Produkte > LUMEL > Alle Produkte des Herstellers LUMEL (235) > Seite 4 nach 4

Hersteller: LUMEL
Category: Ammeters
Description: Ammeter; digital,mounting; 0÷1A; ±(0.5%+1digit); LED; 5 digits
Type of meter: ammeter
Kind of meter: digital; mounting
AC current measuring range: 0...1A
AC current measuring accuracy: ±(0.5% + 1 digit)
Mounting: for DIN rail mounting (optional); on panel
Measurement: AC current
Kind of display used: LED
Display parameters: 5 digits
Digit height: 14mm
Measuring instrument features: with an extra quality inspection certificate
Manufacturer series: N25Z
Supply voltage: 85...253V AC; 85...253V DC
IP rating: IP65
Dimensions (W x H x D): 96x48x64mm
Kind of measurement: indirect with 1A current transformer
Input: current ±1A AC
Related items: ATS-200; CZ/20-810-01-00004; CZ/N24-134-1; CZ/N24-134-2; CZ/N24-134-3

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: programmable; digital,mounting; LED; 5 digits; Char: 14mm
Manufacturer series: N30U
Type of meter: programmable
Digit height: 14mm
Dimensions (W x H x D): 96x48x93mm
Supply voltage: 85...253V AC; 85...253V DC
Output signal: 0...10V; 0/4...20mA
Input: 0...400Ω; 0...4000Ω; current -20...20mA; current time (00,00...23,59); E-type thermocouple (-100...1000°C); J-type thermocouple (-100...1200°C); K-type thermocouple (-100...1370°C); N-type thermocouple (-100...1300°C); Pt 100 (-200...850°C); Pt 500 (-200...850°C); Pt 1000 (-200...850°C); R-type thermocouple (-50...1760°C); S-type thermocouple (-50...1760°C); voltage 10...10V; voltage 0...60mV
Display parameters: 5 digits
Measurement: resistance; temperature
Related items: ATS-200
Measuring instrument features: lack of unit
Kind of meter: digital; mounting
Mounting: for DIN rail mounting (optional); on panel
IP rating: IP65
Kind of display used: LED

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: programmable; digital,mounting; LED; 5 digits; Char: 14mm
Related items: ATS-200
Kind of meter: digital; mounting
Mounting: for DIN rail mounting (optional); on panel
IP rating: IP65
Kind of display used: LED
Type of meter: programmable
Measurement: resistance; temperature
Interface: RS485
Digit height: 14mm
Dimensions (W x H x D): 96x48x93mm
Supply voltage: 85...253V AC; 85...253V DC
Output signal: 0...10V; 0/4...20mA
Input: 0...400Ω; 0...4000Ω; current -20...20mA; current time (00,00...23,59); E-type thermocouple (-100...1000°C); J-type thermocouple (-100...1200°C); K-type thermocouple (-100...1370°C); N-type thermocouple (-100...1300°C); Pt 100 (-200...850°C); Pt 500 (-200...850°C); Pt 1000 (-200...850°C); R-type thermocouple (-50...1760°C); S-type thermocouple (-50...1760°C); voltage 10...10V; voltage 0...60mV
Display parameters: 5 digits
Manufacturer series: N30U
Output: 24V DC/ 30mA; analogue; OC type output; relay

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: programmable; digital,mounting; LED; 5 digits; Char: 14mm
Mounting: for DIN rail mounting (optional); on panel
Kind of meter: digital; mounting
Interface: RS485
Manufacturer series: N30U
IP rating: IP65
Kind of display used: LED
Digit height: 14mm
Dimensions (W x H x D): 96x48x93mm
Supply voltage: 85...253V AC; 85...253V DC
Output signal: 0...10V; 0/4...20mA
Input: 0...400Ω; 0...4000Ω; current -20...20mA; current time (00,00...23,59); E-type thermocouple (-100...1000°C); J-type thermocouple (-100...1200°C); K-type thermocouple (-100...1370°C); N-type thermocouple (-100...1300°C); Pt 100 (-200...850°C); Pt 500 (-200...850°C); Pt 1000 (-200...850°C); R-type thermocouple (-50...1760°C); S-type thermocouple (-50...1760°C); voltage 10...10V; voltage 0...60mV
Display parameters: 5 digits
Related items: ATS-200
Measurement: resistance; temperature
Output: analogue; pulse output; relay
Type of meter: programmable

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: programmable; digital,mounting; LED; 5 digits; Char: 14mm
Mounting: for DIN rail mounting (optional); on panel
Kind of meter: digital; mounting
Manufacturer series: N30U
IP rating: IP65
Kind of display used: LED
Digit height: 14mm
Dimensions (W x H x D): 96x48x93mm
Supply voltage: 20...40V AC; 20...60V DC
Output signal: 0...10V; 0/4...20mA
Input: 0...400Ω; 0...4000Ω; current -20...20mA; current time (00,00...23,59); E-type thermocouple (-100...1000°C); J-type thermocouple (-100...1200°C); K-type thermocouple (-100...1370°C); N-type thermocouple (-100...1300°C); Pt 100 (-200...850°C); Pt 500 (-200...850°C); Pt 1000 (-200...850°C); R-type thermocouple (-50...1760°C); S-type thermocouple (-50...1760°C); voltage 10...10V; voltage 0...60mV
Display parameters: 5 digits
Measuring instrument features: lack of unit
Related items: ATS-200
Measurement: resistance; temperature
Type of meter: programmable

Hersteller: LUMEL
Category: Meters and AC/DC Clamp Probes
Description: Meter: multifunction; digital,pincers type; Øcable: 50mm; LED
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Kind of meter: digital; pincers type
Test: diodes
Manufacturer series: NC12
Kind of display used: LED
Interface language: PL
Bargraph: yes
Temperature measuring range: -200...800°C
Capacitance measuring range: 30nF; 300nF; 3µF; 30µF
DC current measuring range: 200mA...300A; 1kA
AC current measuring range: 200mA...300A; 1kA
DC voltage measuring accuracy: ±(0.25% + 1 digit)
Frequency measuring accuracy: ±(0.5%+1 digit)
DC current measuring accuracy: ±(1.5% + 5 digit)
Resistance measuring accuracy: ±(0.4%+1 digit)
AC voltage measuring accuracy: ±(0.75% + 2 digit)
AC current measuring accuracy: ±(1.5% + 5 digit)
Capacitance measuring accuracy: ±(1%+ 3 digit)
DC voltage measuring range: 30mV; 300mV; 3V; 30V; 300V; 1kV
Max. diameter of measured cable: 50mm
AC voltage measuring range: 3V; 30V; 300V; 1kV
Resistance measuring range: 30Ω; 300Ω; 3kΩ; 30kΩ; 300kΩ; 3MΩ; 30MΩ
Frequency measuring range: 300...100kHz
Measuring instrument features: automatic or manual selection of measuring ranges; automatic power-off; for use with type Pt 100, Pt 1000 thermocouple; HOLD function; MIN/MAX function; rotating clamp jaws; with an extra quality inspection certificate
Measurement: AC current; AC voltage; capacitance; continuity; DC current; DC voltage; duty cycle; frequency; resistance; temperature
Power supply: battery 6F22 9V x1
Type of meter: multifunction

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD; ND25; 1A,5A
Related items: ATS-100
Measuring instrument features: datalogging; real time clock- RTC
Kind of meter: digital; mounting
Interface: Ethernet; USB
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP50
Manufacturer series: ND25
Kind of display used: LCD
Type of meter: network parameters
Illumination: yes
Operating temperature: -20...70°C
Dimensions (W x H x D): 96x96x57mm
Accuracy class: 0.2S
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.5...346.42V
Supply voltage: 100...550V AC; 100...550V DC
Kind of network: 3-wire; 4-wire; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; phase angle θ; phase sequence; power factor; reactive power; THD; time

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD; ND25; 1A,5A
Related items: ATS-100
Kind of meter: digital; mounting
Interface: Ethernet; USB
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP50
Manufacturer series: ND25
Kind of display used: LCD
Type of meter: network parameters
Illumination: yes
Operating temperature: -20...70°C
Dimensions (W x H x D): 96x96x57mm
Accuracy class: 0.2S
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.5...346.42V
Supply voltage: 100...550V AC; 100...550V DC
Kind of network: 3-wire; 4-wire; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; phase angle θ; phase sequence; power factor; reactive power; THD; time

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD; ND25; 1A,5A
Related items: ATS-100
Kind of meter: digital; mounting
Interface: RS485; USB
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP50
Manufacturer series: ND25
Kind of display used: LCD
Type of meter: network parameters
Output: pulse output x2
Illumination: yes
Operating temperature: -20...70°C
Dimensions (W x H x D): 96x96x57mm
Accuracy class: 0.2S
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.5...346.42V
Supply voltage: 100...550V AC; 100...550V DC
Kind of network: 3-wire; 4-wire; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; phase angle θ; phase sequence; power factor; reactive power; THD; time

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD; ND25; 1A,5A
Type of meter: network parameters
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
Mounting: for DIN rail mounting (optional); on panel
Kind of meter: digital; mounting
Kind of display used: LCD
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; phase angle θ; phase sequence; power factor; reactive power; THD; time
Manufacturer series: ND25
Kind of network: 3-wire; 4-wire; three-phase
Input voltage: 57.5...346.42V
Input current: 1A; 5A
Operating frequency: 45...65Hz
Accuracy class: 0.2S
Output: pulse output x2
Interface: Ethernet; RS485; USB
Measuring instrument features: datalogging; real time clock- RTC
Related items: ATS-100
Operating temperature: -20...70°C
IP rating: IP50
Supply voltage: 100...550V AC; 100...550V DC
Dimensions (W x H x D): 96x96x57mm
Illumination: yes

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD TFT 3,5"; 1A,5A
Mounting: for DIN rail mounting (optional); on panel
Operating temperature: -10...55°C
Kind of meter: digital; mounting
Interface: Ethernet; RS485
Manufacturer series: ND30IOT
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP65
Kind of display used: LCD TFT 3,5"
Dimensions (W x H x D): 96x96x77mm
Input current: 1A; 5A
Supply voltage: 85...253V AC; 90...300V DC
Operating frequency: 45...65Hz
Input voltage: 57.7...230V
Display resolution: 320x240
Input: Pt 100 x2
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Related items: ATS-100
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; power factor; reactive power; temperature; THD
Output: analogue; relay x2
Type of meter: network parameters

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD TFT 3,5"; 1A,5A
Display resolution: 320x240
Supply voltage: 85...253V AC; 90...300V DC
Interface: Ethernet; RS485
Type of meter: network parameters
Kind of display used: LCD TFT 3,5"
Kind of meter: digital; mounting
Manufacturer series: ND30IOT
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP65
Operating temperature: -10...55°C
Dimensions (W x H x D): 96x96x77mm
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.7...230V
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; power factor; reactive power; temperature; THD
Related items: ATS-100
Output: analogue; relay x2

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD TFT 3,5"; 1A,5A
Display resolution: 320x240
Supply voltage: 85...253V AC; 90...300V DC
Interface: Ethernet/Profinet; RS485
Type of meter: network parameters
Kind of display used: LCD TFT 3,5"
Kind of meter: digital; mounting
Manufacturer series: ND30PNET
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP65
Operating temperature: -10...55°C
Dimensions (W x H x D): 96x96x77mm
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.7...230V
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; power factor; reactive power; THD
Related items: ATS-100
Output: relay x2

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD TFT 3,5"; 1A,5A
Manufacturer series: ND30PNET
Type of meter: network parameters
Kind of meter: digital; mounting
Interface: Ethernet/Profinet; RS485
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP65
Kind of display used: LCD TFT 3,5"
Input: Pt 100 x2
Operating temperature: -10...55°C
Dimensions (W x H x D): 96x96x77mm
Input current: 1A; 5A
Supply voltage: 20...40V AC; 20...60V DC
Operating frequency: 45...65Hz
Input voltage: 57.7...230V
Display resolution: 320x240
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Related items: ATS-100
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; power factor; reactive power; temperature; THD
Output: analogue; relay x2

Hersteller: LUMEL
Category: Power Network Meters and Analyzers
Description: Meter: network parameters; digital,mounting; LCD TFT 3,5"; 1A,5A
Display resolution: 320x240
Supply voltage: 85...253V AC; 90...300V DC
Interface: RS485
Type of meter: network parameters
Kind of display used: LCD TFT 3,5"
Kind of meter: digital; mounting
Software: download from manufacturers website
Manufacturer series: ND31 LITE
Mounting: for DIN rail mounting (optional); on panel
Kind of measurement: indirect with 1A current transformer; indirect with 5A current transformer
IP rating: IP65
Communictions protocol: Modbus RTU
Operating temperature: -10...55°C
Dimensions (W x H x D): 96x96x77mm
Accuracy class: 0.2S
Input current: 1A; 5A
Operating frequency: 45...65Hz
Input voltage: 57.7/100V; 230/400V
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Measurement: AC current; active power; AC voltage; apparent power; energy; frequency; harmonics; power factor; reactive power; THD
Related items: ATS-100
Output: relay x2

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: reactive power regulator; on panel; LCD; 2x16 characters
IP rating: IP54
Kind of display used: LCD
Mounting: on panel
Type of meter: reactive power regulator
Standard equipment: reducer 144x144mm to 96x96mm
True effective value measurement: True RMS
Dimensions: 96x96mm
Supply voltage: 110...550V AC
Input voltage: 240V
Display parameters: 2x16 characters
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; power factor; reactive electric energy; reactive power; THD; time
Output: alarm; relay x6
Measuring instrument features: bidirectional (4-quadrant); real time clock- RTC

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: reactive power regulator; on panel; LCD; 2x16 characters
IP rating: IP54
Kind of display used: LCD
Mounting: on panel
Type of meter: reactive power regulator
Standard equipment: reducer 144x144mm to 96x96mm
True effective value measurement: True RMS
Dimensions: 96x96mm
Supply voltage: 110...550V AC
Input voltage: 240V
Display parameters: 2x16 characters
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; power factor; reactive electric energy; reactive power; THD; time
Output: alarm; relay x8
Measuring instrument features: bidirectional (4-quadrant); real time clock- RTC

Hersteller: LUMEL
Category: Portable digital multimeters
Description: Digital multimeter; LED; 2,8x/s; VDC: 660mV,6.6V,66V,660V,1kV
Type of meter: digital multimeter
Kind of display used: LED
DC voltage measuring range: 660mV; 6.6V; 66V; 660V; 1kV
DC voltage measuring accuracy: ±(0.4% + 5 digit)
AC voltage measuring range: 660mV; 6.6V; 66V; 660V; 1kV
AC voltage measuring accuracy: ±(1% + 3 digit)
DC current measuring range: 66mA...16A
DC current measuring accuracy: ±(1.5% + 5 digit)
AC current measuring range: 66mA...16A
AC current measuring accuracy: ±(1.5% + 5 digit)
Resistance measuring range: 660...66MΩ
Resistance measuring accuracy: ±(0.8%+5 digit)
Temperature measuring range: 0...1300°C
Temperature measurement accuracy: ±(2% + 3 digit)
Test: diodes
Continuity test: acoustic indication; <30Ω
Measurement: AC current; AC voltage; DC current; DC voltage; resistance; temperature
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Power supply: battery LR6 AA 1,5V x2
Measuring instrument features: auto and manual ranging; automatic and manual sensitivity adjustment; automatic power-off; for use with type-K thermocouple; HOLD function; measures peak values; with an extra quality inspection certificate
Standard equipment: soft case; test leads; user's manual
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX871515; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Weight with battery: 480g
Sampling: 2,8x/s
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Manufacturer series: NP10
Interface language: PL
Bargraph: yes
Operating temperature: 0...50°C
Dimensions (W x H x D): 79x174x38mm

Hersteller: LUMEL
Category: Portable digital multimeters
Description: Digital multimeter; Bluetooth; LCD; 4x/s; True RMS; 10÷1MHz; NP15B
Type of meter: digital multimeter
Measurement: AC voltage; capacitance; conductance; continuity; current (with current clamps); DC voltage; frequency; resistance; temperature (external probe required)
Kind of display used: LCD
DC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
DC voltage measuring accuracy: ±(0.05% + 5 digit)
AC voltage measuring range: 60mV; 600mV; 6V; 60V; 600V; 1kV
AC voltage measuring accuracy: ±(0.5% + 9 digit)
DC current measuring range: 600µA; 6mA; 60mA; 600mA; 10A
DC current measuring accuracy: ±(0.1% + 5 digit)
AC current measuring range: 600µA; 60mA; 600mA; 10A
AC current measuring accuracy: ±(1% + 10 digit)
True effective value measurement: True RMS
Resistance measuring range: 600Ω...40MΩ
Capacitance measuring range: 10nF; 100nF; 1µF; 10µF; 100µF; 1mF
Capacitance measuring accuracy: ±(1%+ 6 digit)
Frequency measuring range: 10...1MHz
Frequency measuring accuracy: ±(0.05%+5 digit)
Temperature measuring range: -210...1372°C
Resistance measuring accuracy: ±(0.1%+10 digit)
Continuity test: acoustic indication; <600kΩ
Operating temperature: 0...50°C
Power supply: battery LR6 AA 1,5V x2
Standard equipment: soft case; test leads; user's manual
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: 5790D; 5793D; 5794D; 5795D; 5797D; BKP60; EX801515; EX871515; EX872502; EX881602; EX881603; EX881605; PKT-PTA; PKT-PTF-10; PKT-PTF-20; PKT-PTF-25; PKT-PTF-30; PKT-PTF-40; PKT-PTF-50; PKT-PTF-55; PKT-PTF-56; PKT-PTF-60; SE027; SE028; SE029; SE030; SE031; SE059; SE060; SE061; SE062; SE001; SE002; SE003; SE004; SE000; TESTO-06020393; TESTO-06020645; TESTO-06024592; TESTO-06024892; TESTO-06280020; TESTO-06281292; TESTO-06287533; TP200; TP400; TP870; TP873; TP873-5M; TP882; TP-111; TP-112; TP-02; TP-03; TP-04; TP-06; TP-08; TP-09; TPK-59; TPK-62; UTT10K; UTT12
Dimensions (W x H x D): 91x200x54mm
Measuring instrument features: alarm activated on limit values exceeding; AUTO HOLD; battery level indication; high voltage indication; logging of MAX, MIN, AVG; low-pass filter; operates with thermocouple types: J, K, Pt100, PT1000; with an extra quality inspection certificate
Battery/ rechargeable battery: battery LR6 AA 1,5V x2
Temperature measurement accuracy: ±(0.3% + 15 digit)
Weight with battery: 500g
Sampling: 4x/s
Optional equipment: external power supply
Test: diodes
Interface: Bluetooth
Manufacturer series: NP15B
Software: included
Interface language: PL
Additional functions: square waveform generator
Bargraph: yes

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Display resolution: 320x240
Dimensions: 262x173x66mm
Interface: Ethernet; LAN; USB Host
Type of meter: power quality analyser
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Kind of display used: LCD TFT 5,6"
Software: included
IP rating: IP51
True effective value measurement: True RMS
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Standard equipment: crocodile clip x5; power supply; Rogowski coil PY-3000A x4; test leads ( 5pcs.); user's manual

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; power supply; Rogowski coil PY-5000A x4; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; current clamp KLC8C-5A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; current clamp CTC0080-50A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; current clamp CTC0130-100A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 320x240
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 320x240
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host
Standard equipment: crocodile clip x5; current clamp CTC1535-1000A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 262x173x66mm
IP rating: IP51
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Standard equipment: crocodile clip x5; power supply; Rogowski coil PY-3000A x4; test leads ( 5pcs.); user's manual
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Interface: Ethernet; LAN; USB Host; WiFi
Software: included
Kind of display used: LCD TFT 5,6"
True effective value measurement: True RMS
Dimensions: 270x190x66mm
Display resolution: 640x480
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Memory capacity: 32GB
Accuracy class: A
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
Type of meter: power quality analyser
Measuring instrument features: graphical display of measurement results
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; power supply; Rogowski coil PY-5000A x4; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; current clamp KLC8C-5A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; current clamp CTC0080-50A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; current clamp CTC0130-100A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; current clamp CTC1535-1000A x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; current clampETCR035AD-1000A-AC/DC x 4; power supply; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; power supply; Rogowski coil SY-1500A x4; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Power Quality Analyzers
Description: Meter: power quality analyser; LCD TFT 5,6"; Resolution: 640x480
Type of meter: power quality analyser
Kind of display used: LCD TFT 5,6"
Kind of network: 3-wire; 4-wire; single-phase; three-phase
Display resolution: 640x480
Measurement: AC current; active electric energy; active power; AC voltage; apparent electric energy; apparent power; frequency; harmonics; inrush current; reactive electric energy; reactive power
True effective value measurement: True RMS
Interface: Ethernet; LAN; USB Host; WiFi
Accuracy class: A
Measuring instrument features: graphical display of measurement results
Standard equipment: crocodile clip x5; power supply; Rogowski coil SY-6000A x4; test leads ( 5pcs.); user's manual
Power supply: rechargeable battery Li-Ion 7,4V x1; rechargeable battery Ni-MH 7,2V 3,8Ah x1
Dimensions: 270x190x66mm
IP rating: IP53
Conform to the norm: CAT III 1000V; CAT IV 600V; EN 61010
Related items: CTC0130-100A; CTC0080-50A; KLC8C-5A; PY-3000A; PY-5000A; SY-1500A; SY-6000A
Software: included
Memory capacity: 32GB

Hersteller: LUMEL
Category: Temperature Transducers
Description: Converter: temperature and humidity; 9÷24VDC; 9÷24VAC; IP65; ±2%
Sensors features: integrated probe
IP rating: IP65
Output configuration: RS485 Modbus RTU
Type of converter: temperature and humidity
Temperature measuring range: -30...80°C
Operating temperature: -20...60°C
Humidity measuring range: 0...100% RH
Tolerance: ±2%
Supply voltage: 9...24V AC; 9...24V DC

Hersteller: LUMEL
Category: Temperature Transducers
Description: Converter: temperature and humidity; 9÷24VDC; 9÷24VAC; IP65; ±2%
Sensors features: integrated probe
IP rating: IP65
Kind of display used: LCD
Output configuration: RS485 Modbus RTU
Type of converter: temperature and humidity
Temperature measuring range: -30...80°C
Operating temperature: -20...60°C
Humidity measuring range: 0...100% RH
Tolerance: ±2%
Supply voltage: 9...24V AC; 9...24V DC

Hersteller: LUMEL
Category: Temperature Transducers
Description: Converter: temperature and humidity; 9÷28VDC; Temp: -20÷60°C
IP rating: IP65
Output configuration: RS485 Modbus RTU
Type of converter: temperature and humidity
Temperature measuring range: -30...80°C
Operating temperature: -20...60°C
Humidity measuring range: 0...100% RH
Tolerance: ±2%
Supply voltage: 9...28V DC

Hersteller: LUMEL
Category: Industrial Networks
Description: Converter; RS232/USB; 5VDC; PD24; plastic
Manufacturer series: PD24
Type of automation module: converter
Enclosure material: plastic
Kind of module: RS232/USB
Power supply: USB
Supply voltage: 5V DC

Hersteller: LUMEL
Category: Industrial Networks
Description: Converter; RS485/ETHERNET; 5÷36VDC; for DIN rail mounting; PD9
Supply voltage: 5...36V DC
Enclosure material: plastic
Mounting: for DIN rail mounting
Manufacturer series: PD9
Type of automation module: converter
Kind of module: RS485/ETHERNET

Hersteller: LUMEL
Category: Industrial Networks
Description: Converter; RS485/ETHERNET/WIFI; 5÷36VDC; for DIN rail mounting
Supply voltage: 5...36V DC
Enclosure material: plastic
Mounting: for DIN rail mounting
Manufacturer series: PD9
Type of automation module: converter
Kind of module: RS485/ETHERNET/WIFI

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; Pt100; temperature; SPDT; on panel
Kind of temperature sensor: Pt100
IP rating: IP20 at terminal side; IP65 (from the front)
Manufacturer series: RE01
Mounting: on panel
Controlled parameter: temperature
Kind of output 2: SPST-NO
Controlled parameter range: -50...100°C; 0...250°C; 0...600°C
Operating temperature: 0...50°C
Body dimensions: 76x34x80mm
Mounting hole diameter: 29x71mm
Supply voltage: 230V AC
Output 1 electrical parameters: 250V AC / 10A
Output 2 electrical parameters: 250V AC / 5A
Kind of output 1: SPDT
Kind of input 1: RTD
Regulation for output 1: AUTOTUNING; ON-OFF; PID
Display parameters: 4 digit
The programming method: rubber keypad
Type of automation module: regulator
Kind of display used: LED

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; temperature; SPST-NO,SSR; on panel
Kind of temperature sensor: Pt100; thermocouple J; thermocouple R; thermocouple S; thermocouple T
Mounting: on panel
Controlled parameter: temperature
Kind of output 2: SPST-NO
Operating temperature: 0...50°C
Body dimensions: 52x52x80mm
Mounting hole diameter: 46x46mm
Supply voltage: 85...270V AC; 85...270V DC
Kind of output 1: SPST-NO; SSR
Kind of input 1: RTD; thermocouple
Regulation for output 1: AUTOTUNING; ON-OFF; PID
Display parameters: 4 digit
The programming method: rubber keypad
Type of automation module: regulator
Kind of display used: LED

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; temperature; SPST-NO; on panel
Kind of temperature sensor: Pt100; thermocouple B; thermocouple C; thermocouple E; thermocouple J; thermocouple K; thermocouple L; thermocouple N; thermocouple R; thermocouple S; thermocouple T; thermocouple U; thermocouple W
Mounting: on panel
Controlled parameter: temperature
Kind of output 2: SPST-NO
Kind of output 3: SPST-NO
Operating temperature: 0...50°C
Body dimensions: 52x52x80mm
Mounting hole diameter: 46x46mm
Supply voltage: 85...270V AC; 85...270V DC
Kind of output 1: SPST-NO
Kind of input 1: analogue; RTD; thermocouple
Regulation for output 1: AUTOTUNING; ON-OFF; PID
Display parameters: 4 digit
The programming method: rubber keypad
Type of automation module: regulator
Kind of display used: LED

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; Pt100; temperature; -50÷100°C; SPDT
Manufacturer series: RE55
Mounting: on panel
Kind of temperature sensor: Pt100
Type of automation module: regulator
Input 1 properties: RTD
Kind of output 1: SPDT
Kind of output 2: SPST-NO
Controlled parameter: temperature
Controlled parameter range: -50...100°C
Operating temperature: 0...50°C
Mounting hole diameter: 92.5x92.5mm
Body dimensions: 96x96x65mm
Supply voltage: 85...253V AC; 85...253V DC
Output 2 electrical parameters: 250V AC / 1A
Display parameters: 4 digit
Output 1 electrical parameters: 250V AC / 2A
The programming method: adjusting screw
IP rating: IP20 at terminal side; IP40 (from the front)
Kind of display used: LED
Regulation for output 1: ON-OFF

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; Pt100; temperature; 0÷150°C; SPDT
IP rating: IP20 at terminal side; IP40 (from the front)
Kind of display used: LED
Regulation for output 1: ON-OFF
Mounting: on panel
Kind of temperature sensor: Pt100
Type of automation module: regulator
Input 1 properties: RTD
Kind of output 1: SPDT
Kind of output 2: SPST-NO
Controlled parameter: temperature
Operating temperature: 0...50°C
Controlled parameter range: 0...150°C
Mounting hole diameter: 92.5x92.5mm
Body dimensions: 96x96x65mm
Supply voltage: 85...253V AC; 85...253V DC
Output 2 electrical parameters: 250V AC / 1A
Output 1 electrical parameters: 250V AC / 2A
Display parameters: 4 digit
Manufacturer series: RE55
The programming method: adjusting screw

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; Pt100; temperature; 0÷150°C; SPDT
IP rating: IP20 at terminal side; IP40 (from the front)
Kind of display used: LED
Regulation for output 1: PID
Mounting: on panel
Kind of temperature sensor: Pt100
Type of automation module: regulator
Input 1 properties: RTD
Kind of output 1: SPDT
Kind of output 2: SPST-NO
Controlled parameter: temperature
Operating temperature: 0...50°C
Controlled parameter range: 0...150°C
Mounting hole diameter: 92.5x92.5mm
Body dimensions: 96x96x65mm
Supply voltage: 85...253V AC; 85...253V DC
Output 2 electrical parameters: 250V AC / 1A
Output 1 electrical parameters: 250V AC / 2A
Display parameters: 4 digit
Manufacturer series: RE55
The programming method: adjusting screw

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; temperature; -999÷9999; SPST-NO
Display parameters: 4 digit
Kind of output 3: SPST-NO
Input 1 properties: analogue voltage; current analog; RTD; thermocouple
The programming method: rubber keypad
Manufacturer series: RE72
Kind of temperature sensor: Pt100; Pt1000; thermocouple B; thermocouple E; thermocouple J; thermocouple K; thermocouple L; thermocouple N; thermocouple R; thermocouple S; thermocouple T
Mounting: on panel
IP rating: IP65 (from the front)
Kind of display used: LED
Type of automation module: regulator
Controlled parameter: temperature
Controlled parameter range: -999...9999
Operating temperature: 0...50°C
Output 1 electrical parameters: 250V AC / 2A
Output 2 electrical parameters: 250V AC / 1A
Body dimensions: 48x48x93mm
Mounting hole diameter: 45x45mm
Supply voltage: 85...253V AC
Output 3 electrical parameters: 250V AC / 1A
Kind of input 1: 0...5/10V; 0/4...20mA; universal
Kind of output 2: SPST-NO
Kind of output 1: SPST-NO
Regulation for output 1: AUTOTUNING; ON-OFF; PID; TIMER

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: regulator; temperature; -999÷9999; SPST-NO
Display parameters: 4 digit
Kind of output 3: SPST-NO
Input 1 properties: analogue voltage; current analog; RTD; thermocouple
The programming method: rubber keypad
Manufacturer series: RE72
Kind of temperature sensor: Pt100; Pt1000; thermocouple B; thermocouple E; thermocouple J; thermocouple K; thermocouple L; thermocouple N; thermocouple R; thermocouple S; thermocouple T
Mounting: on panel
IP rating: IP65 (from the front)
Kind of display used: LED
Type of automation module: regulator
Controlled parameter: temperature
Controlled parameter range: -999...9999
Operating temperature: 0...50°C
Output 1 electrical parameters: 250V AC / 2A
Output 2 electrical parameters: 4...20mA
Body dimensions: 48x48x93mm
Mounting hole diameter: 45x45mm
Supply voltage: 85...253V AC
Output 3 electrical parameters: 250V AC / 1A
Kind of input 1: 0...5/10V; 0/4...20mA; universal
Kind of output 2: analogue
Kind of output 1: SPST-NO
Regulation for output 1: AUTOTUNING; ON-OFF; PID; TIMER

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: dual channel regulator; -999÷9999; SPST-NO
Type of automation module: dual channel regulator
Kind of temperature sensor: Cu100; Ni100; Pt100; Pt500; Pt1000; thermocouple E; thermocouple J; thermocouple K; thermocouple N; thermocouple R; thermocouple S; thermocouple T
Controlled parameter: fluid flow; humidity; pressure; speed; temperature
Kind of input 1: 0...5/10V; 0/4...20mA; universal
Kind of input 3: 0/4...20mA
Mounting: on panel
Manufacturer series: RE92
Number of outputs: 6
Number of inputs: 3
Output 1 electrical parameters: 250V AC / 2A
Supply voltage: 85...253V AC; 85...253V DC
The programming method: PC; rubber keypad
Mounting hole diameter: 92.5x92.5mm
IP rating: IP65 (from the front)
Input 1 properties: analogue voltage; current analog; RTD; thermocouple
Kind of display used: colour; LCD TFT 3,5"
Display resolution: 320x240
Body dimensions: 96x96x100mm
Operating temperature: 0...50°C
Controlled parameter range: -999...9999
Kind of output 1: SPST-NO
Regulation for output 1: AUTOTUNING; ON-OFF; ON-OFF with hysteresis; PID; PROGRAM

Hersteller: LUMEL
Category: Temperature Regulators
Description: Automation module: dual channel regulator; IN 3: 0/4÷20mA; RE92
Type of automation module: dual channel regulator
Kind of temperature sensor: Cu100; Ni100; Pt100; Pt500; Pt1000; thermocouple E; thermocouple J; thermocouple K; thermocouple N; thermocouple R; thermocouple S; thermocouple T
Controlled parameter: fluid flow; humidity; pressure; speed; temperature
Kind of input 1: 0...5/10V; 0/4...20mA; universal
Kind of input 3: 0/4...20mA
Mounting: on panel
Manufacturer series: RE92
Number of outputs: 6
Number of inputs: 2
Output 1 electrical parameters: 250V AC / 2A
Supply voltage: 85...253V AC; 85...253V DC
The programming method: PC; rubber keypad
Mounting hole diameter: 92.5x92.5mm
IP rating: IP65 (from the front)
Input 1 properties: analogue voltage; current analog; RTD; thermocouple
Kind of display used: colour; LCD TFT 3,5"
Display resolution: 320x240
Body dimensions: 96x96x100mm
Operating temperature: 0...50°C

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: synchro; digital,mounting; LED; 127÷120V; 35÷70Hz; SA19
IP rating: IP52
Manufacturer series: SA19
Dimensions (W x H x D): 96x96x111.5mm
Frequency: 35...70Hz
Input voltage: 127...120V
Related items: ATS-100
Kind of meter: digital; mounting
Mounting: for DIN rail mounting (optional); on panel
Kind of display used: LED
Standard equipment: mounting holder x2
Measurement: phase synchronization
Type of meter: synchro

Hersteller: LUMEL
Category: Digital Panel Meters - Others
Description: Meter: synchro; digital,mounting; LED; 63.5V; 35÷70Hz; SA19; IP52
IP rating: IP52
Manufacturer series: SA19
Dimensions (W x H x D): 96x96x111.5mm
Frequency: 35...70Hz
Input voltage: 63.5V
Related items: ATS-100
Kind of meter: digital; mounting
Mounting: for DIN rail mounting (optional); on panel
Kind of display used: LED
Standard equipment: mounting holder x2
Measurement: phase synchronization
Type of meter: synchro

Hersteller: LUMEL
Category: Current Transformers
Description: Transformer: current; Iin: 300A; Iout: 4÷20mA; Øint: 28mm; 50÷60Hz
Mounting: for bus bar; on cable
Measurement: AC current
Kind of measurement: AVG
Type of Transformer: current
IP rating: IP20
Operating temperature: 0...70°C
Output current: 4...20mA
Internal diameter: 28mm
Conductor rail size: 30mmx10mm
Dimensions (a x b x c): 70x92x44mm
Supply voltage: 24V DC
Operating frequency: 50...60Hz
Input current: 300A
Manufacturer series: T22CT
