Illumination: yes
IP rating: IP54
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Resistance to: fall from 1m height
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; drop-like K-type probe; MultiFIX mounting system; test leads; test probes
Measuring instrument features: auto and manual ranging; automatic calibration; automatic power-off; HOLD function; ionization current measurement; low input impedance function (LoZ); low-pass filter; MIN/MAX/DIF/AVG function; MIN/MAX function; PEAK function; selection of AC or AC+DC measurement
Type of meter: digital multimeter
Test: diodes
Continuity test: acoustic indication
Sampling: 5x/s
Temperature measuring range (with K-type thermocouple): -59.6...1200°C
True effective value measurement: True RMS
Bargraph: 61 segm.
Producer guarantee (months): 36
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Dimensions (W x H x D): 90x190x45mm
Bandwidth for AC voltage measurements: 40...400Hz; 400Hz...10kHz
AC current measuring range: 6mA; 60mA; 600mA; 6A; 10A; (20A <30s)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Bandwidth for AC current measurements: 40Hz...1kHz
DC current measuring range: 6mA; 60mA; 600mA; 6A; 10A; 20A < 30s
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
Frequency measuring range: 100mHz...600Hz; 6kHz; 60kHz
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF; 60mF
Battery/ rechargeable battery: battery 6F22 9V x1
Display parameters: (6000)
Frequency measuring accuracy: ±(0.1%+2 digit)
Capacitance measuring accuracy: ±(1%+ 5 digit)
AC current measuring accuracy: ±(1% + 3 digit)
DC voltage measuring accuracy: ±(0.09% + 2 digit)
DC current measuring accuracy: ±(0.8% + 2 digit)
AC voltage measuring accuracy: ±(1% + 3 digit)
Resistance measuring accuracy: ±(1%+2 digit)
Temperature measurement accuracy: ±(0.5% + 2°C)
Kind of display used: LCD
Power supply: battery 6F22 9V x1

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; USB; colour,LCD; (100000); 5x/s; True RMS
Illumination: yes
IP rating: IP67
Interface: USB
Kind of temperature sensor: Pt100; Pt1000; thermocouple J; thermocouple K
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; mains battery charger; test leads; test probes; USB cable
Measuring instrument features: auto and manual ranging; AUTO HOLD; automatic power-off; HOLD function; low input impedance function (LoZ); MIN/MAX/DIF/AVG function; PEAK function; selection of AC or AC+DC measurement
Type of meter: digital multimeter
Test: diodes
Continuity test: acoustic indication
Sampling: 5x/s
Temperature measuring range: -200...800°C
Temperature measuring range (with K-type thermocouple): -40...1200°C
Event memory: 10000
True effective value measurement: True RMS
Producer guarantee (months): 36
Measurement: AC current; AC voltage; capacitance; continuity; dB; dBm; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Dimensions (W x H x D): 90x169x47.1mm
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; (20A <30s)
Resistance measuring range: 1Ω; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
DC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; 20A < 30s
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Frequency measuring range: 10...100Hz; 1kHz; 10kHz; 100kHz; 1MHz; 5MHz
Capacitance measuring range: 1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4
Software: included
Display parameters: (100000)
DC voltage measuring accuracy: ±(0.03% + 8 digit)
DC current measuring accuracy: ±(0.08% + 8 digit)
Resistance measuring accuracy: ±(0.07%+8 digit)
Temperature measurement accuracy: ±0.1%
Kind of display used: colour; LCD
Power supply: rechargeable battery Ni-MH AA 1,2V x4

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; Bluetooth,USB; colour,LCD; (100000); 5x/s
Illumination: yes
IP rating: IP67
Interface: Bluetooth; USB
Kind of temperature sensor: Pt100; Pt1000; thermocouple J; thermocouple K
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; mains battery charger; test leads; test probes; USB cable
Measuring instrument features: auto and manual ranging; AUTO HOLD; automatic power-off; HOLD function; low input impedance function (LoZ); MIN/MAX/DIF/AVG function; PEAK function; selection of AC or AC+DC measurement
Type of meter: digital multimeter
Test: diodes
Continuity test: acoustic indication
Sampling: 5x/s
Temperature measuring range: -200...800°C
Temperature measuring range (with K-type thermocouple): -40...1200°C
Event memory: 30000
True effective value measurement: True RMS
Producer guarantee (months): 36
Measurement: AC current; AC voltage; capacitance; continuity; dB; dBm; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Dimensions (W x H x D): 90x169x47.1mm
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; (20A <30s)
Resistance measuring range: 1Ω; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
DC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; 20A < 30s
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Frequency measuring range: 10...100Hz; 1kHz; 10kHz; 100kHz; 1MHz; 5MHz
Capacitance measuring range: 1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4
Software: included
Display parameters: (100000)
DC voltage measuring accuracy: ±(0.03% + 8 digit)
DC current measuring accuracy: ±(0.08% + 8 digit)
Resistance measuring accuracy: ±(0.07%+8 digit)
Temperature measurement accuracy: ±0.1%
Kind of display used: colour; LCD
Power supply: rechargeable battery Ni-MH AA 1,2V x4

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; USB; colour,LCD; (100000); 5x/s; True RMS
Interface: USB
Kind of temperature sensor: Pt100; Pt1000; thermocouple J; thermocouple K
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Illumination: yes
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; mains battery charger; test leads; test probes; USB cable
Measuring instrument features: auto and manual ranging; AUTO HOLD; automatic power-off; HOLD function; low input impedance function (LoZ); MIN/MAX/DIF/AVG function; PEAK function; selection of AC or AC+DC measurement
Type of meter: digital multimeter
Test: diodes
Continuity test: acoustic indication
Sampling: 5x/s
Temperature measuring range: -200...800°C
Temperature measuring range (with K-type thermocouple): -40...1200°C
Event memory: 10000
True effective value measurement: True RMS
Producer guarantee (months): 36
Measurement: AC current; AC voltage; capacitance; continuity; dB; dBm; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Dimensions (W x H x D): 90x169x47.1mm
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; (20A <30s)
Resistance measuring range: 1Ω; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
DC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; 20A < 30s
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Frequency measuring range: 10...100Hz; 1kHz; 10kHz; 100kHz; 1MHz; 5MHz
Capacitance measuring range: 1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4
Software: included
Display parameters: (100000)
DC voltage measuring accuracy: ±(0.03% + 8 digit)
DC current measuring accuracy: ±(0.08% + 8 digit)
Resistance measuring accuracy: ±(0.07%+8 digit)
Temperature measurement accuracy: ±0.1%
Kind of display used: colour; LCD
Power supply: rechargeable battery Ni-MH AA 1,2V x4
IP rating: IP67

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; Bluetooth,USB; colour,LCD; (100000); 5x/s
Interface: Bluetooth; USB
Kind of temperature sensor: Pt100; Pt1000; thermocouple J; thermocouple K
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Illumination: yes
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Standard equipment: case; mains battery charger; test leads; test probes; USB cable
Measuring instrument features: auto and manual ranging; AUTO HOLD; automatic power-off; HOLD function; low input impedance function (LoZ); MIN/MAX/DIF/AVG function; PEAK function; selection of AC or AC+DC measurement
Type of meter: digital multimeter
Test: diodes
Continuity test: acoustic indication
Sampling: 5x/s
Temperature measuring range: -200...800°C
Temperature measuring range (with K-type thermocouple): -40...1200°C
Event memory: 30000
True effective value measurement: True RMS
Producer guarantee (months): 36
Measurement: AC current; AC voltage; capacitance; continuity; dB; dBm; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Dimensions (W x H x D): 90x169x47.1mm
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; (20A <30s)
Resistance measuring range: 1Ω; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
DC current measuring range: 1mA; 10mA; 100mA; 1A; 10A; 20A < 30s
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Frequency measuring range: 10...100Hz; 1kHz; 10kHz; 100kHz; 1MHz; 5MHz
Capacitance measuring range: 1nF; 10nF; 100nF; 1µF; 10µF; 100µF; 1mF; 10mF
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4
Software: included
Display parameters: (100000)
DC voltage measuring accuracy: ±(0.02% + 8 digit)
DC current measuring accuracy: ±(0.08% + 8 digit)
Resistance measuring accuracy: ±(0.07%+8 digit)
Temperature measurement accuracy: ±0.1%
Kind of display used: colour; LCD
Power supply: rechargeable battery Ni-MH AA 1,2V x4
IP rating: IP67

Hersteller: CHAUVIN ARNOUX
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; colour,LCD 5,7"; 320x240; USB; IP53
Type of meter: appliance meter
Interface: USB
Measurement: AC current (with current clamps); active power; AC voltage; continuity; DC voltage; earthing resistance; frequency; harmonics; impedance; insulation resistance; leakage current; phase sequence; RCD tripping current; RCD tripping time; short circuit loop impedance; votlage drop
Kind of display used: colour; LCD 5,7"
Continuity test: acoustic indication; optical indication
Weight with battery: 2.2kg
Power supply: rechargeable battery Li-Ion 10,8V x1
Standard equipment: 3 crocodile clips; carrying case; hand strap; mains battery charger; neckstrap; remote probe; screen protector preventing scratching (set); test leads; test probes; USB cable
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010; IEC 61326-1
Measuring instrument features: long operating time up to 30 hours; programmable alarm thresholds; test leads resistance compensation
Battery/ rechargeable battery: rechargeable battery Li-Ion 10,8V x1
Test voltage: 50V; 100V; 250V; 500V; 1kV
Display resolution: 320x240
Earthing resistance measuring range: 500mΩ...40Ω; 15kΩ; 40kΩ
Loop impedance measurement: 100...500mΩ; 4Ω; 40Ω; 400Ω
Software: included
Insulation resistance measuring ranges: 0.01MΩ...2GΩ
Illumination: yes
Body dimensions: 280x190x128mm
IP rating: IP53
Loop impedance measuring accuracy: ±(5% + 2 digit)
Earthing resistance measuring accuracy: ±(2% + 2 digit)
RCD test: AC, A and F-type RCDs; general purpose
Optional equipment: CA-C177A; CA-MN77

Hersteller: CHAUVIN ARNOUX
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; colour,LCD 5,7"; 320x240; USB; IP53
Type of meter: appliance meter
Interface: USB
Measurement: AC current (with current clamps); active power; AC voltage; continuity; DC voltage; earthing resistance; frequency; harmonics; impedance; insulation resistance; leakage current; phase sequence; RCD tripping current; RCD tripping time; short circuit loop impedance; votlage drop
Kind of display used: colour; LCD 5,7"
Continuity test: acoustic indication; optical indication
Weight with battery: 2.2kg
Power supply: rechargeable battery Li-Ion 10,8V x1
Standard equipment: 3 crocodile clips; carrying case; hand strap; mains battery charger; neckstrap; remote probe; screen protector preventing scratching (set); test leads; test probes; USB cable
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010; IEC 61326-1
Measuring instrument features: built-in fuse table; long operating time up to 30 hours; programmable alarm thresholds; test leads resistance compensation
Battery/ rechargeable battery: rechargeable battery Li-Ion 10,8V x1
Test voltage: 50V; 100V; 250V; 500V; 1kV
Display resolution: 320x240
Earthing resistance measuring range: 500mΩ...40Ω; 15kΩ; 40kΩ
Loop impedance measurement: 100...500mΩ; 4Ω; 40Ω; 400Ω
Software: included
Insulation resistance measuring ranges: 0.01MΩ...2GΩ
Illumination: yes
Body dimensions: 280x190x128mm
IP rating: IP53
Loop impedance measuring accuracy: ±(5% + 2 digit)
Earthing resistance measuring accuracy: ±(2% + 2 digit)
RCD test: AC, B, B+, EV, A and F-type RCDs; general purpose
Optional equipment: CA-C177A; CA-MN77

Hersteller: CHAUVIN ARNOUX
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; VAC: 0÷800V; ±(1%+2digit); IP54
IP rating: IP54
Illumination: yes
Measurement memory: 2970
Dimensions: 223x126x70mm
Standard equipment: 3 crocodile clips; carrying case; manual (CD); neckstrap; test lead; test leads ( 3pcs.); test probe x1
Measuring instrument features: Pass/Fail function
Type of meter: appliance meter
Continuity test: <10Ω
RCD test: 30mA, 100mA, 300mA, 500mA, 650mA; AC, A-type RCDs; general purpose
Bargraph: yes
Measurement: AC voltage; continuity; insulation resistance; phase sequence; RCD tripping time; resistance
Resistance measuring range: 1...10Ω; 100kΩ
Loop impedance measuring range: 100mΩ...1Ω; 400Ω
AC voltage measuring range: 0...800V
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Insulation resistance measuring ranges: 0...100MΩ; 1GΩ
AC voltage measuring accuracy: ±(1% + 2 digit)
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x6
Conform to the norm: CAT III 600V; EN 61010; EN 61010-2-034; IEC 61010-1; IEC 61010-2-030; IEC 61326-1

Hersteller: CHAUVIN ARNOUX
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; VAC: 2÷550V; 30÷1000Hz; Bluetooth
IP rating: IP54
Illumination: yes
Measurement memory: 2970
Dimensions: 223x126x70mm
Standard equipment: 3 crocodile clips; battery charger/power supply; carrying case; manual (CD); neckstrap; test lead; test leads ( 3pcs.); test probe x1; USB cable
Measuring instrument features: automatic generation of PDF file with recorded data; magnetized case; Pass/Fail function
Type of meter: appliance meter
Continuity test: <10Ω
RCD test: 30mA, 100mA, 300mA, 500mA, 650mA; AC, A-type RCDs; general purpose
Bargraph: yes
Measurement: AC current (with current clamps); AC voltage; continuity; earthing resistance; frequency; insulation resistance; phase sequence; RCD tripping time; resistance
Resistance measuring range: 1...10Ω; 100kΩ
Loop impedance measuring range: 100mΩ...1Ω; 400Ω
AC voltage measuring range: 2...550V
Frequency measuring range: 30...1000Hz
Earthing resistance measuring range: 500mΩ...100Ω; 1kΩ; 2kΩ
Battery/ rechargeable battery: rechargeable battery Ni-MH AA x6
Software: dedicated mobile app
Insulation resistance measuring ranges: 0...100MΩ; 1GΩ
Frequency measuring accuracy: ±(0.1%+1 digit)
AC voltage measuring accuracy: ±(1% + 2 digit)
Kind of display used: LCD
Power supply: rechargeable battery Ni-MH AA x6
Interface: Bluetooth
Conform to the norm: CAT III 600V; EN 61010; EN 61010-2-034; IEC 61010-1; IEC 61010-2-030; IEC 61326-1

Hersteller: CHAUVIN ARNOUX
Category: Multimeters for Electrical Installations
Description: Meter: appliance meter; LCD; VAC: 2÷550V; 30÷1000Hz; Bluetooth
IP rating: IP54
Illumination: yes
Measurement memory: 2970
Dimensions: 223x126x70mm
Standard equipment: 3 crocodile clips; battery charger/power supply; carrying case; continuity rod; kit for earth ground resistance measurement 15m; manual (CD); neckstrap; test lead; test leads ( 3pcs.); test probe x1; USB cable
Measuring instrument features: automatic generation of PDF file with recorded data; magnetized case; Pass/Fail function
Type of meter: appliance meter
Continuity test: <10Ω
RCD test: 30mA, 100mA, 300mA, 500mA, 650mA; AC, A-type RCDs; general purpose
Bargraph: yes
Measurement: AC current (with current clamps); AC voltage; continuity; earthing resistance; frequency; insulation resistance; phase sequence; RCD tripping time; resistance
Resistance measuring range: 1...10Ω; 100kΩ
Loop impedance measuring range: 100mΩ...1Ω; 400Ω
AC voltage measuring range: 2...550V
Frequency measuring range: 30...1000Hz
Earthing resistance measuring range: 500mΩ...100Ω; 1kΩ; 2kΩ
Battery/ rechargeable battery: rechargeable battery Ni-MH AA x6
Software: dedicated mobile app
Insulation resistance measuring ranges: 0...100MΩ; 1GΩ
Frequency measuring accuracy: ±(0.1%+1 digit)
AC voltage measuring accuracy: ±(1% + 2 digit)
Kind of display used: LCD
Power supply: rechargeable battery Ni-MH AA x6
Interface: Bluetooth
Conform to the norm: CAT III 600V; EN 61010; EN 61010-2-034; IEC 61010-1; IEC 61010-2-030; IEC 61326-1

Hersteller: CHAUVIN ARNOUX
Category: Electrical Safety Testers
Description: Safety analyzer; 0÷9.999MΩ; Touchpad: yes; Interface: WiFi
IP rating: IP40
Dimensions: 407x341x205mm
Standard equipment: 3 crocodile clips; carrying case; mains cable; test lead; test probe x4; USB A / USB B cable; user's manual
Type of meter: safety analyzer
RCD test: 10mA, 30mA, 100mA, 300mA, 500mA, 1000mA ; general purpose
Measurement: AC current (with current clamps); continuity; insulation resistance; leakage current; loop/line impedance; phase sequence; RCD tripping time
Test voltage: 100V; 250V; 500V; 1kV
Software: download from manufacturers website
Insulation resistance measuring ranges: 0...9.999MΩ
Touchpad: yes
Supply voltage: 100...240V AC
Interface: WiFi

Hersteller: CHAUVIN ARNOUX
Category: Miliohmmeters
Description: Milli-ohm meter; LCD; R range: 1uΩ÷2.5kΩ; Interface: RS232
Kind of display used: LCD
Power supply: rechargeable battery Ni-MH x1
Interface: RS232
Measurement memory: 150
Dimensions: 270x250x180mm
Standard equipment: Kelvin test leads; mains cable; RS232 cable; user's manual
Measuring instrument features: automatic discharge after test; calculation of R at a reference temperature – Pt100 Ω probe; programmable alarm thresholds
Type of meter: milli-ohm meter
Resistance measuring range: 1µΩ...2.5kΩ
Test current: 1mA @ 2.5kΩ; 10mA @ 250Ω; 100mA @ 25Ω; 1A @ 2500mΩ; 10A @ 5mΩ; 10A @ 25mΩ; 10A @ 250mΩ
Software: included
Resistance measuring accuracy: ±(0.05%+1µΩ)

Hersteller: CHAUVIN ARNOUX
Category: Earth Resistance Meter
Description: Meter: grounding resistance; Øcable: 32mm; OLED; IP40
Type of meter: grounding resistance
Max. diameter of measured cable: 32mm
Kind of display used: OLED
Earthing resistance measuring range: 10...100mΩ; 1Ω; 50Ω; 150Ω; 250Ω; 450Ω; 650Ω; 1.2kΩ
Earthing resistance measuring accuracy: ±(1.5% + 0.01Ω)
AC current measuring range: 10mA; 100mA; 300mA; 3A; 20A
AC current measuring accuracy: ±(2% + 200µA)
Body dimensions: 300x106x56mm
Weight with battery: 1.2kg
Power supply: battery LR6 AA 1,5V x4
Conform to the norm: CAT III 150V; CAT IV 100V; EN 61010
Standard equipment: hard case; wristbands
Measuring instrument features: AUTO HOLD; calibration function; manual HOLD function or automatic PRE-HOLD; measurements on wires and rectangular bars; programmable alarm thresholds: current, impedance
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Measurement memory: 300
Related items: CA-P01122301
IP rating: IP40

Hersteller: CHAUVIN ARNOUX
Category: Earth Resistance Meter
Description: Meter: grounding resistance; LCD; 0.05÷50kΩ; IP65; Illumin: yes
Kind of display used: LCD
Power supply: battery LR6 AA 1,5V x6
IP rating: IP65
Body dimensions: 223x126x70mm
Conform to the norm: CAT IV 600V; EN 61010; EN 61557
Illumination: yes
Standard equipment: user's manual
Type of meter: grounding resistance
Weight with battery: 1kg
Earthing resistance measuring range: 0.05...50kΩ
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Earthing resistance measuring accuracy: ±(2% + 1 digit)

Hersteller: CHAUVIN ARNOUX
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; analogue; VAC: 0÷600V
Type of meter: insulation resistance
Kind of display used: analogue
Measurement: AC voltage; insulation resistance
AC voltage measuring range: 0...600V
Test voltage: 500V
Conform to the norm: CAT III 600V; EN 61010
Standard equipment: 1 crocodile clips; test leads ( 2pcs.); test probe x1; user's manual
Power supply: battery AA 1,5V x4
Body dimensions: 167x106x55mm
Insulation resistance measuring ranges: 1GΩ
Battery/ rechargeable battery: battery AA 1,5V x4
Continuity test: -10Ω...10Ω

Hersteller: CHAUVIN ARNOUX
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; analogue; R range: 0÷1kΩ
Kind of display used: analogue
Power supply: battery AA 1,5V x4
Body dimensions: 167x106x55mm
Conform to the norm: CAT III 600V; EN 61010
Standard equipment: 1 crocodile clips; test leads ( 2pcs.); test probe x1; user's manual
Type of meter: insulation resistance
Continuity test: -10Ω...10Ω
Measurement: AC voltage; insulation resistance; resistance
Test voltage: 250V; 500V; 1kV
Resistance measuring range: 0...1kΩ
AC voltage measuring range: 0...600V
Battery/ rechargeable battery: battery AA 1,5V x4
Insulation resistance measuring ranges: 1GΩ

Hersteller: CHAUVIN ARNOUX
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; (4000); VAC: 300mV÷400V,700V
Type of meter: insulation resistance
Kind of display used: LCD
Body dimensions: 211x108x60mm
Power supply: battery LR6 AA 1,5V x6
Conform to the norm: CAT IV 600V; EN 61243-3:2010; IEC 61010-1; IEC 61010-2-030; IEC 61326-1
Standard equipment: carrying case; crocodile clip; test leads; test probe x1
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Measurement memory: 300
Weight without batteries: 850g
Continuity test: <10Ω; <100Ω
Bargraph: yes
Test voltage: 50V; 100V; 250V; 500V; 1kV
Resistance measuring range: 4kΩ; 40kΩ; 400kΩ; 1MΩ
DC voltage measuring range: 300mV...400V; 700V
AC voltage measuring range: 300mV...400V; 700V
Insulation resistance measuring ranges: 10...999kΩ; 4MΩ; 40MΩ; 400MΩ; 4GΩ; 40GΩ; 200GΩ
Display parameters: (4000)
DC voltage measuring accuracy: ±(3% + 2 digit)
Resistance measuring accuracy: ±(3%+2 digit)
Insulation resistance measuring accuracy: ±(3% + 2digit)
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Insulation Resistance Meters
Description: Meter: insulation resistance; LCD; (4000); VAC: 300mV÷400V,700V
Type of meter: insulation resistance
Kind of display used: LCD
Body dimensions: 211x108x60mm
Power supply: battery LR6 AA 1,5V x6
Conform to the norm: CAT IV 600V; EN 61243-3:2010; IEC 61010-1; IEC 61010-2-030; IEC 61326-1
Standard equipment: carrying case; crocodile clip; test leads; test probe x1
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Measurement memory: 1300
Interface: Bluetooth
Weight without batteries: 850g
Continuity test: <10Ω; <100Ω
Bargraph: yes
Test voltage: 50V; 100V; 250V; 500V; 1kV
Resistance measuring range: 4kΩ; 40kΩ; 400kΩ; 1MΩ
DC voltage measuring range: 300mV...400V; 700V
AC voltage measuring range: 300mV...400V; 700V
Capacitance measuring range: 0.1...400nF; 4µF; 10µF
Software: included
Insulation resistance measuring ranges: 10...999kΩ; 4MΩ; 40MΩ; 400MΩ; 4GΩ; 40GΩ; 200GΩ
Display parameters: (4000)
DC voltage measuring accuracy: ±(3% + 2 digit)
Resistance measuring accuracy: ±(3%+2 digit)
Insulation resistance measuring accuracy: ±(3% + 2digit)
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Phase Sequence Indicators
Description: Tester: phase sequence; LCD; Freq: 15÷400Hz; IP40
Type of tester: phase sequence
Kind of display used: LCD
Phase-to-phase voltage range for phase sequence indication: 40...850V AC
Operating frequency: 15...400Hz
IP rating: IP40
Body dimensions: 130x69x32mm
Weight with battery: 130g
Power supply: from tested wiring system
Conform to the norm: CAT III 600V; EN 61010; IEC 61557-7
Measurement: motor's rotation direction; phase sequence
Standard equipment: 3 crocodile clips; case; test leads ( 3pcs.)

Hersteller: CHAUVIN ARNOUX
Category: Phase Sequence Indicators
Description: Tester: phase sequence; LED; Freq: 15÷400Hz; IP40
Type of tester: phase sequence
Kind of display used: LED
Phase-to-phase voltage range for phase sequence indication: 40...600V AC
Operating frequency: 15...400Hz
IP rating: IP40
Body dimensions: 130x69x32mm
Weight with battery: 170g
Power supply: battery 9V x1
Conform to the norm: CAT III 600V; EN 61010; IEC 61557-7
Measurement: motor's rotation direction; phase sequence
Measuring instrument features: non-contact determination of rotation field direction; voltage indicator individual for each phase
Standard equipment: 3 crocodile clips; case; test leads ( 3pcs.)

Hersteller: CHAUVIN ARNOUX
Category: Metals & cables detectors
Description: Wire localizer; LCD; 12÷300VAC,12÷300VDC; Output signal: 125kHz
Kind of display used: LCD
Power supply: battery 6LR61 9V x7
Conform to the norm: CAT III 300V; EN 61010
Type of tester: wire localizer
Receiver dimensions: 241.5x78x38.5mm
Transmitter dimensions: 190x89x42.5mm
Standard equipment: a bayonet adapter B22; adapter for main socket; a earth spike; a screw adapter E27; case; crocodile clips; receiver; test leads; transmitter
Additional functions: torch
Measuring instrument features: detection of a metallic water supply and heating pipe; detection of faults in an in floor heating system; detection of the constricted (plugged) part of nonmetallic pipe; identification of supply circuit on the same floor; identyfication of pairs
Detection: conductors at depth up to 2m (1-pole application); conductors at depth up to 0,5m (2-pole application); localisation of wire breaks; localises discontinuity in live conductors; localizes cable routes in ground; localizes given electric circuit protection; localizes routes of metal pipes for water and central heating systems; locating and tracing lines and outlets
Output signal: 125kHz
Detected voltage range: 12...300V AC; 12...300V DC
Battery/ rechargeable battery: battery 6LR61 9V x7
Bargraph: yes

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (1999); VDC: 200mV,2V,20V,200V,600V
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Standard equipment: fixed test leads
Additional functions: torch
Measuring instrument features: automatic power-off; autoranging; contactless voltage detector; HOLD function; low battery indicator; permanently connected test leads; pocket size
Type of meter: digital multimeter
Continuity test: acoustic indication; <60Ω
Measurement: AC voltage; continuity; DC voltage; resistance
Dimensions (W x H x D): 55x104x32.5mm
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 2V; 20V; 200V; 600V
Diode test: 1mA @1.5V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Display parameters: (1999)
DC voltage measuring accuracy: ±(0.5% + 3 digit)
AC voltage measuring accuracy: ±(1% + 8 digit)
Resistance measuring accuracy: ±(0.08%+5 digit)
Kind of display used: LCD
Power supply: battery LR03 AAA 1,5V x2

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; (1999); VDC: 200mV,2V,20V,200V,600V
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Standard equipment: fixed test leads
Additional functions: torch
Measuring instrument features: automatic power-off; autoranging; contactless voltage detector; HOLD function; low battery indicator; permanently connected test leads; pocket size
Type of meter: digital multimeter
Continuity test: acoustic indication; <60Ω
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; resistance
Dimensions (W x H x D): 55x104x32.5mm
AC current measuring range: 0.2mA; 2mA; 20mA; 200mA
Resistance measuring range: 200Ω; 2kΩ; 20kΩ; 200kΩ; 2MΩ; 20MΩ
DC current measuring range: 0.2mA; 2mA; 20mA; 200mA
DC voltage measuring range: 200mV; 2V; 20V; 200V; 600V
AC voltage measuring range: 2V; 20V; 200V; 600V
Diode test: 1mA @1.5V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Display parameters: (1999)
AC current measuring accuracy: ±(2.5% + 10 digit)
DC voltage measuring accuracy: ±(0.5% + 3 digit)
DC current measuring accuracy: ±(2% + 8 digit)
AC voltage measuring accuracy: ±(1% + 8 digit)
Resistance measuring accuracy: ±(0.08%+5 digit)
Kind of display used: LCD
Power supply: battery LR03 AAA 1,5V x2

Hersteller: CHAUVIN ARNOUX
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LEDs; VAC: 12V,24V,50V,127V,230V,400V,690V
Type of tester: electrical
Kind of display used: LEDs
DC voltage measuring range: 12V; 24V; 50V; 127V; 230V; 400V; 750V
Conform to the norm: CAT IV 600V; EN 61010; IEC 61326-1; NF C 18-510
Power supply: battery LR03 AAA 1,5V x2
Measuring instrument features: AutoTest function; hazardous voltage indicator (>50V AC or 120V DC); low battery indicator; polarization indicator; single-pole voltage testing
Standard equipment: carrying strap; IP2X test probes; test lead
Body dimensions: 163x64x40mm
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Weight with battery: 210g
Continuity test: acoustic indication; optical indication; <100Ω
Bandwidth for AC voltage measurements: 16.66...800Hz
AC voltage measuring range: 12V; 24V; 50V; 127V; 230V; 400V; 690V
IP rating: IP65
Resistance to: fall from 2m height

Hersteller: CHAUVIN ARNOUX
Category: Indicators, Voltage & Continuity Testers
Description: Tester: electrical; LCD; VAC: 0÷690V; 50/60Hz; VDC: 0÷690V; IP54
Type of tester: electrical
Continuity test: acoustic indication; optical indication
Conform to the norm: CAT III 600V; EN 61010
Body dimensions: 180x52x45mm
Standard equipment: test probe x1
Measuring instrument features: low battery indicator; polarization indicator; single-pole voltage testing
Weight with battery: 200g
Bargraph: yes
Bandwidth for AC voltage measurements: 50/60Hz
DC voltage measuring range: 0...690V
AC voltage measuring range: 0...690V
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Kind of display used: LCD
Power supply: battery LR03 AAA 1,5V x2
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Accessories - Others
Description: Adapter; 95x50x38mm; IP20
Type of test accessories: adapter
Dimensions: 95x50x38mm
IP rating: IP20
Related items: CA-742; CA-762

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; VDC: 3V,30V,300V,1kV; Test: diodes; IP54
Type of meter: digital multimeter
Measurement: AC voltage; capacitance; continuity; DC voltage; resistance
Kind of display used: LCD
DC voltage measuring range: 3V; 30V; 300V; 1kV
DC voltage measuring accuracy: ±(2% + 3 digit)
AC voltage measuring range: 3V; 30V; 300V; 1kV
AC voltage measuring accuracy: ±(3% + 4 digit)
Resistance measuring range: 300Ω; 3kΩ; 30kΩ; 300kΩ; 3MΩ; 30MΩ
Capacitance measuring range: 3nF; 30nF; 300nF; 3µF; 30µF; 300µF; 3mF; 30mF
Capacitance measuring accuracy: ±(5%+ 5 digit)
Resistance measuring accuracy: ±(3%+3 digit)
Test: diodes
Continuity test: acoustic indication; <30Ω
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: test probes
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 180x52x45mm
Measuring instrument features: autoranging; contactless voltage detector; low battery indicator; replaceable measuring tips
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Illumination: yes
IP rating: IP54
Resistance to: fall from 2m height

Hersteller: CHAUVIN ARNOUX
Category: Portable digital multimeters
Description: Digital multimeter; LCD; VDC: 3V,30V,300V,1kV; Test: diodes; IP54
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; continuity; DC voltage; resistance
Kind of display used: LCD
DC voltage measuring range: 3V; 30V; 300V; 1kV
DC voltage measuring accuracy: ±(2% + 3 digit)
AC voltage measuring range: 3V; 30V; 300V; 1kV
AC voltage measuring accuracy: ±(3% + 4 digit)
Resistance measuring range: 300Ω; 3kΩ; 30kΩ; 300kΩ; 3MΩ; 30MΩ
Capacitance measuring range: 3nF; 30nF; 300nF; 3µF; 30µF; 300µF; 3mF; 30mF
Capacitance measuring accuracy: ±(5%+ 5 digit)
Resistance measuring accuracy: ±(3%+3 digit)
Test: diodes
Continuity test: acoustic indication; <30Ω
Power supply: battery LR03 AAA 1,5V x2
Standard equipment: probe MiniFlex; test probes; Velcro strap
Conform to the norm: CAT III 600V; EN 61010
Dimensions (W x H x D): 180x52x45mm
Measuring instrument features: autoranging; contactless voltage detector; low battery indicator; replaceable measuring tips
Battery/ rechargeable battery: battery LR03 AAA 1,5V x2
Illumination: yes
AC current measuring range: 500mA...30A; 300A
AC current measuring accuracy: ±(3% + 5 digit)
IP rating: IP54
Resistance to: fall from 2m height

Hersteller: CHAUVIN ARNOUX
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD; VAC: 6÷600V; True RMS; 40÷70Hz
Type of meter: power quality analyser
Kind of display used: LCD
Dimensions: 211x108x60mm
Standard equipment: 2 crocodile clips; optical cable with USB; test leads ( 2pcs.); test probes
Conform to the norm: CAT III 600V; EN 61010
Illumination: yes
Measuring instrument features: automatic power-off; automatic recognition various current detectors; datalogging; indicates phase sequence
Weight with battery: 880g
Optional equipment: CA-1711 techometr probe
Continuity test: acoustic indication
Pollution degree: 2
True effective value measurement: True RMS
Measurement: AC current (with current clamps); active power; AC voltage; apparent power; DC current (with current clamps); Displacement Power Factor (DPF); frequency; harmonics; inrush current; power factor; reactive power; resistance; rpm velocity; temperature (option)
AC voltage measuring range: 6...600V
Frequency measuring range: 40...70Hz
Battery/ rechargeable battery: battery LR6 AA 1,5V x6
Software: Power Analyser Transfer
Power supply: battery LR6 AA 1,5V x6
IP rating: IP54

Hersteller: CHAUVIN ARNOUX
Category: Power Quality Analyzers
Description: Meter: power quality analyser; colour,LCD TFT; Interface: USB
Power supply: rechargeable battery Ni-MH x1
IP rating: IP53
Supply voltage: 100...240V AC
Kind of network: three-phase
Interface: USB
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010; IEC 61000-4-30
Display resolution: 320x240
Dimensions: 240x180x55mm
Standard equipment: 12-colour set to mark leads and inputs; aligator clip x5; carrying case; mains cable; manual (CD); screen protector preventing scratching (set); test leads ( 5pcs.); USB cable
Measuring instrument features: automatic recognition various current detectors; more than 450 recordable values with the required parameters and graphic displays; operation of several modes in parallel; possibility of viewing the data during a campaign; up to 40 alarms can be set simultaneously
Type of meter: power quality analyser
Producer guarantee (months): 36
Measurement: AC current (with current clamps); active power; AC voltage; apparent power; DC current (option); DC voltage; distorting power; energy; harmonics; inrush current; K factor for transformers; reactive power; short or long-term flicker
Software: Power Analyser Transfer
Kind of display used: colour; LCD TFT
Number of inputs: 9

Hersteller: CHAUVIN ARNOUX
Category: Manometers and Pressure Meters
Description: Manometer; -100÷100psi; LCD; Meas.accur: ±0,3%; 0÷50°C
Type of meter: manometer
Pressure measuring range: -100...100psi
Kind of display used: LCD
Measurement accuracy: ±0,3%
Dimensions: 72x182x30mm
Power supply: battery 6LR61 9V x1
Measuring instrument features: AUTO HOLD; automatic power-off; differential pressure measurements; logging of MAX, MIN
Standard equipment: 2 connection tubes; soft case; user's manual
Measurement: pressure
Measuring unit: bar; cm H₂O; ft H₂O; in Hg; in H₂O; kg/cm²; kPa; mm Hg; ozin²
Operating temperature: 0...50°C
Measuring resolution: 0,01 psi
Battery/ rechargeable battery: battery 6LR61 9V x1
Illumination: yes
