Produkte > EPCOS - TDK ELECTRONICS > Alle Produkte des Herstellers EPCOS - TDK ELECTRONICS (24367) > Seite 407 nach 407
| Foto | Bezeichnung | Hersteller | Beschreibung |
Verfügbarkeit |
Preis |
||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| B66421U0160K197 | EPCOS - TDK Electronics |
Description: EFD25/13/9 N97 160 +10% Tolerance: ±10% Packaging: Bulk Material: N97 Length: 0.984" (25.00mm) Width: 0.358" (9.10mm) Height: 0.492" (12.50mm) Core Type: EFD Supplier Device Package: EFD 25 x 13 x 9 Inductance Factor (Al): 160 nH Finish: Uncoated Gap: Gapped Effective Permeability (µe): 125.0 Core Factor (ΣI/A) mm⁻¹: 0.98 Effective Length (le) mm: 57.0 Effective Area (Ae) mm²: 58.0 Minimum Core Cross Section (Amin) mm²: 57.0 Effective Magnetic Volume (Ve) mm³: 3310.0 |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | |||||||||||||||
 |
B43610B5128M050 | EPCOS - TDK Electronics |
 Description: 450V, 1200UF (M), D40X65Packaging: Bulk Tolerance: ±20% Package / Case: Radial, Can - Snap-In - 4 Lead Size / Dimension: 1.575" Dia (40.00mm) Polarization: Polar Mounting Type: Through Hole Operating Temperature: -40°C ~ 85°C Applications: General Purpose Lead Spacing: 0.886" (22.50mm) ESR (Equivalent Series Resistance): 100mOhm @ 100Hz Lifetime @ Temp.: 5000 Hrs @ 85°C Height - Seated (Max): 2.638" (67.00mm) Capacitance: 1.2 mF Voltage - Rated: 450 V Impedance: 160 mOhms Ripple Current @ Low Frequency: 5.33 A @ 100 Hz |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | ||||||||||||||
|
|
B43610B5158M050 | EPCOS - TDK Electronics |
Description: 450V, 1500UF (M), D40X75 Packaging: Bulk Tolerance: ±20% Package / Case: Radial, Can - Snap-In - 4 Lead Size / Dimension: 1.575" Dia (40.00mm) Polarization: Polar Mounting Type: Through Hole Operating Temperature: -40°C ~ 85°C Applications: General Purpose Lead Spacing: 0.886" (22.50mm) ESR (Equivalent Series Resistance): 80mOhm @ 100Hz Lifetime @ Temp.: 5000 Hrs @ 85°C Height - Seated (Max): 3.031" (77.00mm) Capacitance: 1.5 mF Voltage - Rated: 450 V Impedance: 130 mOhms Ripple Current @ Low Frequency: 6.28 A @ 100 Hz |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | ||||||||||||||
 |
B43613B5128M050 | EPCOS - TDK Electronics |
Description: 450V, 1200UF (M), D45X65 Tolerance: ±20% Packaging: Bulk Package / Case: Radial, Can - Snap-In - 4 Lead Size / Dimension: 1.772" Dia (45.00mm) Polarization: Polar Mounting Type: Through Hole Operating Temperature: -40°C ~ 105°C Applications: General Purpose Lead Spacing: 0.886" (22.50mm) ESR (Equivalent Series Resistance): 80mOhm @ 100Hz Lifetime @ Temp.: 5000 Hrs @ 105°C Height - Seated (Max): 2.638" (67.00mm) Capacitance: 1.2 mF Voltage - Rated: 450 V Impedance: 130 mOhms Ripple Current @ Low Frequency: 4.85 A @ 100 Hz |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | ||||||||||||||
|
|
B43613B5188M050 | EPCOS - TDK Electronics |
Description: 450V, 1800UF (M), D50X80 Tolerance: ±20% Packaging: Bulk Package / Case: Radial, Can - Snap-In - 4 Lead Size / Dimension: 1.969" Dia (50.00mm) Polarization: Polar Mounting Type: Through Hole Operating Temperature: -40°C ~ 105°C Applications: General Purpose Lead Spacing: 0.886" (22.50mm) ESR (Equivalent Series Resistance): 55mOhm @ 100Hz Lifetime @ Temp.: 5000 Hrs @ 105°C Height - Seated (Max): 3.228" (82.00mm) Capacitance: 1.8 mF Voltage - Rated: 450 V Impedance: 85 mOhms Ripple Current @ Low Frequency: 6.37 A @ 100 Hz |
Produkt ist nicht verfügbar |
Im Einkaufswagen Stück im Wert von UAH | ||||||||||||||
 |
B65525J0000R049 | EPCOS - TDK Electronics |
Description: FERRITE CORE ER 800NH N49 2PCS Tolerance: -20%, +30% Packaging: Tape & Reel (TR) Material: N49 Length: 0.433" (11.00mm) Width: 0.236" (6.00mm) Height: 0.098" (2.50mm) Core Type: ER Supplier Device Package: ER 11 x 5 Inductance Factor (Al): 800 nH Finish: Uncoated Gap: Ungapped Effective Permeability (µe): 715.0 Core Factor (ΣI/A) mm⁻¹: 1.1 Effective Length (le) mm: 14.1 Effective Area (Ae) mm²: 12.4 Effective Magnetic Volume (Ve) mm³: 174.0 |
auf Bestellung 7000 Stücke: Lieferzeit 10-14 Tag (e) |
|
||||||||||||||
|
|
B65525J0000R049 | EPCOS - TDK Electronics |
Description: FERRITE CORE ER 800NH N49 2PCS Tolerance: -20%, +30% Packaging: Cut Tape (CT) Material: N49 Length: 0.433" (11.00mm) Width: 0.236" (6.00mm) Height: 0.098" (2.50mm) Core Type: ER Supplier Device Package: ER 11 x 5 Inductance Factor (Al): 800 nH Finish: Uncoated Gap: Ungapped Effective Permeability (µe): 715.0 Core Factor (ΣI/A) mm⁻¹: 1.1 Effective Length (le) mm: 14.1 Effective Area (Ae) mm²: 12.4 Effective Magnetic Volume (Ve) mm³: 174.0 |
auf Bestellung 7362 Stücke: Lieferzeit 10-14 Tag (e) |
|
| B66421U0160K197 |
Hersteller: EPCOS - TDK Electronics
Description: EFD25/13/9 N97 160 +10%
Tolerance: ±10%
Packaging: Bulk
Material: N97
Length: 0.984" (25.00mm)
Width: 0.358" (9.10mm)
Height: 0.492" (12.50mm)
Core Type: EFD
Supplier Device Package: EFD 25 x 13 x 9
Inductance Factor (Al): 160 nH
Finish: Uncoated
Gap: Gapped
Effective Permeability (µe): 125.0
Core Factor (ΣI/A) mm⁻¹: 0.98
Effective Length (le) mm: 57.0
Effective Area (Ae) mm²: 58.0
Minimum Core Cross Section (Amin) mm²: 57.0
Effective Magnetic Volume (Ve) mm³: 3310.0
Description: EFD25/13/9 N97 160 +10%
Tolerance: ±10%
Packaging: Bulk
Material: N97
Length: 0.984" (25.00mm)
Width: 0.358" (9.10mm)
Height: 0.492" (12.50mm)
Core Type: EFD
Supplier Device Package: EFD 25 x 13 x 9
Inductance Factor (Al): 160 nH
Finish: Uncoated
Gap: Gapped
Effective Permeability (µe): 125.0
Core Factor (ΣI/A) mm⁻¹: 0.98
Effective Length (le) mm: 57.0
Effective Area (Ae) mm²: 58.0
Minimum Core Cross Section (Amin) mm²: 57.0
Effective Magnetic Volume (Ve) mm³: 3310.0
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| B43610B5128M050 |
|
Hersteller: EPCOS - TDK Electronics
Description: 450V, 1200UF (M), D40X65
Packaging: Bulk
Tolerance: ±20%
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.575" Dia (40.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 100mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 85°C
Height - Seated (Max): 2.638" (67.00mm)
Capacitance: 1.2 mF
Voltage - Rated: 450 V
Impedance: 160 mOhms
Ripple Current @ Low Frequency: 5.33 A @ 100 Hz
Description: 450V, 1200UF (M), D40X65
Packaging: Bulk
Tolerance: ±20%
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.575" Dia (40.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 100mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 85°C
Height - Seated (Max): 2.638" (67.00mm)
Capacitance: 1.2 mF
Voltage - Rated: 450 V
Impedance: 160 mOhms
Ripple Current @ Low Frequency: 5.33 A @ 100 Hz
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| B43610B5158M050 |
|
Hersteller: EPCOS - TDK Electronics
Description: 450V, 1500UF (M), D40X75
Packaging: Bulk
Tolerance: ±20%
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.575" Dia (40.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 80mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 85°C
Height - Seated (Max): 3.031" (77.00mm)
Capacitance: 1.5 mF
Voltage - Rated: 450 V
Impedance: 130 mOhms
Ripple Current @ Low Frequency: 6.28 A @ 100 Hz
Description: 450V, 1500UF (M), D40X75
Packaging: Bulk
Tolerance: ±20%
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.575" Dia (40.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 80mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 85°C
Height - Seated (Max): 3.031" (77.00mm)
Capacitance: 1.5 mF
Voltage - Rated: 450 V
Impedance: 130 mOhms
Ripple Current @ Low Frequency: 6.28 A @ 100 Hz
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| B43613B5128M050 |
|
Hersteller: EPCOS - TDK Electronics
Description: 450V, 1200UF (M), D45X65
Tolerance: ±20%
Packaging: Bulk
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.772" Dia (45.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 105°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 80mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 105°C
Height - Seated (Max): 2.638" (67.00mm)
Capacitance: 1.2 mF
Voltage - Rated: 450 V
Impedance: 130 mOhms
Ripple Current @ Low Frequency: 4.85 A @ 100 Hz
Description: 450V, 1200UF (M), D45X65
Tolerance: ±20%
Packaging: Bulk
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.772" Dia (45.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 105°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 80mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 105°C
Height - Seated (Max): 2.638" (67.00mm)
Capacitance: 1.2 mF
Voltage - Rated: 450 V
Impedance: 130 mOhms
Ripple Current @ Low Frequency: 4.85 A @ 100 Hz
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| B43613B5188M050 |
|
Hersteller: EPCOS - TDK Electronics
Description: 450V, 1800UF (M), D50X80
Tolerance: ±20%
Packaging: Bulk
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.969" Dia (50.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 105°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 55mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 105°C
Height - Seated (Max): 3.228" (82.00mm)
Capacitance: 1.8 mF
Voltage - Rated: 450 V
Impedance: 85 mOhms
Ripple Current @ Low Frequency: 6.37 A @ 100 Hz
Description: 450V, 1800UF (M), D50X80
Tolerance: ±20%
Packaging: Bulk
Package / Case: Radial, Can - Snap-In - 4 Lead
Size / Dimension: 1.969" Dia (50.00mm)
Polarization: Polar
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 105°C
Applications: General Purpose
Lead Spacing: 0.886" (22.50mm)
ESR (Equivalent Series Resistance): 55mOhm @ 100Hz
Lifetime @ Temp.: 5000 Hrs @ 105°C
Height - Seated (Max): 3.228" (82.00mm)
Capacitance: 1.8 mF
Voltage - Rated: 450 V
Impedance: 85 mOhms
Ripple Current @ Low Frequency: 6.37 A @ 100 Hz
Produkt ist nicht verfügbar
Im Einkaufswagen
Stück im Wert von UAH
| B65525J0000R049 |
|
Hersteller: EPCOS - TDK Electronics
Description: FERRITE CORE ER 800NH N49 2PCS
Tolerance: -20%, +30%
Packaging: Tape & Reel (TR)
Material: N49
Length: 0.433" (11.00mm)
Width: 0.236" (6.00mm)
Height: 0.098" (2.50mm)
Core Type: ER
Supplier Device Package: ER 11 x 5
Inductance Factor (Al): 800 nH
Finish: Uncoated
Gap: Ungapped
Effective Permeability (µe): 715.0
Core Factor (ΣI/A) mm⁻¹: 1.1
Effective Length (le) mm: 14.1
Effective Area (Ae) mm²: 12.4
Effective Magnetic Volume (Ve) mm³: 174.0
Description: FERRITE CORE ER 800NH N49 2PCS
Tolerance: -20%, +30%
Packaging: Tape & Reel (TR)
Material: N49
Length: 0.433" (11.00mm)
Width: 0.236" (6.00mm)
Height: 0.098" (2.50mm)
Core Type: ER
Supplier Device Package: ER 11 x 5
Inductance Factor (Al): 800 nH
Finish: Uncoated
Gap: Ungapped
Effective Permeability (µe): 715.0
Core Factor (ΣI/A) mm⁻¹: 1.1
Effective Length (le) mm: 14.1
Effective Area (Ae) mm²: 12.4
Effective Magnetic Volume (Ve) mm³: 174.0
auf Bestellung 7000 Stücke:
Lieferzeit 10-14 Tag (e)| Anzahl | Preis |
|---|---|
| 1000+ | 1.32 EUR |
| B65525J0000R049 |
|
Hersteller: EPCOS - TDK Electronics
Description: FERRITE CORE ER 800NH N49 2PCS
Tolerance: -20%, +30%
Packaging: Cut Tape (CT)
Material: N49
Length: 0.433" (11.00mm)
Width: 0.236" (6.00mm)
Height: 0.098" (2.50mm)
Core Type: ER
Supplier Device Package: ER 11 x 5
Inductance Factor (Al): 800 nH
Finish: Uncoated
Gap: Ungapped
Effective Permeability (µe): 715.0
Core Factor (ΣI/A) mm⁻¹: 1.1
Effective Length (le) mm: 14.1
Effective Area (Ae) mm²: 12.4
Effective Magnetic Volume (Ve) mm³: 174.0
Description: FERRITE CORE ER 800NH N49 2PCS
Tolerance: -20%, +30%
Packaging: Cut Tape (CT)
Material: N49
Length: 0.433" (11.00mm)
Width: 0.236" (6.00mm)
Height: 0.098" (2.50mm)
Core Type: ER
Supplier Device Package: ER 11 x 5
Inductance Factor (Al): 800 nH
Finish: Uncoated
Gap: Ungapped
Effective Permeability (µe): 715.0
Core Factor (ΣI/A) mm⁻¹: 1.1
Effective Length (le) mm: 14.1
Effective Area (Ae) mm²: 12.4
Effective Magnetic Volume (Ve) mm³: 174.0
auf Bestellung 7362 Stücke:
Lieferzeit 10-14 Tag (e)| Anzahl | Preis |
|---|---|
| 5+ | 3.68 EUR |
| 10+ | 2.54 EUR |
| 25+ | 2.17 EUR |
| 50+ | 1.91 EUR |
| 100+ | 1.67 EUR |
| 250+ | 1.38 EUR |
| 500+ | 1.32 EUR |
