Produkte > GOSSEN METRAWATT > Alle Produkte des Herstellers GOSSEN METRAWATT (311) > Seite 3 nach 6

Hersteller: GOSSEN METRAWATT
Category: Multimeters for Electrical Installations
Description: Test panel; Equipment: key x2,user's manual,jumpers; 230/400VAC
Type of test accessories: test panel
Standard equipment: jumpers; key x2; user's manual
Conform to the norm: EN 60529; EN 61010; VDE 0100
Measuring instruments application: simulation of damage and irregularities in electrical circuits
Body dimensions: 297x456x80mm
Number of switches: 25
Rated voltage: 230/400V AC

Hersteller: GOSSEN METRAWATT
Category: Indicators, Voltage & Continuity Testers
Description: Meter: resistance; 0÷20Ω; 30m
Measurement: continuity; resistance
Type of meter: resistance
Battery/ rechargeable battery: battery AA x4
Power supply: battery AA x4
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61557
Resistance measuring range: 0...20Ω
Cable length: 30m
Measuring instrument features: acoustic and optical alarm; automatic polarization selection
Standard equipment: adapter for main socket; cable reel; carrying strap; crocodile clip; jumper; telescopic arm; test lead; test probe

Hersteller: GOSSEN METRAWATT
Category: Indicators, Voltage & Continuity Testers
Description: Meter: resistance; 0÷20Ω; ±8%; 30m; Resol: 0,01Ω
Measurement: continuity; resistance
Type of meter: resistance
Battery/ rechargeable battery: battery AA 1,5V x4
Power supply: battery AA 1,5V x4
Conform to the norm: CAT III 600V; CAT IV 300V; EN 60529; EN 61010; EN 61326; EN 61557; IEC 61326-1
Operating temperature: -20...55°C
Resistance measuring range: 0...20Ω
Cable length: 30m
Resistance measuring accuracy: ±8%
Measuring resolution: 0,01Ω
Measuring instrument features: acoustic and optical alarm; automatic polarization selection; automatic power-off
Standard equipment: adapter for main socket; cable reel; carrying strap; crocodile clip; jumper; test lead; test probe

Hersteller: GOSSEN METRAWATT
Category: PV and EVSE Testers and Meters
Description: Test acces: test leads; Equipment: magnetic catch; photovoltaics
Type of test accessories: test leads
Related items: GM-M320A; GM-M360C; GM-M360D; GM-M360F
Application: photovoltaics
Cable/adapter structure: MC4
Conform to the norm: CAT III 1000V
Connector variant: magnetic
Operating temperature: -10...60°C
Cable length: 1.5m
Current rating: 4A
Standard equipment: magnetic catch

Hersteller: GOSSEN METRAWATT
Category: Electronic Loads
Description: Test acces: mains cable; 0.4mm
Related items: GM-K852A; GM-K853A; GM-K854A; GM-K855A
Type of test accessories: mains cable
Length: 0.4mm

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD 7"; Network: three-phase; 4GB
Standard equipment: case; mains battery charger; manufacturer's calibration certificate; test leads
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Software: DranView 7
Related items: GM-Z802C; GM-Z802D; GM-Z802F; GM-Z802G; GM-Z802H; GM-Z802I; GM-Z802J; GM-Z802K; GM-Z802L; GM-Z802M; GM-Z818R
IP rating: IP50
Kind of display used: LCD 7"
Manufacturer series: MAVOWATT 240
Type of meter: power quality analyser
Battery/ rechargeable battery: rechargeable battery Ni-MH x1
Kind of network: three-phase
Kit contents: TR251OB - 4 current clamp adapters
Touchpad: yes
Dimensions: 255.78x207.26x105.41mm
Frequency: 15...20Hz; 45...65Hz
Supply voltage: 85...265V AC
Measurement memory: 10k
Memory capacity: 4GB
Measuring instrument features: 4 current inputs; 4 voltage inputs up to 1000 V RMS; 8 independent input channels; automatic limit value settings; automatic report generation; energy monitring and recording; graphical display of measurement results; Intelligent Answer Modules; phase vector display; real-time value monitoring; time synchronization via GPS and NTP
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; crest factor; Displacement Power Factor (DPF); energy; inrush current; power factor; reactive electric energy; reactive power; THD; TID
Power supply: rechargeable battery Ni-MH x1
Interface: Bluetooth; Ethernet; VNC; WiFi

Hersteller: GOSSEN METRAWATT
Category: Insulation Resistance Meters
Description: Test lead; red; 10m; Type: insulated; banana 4mm plug x2
Related items: GM-M555A
Connector variant: insulated
Colour: red
Type of test accessories: test lead
Length: 10m
Cable/adapter structure: banana 4mm plug x2
Conform to the norm: CAT IV 1000V; EN 61010

Hersteller: GOSSEN METRAWATT
Category: Insulation Resistance Meters
Description: Test lead; blue; 5m; Type: insulated; banana 4mm plug x2
Connector variant: insulated
Type of test accessories: test lead
Length: 5m
Cable/adapter structure: banana 4mm plug x2
Colour: blue
Conform to the norm: CAT IV 1000V; EN 61010
Related items: GM-M555A

Hersteller: GOSSEN METRAWATT
Category: LAN and Telephone Networks Testers
Description: Meter: reflectometer; LCD; Detection: place of cable failure
Type of meter: reflectometer
Kind of display used: LCD
Interface: Bluetooth
Measuring instrument features: AUTO set up for instant use; cursor x2; HOLD function
Standard equipment: 2 crocodile clips; BNC adapter; carrying strap; case; test probes; user's manual
Software: Metracable Manager PC
IP rating: IP52
Detection: place of cable failure
Operating temperature: -10...50°C
Dimensions: 195x100x45mm
Measurement accuracy: 1%
Input impedance: 50Ω; 75Ω; 100Ω; 125Ω
Display resolution: 240x128
Measuring resolution: 0,3m; 3,125ns
Measuring range: 14km
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Power supply: battery LR6 AA 1,5V x4
Measuring instruments application: for all types of electrical cables

Hersteller: GOSSEN METRAWATT
Category: LAN and Telephone Networks Testers
Description: Meter: reflectometer; LCD; Detection: place of cable failure
Type of meter: reflectometer
Kind of display used: LCD
Interface: Bluetooth
Measuring instrument features: AUTO set up for instant use; cursor x2; HOLD function
Standard equipment: 2 crocodile clips; BNC adapter; carrying strap; case; test probes; user's manual
Software: Metracable Manager PC
IP rating: IP52
Detection: place of cable failure
Operating temperature: -10...50°C
Dimensions: 195x100x45mm
Measurement accuracy: 1%
Input impedance: 50Ω; 75Ω; 100Ω; 125Ω
Display resolution: 240x128
Measuring resolution: 0,3m; 3,125ns
Measuring range: 14km
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Power supply: battery LR6 AA 1,5V x4
Measuring instruments application: for all types of electrical cables
Anzahl je Verpackung: 1 Stücke

Hersteller: GOSSEN METRAWATT
Category: Calibrators
Description: Meter: multimeter calibrator; Diode test: 1mA@3.2V; frequency
Type of meter: multimeter calibrator
Kind of display used: LCD
Display parameters: 4,75 digit; (30000)
True effective value measurement: True RMS AC
DC voltage measuring range: 60mV; 300mV; 3V; 30V; 300V
DC voltage measuring accuracy: ±(0.05% + 10 digit)
AC voltage measuring range: 60mV; 300mV; 3V; 30V; 300V
AC voltage measuring accuracy: ±(0.2% + 30 digit)
DC current measuring range: 0.3mA; 3mA; 30mA; 300mA
DC current measuring accuracy: ±(0.05% + 15 digit)
AC current measuring range: 0.3mA; 3mA; 30mA; 300mA
AC current measuring accuracy: ±(0.015% + 0.005% range); ±(0.5% + 30 digit)
Resistance measuring range: 300Ω; 3kΩ; 30kΩ; 300kΩ; 3MΩ; 30MΩ
Resistance measuring accuracy: ±(0.1%+5 digit)
Capacitance measuring range: 30nF; 300nF; 3µF; 30µF; 300µF
Capacitance measuring accuracy: ±(1%+ 6 digit)
Frequency measuring range: 300Hz; 3kHz; 30kHz; 300kHz
Frequency measuring accuracy: ±(0.05%+5 digit)
Diode test: 1mA @3.2V
Continuity test: acoustic indication; <300Ω
Measurement: 0-20mA current loop; 0-24mA current loop; 4-20mA current loop; AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; resistance; temperature
Interface: IR (option)
Measuring instrument features: dual mode – simultaneous calibration and measurement; frequency generator; HOLD function; MIN/MAX function; operates with thermocouple types: J, K, T, S, B, E, N, L, U, R, Pt100, PT1000, Ni100, Ni1000
Current source: 0...24mA
Standard equipment: calibration certificate DAkkS; carrying strap; holster; test leads ( 3pcs.); user's manual
Dimensions: 200x87x45mm
Producer guarantee (months): 36
Memory capacity: 16Mb
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Power supply: battery LR6 AA 1,5V x2
Additional functions: calibrator; data logger; multimeter; simulator
Conform to the norm: CAT II 600V; EN 61010
Kind of calibrator: current; frequency; loop; resistance; RTD; thermocouple; voltage
Software: LabVIEW
IP rating: IP65

Hersteller: GOSSEN METRAWATT
Category: Batteries Testers
Description: Tester: batteries and rechargeable batteries; 96x154x33mm; IP40
AC voltage measuring range: 0...300V
DC voltage measuring range: -600...600V
Resistance measuring range: 0...1000mΩ
Temperature measuring range: -230...230°C
Standard equipment: carrying strap; crocodile clip x2; hard case; Kelvin probe x2; manufacturer's calibration certificate; power supply; test probe x2; user's manual
Conform to the norm: CAT III 600V; EN 61010
Measuring instrument features: battery identification by means of RFID tag reader; capacity test: recording of discharge current and voltage curve; impact resistant holster; measurement of block voltages up to ± 24.5 VDC; Rct and Rel measurement methods- possible electrical and electro-chemical damage to the battery block is reliably detected
Kind of display used: LCD
Measurement: AC voltage; DC voltage; resistance; temperature
Battery/ rechargeable battery: rechargeable battery Ni-MH AA 1,2V x4
Power supply: rechargeable battery Ni-MH AA 1,2V x4
Dimensions: 96x154x33mm
Measurement memory: 30000
Interface: Bluetooth
Type of tester: batteries and rechargeable batteries
Supported formats: CSV
Application: for battery systems; for UPS
Related items: GM-Z202B; GM-Z204A; GM-Z227F; GM-Z680A
Software: included
IP rating: IP40

Hersteller: GOSSEN METRAWATT
Category: Meters and AC/DC Clamp Probes
Description: Meter: ammeter; digital,pincers type; Øcable: 30mm; LCD; (2000)
Type of meter: ammeter
Kind of meter: digital; pincers type
Max. diameter of measured cable: 30mm
Kind of display used: LCD
Display parameters: (2000)
DC current measuring range: 100mA; 1A
AC current measuring range: 100mA; 1A; 10A
Measuring instrument features: HOLD function; zeroing function
DC current measuring accuracy: ±(1% + 10 digit)
AC current measuring accuracy: ±(1% + 10 digit)
Body dimensions: 33x170x24mm
Power supply: battery LR6 AA 1,5V x4
Standard equipment: case; data logger cable; user's manual
Measurement: AC current; DC current; leakage current
Conform to the norm: CAT II 600V; CAT III 300V; EN 61010
Battery/ rechargeable battery: battery LR6 AA 1,5V x4

Hersteller: GOSSEN METRAWATT
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 34mm; LCD
Measuring instrument features: auto and manual ranging; HOLD function; MIN/MAX function
Power supply: battery 6LR61 9V x1
Battery/ rechargeable battery: battery 6LR61 9V x1
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Kind of meter: digital; pincers type
Type of meter: multifunction
Kind of display used: LCD
True effective value measurement: True RMS
DC voltage measuring range: 0...1kV
AC current measuring range: 150mA...600A
DC current measuring range: 600A; 900A
Resistance measuring range: 0...60MΩ
Body dimensions: 222x78x42mm
Max. diameter of measured cable: 34mm
AC voltage measuring range: 150mV...1kV
Frequency measuring accuracy: ±(0.4%+1 digit)
AC voltage measuring accuracy: ±(1% + 3 digit)
AC current measuring accuracy: ±(1.2% + 3 digit)
DC voltage measuring accuracy: ±(1% + 3 digit)
DC current measuring accuracy: ±(1% + 3 digit)
Resistance measuring accuracy: ±(1%+5 digit)
Diode test: 3.1V
Standard equipment: case; crocodile clip x1; K-type temperature probe; test leads; user's manual
Frequency measuring range: 5...20kHz
Display parameters: 4 digit (60000)
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; frequency; inrush current; resistance; temperature
Continuity test: acoustic indication; <40Ω

Hersteller: GOSSEN METRAWATT
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 34mm; LCD
Measuring instrument features: auto and manual ranging; HOLD function; MIN/MAX function; phase detector
Power supply: battery 6LR61 9V x1
Battery/ rechargeable battery: battery 6LR61 9V x1
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Kind of meter: digital; pincers type
Type of meter: multifunction
Kind of display used: LCD
True effective value measurement: True RMS
DC voltage measuring range: 0...1kV
AC current measuring range: 150mA...600A
DC current measuring range: 600A; 900A
Resistance measuring range: 0...60MΩ
Body dimensions: 222x78x42mm
Max. diameter of measured cable: 34mm
AC voltage measuring range: 150mV...1kV
Frequency measuring accuracy: ±(0.4%+1 digit)
AC voltage measuring accuracy: ±(1% + 3 digit)
AC current measuring accuracy: ±(1.2% + 3 digit)
DC voltage measuring accuracy: ±(1% + 3 digit)
DC current measuring accuracy: ±(1% + 3 digit)
Resistance measuring accuracy: ±(1%+5 digit)
Diode test: 3.1V
Apparent power measurement: 900kVA
Reactive power measurement: 900kVAR
Active power measurement: 900kW
Standard equipment: case; crocodile clip x1; test leads; user's manual
Frequency measuring range: 5...20kHz
Display parameters: 4 digit (60000)
Measurement: AC current; active power; AC voltage; continuity; DC current; DC voltage; frequency; inrush current; power; power factor; reactive power; resistance; THD
Continuity test: acoustic indication; <40Ω

Hersteller: GOSSEN METRAWATT
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 48mm; LCD
Interface: Bluetooth
Measuring instrument features: HOLD function; MIN/MAX function
Power supply: battery LR6 AA 1,5V x4
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Conform to the norm: CAT IV 1000V; EN 61010
Kind of meter: digital; pincers type
Type of meter: multifunction
Software: included
Kind of display used: LCD
True effective value measurement: True RMS
DC voltage measuring range: 0...1kV
AC current measuring range: 0...1.5kA
DC current measuring range: 0...1.5kA
Resistance measuring range: 0...100kΩ
Body dimensions: 272x92x41mm
Max. diameter of measured cable: 48mm
AC voltage measuring range: 150mV...1kV
Frequency measuring accuracy: ±(0.4%+1 digit)
AC voltage measuring accuracy: ±(1% + 3 digit)
AC current measuring accuracy: ±(1% + 3 digit)
DC voltage measuring accuracy: ±(1% + 3 digit)
DC current measuring accuracy: ±(1% + 3 digit)
Resistance measuring accuracy: ±(1%+5 digit)
Diode test: 3.1V
Apparent power measurement: 5...1000VA
Reactive power measurement: 5...1000VAR
Active power measurement: 5...1500W
Standard equipment: 2 crocodile clips; case; test leads; user's manual
Frequency measuring range: 5...20kHz
Display parameters: 4 digit (60000)
Measurement: AC current; active power; AC voltage; apparent power; continuity; DC current; DC voltage; frequency; inrush current; power; power factor; reactive power; resistance; THD
Continuity test: acoustic indication; <40Ω

Hersteller: GOSSEN METRAWATT
Category: Earth Resistance Meter
Description: Meter: grounding resistance; Øcable: 35mm; OLED; 10mΩ÷1.5kΩ; IP40
Interface: Bluetooth
Measuring instrument features: HOLD function
Power supply: battery LR6 AA 1,5V x4
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Conform to the norm: CAT IV 600V; EN 61010
Type of meter: grounding resistance
IP rating: IP40
Kind of display used: OLED
Leakage current: 0.0002...40A
Earthing resistance measuring range: 10mΩ...1.5kΩ
Body dimensions: 262x95x55mm
Max. diameter of measured cable: 35mm
Earthing resistance measuring accuracy: ±(1.5% + 0.01Ω)
Standard equipment: calibration loop; manufacturer's calibration certificate; user's manual
Measurement: Ground loop resistance; leakage current; loop inductance; touch voltage

Hersteller: GOSSEN METRAWATT
GM-M320A Meters and AC/DC Clamp Probes

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; LED; Øcable: 610mm; ±1%
Type of test accessories: AC current flexiable clamp adapter
Kind of display used: LED
Max. diameter of measured cable: 610mm
AC current measuring range: 30A; 300A; 3kA
AC current measuring accuracy: ±1%
Measuring instrument features: low battery indicator
Standard equipment: user's manual
Pollution degree: 2
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Cable length: 2m
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; LED; Øcable: 910mm; ±1%
Type of test accessories: AC current flexiable clamp adapter
Kind of display used: LED
Max. diameter of measured cable: 910mm
AC current measuring range: 30A; 300A; 3kA
AC current measuring accuracy: ±1%
Measuring instrument features: low battery indicator
Standard equipment: mains cable; user's manual
Pollution degree: 2
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Cable length: 2m
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; LED; Øcable: 1220mm; ±1%
Type of test accessories: AC current flexiable clamp adapter
Kind of display used: LED
Max. diameter of measured cable: 1220mm
AC current measuring range: 30A; 300A; 3kA
AC current measuring accuracy: ±1%
Measuring instrument features: low battery indicator
Standard equipment: mains cable; user's manual
Pollution degree: 2
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Cable length: 2m
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 30A,300A,3kA; ±1%
Type of test accessories: AC current flexiable clamp adapter
AC current measuring range: 30A; 300A; 3kA
AC current measuring accuracy: ±1%

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 30A,300A,3kA; 10Hz÷20kHz
Type of test accessories: AC current flexiable clamp adapter
Measurement: AC current
AC current measuring range: 30A; 300A; 3kA
Kind of connector: banana 4mm plug x3
Frequency: 10Hz...20kHz
Power supply: battery AA 1,5V x2
Dimensions: 110x65x23mm
IP rating: IP40
Conform to the norm: CAT III 1000V; CAT IV 600V
Operating temperature: -20...65°C
Cable length: 0.91m
Output signal: 1mV/1A; 10mV/1A; 100mV/1A
Gear: 10:1; 100:1; 1000:1

Hersteller: GOSSEN METRAWATT
Category: Meters and AC Clamp Probes
Description: AC current flexiable clamp adapter; I AC: 3A,30A,300A; Len: 2m
IP rating: IP40
Related items: GM-M192A; GM-M194A; GM-M197A; GM-M245A; GM-M248A; GM-M250T; GM-M687A
Operating temperature: -20...65°C
Frequency: 20Hz...100kHz
Cable length: 2m
Dimensions: 110x65x23mm
Probe length: 160mm
Gear: 1:1; 10:1; 100:1
AC current measuring range: 3A; 30A; 300A
Output signal: 1V/1A; 10mA/1A; 100mV/1A
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Kind of connector: banana 4mm plug
Power supply: battery LR6 AA 1,5V x2
Conform to the norm: CAT III 1000V; CAT IV 600V

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 30A,300A,3kA; ±1%
Type of test accessories: AC current flexiable clamp adapter
AC current measuring range: 30A; 300A; 3kA
AC current measuring accuracy: ±1%

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; Jaw capacity: 70mm
Type of test accessories: AC current flexiable clamp adapter
Jaw capacity: 70mm
Measurement: AC current
AC current measuring range: 3A; 30A; 300A
Kind of connector: 4pin Hypertronics plug
Frequency: 10Hz...20kHz
Power supply: battery AA 1,5V x2
Dimensions: 110x65x23mm
IP rating: IP40
Conform to the norm: CAT III 1000V; CAT IV 600V
Operating temperature: -20...65°C
Output signal: 10mV/1A; 100mV/1A; 1000mV/1A
Gear: 10:1; 100:1; 1000:1

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Power supply: battery AA 1,5V x2
Conform to the norm: CAT III 1000V; CAT IV 600V
IP rating: IP40
Operating temperature: -20...65°C
AC current measuring range: 60A; 600A; 6kA
Dimensions: 110x65x23mm
Cable length: 0.61m
Frequency: 10Hz...10kHz
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 1-phase DUTs
Kind of connector: 4pin Hypertronics plug
Related items: GM-Z817M
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Conform to the norm: CAT III 1000V; CAT IV 600V
Related items: GM-Z817M
IP rating: IP40
Operating temperature: -20...65°C
Dimensions: 110x65x23mm
Cable length: 0.91m
Frequency: 10Hz...10kHz
AC current measuring range: 60A; 600A; 6kA
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 1-phase DUTs
Kind of connector: 4pin Hypertronics plug
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Power supply: battery AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Conform to the norm: CAT III 1000V; CAT IV 600V
Related items: GM-Z817M
IP rating: IP40
Operating temperature: -20...65°C
Dimensions: 110x65x23mm
Cable length: 1.22m
Frequency: 10Hz...10kHz
AC current measuring range: 60A; 600A; 6kA
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 1-phase DUTs
Kind of connector: 4pin Hypertronics plug
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Power supply: battery AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Conform to the norm: CAT III 1000V; CAT IV 600V
Related items: GM-Z817M
IP rating: IP40
Operating temperature: -20...65°C
Dimensions: 110x65x23mm
Cable length: 0.61m
Frequency: 10Hz...10kHz
AC current measuring range: 60A; 600A; 6kA
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 3-phase DUTs
Kind of connector: 4pin Hypertronics plug
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Power supply: battery AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Conform to the norm: CAT III 1000V; CAT IV 600V
Related items: GM-Z817M
IP rating: IP40
Operating temperature: -20...65°C
Dimensions: 110x65x23mm
Cable length: 0.91m
Frequency: 10Hz...10kHz
AC current measuring range: 60A; 600A; 6kA
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 3-phase DUTs
Kind of connector: 4pin Hypertronics plug
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Power supply: battery AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Power Quality Analyzers
Description: AC current flexiable clamp adapter; 60A,600A,6kA; 10Hz÷10kHz
Conform to the norm: CAT III 1000V; CAT IV 600V
Related items: GM-Z817M
IP rating: IP40
Operating temperature: -20...65°C
Dimensions: 110x65x23mm
Cable length: 1.22m
Frequency: 10Hz...10kHz
AC current measuring range: 60A; 600A; 6kA
Output signal: 0,5mV/1A; 5mV/1A; 50mV/1A
Test: 3-phase DUTs
Kind of connector: 4pin Hypertronics plug
Measurement: AC current
Type of test accessories: AC current flexiable clamp adapter
Power supply: battery AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Multimeters for Electrical Installations
Description: Tester: detector; Detection: localizes breakers and fuses; IP20
Type of tester: detector
Detection: localizes breakers and fuses
IP rating: IP20
Conform to the norm: CAT III 250V; EN 61010
Power supply: battery 6LR61 9V x1
Measuring instrument features: automatic power-off
Transmitter dimensions: 160x85x35mm
Receiver dimensions: 210x50x35mm
Standard equipment: case; mains cable; test probes; user's manual
Battery/ rechargeable battery: battery 6LR61 9V x1

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 3 6/7-digit; 2x/s; True RMS; 100÷1kHz
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Power supply: battery LR6 AA 1,5V x2
Type of meter: digital multimeter
Standard equipment: calibration certificate DAkkS; holster; test leads; user's manual
Conform to the norm: CAT III 600V; EN 61010
IP rating: IP40
Kind of display used: LCD
True effective value measurement: True RMS
Bargraph: yes
Temperature measuring range: -50...400°C
Operating temperature: -10...50°C
AC current measuring range: 60mA; 600mA; 6A; 10A
DC current measuring range: 60mA; 600mA; 6A; 10A
DC voltage measuring range: 600mV; 6V; 60V; 600V
AC voltage measuring range: 600mV; 6V; 60V; 600V
Diode test: 3V
Frequency measuring accuracy: ±(0.1%+2 digit)
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 40MΩ
DC voltage measuring accuracy: ±(0.5% + 5 digit)
Dimensions (W x H x D): 84x195x35mm
DC current measuring accuracy: ±(1% + 5 digit)
Resistance measuring accuracy: ±(0.7%+3 digit)
Temperature measurement resolution: 0.1°C
Temperature measurement accuracy: ±(1% + 5°C)
AC voltage measuring accuracy: ±(1% + 5 digit)
AC current measuring accuracy: ±(1% + 5 digit)
Pollution degree: 2
Frequency measuring range: 100...1kHz
Producer guarantee (months): 36
Weight with battery: 350g
Measuring instrument features: 1,6A/1000V fuse; 10A/1000V fuse; auto and manual ranging; HOLD function; MIN/MAX function
Sampling: 2x/s
Display parameters: 3 6/7-digit
Measurement: AC current; AC voltage; continuity; DC current; DC voltage; frequency; resistance; temperature
Manufacturer series: METRAHIT

Hersteller: GOSSEN METRAWATT
Category: Miliohmmeters
Description: Milli-ohm meter; LCD; 4,75 digit; 30mΩ,300mΩ,3Ω,30Ω; Resol: 10uΩ
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Standard equipment: calibration certificate DAkkS; case; Kelvin clip; Kelvin probe
Application: chemical industry; explosive zone
IP rating: IP54
Kind of display used: LCD
Type of meter: milli-ohm meter
Operating temperature: -10...50°C
Resistance measuring range: 30mΩ; 300mΩ; 3Ω; 30Ω
Dimensions (W x H x D): 84x195x35mm
Resistance measuring accuracy: ±(1%+10 digit)
Producer guarantee (months): 36
Weight with battery: 380g
Measurement memory: 1200
Display parameters: 4,75 digit
Measuring instrument features: 4-wire measurement possibility; automatic power-off; autoranging; HOLD function; impact resistant holster
Measuring resolution: 10µΩ
Measurement: resistance
Conform to the norm: ATEX Ex; CAT I 50V; EN 61010
Power supply: battery LR6 AA 1,5V x4

Hersteller: GOSSEN METRAWATT
Category: Analog Multimeters
Description: Analogue multimeter; analogue; VAC: 0÷1.5V,5V,15V,50V,150V,500V
Type of meter: analogue multimeter
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Kind of display used: analogue
DC voltage measuring range: 0...150mV; 500mV; 1.5V; 5V; 15V; 50V; 150V; 500V
AC voltage measuring range: 0...1.5V; 5V; 15V; 50V; 150V; 500V
DC current measuring range: 50µA; 1.5mA; 15mA; 150mA; 1.5A; 15A
AC current measuring range: 1.5mA; 15mA; 150mA; 1.5A; 15A
Resistance measuring range: 1...1MΩ
Operating temperature: 0...40°C
IP rating: IP40
Weight with battery: 300g
Power supply: battery R6 AA 1,5V x1
Standard equipment: user's manual
Conform to the norm: CAT II 500V; EN 61010
Dimensions (W x H x D): 92x126x45mm
Producer guarantee (months): 36
Battery/ rechargeable battery: battery R6 AA 1,5V x1
Manufacturer series: METRAHIT
Capacitance measuring range: 2µF...200mF

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 4,5 digit (19999); 2x/s; True RMS; IP52
Measurement: AC voltage; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication; <100Ω
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Standard equipment: calibration certificate DAkkS; test leads KS17-2; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Type of meter: digital multimeter
IP rating: IP52
Kind of display used: LCD
True effective value measurement: True RMS
Bargraph: yes
Temperature measuring range: -250...1372°C
Operating temperature: -10...50°C
Temperature measurement accuracy: ±(0.3% + 15 digit)
DC voltage measuring accuracy: ±(0.05% + 3 digit)
Temperature measurement resolution: 0.1°C
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Dimensions (W x H x D): 200x87x45mm
Resistance measuring accuracy: ±(0.2%+5 digit)
AC voltage measuring accuracy: ±(0.5% + 9 digit)
Frequency measuring accuracy: ±(3%+9 digit)
Pollution degree: 2
Diode test: 5.1V
Frequency measuring range: 15Hz...1kHz
Producer guarantee (months): 36
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 40MΩ
Weight with battery: 350g
Sampling: 2x/s
Measuring instrument features: automatic power-off; for use with type-K thermocouple; HOLD function; MIN/MAX function
Display parameters: 4,5 digit (19999)
Manufacturer series: METRAHIT

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 4,5 digit (19999); 2x/s; I DC: 1A,10A
Manufacturer series: METRAHIT
Standard equipment: calibration certificate DAkkS; test leads KS17-2; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Type of meter: digital multimeter
IP rating: IP52
Kind of display used: LCD
True effective value measurement: True RMS
Bargraph: yes
Temperature measuring range: -250...1372°C
Operating temperature: -10...50°C
Dimensions (W x H x D): 200x87x45mm
DC voltage measuring accuracy: ±(0.05% + 3 digit)
Temperature measurement resolution: 0.1°C
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Resistance measuring accuracy: ±(0.2%+5 digit)
Temperature measurement accuracy: ±(0.3% + 15 digit)
DC current measuring accuracy: ±(0.5% + 3 digit)
AC voltage measuring accuracy: ±(0.5% + 9 digit)
AC current measuring range: 1A; 10A
DC current measuring range: 1A; 10A
Frequency measuring accuracy: ±(1%+9 digit)
AC current measuring accuracy: ±(1.5% + 10 digit)
Pollution degree: 2
Diode test: 5.1V
Frequency measuring range: 15Hz...10kHz
Producer guarantee (months): 36
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 40MΩ
Weight with battery: 350g
Sampling: 2x/s
Display parameters: 4,5 digit (19999)
Measuring instrument features: 10A/1000V fuse; automatic power-off; for use with type-K thermocouple; HOLD function; MIN/MAX function
Measurement: AC current; AC voltage; DC current; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication; <100Ω
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 4,5 digit (19999); 2x/s; I DC: 1A,10A
Manufacturer series: METRAHIT
Standard equipment: calibration certificate DAkkS; holster; test leads KS17-2; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Type of meter: digital multimeter
IP rating: IP52
Kind of display used: LCD
True effective value measurement: True RMS
Bargraph: yes
Temperature measuring range: -250...1372°C
Operating temperature: -10...50°C
Dimensions (W x H x D): 200x87x45mm
DC voltage measuring accuracy: ±(0.05% + 3 digit)
Temperature measurement resolution: 0.1°C
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Resistance measuring accuracy: ±(0.2%+5 digit)
Temperature measurement accuracy: ±(0.3% + 15 digit)
DC current measuring accuracy: ±(0.5% + 3 digit)
AC voltage measuring accuracy: ±(0.5% + 9 digit)
AC current measuring range: 1A; 10A
DC current measuring range: 1A; 10A
Frequency measuring accuracy: ±(1%+9 digit)
AC current measuring accuracy: ±(1.5% + 10 digit)
Pollution degree: 2
Diode test: 5.1V
Frequency measuring range: 15Hz...10kHz
Producer guarantee (months): 36
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 40MΩ
Weight with battery: 350g
Sampling: 2x/s
Display parameters: 4,5 digit (19999)
Measuring instrument features: 10A/1000V fuse; automatic power-off; for use with type-K thermocouple; HOLD function; MIN/MAX function
Measurement: AC current; AC voltage; DC current; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication; <100Ω
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; LCD; 4,5 digit (19999); 2x/s; True RMS; IP52
Type of meter: digital multimeter
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; frequency; resistance; temperature
Kind of display used: LCD
Display parameters: 4,5 digit (19999)
Sampling: 2x/s
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring accuracy: ±(0.05% + 3 digit)
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC voltage measuring accuracy: ±(0.5% + 9 digit)
DC current measuring range: 10mA; 100mA; 1A; 10A
DC current measuring accuracy: ±(0.1% + 5 digit)
AC current measuring range: 10mA; 100mA; 1A; 10A
AC current measuring accuracy: ±(1% + 10 digit)
True effective value measurement: True RMS
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 40MΩ
Capacitance measuring range: 10nF; 100nF; 1µF; 10µF; 100µF; 1mF
Capacitance measuring accuracy: ±(1%+ 6 digit)
Frequency measuring range: 15Hz...10kHz
Frequency measuring accuracy: ±(1%+9 digit)
Temperature measuring range: -250...1372°C
Temperature measurement accuracy: ±(0.3% + 15 digit)
Resistance measuring accuracy: ±(0.2%+5 digit)
Temperature measurement resolution: 0.1°C
Diode test: 5.1V
Continuity test: acoustic indication; <100Ω
Operating temperature: -10...50°C
Pollution degree: 2
IP rating: IP52
Weight with battery: 350g
Power supply: battery LR6 AA 1,5V x2
Standard equipment: calibration certificate DAkkS; holster; test leads KS17-2; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Dimensions (W x H x D): 200x87x45mm
Producer guarantee (months): 36
Measuring instrument features: 10A/1000V fuse; automatic power-off; for use with type-K thermocouple; HOLD function; MIN/MAX function; protective rubber cover
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Manufacturer series: METRAHIT
Bargraph: yes

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; IR; LCD; 4,5 digit (19999); 2x/s; True RMS
Operating temperature: -10...50°C
Manufacturer series: METRAHIT
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Type of meter: digital multimeter
Interface: IR
Standard equipment: calibration certificate DAkkS; test leads KS17-2; user's manual
Kind of display used: LCD
IP rating: IP52
True effective value measurement: True RMS
Bargraph: yes
Temperature measuring range: -250...1372°C
Capacitance measuring range: 10nF; 100nF; 1µF; 10µF; 100µF; 1mF
DC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
AC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
AC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
Diode test: 5.1V
DC voltage measuring accuracy: ±(0.05% + 3 digit)
Resistance measuring accuracy: ±(0.2%+5 digit)
Frequency measuring accuracy: ±(1%+9 digit)
Frequency measuring range: 15Hz...20kHz
AC voltage measuring accuracy: ±(0.5% + 9 digit)
DC current measuring accuracy: ±(0.5% + 3 digit)
Temperature measurement accuracy: ±(0.3% + 15 digit)
Dimensions (W x H x D): 200x87x45mm
Temperature measurement resolution: 0.1°C
AC current measuring accuracy: ±(1.5% + 10 digit)
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 40MΩ
Capacitance measuring accuracy: ±(1%+ 6 digit)
Pollution degree: 2
Producer guarantee (months): 36
Weight with battery: 350g
Sampling: 2x/s
Memory capacity: 4Mb
Display parameters: 4,5 digit (19999)
Measuring instrument features: 10A/1000V fuse; automatic power-off; HOLD function; MIN/MAX function; operates with thermocouple types: K, Pt100, PT1000; with power pack socket
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; frequency; resistance; temperature
Continuity test: acoustic indication; <100Ω
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010

Hersteller: GOSSEN METRAWATT
Category: Calibrators
Description: Meter: AS-i industrial networks; VDC: 2÷35V; 0÷150mA; METRAHIT
Type of meter: AS-i industrial networks
DC voltage measuring range: 2...35V
DC voltage measuring accuracy: ±(3.5% + 2 digit)
DC current measuring range: 0...150mA
DC current measuring accuracy: ±(5% + 2 digit)
Dimensions: 84x195x35mm
Power supply: battery LR6 AA 1,5V x4
Measuring instrument features: measurement of voltage in the AS interface conductor and measurement of operating current for AS-i slaves; reading and writing of the cyclical input and output channels of CTT2 slaves; read-out and selection of slave addresses 0 to 31, 1A to 31A or 1B to 31B for all AS interface slaves; read-out and setting of the ID1 code; read-out of data objects, identifiers and diagnostics in case of CTT2 slaves; read-out of the safety code sequences of safety relevant input slaves (ASIsafe); read-out of the slave profile (IO, ID, ID2); recognition of reversed polarity and overload; selection of slave parameters for test purposes and read-back of the parameter echo; storage of complete network configurations (profiles of all slaves) as an addressing aide; suitable for all types of digital and analog slaves which comply with AS-i specification V3.0; testing of input and output data from digital and analog slaves in accordance with AS interface specification V3.0
Standard equipment: carrying strap; connection cable Z236A; holster; user's manual
Related items: GM-Z231G; GM-Z236A
Battery/ rechargeable battery: battery LR6 AA 1,5V x4
Manufacturer series: METRAHIT

Hersteller: GOSSEN METRAWATT
Category: Calibrators
Description: Meter: calibrator; frequency,voltage,current,loop,resistance
Standard equipment: calibration certificate DAkkS; holster; test leads; user's manual
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Manufacturer series: METRAHIT
Kind of display used: LCD
Interface: USB (option)
Current source: 0...24mA
DC current measuring range: 0...24mA
DC voltage measuring accuracy: ±(0.05% + 0.2mV)
Resistance measuring accuracy: ±(0.05%+200mΩ)
Frequency measuring accuracy: ±(0.05%+0.2Hz)
Dimensions: 200x87x45mm
DC voltage measuring range: 300mV; 3V; 10V; 15V
Producer guarantee (months): 36
Frequency measuring range: 1...1kHz
Display parameters: (30000)
Resistance measuring range: 5...2kΩ
Power supply: battery LR6 AA 1,5V x2
Type of meter: calibrator
Kind of calibrator: current; frequency; loop; resistance; RTD; thermocouple; voltage
Measuring instrument features: frequency generator; HOLD function; operates with thermocouple types: J, K, T, S, B, E, N, L, U, R, Pt100, PT1000, Ni100, Ni1000
IP rating: IP54

Hersteller: GOSSEN METRAWATT
Category: Calibrators
Description: Multimeters; METRAHIT
Type of measuring kit: multimeters
Standard equipment: calibration certificate DAkkS; hard case; holster; test leads; user's manual
Kit contents: calibrator METRAHIT CAL; digital multimeter METRAHIT-AM-XTRA
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Manufacturer series: METRAHIT

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; IR; LCD; 4,75 digit; True RMS; Resol: 0.1°C
Type of meter: digital multimeter
Kind of display used: LCD
Display parameters: 4,75 digit
True effective value measurement: True RMS
DC voltage measuring range: 300mV; 3V; 30V; 300V; 1kV
AC voltage measuring range: 300mV; 3V; 30V; 300V; 1kV
DC current measuring range: 0.3mA; 3mA; 30mA; 300mA; 3A; 10A
AC current measuring range: 0.3mA; 3mA; 30mA; 300mA; 3A; 10A
Resistance measuring range: 300Ω; 3kΩ; 30kΩ; 300kΩ; 3MΩ; 30MΩ
Capacitance measuring range: 30nF; 300nF; 3µF; 30µF; 300µF
Frequency measuring range: 300Hz; 3kHz; 30kHz; 300kHz
Frequency measuring accuracy: ±(0.1%+2 digit)
Temperature measuring range: -250...1372°C
Test: diodes
Continuity test: acoustic indication; <90Ω
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; frequency; insulation resistance; resistance; temperature
Interface: IR
Measuring instrument features: interturn short-circuit detection with COIL test adapter; low-pass filter; MIN/MAX function; operates with thermocouple types: K, Pt100, PT1000
Standard equipment: calibration certificate DAkkS; test leads KS17-2
Dimensions (W x H x D): 200x87x45mm
Temperature measurement resolution: 0.1°C
Test voltage: 50V; 100V; 250V; 500V; 1kV
Producer guarantee (months): 36
Weight with battery: 350g
Insulation resistance measuring ranges: 3.1GΩ
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Power supply: battery LR6 AA 1,5V x2
Conform to the norm: CAT II 1000V; CAT III 600V; EN 61010
Related items: GM-Z270F
IP rating: IP54
Manufacturer series: METRAHIT
Bargraph: yes

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; IR; LCD; (60000); VDC: 60mV,600mV,6V,60V,600V
Type of meter: digital multimeter
Interface: IR
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; capacitance; conductance; crest factor; DC current; DC voltage; frequency; harmonics; power factor; reactive electric energy; reactive power; resistance; temperature
Kind of display used: LCD
Display parameters: (60000)
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V
DC voltage measuring accuracy: ±(0.02% + 15 digit)
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V
AC voltage measuring accuracy: ±(0.2% + 30 digit)
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring accuracy: ±(0.05% + 20 digit)
AC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
AC current measuring accuracy: ±(0.5% + 25 digit)
True effective value measurement: True RMS AC; True RMS AC+DC
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Capacitance measuring range: 60nF; 600nF; 6µF; 60µF; 600µF
Capacitance measuring accuracy: ±(1%+ 6 digit)
Frequency measuring range: 600Hz; 6kHz; 60kHz; 300kHz
Frequency measuring accuracy: ±(0.05%+5 digit)
Temperature measuring range: -150...1372°C
Resistance measuring accuracy: ±(0.1%+5 digit)
Temperature measurement resolution: 0.1°C
Test: diodes
Continuity test: acoustic indication; <500Ω
IP rating: IP52
Weight with battery: 400g
Power supply: battery LR6 AA 1,5V x2
Standard equipment: calibration certificate DAkkS; carrying strap; test leads; user's manual
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Dimensions (W x H x D): 200x87x45mm
Producer guarantee (months): 36
Measuring instrument features: auto and manual ranging; impact resistant holster; operates with thermocouple types: K, Pt100, PT1000
Battery/ rechargeable battery: battery LR6 AA 1,5V x2

Hersteller: GOSSEN METRAWATT
Category: Portable digital multimeters
Description: Digital multimeter; IR; LCD; (60000); VDC: 60mV,600mV,6V,60V,600V
Continuity test: acoustic indication; <500Ω
Standard equipment: calibration certificate DAkkS; carrying strap; CP1800 - current clamp; hard case; shunt SR9800; test leads; user's manual
Measuring instrument features: auto and manual ranging; impact resistant holster; operates with thermocouple types: K, Pt100, PT1000
Power supply: battery LR6 AA 1,5V x2
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Conform to the norm: CAT III 600V; CAT IV 300V; EN 61010
Type of meter: digital multimeter
Test: diodes
IP rating: IP52
Interface: IR
Kind of display used: LCD
True effective value measurement: True RMS AC; True RMS AC+DC
Temperature measuring range: -150...1372°C
Capacitance measuring range: 60nF; 600nF; 6µF; 60µF; 600µF
AC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 6A; 10A
DC voltage measuring accuracy: ±(0.02% + 15 digit)
Frequency measuring accuracy: ±(0.05%+5 digit)
DC current measuring accuracy: ±(0.05% + 20 digit)
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V
Temperature measurement resolution: 0.1°C
Resistance measuring accuracy: ±(0.1%+5 digit)
Dimensions (W x H x D): 200x87x45mm
AC voltage measuring accuracy: ±(0.2% + 30 digit)
AC current measuring accuracy: ±(0.5% + 25 digit)
Capacitance measuring accuracy: ±(1%+ 6 digit)
Producer guarantee (months): 36
Weight with battery: 400g
Frequency measuring range: 600Hz; 6kHz; 60kHz; 300kHz
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Display parameters: (60000)
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; capacitance; conductance; crest factor; DC current; DC voltage; frequency; harmonics; power factor; reactive electric energy; reactive power; resistance; temperature
