Produkte > UNI-T > Alle Produkte des Herstellers UNI-T (595) > Seite 7 nach 10

Hersteller: UNI-T
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 60MHz; LCD TFT 5,7"; Ch: 2; 250Msps; ≤5.8ns
Type of oscilloscope: handheld oscilloscope
Band: 60MHz
Kind of display used: LCD TFT 5,7"
Number of channels: 2
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Sampling: 250Msps
Memory record length: 7.5kpts
Time base: 5n...50s/div
Display resolution: 320x240
Trigger: alternate; falling-edge; impulse width; rising-edge
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(1% + 5 digit)
DC current measuring range: 6mA; 60mA; 600mA; 6A
DC current measuring accuracy: ±(1.2% + 5 digit); ±(1.5% + 5 digit) @6A
AC voltage measuring range: 600mV; 6V; 60V; 600V; 700V
AC voltage measuring accuracy: ±(1.2% + 5 digit)
AC current measuring accuracy: ±(2% + 5 digit); ±(2.5% + 5 digit)@6A
AC current measuring range: 6mA; 60mA; 600mA; 6A
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(600Ω); ±(1.5%+5 digit)@(6MΩ); ±(1.5%+5 digit)@(60MΩ)
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF
Capacitance measuring accuracy: ±(4%+ 5 digit); ±(5%+10 digit) @ 6nF...6mF
Rise time: ≤5.8ns
Input sensitivity: 5mV/div...50V/div
Interface: USB Host; USB OTG
Power supply: rechargeable battery Li-Ion 7,4V 4400mAh x1
Dimensions: 268x168x60mm
Measuring instrument features: automatic measurement of many parameters; multimeter function
Standard equipment: adapter DC; mains cable; shunt x2; test probe x2
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 4400mAh x1
Display parameters: (5999)

Hersteller: UNI-T
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 100MHz; LCD TFT 5,7"; Ch: 2; 500Msps
Display parameters: (5999)
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Standard equipment: adapter DC; mains cable; shunt x2; test probe x2
Trigger: alternate; falling-edge; impulse width; rising-edge
Measuring instrument features: automatic measurement of many parameters; multimeter function
Type of oscilloscope: handheld oscilloscope
Kind of display used: LCD TFT 5,7"
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 4400mAh x1
Power supply: rechargeable battery Li-Ion 7,4V 4400mAh x1
Interface: USB Host; USB OTG
Rise time: ≤3.5ns
Time base: 5n...50s/div
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF
Input sensitivity: 5mV/div...50V/div
DC current measuring range: 6mA; 60mA; 600mA; 6A
AC current measuring range: 6mA; 60mA; 600mA; 6A
Dimensions: 268x168x60mm
AC voltage measuring range: 600mV; 6V; 60V; 600V; 700V
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
Number of channels: 2
DC voltage measuring accuracy: ±(1% + 5 digit)
AC voltage measuring accuracy: ±(1.2% + 5 digit)
DC current measuring accuracy: ±(1.2% + 5 digit); ±(1.5% + 5 digit) @6A
Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(600Ω); ±(1.5%+5 digit)@(6MΩ); ±(1.5%+5 digit)@(60MΩ)
AC current measuring accuracy: ±(2% + 5 digit); ±(2.5% + 5 digit)@6A
Capacitance measuring accuracy: ±(4%+ 5 digit); ±(5%+10 digit) @ 6nF...6mF
Display resolution: 320x240
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Memory record length: 7.5kpts
Band: 100MHz
Sampling: 500Msps

Hersteller: UNI-T
Category: Portable Oscilloscopes, Scopemeters
Description: Handheld oscilloscope; 200MHz; LCD TFT 5,7"; Ch: 2; 1Gsps; 7.5kpts
Type of oscilloscope: handheld oscilloscope
Number of channels: 2
Band: 200MHz
Sampling: 1Gsps
Memory record length: 7.5kpts
Kind of display used: LCD TFT 5,7"
Trigger: alternate; falling-edge; impulse width; rising-edge
Time base: 5n...50s/div
Interface: USB Host
Rise time: ≤1.8ns
Input sensitivity: 5mV/div...50V/div
Measuring instrument features: automatic measurement of many parameters; multimeter function
Standard equipment: adapter DC; mains cable; shunt x2; test probe x2
Display resolution: 320x240
Power supply: rechargeable battery Li-Ion 7,4V 4400mAh x1
Capacitance measuring range: 6nF; 60nF; 600nF; 6µF; 60µF; 600µF; 6mF
AC current measuring range: 6mA; 60mA; 600mA; 6A
DC current measuring range: 6mA; 60mA; 600mA; 6A
Dimensions: 268x168x60mm
AC voltage measuring range: 600mV; 6V; 60V; 600V; 700V
DC voltage measuring range: 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(1% + 5 digit)
Resistance measuring accuracy: ±(1.2%+5 digit); ±(1.5%+5 digit)@(600Ω); ±(1.5%+5 digit)@(6MΩ); ±(1.5%+5 digit)@(60MΩ)
AC voltage measuring accuracy: ±(1.5% + 5 digit)
DC current measuring accuracy: ±(1.2% + 5 digit); ±(1.5% + 5 digit) @6A
AC current measuring accuracy: ±(2% + 5 digit); ±(2.5% + 5 digit)@6A
Capacitance measuring accuracy: ±(4%+ 5 digit); ±(5%+10 digit) @ 6nF...6mF
Measurement: AC current; AC voltage; capacitance; DC current; DC voltage; resistance
Resistance measuring range: 600Ω; 6kΩ; 60kΩ; 600kΩ; 6MΩ; 60MΩ
Display parameters: (5999)
Battery/ rechargeable battery: rechargeable battery Li-Ion 7,4V 4400mAh x1

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 50MHz; 1Gsps; 64kpts; 2n÷50s/div; ≤7ns
Type of oscilloscope: digital
Number of channels: 2
Band: 50MHz
Sampling: 1Gsps
Memory record length: 64kpts
Kind of display used: colour; LCD TFT 7"
Trigger: alternative; falling-edge; impulse width; rising-edge; video signal
Time base: 2n...50s/div
Input coupling: AC, DC, GND
Interface: USB
Rise time: ≤7ns
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...20V/div
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Dimensions: 306x138x124mm
Supply voltage: 100...240V AC
Vertical resolution: 8bit

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 50MHz; 500Msps; 64kpts; 2n÷50s/div
Type of oscilloscope: digital
Number of channels: 2
Band: 50MHz
Sampling: 500Msps
Memory record length: 64kpts
Kind of display used: LCD TFT 7"; LED
Trigger: alternative; falling-edge; impulse width; rising-edge; video signal
Time base: 2n...50s/div
Input coupling: AC, DC, GND
Interface: USB device; USB Host
Rise time: ≤7ns
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...20V/div
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, multiplification, division and signal phase reversing
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Dimensions: 306x138x124mm
Supply voltage: 100...240V AC
Display resolution: 800x480

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 70MHz; 500Msps; 64kpts; 2n÷50s/div
Type of oscilloscope: digital
Number of channels: 2
Band: 70MHz
Sampling: 500Msps
Memory record length: 64kpts
Kind of display used: colour; LCD TFT 7"
Trigger: alternative; falling-edge; impulse width; rising-edge; video signal
Time base: 2n...50s/div
Max. input voltage: 400V
Input coupling: AC, DC, GND
Interface: USB
Rise time: ≤5ns
Input impedance: 1MΩ/24pF
Input sensitivity: 1mV/div...20V/div
Measuring instrument features: automatic measurement of many parameters; mathematical functions: addition, subtraction, division, multiplication and FFT
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Dimensions: 306x138x124mm
Supply voltage: 100...240V AC

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 64kpts; 2n÷50s/div
Kind of display used: colour; LCD TFT 7"
Type of oscilloscope: digital
Software: included
Time base: 2n...50s/div
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...20V/div
Dimensions: 306x147x122mm
Number of channels: 2
Supply voltage: 100...240V AC
Max. input voltage: 400V
Memory record length: 64kpts
Input impedance: 1MΩ/18pF
Band: 100MHz
Sampling: 1Gsps
Input coupling: AC, DC, GND
Standard equipment: mains cable; oscilloscope probe x3; USB cable
Trigger: alternative; falling-edge; impulse width; rising-edge
Measuring instrument features: automatic measurement of many parameters
Interface: USB

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 500Msps; 64kpts; 2n÷50s/div
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 500Msps
Memory record length: 64kpts
Kind of display used: colour; LCD TFT 7"
Trigger: alternative; falling-edge; impulse width; rising-edge; video signal
Time base: 2n...50s/div
Max. input voltage: 400V
Input coupling: AC, DC, GND
Interface: USB
Rise time: ≤3.5ns
Input impedance: 1MΩ/18pF
Input sensitivity: 1mV/div...20V/div
Measuring instrument features: automatic measurement of many parameters; defined part of displayed signal zoom
Standard equipment: mains cable; oscilloscope probe x2
Supply voltage: 100...240V AC
Dimensions: 306x138x124mm

Hersteller: UNI-T
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 64kpts; 2n÷50s/div
Input coupling: AC, DC, GND
Standard equipment: mains cable; oscilloscope probe x2; USB cable
Trigger: alternative; falling-edge; impulse width; rising-edge
Measuring instrument features: automatic measurement of many parameters
Kind of display used: colour; LCD TFT 7"
Type of oscilloscope: digital
Interface: USB
Rise time: ≤1.8ns
Time base: 2n...50s/div
Input sensitivity: 1mV/div...20V/div
Dimensions: 306x138x124mm
Number of channels: 2
Supply voltage: 100...240V AC
Max. input voltage: 400V
Memory record length: 64kpts
Input impedance: 1MΩ/18pF
Band: 200MHz
Sampling: 1Gsps

Hersteller: UNI-T
Category: Power Meters and Analyzers
Description: Meter: power; LCD TFT 4,3"; 20A; 600V; Support: Modbus,SCPI
Type of meter: power
Measurement: AC current; active power; AC voltage; apparent power; DC current; DC voltage; frequency
Kind of display used: LCD TFT 4,3"
Maximum current: 20A
Max. voltage: 600V
Interface: Ethernet; GPIB; RS232; USB
Standard equipment: 2 crocodile clips; guard; mains cable; test leads ( 2pcs.)
Support: Modbus; SCPI

Hersteller: UNI-T
Category: Power Meters and Analyzers
Description: Meter: power; LCD TFT 4,3"; 50A; 1kV; Support: Modbus,SCPI
Type of meter: power
Measurement: AC current; active power; AC voltage; apparent power; DC current; DC voltage; frequency
Kind of display used: LCD TFT 4,3"
Maximum current: 50A
Max. voltage: 1kV
Interface: Ethernet; GPIB; RS232; USB
Standard equipment: 2 crocodile clips; guard; mains cable; test leads ( 2pcs.)
Support: Modbus; SCPI

Hersteller: UNI-T
Category: Power Meters and Analyzers
Description: Meter: power; LCD; True RMS AC,True RMS AC+DC; 20A; 600V; 40÷400Hz
Kind of display used: LCD
Measuring instrument features: auto and manual ranging; possibility of displaying many readouts on single screen; programmable alarm thresholds
Dimensions: 214x88x340mm
Supply voltage: 100...240V AC
Type of meter: power
Interface: RS232; RS485
Support: SCPI
True effective value measurement: True RMS AC; True RMS AC+DC
Maximum current: 20A
Frequency: 40...400Hz
Max. voltage: 600V
Measurement: AC current; active power; AC voltage; DC current; DC voltage; frequency; power factor
Standard equipment: mains cable

Hersteller: UNI-T
Category: Power Meters and Analyzers
Description: Meter: power; LCD; True RMS AC; 10A; 600V; 40÷70Hz; 100÷240VAC
Kind of display used: LCD
Measuring instrument features: auto and manual ranging; possibility of displaying many readouts on single screen; programmable alarm thresholds
Dimensions: 214x88x340mm
Supply voltage: 100...240V AC
Type of meter: power
Interface: RS232; RS485
Support: SCPI
True effective value measurement: True RMS AC
Maximum current: 10A
Frequency: 40...70Hz
Max. voltage: 600V
Measurement: AC current; active power; AC voltage; apparent power; DC current; DC voltage; frequency; power factor
Standard equipment: mains cable

Hersteller: UNI-T
Category: Power Meters and Analyzers
Description: Meter: power; LCD; True RMS AC; 20A; 600V; 40÷400Hz; 100÷240VAC
Kind of display used: LCD
Measuring instrument features: auto and manual ranging; possibility of displaying many readouts on single screen; programmable alarm thresholds
Dimensions: 214x88x340mm
Supply voltage: 100...240V AC
Type of meter: power
Interface: RS232; RS485
Support: SCPI
True effective value measurement: True RMS AC
Maximum current: 20A
Frequency: 40...400Hz
Max. voltage: 600V
Measurement: AC current; active power; AC voltage; apparent power; DC current; DC voltage; frequency; power factor; THD
Standard equipment: mains cable

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 20MHz; LCD TFT 4,3"; 480x272
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 20MHz
Waveform frequency range: 1µHz...5MHz (arbitrary waveform); 1µHz...10MHz (pulse waveform); 1µHz...10MHz (rectangular waveform); 1µHz...20MHz (sinus waveform); 1µHz...400kHz (ramp waveform)
Kind of display used: LCD TFT 4,3"
Display resolution: 480x272
Number of channels: 2
Vertical resolution: 16bit
Output parameters: impedance: 50Ω
Dimensions: 215x103x316mm
Interface: USB
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Sampling: 200Msps
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Measuring instrument features: 200 runs memory
Supply voltage: 100...240V AC

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 20MHz; LCD TFT 4,3"; 480x272
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 20MHz
Waveform frequency range: 1µHz...5MHz (arbitrary waveform); 1µHz...10MHz (pulse waveform); 1µHz...10MHz (rectangular waveform); 1µHz...20MHz (sinus waveform); 1µHz...400kHz (ramp waveform)
Kind of display used: LCD TFT 4,3"
Display resolution: 480x272
Number of channels: 2
Vertical resolution: 16bit
Output parameters: impedance: 50Ω
Dimensions: 215x103x316mm
Interface: USB
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Sampling: 200Msps
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Measuring instrument features: 4 Watt power output, <100kHz; 200 runs memory
Supply voltage: 100...240V AC

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 40MHz; LCD TFT 4,3"; 480x272
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Output parameters: impedance: 50Ω
Kind of display used: LCD TFT 4,3"
Interface: USB
Dimensions: 215x103x316mm
Number of channels: 2
Vertical resolution: 16bit
Supply voltage: 100...240V AC
Display resolution: 480x272
Maximum waveform frequency: 40MHz
Waveform frequency range: 1µHz...1MHz (ramp waveform); 1µHz...20MHz (pulse waveform); 1µHz...20MHz (square waveform); 1µHz...40MHz (sinus waveform)
Sampling: 200Msps
Measuring instrument features: 200 runs memory
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 25MHz; LCD TFT 4,3"; 480x272
Supply voltage: 100...240V AC
Standard equipment: cable BNC-BNC x2; mains cable; USB cable
Kind of display used: LCD TFT 4,3"
Dimensions: 265x110x320mm
Number of channels: 2
Vertical resolution: 14bit
Display resolution: 480x272
Maximum waveform frequency: 25MHz
Waveform frequency range: 1µHz...5MHz (arbitrary waveform); 1µHz...5MHz (pulse waveform); 1µHz...5MHz (rectangular waveform); 1µHz...25MHz (sinus waveform); 1µHz...400kHz (ramp waveform)
Sampling: 125Msps
Kind of modulation: AM; ASK; FM; FSK; PM; PSK; PWM
Interface: USB
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD TFT 4,3"; 800x480
Supply voltage: 100...240V AC
Standard equipment: BNC cable; USB cable
Kind of display used: LCD TFT 4,3"
Dimensions: 305x230x93mm
Number of channels: 2
Vertical resolution: 16bit
Display resolution: 800x480
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...15MHz (arbitrary waveform); 1µHz...20MHz (pulse waveform); 1µHz...25MHz (square waveform); 1µHz...60MHz (sinus waveform)
Sampling: 320Msps
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Interface: USB
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; 480x272; Ch: 2; 100÷240VAC
Supply voltage: 100...240V AC
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Output parameters: impedance: 50Ω
Kind of display used: LCD TFT 4,3"; touch screen
Dimensions: 215x103x316mm
Number of channels: 2
Vertical resolution: 16bit
Display resolution: 480x272
Maximum waveform frequency: 60MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...30MHz (arbitrary waveform); 1µHz...30MHz (harmonic waveform); 1µHz...30MHz (pulse waveform); 1µHz...30MHz (square waveform); 1µHz...60MHz (sinus waveform)
Sampling: 625Msps
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Interface: LAN; USB device; USB Host
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD TFT 4,3"; 800x480
Supply voltage: 100...240V AC
Standard equipment: BNC cable; USB cable
Kind of display used: LCD TFT 4,3"
Dimensions: 305x230x93mm
Number of channels: 2
Vertical resolution: 16bit
Display resolution: 800x480
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...4MHz (ramp waveform); 1µHz...20MHz (arbitrary waveform); 1µHz...25MHz (pulse waveform); 1µHz...25MHz (square waveform); 1µHz...80MHz (sinus waveform)
Sampling: 320Msps
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Interface: USB
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; 480x272; Ch: 2; 100÷240VAC
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...4MHz (ramp waveform); 1µHz...40MHz (arbitrary waveform); 1µHz...40MHz (harmonic waveform); 1µHz...40MHz (pulse waveform); 1µHz...40MHz (square waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD TFT 4,3"; touch screen
Display resolution: 480x272
Number of channels: 2
Vertical resolution: 16bit
Output parameters: impedance: 50Ω
Dimensions: 215x103x316mm
Interface: LAN; USB device; USB Host
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Sampling: 625Msps
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Supply voltage: 100...240V AC

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 120MHz; LCD TFT 4,3"; 800x480
Standard equipment: BNC cable; USB cable
Kind of display used: LCD TFT 4,3"
Dimensions: 305x230x93mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 16bit
Display resolution: 800x480
Maximum waveform frequency: 120MHz
Waveform frequency range: 1µHz...2MHz (arbitrary waveform); 1µHz...5MHz (ramp waveform); 1µHz...30MHz (pulse waveform); 1µHz...30MHz (square waveform); 1µHz...120MHz (sinus waveform)
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Sampling: 320Msps
Interface: USB
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 120MHz; 480x272; Ch: 2; 100÷240VAC
Standard equipment: BNC-BNC cable; BNC cable - crocodile clip; mains cable; USB cable
Output parameters: impedance: 50Ω
Kind of display used: LCD TFT 4,3"; touch screen
Dimensions: 215x103x316mm
Number of channels: 2
Supply voltage: 100...240V AC
Vertical resolution: 16bit
Display resolution: 480x272
Maximum waveform frequency: 120MHz
Waveform frequency range: 1µHz...5MHz (ramp waveform); 1µHz...50MHz (arbitrary waveform); 1µHz...50MHz (harmonic waveform); 1µHz...50MHz (pulse waveform); 1µHz...50MHz (square waveform); 1µHz...120MHz (sinus waveform)
Kind of modulation: 3FSK; 4FSK; AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Sampling: 625Msps
Interface: LAN; USB device; USB Host
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 80MHz; LCD TFT 8"; 800x480; Ch: 2
Type of laboratory generator: arbitrary, function
Maximum waveform frequency: 80MHz
Waveform frequency range: 1µHz...2MHz (ramp waveform); 1µHz...20MHz (arbitrary waveform); 1µHz...30MHz (pulse waveform); 1µHz...30MHz (square waveform); 1µHz...80MHz (sinus waveform)
Kind of display used: LCD TFT 8"
Display resolution: 800x480
Number of channels: 2
Vertical resolution: 16bit
Dimensions: 336x164x108mm
Interface: USB
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Sampling: 500Msps
Standard equipment: cable BNC-BNC x2; mains cable; USB cable
Supply voltage: 100...240V AC

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 120MHz; LCD TFT 8"; 800x480; Ch: 2
Supply voltage: 100...240V AC
Standard equipment: cable BNC-BNC x2; mains cable; USB cable
Kind of display used: LCD TFT 8"
Dimensions: 336x164x108mm
Number of channels: 2
Vertical resolution: 16bit
Display resolution: 800x480
Maximum waveform frequency: 120MHz
Waveform frequency range: 1µHz...3MHz (ramp waveform); 1µHz...3MHz (triangle waveform); 1µHz...40MHz (pulse waveform); 1µHz...40MHz (rectangular waveform); 1µHz...120MHz (sinus waveform)
Sampling: 500Msps
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Interface: USB
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 30MHz; LCD TFT 4,3"; 480x272
Sampling: 200Msps
Waveform frequency range: 1µHz...10MHz (arbitrary waveform); 1µHz...15MHz (pulse waveform); 1µHz...15MHz (rectangular waveform); 1µHz...30MHz (sinus waveform); 1µHz...400kHz (ramp waveform)
Kind of modulation: AM; FM; FSK; PM
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function
Standard equipment: BNC cable - crocodile clip; mains cable; USB cable
Output parameters: impedance: 50Ω
Kind of display used: LCD TFT 4,3"
Interface: USB
Dimensions: 172x90x68mm
Number of channels: 2
Vertical resolution: 14bit
Supply voltage: 100...240V AC
Display resolution: 480x272
Maximum waveform frequency: 30MHz

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 350MHz; 1280x800; Ch: 4
Supply voltage: 100...240V AC
Standard equipment: BNC cable - crocodile clip; mains cable; USB cable
Communictions protocol: I2C; SPI; UART
Kind of display used: LCD TFT 10,1"; touch screen
Dimensions: 370x115x185mm
Number of channels: 4
Vertical resolution: 14bit
Display resolution: 1280x800
Maximum waveform frequency: 350MHz
Waveform frequency range: 1µHz...20MHz (ramp waveform); 1µHz...80MHz (arbitrary waveform); 1µHz...120MHz (pulse waveform); 1µHz...120MHz (rectangular waveform); 1µHz...350MHz (sinus waveform)
Sampling: 2,5Gsps
Kind of modulation: AM; ASK; BPSK; FM; FSK; OSK; PM; PSK; PWM; QAM; QPSK; SUM
Interface: LAN; USB
Waveforms: arbitrary; DC; harmonic; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function

Hersteller: UNI-T
Category: Generators and Frequency Meters
Description: Generator: arbitrary, function; 60MHz; LCD TFT 4,3"; 480x272
Sampling: 200Msps
Waveform frequency range: 1µHz...10MHz (arbitrary waveform); 1µHz...20MHz (pulse waveform); 1µHz...20MHz (rectangular waveform); 1µHz...60MHz (sinus waveform); 1µHz...400kHz (ramp waveform)
Kind of modulation: AM; FM; FSK; PM
Waveforms: arbitrary; DC; impulse; noise; ramp; sinus; square
Type of laboratory generator: arbitrary, function
Standard equipment: BNC cable - crocodile clip; mains cable; USB cable
Output parameters: impedance: 50Ω
Kind of display used: LCD TFT 4,3"
Interface: USB
Dimensions: 172x90x68mm
Number of channels: 2
Vertical resolution: 14bit
Supply voltage: 100...240V AC
Display resolution: 480x272
Maximum waveform frequency: 60MHz

Hersteller: UNI-T
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; passive; 200MHz; Uin max: 600V; 1.2m
Type of measuring probe: for oscilloscope
Kind of probe: passive
Band: 200MHz
Cable/adapter structure: angle plug BNC
Gear: 1:1; 10:1
Cable length: 1.2m
Test voltage: 300V; 600V
Max. input voltage: 600V

Hersteller: UNI-T
Category: Infrared Cameras - Others
Description: Infrared camera; LCD TFT 2,8"; 200x150; 9Hz; -10÷400°C; 35°x26°
Measuring instrument features: acoustic and optical alarm; wide palette of colours
Supported formats: BMP
Power supply: rechargeable battery Li-Ion 3,6V 5000mAh x1
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,6V 5000mAh x1
Standard equipment: manual (CD); microSD memory card; USB cable
Type of meter: infrared camera
Resistance to: fall from 2m height
IP rating: IP65
Kind of display used: LCD TFT 2,8"
Interface: microSD; USB
Temperature measuring range: -10...400°C
Thermal sensitivity (NETD): ≤100mK
Body dimensions: 236x75.5x86mm
Temperature measurement accuracy: ±2%; ±2°C
Refresh rate: 9Hz
Field of observation: 35° x 26°
Camera resolution: 200x150
Display resolution: 320x240
Emissivity value: 0,01...1

Hersteller: UNI-T
Category: Infrared Cameras - Others
Description: Infrared camera; LCD TFT 2,8"; 32x32; 9Hz; -20÷1000°C; 30°x30°
Power supply: rechargeable battery 3,7V 2600mAh x1
Battery/ rechargeable battery: rechargeable battery 3,7V 2600mAh x1
Standard equipment: microSD memory card; USB cable; user's manual
Type of meter: infrared camera
Kind of display used: LCD TFT 2,8"
Interface: microSD
Temperature measuring range: -20...1000°C
Thermal sensitivity (NETD): <150m°C
Body dimensions: 205x124x65mm
Temperature measurement accuracy: ±2%; ±2°C
Refresh rate: 9Hz
Field of observation: 30° x 30°
Camera resolution: 32x32
Display resolution: 640x480
Emissivity value: 0,01...1

Hersteller: UNI-T
Category: Infrared Cameras - Others
Description: Infrared camera; LCD TFT 3,5"; 320x240; 9Hz; -40÷400°C; 56°x42°
Related items: UT-Z003
Measuring instrument features: automatic power-off; wide palette of colours
Supported formats: JPG
Power supply: rechargeable battery Li-Ion 3,6V 5000mAh x1
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,6V 5000mAh x1
Standard equipment: microSD memory card; USB cable; user's manual
Type of meter: infrared camera
IP rating: IP54
Kind of display used: LCD TFT 3,5"
Interface: microSD; USB; WiFi
Temperature measuring range: -40...400°C
Thermal sensitivity (NETD): ≤65mK
Temperature measurement accuracy: ±2%; ±2°C
Refresh rate: 9Hz
Field of observation: 56° x 42°
Camera resolution: 320x240
Display resolution: 640x480
Emissivity value: 0,01...1

Hersteller: UNI-T
Category: Infrared Cameras - Others
Description: Infrared camera; LCD TFT 3,5"; 320x240; 9Hz; -40÷400°C; 56°x42°
Related items: UT-Z003
Measuring instrument features: alarms breach of limit values; digital zoom x2; digital zoom x4; transfer measurement data wireless; wide palette of colours
Supported formats: AVI; JPG
Power supply: rechargeable battery Li-Ion 3,7V 5200mAh x1
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V 5200mAh x2
Standard equipment: microSD memory card; USB cable; user's manual
Type of meter: infrared camera
Resistance to: fall from 2m height
IP rating: IP54
Kind of display used: LCD TFT 3,5"
Interface: microSD; USB; WiFi
Temperature measuring range: -40...400°C
Thermal sensitivity (NETD): ≤65mK
Body dimensions: 260x97x99mm
Temperature measurement accuracy: ±2%; ±2°C
Refresh rate: 9Hz
Field of observation: 56° x 42°
Camera resolution: 320x240
Display resolution: 640x480

Hersteller: UNI-T
Category: Test Leads - Sets
Description: Test leads; Umax: 600V; Imax: 10A; Len: 0.9m; black,red; 2pcs.
Type of test accessories: test leads
Max. voltage: 600V
Maximum current: 10A
Cable length: 0.9m
Test lead configuration: angular banana plug 4mm x2; probe tip x2
Colour: black; red
Conform to the norm: CAT II 600V; EN 61010
Quantity in set/package: 2pcs.

Hersteller: UNI-T
Category: Test Leads - Sets
Description: Test leads; Umax: 1kV; Imax: 10A; Len: 900mm; black,red; 2pcs.
Type of test accessories: test leads
Test lead configuration: angular banana plug 4mm x2; probe tip x2
Colour: black; red
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Bit length: 130mm
Cable length: 0.9m
Quantity in set/package: 2pcs.
Maximum current: 10A
Max. voltage: 1kV

Hersteller: UNI-T
Category: Distance Meters
Description: Distance meter; LCD; 4÷550m; Meas.accur: ±1m; Unit: yard,m; 7°
Interface: USB
Measuring instrument features: automatic power-off; low battery indicator
Type of meter: distance meter
Kind of meter: laser
Kind of display used: LCD
Measuring unit: m; yard
Battery/ rechargeable battery: rechargeable battery Li-Ion 3,7V x1
Power supply: rechargeable battery Li-Ion 3,7V x1
Standard equipment: USB cable; user's manual
Body dimensions: 114x78x46mm
Distance measurement range: 4...550m
Magnification: x6
Viewing angle: 7°
Measurement accuracy: ±1m

Hersteller: UNI-T
Category: Single Test Leads
Description: Test lead; 1kV; 10A; probe tip x2,angular banana plug 4mm x2
Type of test accessories: test lead
Max. voltage: 1kV
Maximum current: 10A
Test lead configuration: angular banana plug 4mm x2; probe tip x2
Colour: red
Conform to the norm: CAT II 1000V; EN 61010
Illumination: LED

Hersteller: UNI-T
Category: One Channel Power Supplies
Description: Power supply: laboratory; single-channel,linear; 0÷32VDC; 0÷3A
Type of laboratory power supply: laboratory
Kind of power supply: linear; single-channel
Kind of display used: LED
Number of channels: 1
Output voltage: 0...32V DC
Output current: 0...3A
Output voltage resolution: 0.1V
Output current resolution: 10mA
Measuring instrument features: automatic switching to constant voltage or constant current operation
Protection: anti-overload OPP
Dimensions: 145x175x284mm
Supply voltage: 100...240V AC
Voltage (regulated) ripple and noise: ≤1mVrms

Hersteller: UNI-T
Category: One Channel Power Supplies
Description: Power supply: laboratory; single-channel,linear; 0÷32VDC; 0÷5A
Type of laboratory power supply: laboratory
Kind of power supply: linear; single-channel
Kind of display used: LED
Number of channels: 1
Output voltage: 0...32V DC
Output current: 0...5A
Output voltage resolution: 0.1V
Output current resolution: 10mA
Measuring instrument features: automatic switching to constant voltage or constant current operation
Protection: anti-overload OPP
Dimensions: 145x175x284mm
Supply voltage: 100...240V AC
Voltage (regulated) ripple and noise: ≤1mVrms

Hersteller: UNI-T
Category: Multichannel Power Supplies
Description: Power supply: laboratory; linear,multi-channel; 0÷32VDC; 0÷3A
Type of laboratory power supply: laboratory
Kind of power supply: linear; multi-channel
Kind of display used: LED
Number of channels: 3
Output voltage 2: 0...32V DC
Output current: 0...3A
Output voltage resolution: 10mV
Output current resolution: 1mA
Protection: anti-overload OPP
Dimensions: 319x146x226mm
Supply voltage: 100...240V AC
Voltage (regulated) ripple and noise: ≤1mVrms
Output current 2: 0...3A
Output voltage: 0...32V DC
Output current 3: 3A
Output voltage 3: 5V DC
Display parameters: 4 digit
Measuring instrument features: automatic switching to constant voltage or constant current operation; MASTER and SLAVE - voltage and current tracking mode of outputs at serial or parallel operation

Hersteller: UNI-T
Category: Multichannel Power Supplies
Description: Power supply: laboratory; linear,multi-channel; 0÷32VDC; 0÷5A
Type of laboratory power supply: laboratory
Kind of power supply: linear; multi-channel
Kind of display used: LED
Number of channels: 3
Output voltage 2: 0...32V DC
Output current: 0...5A
Output voltage resolution: 10mV
Output current resolution: 1mA
Protection: anti-overload OPP
Dimensions: 319x146x226mm
Supply voltage: 100...240V AC
Voltage (regulated) ripple and noise: ≤1mVrms
Output current 2: 0...5A
Output voltage: 0...32V DC
Output current 3: 3A
Output voltage 3: 5V DC
Display parameters: 4 digit
Measuring instrument features: automatic switching to constant voltage or constant current operation; MASTER and SLAVE - voltage and current tracking mode of outputs at serial or parallel operation

Hersteller: UNI-T
Category: One Channel Power Supplies
Description: Power supply: laboratory; single-channel,linear; 0÷30VDC; 0÷3A
Type of laboratory power supply: laboratory
Kind of power supply: linear; single-channel
Kind of display used: LED
Number of channels: 1
Output voltage 2: 0...30V DC
Output current: 0...3A
Output voltage resolution: 10mV
Output current resolution: 1mA
Voltage stabilisation: ≤0.01%+ 3mV
Current stabilisation: ≤0.1%+ 5mA
Maximum power: 90W
Protection: anti-overload OPP; short circuit protection SCP
Dimensions: 105x155x210mm
Supply voltage: 100...240V AC
Voltage (regulated) ripple and noise: ≤1mVrms
Display parameters: 4 digit

Hersteller: UNI-T
Category: One Channel Power Supplies
Description: Power supply: laboratory; single-channel,linear; 0÷30VDC; 0÷5A
Protection: anti-overload OPP; anti-overvoltage OVP
Type of laboratory power supply: laboratory
Kind of display used: LED
Kind of power supply: linear; single-channel
Output current: 0...5A
Output voltage 2: 0...30V DC
Output current resolution: 1mA
Voltage (regulated) ripple and noise: ≤2mVrms
Output voltage resolution: 10mV
Voltage stabilisation: ≤0.01%+ 5mV
Dimensions: 105x160x240mm
Current stabilisation: ≤0.1%+ 10mA
Number of channels: 1
Supply voltage: 100...240V AC
Maximum power: 150W

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Probe: set of probes for EMI measurements
Type of measuring probe: set of probes for EMI measurements
Kit contents: cable SMA-SMB; carrying case; SMA (f) - N(m) adapter; test probe x4

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Spectrum analyzer; 0.009÷1500MHz; HDMI,LAN,USB; Resolution: 1Hz
Type of meter: spectrum analyzer
Frequency: 9kHz...1.5GHz
Interface: HDMI; LAN; USB
Resolution: 1Hz
Kind of display used: LCD TFT 10,1"; touch screen
Amplitude: reference level: -100dBm...30dBm
Dimensions: 378x218x120mm
Related items: UTS-EMI01
Standard equipment: USB cable
Display resolution: 1280x800
Supply voltage: 100/240V AC

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Spectrum analyzer; 0.009÷1500MHz; HDMI,LAN,USB; Resolution: 1Hz
Type of meter: spectrum analyzer
Frequency: 9kHz...1.5GHz
Interface: HDMI; LAN; USB
Resolution: 1Hz
Kind of display used: LCD TFT 10,1"; touch screen
Amplitude: reference level: -100dBm...30dBm
Dimensions: 378x218x120mm
Related items: UTS-EMI01
Standard equipment: USB cable
Display resolution: 1280x800
Supply voltage: 100/240V AC
Additional functions: tracking generator

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Spectrum analyzer; 0.009÷3200MHz; HDMI,LAN,USB; Resolution: 1Hz
Type of meter: spectrum analyzer
Frequency: 9kHz...3.2GHz
Interface: HDMI; LAN; USB
Resolution: 1Hz
Kind of display used: LCD TFT 10,1"; touch screen
Dimensions: 378x218x120mm
Standard equipment: USB cable
Display resolution: 1280x800
Supply voltage: 100/240V AC
Related items: UTS-EMI01
Amplitude: reference level: -100dBm...30dBm

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Measurement: analog demodulation

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Additional functions: advanced triggering function

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Measurement: analog demodulation
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Additional functions: advanced triggering function
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option; Additional functions: spectrum analysis
Type of test accessories: expansion option
Additional functions: spectrum analysis
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Measurement: EMI
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Additional functions: FDD-LTE triggering and decoding
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option; Additional functions: I/Q signals analyzer
Type of test accessories: expansion option
Additional functions: I/Q signals analyzer
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option; Additional functions: NR40 decode
Type of test accessories: expansion option
Additional functions: NR40 decode
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Additional functions: TDD-LTE triggering and decoding
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option; Additional functions: vector signal analysis
Type of test accessories: expansion option
Additional functions: vector signal analysis
Related items: UTS3036A; UTS3060A; UTS3084A

Hersteller: UNI-T
Category: Spectrum Analyzers
Description: Expansion option
Type of test accessories: expansion option
Measurement: analog demodulation
Related items: UTS3021B; UTS3036B
