Produkte > GW INSTEK > Alle Produkte des Herstellers GW INSTEK (608) > Seite 3 nach 11

Hersteller: GW INSTEK
Category: Benchtop digital multimeters
Description: Benchtop multimeter; colour,LCD TFT 4,3"; 6,5 digit (2000000)
Manufacturer series: GDM-9000
DC voltage measuring accuracy: ±(0.014% + 0.001% range)
Standard equipment: cable GTL-207; cable GTL-246; mains cable
Temperature measuring range (with T-type thermocouple): -200...1372°C
DC current measuring accuracy: ±(0.05% + 0.005% range)
Temperature measuring range with N-type thermocouple: -200...1372°C
Kind of display used: colour; LCD TFT 4,3"
Temperature measuring range (with R-type thermocouple): -50...1870°C
True effective value measurement: True RMS AC
DC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC current measuring accuracy: ±(0.13% + 0.04% range)
Sampling: 1000x/s
Display resolution: 480x272
Measurement memory: 10k
Temperature measuring range (with E-type thermocouple): -200...1372°C
AC voltage measuring range: 1...750V
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
Temperature measuring range (with J-type thermocouple): -200...1372°C
Interface: LAN; RS232; USB
Temperature measuring range (with S-type thermocouple): -50...1870°C
Resistance measuring accuracy: ±(0.014%+0.001% range)
AC voltage measuring accuracy: ±(0.09% + 0.04% range)
Type of meter: benchtop multimeter
Software: included
Measurement: AC current; AC voltage; DC current; DC voltage; resistance; resistance (2-wire); resistance (4-wire)
Display parameters: 6,5 digit (2000000)
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A
Temperature measuring range (with K-type thermocouple): -200...1372°C

Hersteller: GW INSTEK
Category: Benchtop digital multimeters
Description: Benchtop multimeter; colour,LCD TFT 4,3"; 6,5 digit (2000000)
Type of meter: benchtop multimeter
Kind of display used: colour; LCD TFT 4,3"
Display parameters: 6,5 digit (2000000)
True effective value measurement: True RMS AC
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring accuracy: ±(0.014% + 0.001% range)
AC voltage measuring range: 1...750V
AC voltage measuring accuracy: ±(0.09% + 0.04% range)
DC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
DC current measuring accuracy: ±(0.05% + 0.005% range)
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.014%+0.001% range)
Measurement: AC current; AC voltage; DC current; DC voltage; resistance; resistance (2-wire); resistance (4-wire)
Interface: GPIB; LAN; RS232; USB
Standard equipment: cable GTL-207; cable GTL-246; mains cable
Temperature measuring range with N-type thermocouple: -200...1372°C
Temperature measuring range (with R-type thermocouple): -50...1870°C
AC current measuring accuracy: ±(0.13% + 0.04% range)
Sampling: 1000x/s
Display resolution: 480x272
Measurement memory: 100000
Temperature measuring range (with E-type thermocouple): -200...1372°C
Temperature measuring range (with J-type thermocouple): -200...1372°C
Temperature measuring range (with S-type thermocouple): -50...1870°C
Software: included
Temperature measuring range (with K-type thermocouple): -200...1372°C
Manufacturer series: GDM-9000
Temperature measuring range (with T-type thermocouple): -200...1372°C

Hersteller: GW INSTEK
Category: Benchtop digital multimeters
Description: Benchtop multimeter; colour,LCD TFT 4,3"; 6,5 digit (2000000)
Manufacturer series: GDM-9000
DC voltage measuring accuracy: ±(0.01% + 0.001% range)
Standard equipment: cable GTL-207; cable GTL-246; mains cable
Temperature measuring range (with T-type thermocouple): -200...1372°C
DC current measuring accuracy: ±(0.05% + 0.005% range)
Temperature measuring range with N-type thermocouple: -200...1372°C
Kind of display used: colour; LCD TFT 4,3"
Temperature measuring range (with R-type thermocouple): -50...1870°C
True effective value measurement: True RMS AC
DC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
AC current measuring accuracy: ±(0.1% + 0.04% range)
Sampling: 10000x/s
Display resolution: 480x272
Measurement memory: 100000
Temperature measuring range (with E-type thermocouple): -200...1372°C
AC voltage measuring range: 1...750V
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
Temperature measuring range (with J-type thermocouple): -200...1372°C
Interface: LAN; RS232; USB
Temperature measuring range (with S-type thermocouple): -50...1870°C
Resistance measuring accuracy: ±(0.01%+0.001% range)
AC voltage measuring accuracy: ±(0.06% + 0.04% range)
Type of meter: benchtop multimeter
Software: included
Measurement: AC current; AC voltage; DC current; DC voltage; resistance; resistance (2-wire); resistance (4-wire)
Display parameters: 6,5 digit (2000000)
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A
Temperature measuring range (with K-type thermocouple): -200...1372°C

Hersteller: GW INSTEK
Description: GW INSTEK - GDM-9061 - Tisch-Digitalmultimeter, 6.5, Digital-I/O, LAN, RS232C, USB, 10 A, 750 V, 100 Mohm
tariffCode: 90303100
Messwert Gleichspannung, max.: 1kV
Messwert Wechselspannung, max.: 750V
Messwert Widerstand, max.: 100Mohm
euEccn: NLR
Messwert Gleichstrom, max.: 10A
rohsCompliant: Y-EX
hazardous: false
rohsPhthalatesCompliant: YES
isCanonical: Y
Netzsteckertyp: -
Herstellergewährleistung: -
SVHC: No SVHC (10-Jun-2022)
Anzahl der Stellen: 6.5
DMM-Funktionen: AC/DC-Strom, AC/DC-Spannung, Kapazität, Durchgang, Diode, Frequenz, Periode, Temperatur
DMM-Konnektivität: Digital-I/O, LAN, RS232C, USB
Produktpalette: GDM-906X Series
productTraceability: No
usEccn: 3A992.a
Messwert Wechselstrom, max.: 10A

Hersteller: GW INSTEK
Category: Benchtop digital multimeters
Description: Benchtop multimeter; colour,LCD TFT 4,3"; 6,5 digit (2000000)
Type of meter: benchtop multimeter
Kind of display used: colour; LCD TFT 4,3"
Display parameters: 6,5 digit (2000000)
True effective value measurement: True RMS AC
DC voltage measuring range: 100mV; 1V; 10V; 100V; 1kV
DC voltage measuring accuracy: ±(0.01% + 0.001% range)
AC voltage measuring range: 1...750V
AC voltage measuring accuracy: ±(0.06% + 0.04% range)
DC current measuring range: 100µA; 1mA; 10mA; 100mA; 1A; 10A
DC current measuring accuracy: ±(0.05% + 0.005% range)
AC current measuring range: 1mA; 10mA; 100mA; 1A; 10A
Resistance measuring range: 100Ω; 1kΩ; 10kΩ; 100kΩ; 1MΩ; 10MΩ; 100MΩ
Resistance measuring accuracy: ±(0.01%+0.001% range)
Measurement: AC current; AC voltage; DC current; DC voltage; resistance; resistance (2-wire); resistance (4-wire)
Interface: GPIB; LAN; RS232; USB
Standard equipment: cable GTL-207; cable GTL-246; mains cable
Temperature measuring range with N-type thermocouple: -200...1372°C
Temperature measuring range (with R-type thermocouple): -50...1870°C
AC current measuring accuracy: ±(0.1% + 0.04% range)
Sampling: 10000x/s
Display resolution: 480x272
Measurement memory: 100000
Temperature measuring range (with E-type thermocouple): -200...1372°C
Temperature measuring range (with J-type thermocouple): -200...1372°C
Temperature measuring range (with S-type thermocouple): -50...1870°C
Software: included
Temperature measuring range (with K-type thermocouple): -200...1372°C
Manufacturer series: GDM-9000
Temperature measuring range (with T-type thermocouple): -200...1372°C

Hersteller: GW INSTEK
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; active,differential; 15MHz(20: 1),25MHz
Type of measuring probe: for oscilloscope
Measuring instruments application: for GW Instek oscilloscopes
Power supply: power supply 9V DC
Output impedance: 50Ω
Kind of probe: active; differential
Rise time: 14ns
Input impedance: 4MΩ/1.2pF
Cable/adapter structure: BNC plug
Band: 15MHz (20:1); 25MHz
Attenuator: 20:1; 50:1; 200:1
Max. input voltage: 600V

Hersteller: GW INSTEK
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; active,differential; 6.5kV; 7ns
Kind of probe: active; differential
Type of measuring probe: for oscilloscope
Rise time: 7ns
Input impedance: 54MΩ/1.2pF
Cable/adapter structure: BNC plug
Band: 25MHz (100:1); 50MHz
Attenuator: 100:1; 200:1; 500:1; 1000:1
Max. input voltage: 6.5kV
Measuring instruments application: for GW Instek oscilloscopes
Power supply: power supply 9V DC
Output impedance: 50Ω

Hersteller: GW INSTEK
Category: Probes for Oscilloscopes and Scopometers
Description: Probe: for oscilloscope; active,differential; 6.5kV; 3.5ns
Type of measuring probe: for oscilloscope
Measuring instruments application: for GW Instek oscilloscopes
Power supply: power supply 9V DC
Output impedance: 50Ω
Kind of probe: active; differential
Rise time: 3.5ns
Input impedance: 54MΩ/1.2pF
Cable/adapter structure: BNC plug
Band: 50MHz (100:1); 100MHz
Attenuator: 100:1; 200:1; 500:1; 1000:1
Max. input voltage: 6.5kV

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-1072-U - Digitales Oszilloskop, GDS1000-U, 2 Kanäle, 70 MHz, 250 MS/s, 4kpts, 5 ns
Lieferumfang des Kits: 1 passiver Tastkopf (70MHz, 1:1, 10:1, umschaltbar) pro Kanal (GTP-070A-4)
Berechnete Anstiegszeit: 5
Abtastrate: 250
Aufzeichnungslänge (Speichertiefe): 4kpts
Netzsteckertyp: EU, UK
Herstellergewährleistung: Lebenslang
Produktpalette: GDS1000-U
Bandbreite: 70
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: QVGA LCD, farbig
SVHC: No SVHC (17-Jan-2022)

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Band: 100MHz
Vertical resolution: 8bit
Kind of display used: colour; LCD 7"
Number of channels: 2
Sampling: 1Gsps
Memory record length: 10Mpts
Time base: 5n...100s/div
Display resolution: 800x480
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Interface: USB
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Manufacturer series: GDS-1000B
Connectors for the country: Europe
Max. input voltage: 300V
Trigger coupling: AC; DC; highpass; lowpass

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 4; 100MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Band: 100MHz
Vertical resolution: 8bit
Kind of display used: colour; LCD 7"
Number of channels: 4
Sampling: 1Gsps
Memory record length: 10Mpts
Time base: 5n...100s/div
Display resolution: 800x480
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Rise time: ≤3.5ns
Input sensitivity: 1mV/div...10V/div
Interface: USB
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Manufacturer series: GDS-1000B
Connectors for the country: Europe
Max. input voltage: 300V
Trigger coupling: AC; DC; highpass; lowpass

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; Ch: 2; 200MHz; 1Gsps; 10Mpts; colour,LCD 7"
Type of oscilloscope: digital
Band: 200MHz
Vertical resolution: 8bit
Kind of display used: colour; LCD 7"
Number of channels: 2
Sampling: 1Gsps
Memory record length: 10Mpts
Time base: 5n...100s/div
Display resolution: 800x480
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Interface: USB
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; background noise filter; measurements by means of cursors; protocols analyse: I2C, SPI, RS232/UART, CAN, LIN; X-Y operation mode
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Manufacturer series: GDS-1000B
Max. input voltage: 300V
Trigger coupling: AC; DC; highpass; lowpass

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-1202B - Digitales Oszilloskop, GDS-1000B, 2 Analog, 1 externer Trigger, 200 MHz, 1 GSPS, 10Mpts, 1.75 ns
Lieferumfang des Kits: DSO, passiver 200MHz-Tastkopf GTP-200B-4, Netzkabel, Handbuch auf CD, Kurzanleitung
Berechnete Anstiegszeit: 1.75
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 1 Jahr
Produktpalette: GDS-1000B
Bandbreite: 200
Oszilloskopkanäle: 2 Analog, 1 externer Trigger
Oszilloskopanzeige: WVGA-TFT-Farbanzeige
SVHC: No SVHC (17-Jan-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-207 - Oszilloskop, GDS200, 2 Kanäle, 70 MHz, 1 GSPS, 1Mpts, 5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 1Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS200
Bandbreite: 70
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Portable Oscilloscopes, Scopemeters
Description: Portable oscilloscope; 70MHz; LCD; Ch: 2; 1Gsps (in real time)
Number of channels: 2
Type of oscilloscope: portable oscilloscope
Connectors for the country: Europe
Kind of display used: LCD
Touchpad: yes
Time base: 5n...100s/div
Rise time: ≤5ns
Input sensitivity: 2mV/div
AC current measuring range: 50mA; 0.5A; 10A
DC current measuring range: 50mA; 500mA; 10A
DC voltage measuring range: 50mV; 500mV; 5V; 50V; 500V; 1kV
AC voltage measuring range: 50mV; 500mV; 5V; 50V; 700V
Dimensions: 240x136x60mm
Resistance measuring accuracy: ±(0.3%+3 digit)@(500Ω); ±(0.3%+3 digit)@(5kΩ); ±(0.3%+3 digit)@(50kΩ); ±(0.3%+3 digit)@(500kΩ); ±(0.5%+5 digit)@(5MΩ)
AC voltage measuring accuracy: ±(1.5% + 15 digit)
AC current measuring accuracy: ±(1.5% + 15 digit)@50mA; ±(1.5% + 15 digit)@500mA; ±(3% + 15 digit)@10A
Screen size: 7"
Supply voltage: 100...240V AC
Max. input voltage: 300V
Display resolution: 480x800
Resistance measuring range: 500Ω; 5kΩ; 50kΩ; 500kΩ; 5MΩ
Memory record length: 1Mpts/ch
Input impedance: 1MΩ
Sampling: 1Gsps (in real time)
Band: 70MHz
Measuring instrument features: HOLD function; MIN/MAX function
Measurement: AC current; AC voltage; DC current; DC voltage; resistance

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2072E - Digitales Oszilloskop, GDS-2000E, 2 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2072E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 70MHz; 2Mpts; LCD 8"; 1n÷100s/div
Number of channels: 4
Related items: DS2-8LA
Input coupling: AC, DC, GND
Trigger: alternative; falling-edge; impulse width; rising-edge
Trigger modes: automatic; normal; single
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Interface: Ethernet (option); GPIB (option); RS232; USB
Connectors for the country: Europe
Software: included
Kind of display used: LCD 8"
Time base: 1n...100s/div
Rise time: ≤5ns
Input sensitivity: 1mV/div...10V/div
Dimensions: 380x220x145mm
Vertical resolution: 8bit
Supply voltage: 100...240V AC
Measurement memory: 24
Max. input voltage: 300V
Memory record length: 2Mpts
Input impedance: 1MΩ/16pF
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Band: 70MHz
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Trigger coupling: AC; DC; highpass; lowpass

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2074E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 70 MHz, 1 GSPS, 10Mpts, 5 ns
Lieferumfang des Kits: DSO GDS-2074E, 1 passiver 70MHz-Tastkopf GTP-070A-4 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 70
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-210 - Oszilloskop, GDS200, 2 Kanäle, 100 MHz, 1 GSPS, 1Mpts, 3.5 ns
Lieferumfang des Kits: 1 Tastkopf für 100MHz (GTP-100A-4), 2 Messleitungen (GTL-207), Netzkabel, Kurzanleitung, Benutzerhandbuch auf CD.
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 1Mpts
Netzsteckertyp: -
Herstellergewährleistung: -
Produktpalette: GDS200
Bandbreite: 100
Oszilloskopkanäle: 2 Kanäle
Oszilloskopanzeige: WVGA-LCD, Touchscreen, Farbe
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤3.5ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 100MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 2
Software: included
Max. input voltage: 300V

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Number of channels: 2
Band: 100MHz
Sampling: 1Gsps
Memory record length: 10Mpts
Kind of display used: LCD TFT 8"
Trigger modes: automatic; normal; single
Time base: 1n...100s/div
Max. input voltage: 300V
Vertical resolution: 8bit
Input coupling: AC, DC, GND
Trigger coupling: AC; DC; highpass; lowpass
Interface: LAN; USB
Manufacturer series: GDS-2000E
Rise time: ≤3.5ns
Input impedance: 1MΩ/16pF
Input sensitivity: 1mV/div...10V/div
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Dimensions: 384x208x127.3mm
Display resolution: 800x480
Kind of oscilloscope: DSO
Connectors for the country: Europe

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 2Mpts; LCD 8"; ≤3.5ns
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤3.5ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 100MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 4
Software: included
Max. input voltage: 300V

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 100MHz; 1Gsps; 10Mpts; LCD TFT 8"
Number of channels: 4
Trigger modes: automatic; normal; single
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Manufacturer series: GDS-2000E
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Input sensitivity: 1mV/div...10V/div
Memory record length: 10Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Kind of display used: LCD TFT 8"
Input coupling: AC, DC, GND
Rise time: ≤3.5ns
Sampling: 1Gsps
Display resolution: 800x480
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 100MHz
Time base: 1n...100s/div
Interface: LAN; USB
Max. input voltage: 300V

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2104E - Digitales Oszilloskop, GDS-2000E, 4 Kanäle, 100 MHz, 1 GSPS, 10Mpts, 3.5 ns
Lieferumfang des Kits: DSO GDS-2104E, 1 passiver 150MHz-Tastkopf GTP-150A-4 (10:1/1:1), Netzkabel, Kurzanleitung, CD
Berechnete Anstiegszeit: 3.5
Abtastrate: 1
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
Produktpalette: GDS-2000E
Bandbreite: 100
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤1.7ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 200MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 2
Software: included
Max. input voltage: 300V
Trigger modes: automatic; normal; single

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 2Mpts; LCD 8"; ≤1.7ns
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤1.7ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 200MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 4
Software: included
Max. input voltage: 300V

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2204E - Digitales Oszilloskop, GDS-2000E Series, 4 Kanäle, 200 MHz, 1 GSPS, 10Mpts, 1.75 ns
tariffCode: 90302000
euEccn: NLR
rohsCompliant: Y-EX
Lieferumfang des Kits: DSO GDS-2204E, vier passive Tastköpfe GTP-200B-4 (200MHz, 10:1/1:1 umschaltbar), je 1 pro Kanal, Netzkabel, Kurzanleitung & Handbuch auf CD.
Berechnete Anstiegszeit: 1.75ns
hazardous: false
rohsPhthalatesCompliant: YES
Abtastrate: 1GSPS
isCanonical: Y
Aufzeichnungslänge (Speichertiefe): 10Mpts
Netzsteckertyp: UK, Typ G
Herstellergewährleistung: 3 Jahre
SVHC: No SVHC (10-Jun-2022)
Produktpalette: GDS-2000E Series
Bandbreite: 200MHz
productTraceability: No
usEccn: 3A992.g
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: TFT-LCD-Farbanzeige

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 200MHz; 1Gsps; 10Mpts; LCD TFT 8"
Type of oscilloscope: digital
Band: 200MHz
Vertical resolution: 8bit
Kind of display used: LCD TFT 8"
Number of channels: 4
Sampling: 1Gsps
Memory record length: 10Mpts
Time base: 1n...100s/div
Display resolution: 800x480
Input coupling: AC, DC, GND
Trigger modes: automatic; normal; single
Rise time: ≤1.75ns
Input sensitivity: 1mV/div...10V/div
Interface: LAN; USB
Input impedance: 1MΩ/16pF
Dimensions: 384x208x127.3mm
Measuring instrument features: automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); background noise filter; protocols analyse: CAN/LIN; protocols analyse: I2C, SPI, UART
Standard equipment: mains cable; oscilloscope probe (1 per channel)
Manufacturer series: GDS-2000E
Connectors for the country: Europe
Max. input voltage: 300V
Kind of oscilloscope: DSO
Trigger coupling: AC; DC; highpass; lowpass

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 250MHz; 2,5Gsps (in real time)
Type of oscilloscope: digital
Number of channels: 4
Band: 250MHz
Sampling: 2,5Gsps (in real time)
Memory record length: 100Mpts
Kind of display used: LCD TFT 10,1"
Trigger: falling-edge; impulse width; Nth Edge; rising-edge; RS232/UART
Time base: 0.5n...1ks/div
Input coupling: AC, DC, GND
Interface: Ethernet; USB 2.0
Rise time: 1.75ns
Input impedance: 1MΩ/15pF
Input sensitivity: 500µV/div...10V/div
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); built-in frequency meter; it can be powered by a portable powerbank via UBC-C port; mathematical functions: addition, subtraction, division, multiplication and FFT; protocols analyse: I2C, CAN, SPI, RS232/UART; voltmeter function; X-Y, ROLL operation mode
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Dimensions: 325x209.5x111.5mm
Supply voltage: 100...240V AC
Connectors for the country: Europe
Trigger modes: automatic; normal; single
Kind of oscilloscope: DSO
Vertical resolution: 12bit

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 250MHz; 2,5Gsps (in real time)
Type of oscilloscope: digital
Kind of oscilloscope: DSO
Number of channels: 4
Band: 250MHz
Sampling: 2,5Gsps (in real time)
Memory record length: 100Mpts
Kind of display used: LCD TFT 10,1"
Trigger modes: automatic; normal; single
Trigger: falling-edge; impulse width; Nth Edge; rising-edge; RS232/UART
Time base: 0.5n...1ks/div
Vertical resolution: 12bit
Input coupling: AC, DC, GND
Interface: Ethernet; USB 2.0
Rise time: 1.75ns
Input impedance: 1MΩ/15pF
Input sensitivity: 500µV/div...10V/div
Measuring instrument features: 20 sets memory; arbitrary waveform generator; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); built-in frequency meter; it can be powered by a portable powerbank via UBC-C port; mathematical functions: addition, subtraction, division, multiplication and FFT; protocols analyse: I2C, CAN, SPI, RS232/UART; voltmeter function; X-Y, ROLL operation mode
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Supply voltage: 100...240V AC
Connectors for the country: Europe
Dimensions: 325x209.5x111.5mm

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 2; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤1.17ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 300MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 2
Software: included
Max. input voltage: 300V
Trigger modes: automatic; normal; single

Hersteller: GW INSTEK
Description: GW INSTEK - GDS-2304A - Digitales Oszilloskop, GDS-2000A Series, 4 Kanäle, 300 MHz, 2 GSPS, 2Mpts, 1.17 ns
tariffCode: 90302000
rohsCompliant: Y-EX
Lieferumfang des Kits: DSO GDS-2304A, 1 passiver 350MHz-Tastkopf GTP-350A-2 pro Kanal (1:1, 10:1), Netzkabel, Dokumentation auf CD
Berechnete Anstiegszeit: 1.17ns
hazardous: false
rohsPhthalatesCompliant: YES
Abtastrate: 2GSPS
Aufzeichnungslänge (Speichertiefe): 2Mpts
usEccn: 3A992.g
Netzsteckertyp: -
Herstellergewährleistung: 3 Jahre
euEccn: NLR
Produktpalette: GDS-2000A Series
Bandbreite: 300MHz
productTraceability: No
Oszilloskopkanäle: 4 Kanäle
Oszilloskopanzeige: SVGA LCD, farbig
SVHC: No SVHC (10-Jun-2022)

Hersteller: GW INSTEK
Category: Digital Oscilloscopes
Description: Oscilloscope: digital; DSO; Ch: 4; 300MHz; 2Mpts; LCD 8"; ≤1.17ns
Trigger modes: automatic; normal; single
Supply voltage: 100...240V AC
Measuring instrument features: 20 sets memory; automatic measurement of many parameters; AUTOSET function for setting display parameters (time base, gain); mathematical functions: addition, subtraction, division, multiplication and FFT; X-Y, ROLL operation mode
Kind of oscilloscope: DSO
Standard equipment: mains cable; oscilloscope probe with 1:1/10:1 divider
Input sensitivity: 1mV/div...10V/div
Memory record length: 2Mpts
Type of oscilloscope: digital
Vertical resolution: 8bit
Related items: DS2-8LA
Kind of output connector: D-Sub female socket; D-Sub male socket; GPIB socket; RJ45 socket; USB A socket; USB B socket
Kind of display used: LCD 8"
Input coupling: AC, DC, GND
Rise time: ≤1.17ns
Trigger: alternative; falling-edge; impulse width; rising-edge
Sampling: 2Gsps (in real time); 100Gsps (in equivalent time)
Input impedance: 1MΩ/16pF
Dimensions: 380x220x145mm
Measurement memory: 24
Connectors for the country: Europe
Trigger coupling: AC; DC; highpass; lowpass
Band: 300MHz
Time base: 1n...100s/div
Interface: Ethernet (option); GPIB (option); RS232; USB
Number of channels: 4
Software: included
Max. input voltage: 300V
