Hersteller: Diodes Incorporated
Description: MOSFET N-CH 30V 270MA SOT523
Packaging: Tape & Reel (TR)
Package / Case: SOT-523
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 270mA (Ta)
Rds On (Max) @ Id, Vgs: 2Ohm @ 10mA, 4V
Power Dissipation (Max): 280mW (Ta)
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Supplier Device Package: SOT-523
Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 0.5 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 36.3 pF @ 5 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 40V 8A 6UDFN
Packaging: Tape & Reel (TR)
Package / Case: 6-PowerUDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 8A (Ta)
Rds On (Max) @ Id, Vgs: 20mOhm @ 8A, 10V
Power Dissipation (Max): 660mW (Ta)
Vgs(th) (Max) @ Id: 2.4V @ 250µA
Supplier Device Package: U-DFN2020-6 (Type E)
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 40 V
Gate Charge (Qg) (Max) @ Vgs: 19.1 nC @ 20 V
Input Capacitance (Ciss) (Max) @ Vds: 1060 pF @ 20 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 50V 360MA SOT323
Packaging: Tape & Reel (TR)
Package / Case: SC-70, SOT-323
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 360mA (Ta)
Rds On (Max) @ Id, Vgs: 2Ohm @ 270mA, 10V
Power Dissipation (Max): 320mW (Ta)
Vgs(th) (Max) @ Id: 1.5V @ 100µA
Supplier Device Package: SOT-323
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 50 V
Gate Charge (Qg) (Max) @ Vgs: 1.2 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 45.8 pF @ 25 V

Hersteller: Diodes Incorporated
Description: MOSFET P-CH 20V 4.5A TSOT26
Packaging: Tape & Reel (TR)
Package / Case: SOT-23-6 Thin, TSOT-23-6
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 4.5A (Ta)
Rds On (Max) @ Id, Vgs: 45mOhm @ 4.5A, 4.5V
Power Dissipation (Max): 1.2W (Ta)
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Supplier Device Package: TSOT-23-6
Drive Voltage (Max Rds On, Min Rds On): 2.5V, 4.5V
Vgs (Max): ±8V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 14.4 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 1496 pF @ 15 V

Hersteller: Diodes Incorporated
Description: MOSFET P-CH 30V 11.5A PWRDI3333

Hersteller: Diodes Incorporated
Description: MOSFET P-CH 30V 10.6A TO252

Hersteller: Diodes Incorporated
Description: DIODE ARR SCHOTTKY 100V ITO220AB
Packaging: Tube
Package / Case: TO-220-3 Full Pack, Isolated Tab
Mounting Type: Through Hole
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: Schottky
Diode Configuration: 1 Pair Common Cathode
Current - Average Rectified (Io) (per Diode): 15A
Supplier Device Package: ITO-220AB
Operating Temperature - Junction: -50°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 100 V
Voltage - Forward (Vf) (Max) @ If: 840 mV @ 15 A
Current - Reverse Leakage @ Vr: 50 µA @ 100 V

Hersteller: Diodes Incorporated
Description: IC ELECTRONIC FUSE 10UDFN
Packaging: Tape & Reel (TR)
Package / Case: 10-UFDFN Exposed Pad
Sensing Method: High-Side
Mounting Type: Surface Mount
Function: Electronic Fuse
Voltage - Input: 9V ~ 18V
Current - Output: 3.6A
Operating Temperature: -40°C ~ 150°C
Supplier Device Package: U-DFN3030-10

Hersteller: Diodes Incorporated
Description: IC OP AMP 1CH SOT-25
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Output Type: Rail-to-Rail
Mounting Type: Surface Mount
Amplifier Type: CMOS
Operating Temperature: -40°C ~ 125°C
Current - Supply: 550µA
Slew Rate: 2V/µs
Gain Bandwidth Product: 1.9 MHz
Current - Input Bias: 1 pA
Voltage - Input Offset: 500 µV
Supplier Device Package: SOT-25
Part Status: Active
Number of Circuits: 1
Current - Output / Channel: 8 mA
Voltage - Supply Span (Min): 2.7 V
Voltage - Supply Span (Max): 16 V

Hersteller: Diodes Incorporated
Description: IC CURR MONITOR HIGH SIDE SOT23

Hersteller: Diodes Incorporated
Description: IC REG LINEAR 1.5V 250MA SOT89-3
Packaging: Tape & Reel (TR)
Package / Case: TO-243AA
Output Type: Fixed
Mounting Type: Surface Mount
Current - Output: 250mA
Operating Temperature: -40°C ~ 85°C
Output Configuration: Positive
Current - Quiescent (Iq): 1.5 µA
Voltage - Input (Max): 6V
Number of Regulators: 1
Supplier Device Package: SOT-89-3
Voltage - Output (Min/Fixed): 1.5V
Voltage Dropout (Max): 1.3V @ 250mA
Protection Features: Over Current

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 25V 260MA SOT23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 260mA (Ta)
Rds On (Max) @ Id, Vgs: 4Ohm @ 400mA, 4.5V
Power Dissipation (Max): 320mW (Ta)
Vgs(th) (Max) @ Id: 1.1V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 2.7V, 4.5V
Vgs (Max): 8V
Drain to Source Voltage (Vdss): 25 V
Gate Charge (Qg) (Max) @ Vgs: 0.36 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 27.9 pF @ 10 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 100V 1.4A SOT23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.4A (Ta)
Rds On (Max) @ Id, Vgs: 220mOhm @ 1.6A, 10V
Power Dissipation (Max): 1.3W (Ta)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 8.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 401 pF @ 25 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 20V 9A X1-DFN1616-6
Packaging: Tape & Reel (TR)
Package / Case: 6-PowerUFDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 9A (Ta)
Rds On (Max) @ Id, Vgs: 14mOhm @ 9A, 4.5V
Power Dissipation (Max): 610mW (Ta)
Vgs(th) (Max) @ Id: 900mV @ 250µA
Supplier Device Package: X1-DFN1616-6 (Type E)
Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
Vgs (Max): ±10V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 21.5 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 1788 pF @ 10 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 20V 250MA 3DFN
Packaging: Tape & Reel (TR)
Package / Case: 3-XFDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 250mA (Ta)
Rds On (Max) @ Id, Vgs: 990mOhm @ 100mA, 4.5V
Power Dissipation (Max): 320mW (Ta)
Vgs(th) (Max) @ Id: 1V @ 250µA
Supplier Device Package: X2-DFN0606-3
Drive Voltage (Max Rds On, Min Rds On): 1.2V, 4.5V
Vgs (Max): ±8V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 0.5 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 55.2 pF @ 16 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 300V 250MA SOT23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 250mA (Ta)
Rds On (Max) @ Id, Vgs: 4Ohm @ 300mA, 10V
Power Dissipation (Max): 310mW (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-23-3
Drive Voltage (Max Rds On, Min Rds On): 2.7V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 300 V
Gate Charge (Qg) (Max) @ Vgs: 7.6 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 187.3 pF @ 25 V

Hersteller: Diodes Incorporated
Description: IC AUDIO AMP D 16-SO
Features: Depop, Short-Circuit and Thermal Protection, Shutdown
Packaging: Tape & Reel (TR)
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Output Type: 2-Channel (Stereo)
Mounting Type: Surface Mount
Type: Class D
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 2.5V ~ 6V
Max Output Power x Channels @ Load: 2.4W x 2 @ 4Ohm
Supplier Device Package: 16-SO
Part Status: Active

Hersteller: Diodes Incorporated
Description: DIODE SBR 60V 8A POWERDI5
Packaging: Tape & Reel (TR)
Package / Case: PowerDI™ 5
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Super Barrier
Current - Average Rectified (Io): 8A
Supplier Device Package: PowerDI™ 5
Operating Temperature - Junction: -65°C ~ 150°C
Part Status: Active
Voltage - DC Reverse (Vr) (Max): 60 V
Voltage - Forward (Vf) (Max) @ If: 530 mV @ 8 A
Current - Reverse Leakage @ Vr: 600 µA @ 60 V

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJUSTABLE 4A 8SO

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJ 5A SYNC 8-SO

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 25V 260MA SOT23
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 260mA (Ta)
Rds On (Max) @ Id, Vgs: 4Ohm @ 400mA, 4.5V
Power Dissipation (Max): 320mW (Ta)
Vgs(th) (Max) @ Id: 1.1V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 2.7V, 4.5V
Vgs (Max): 8V
Drain to Source Voltage (Vdss): 25 V
Gate Charge (Qg) (Max) @ Vgs: 0.36 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 27.9 pF @ 10 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 100V 1.4A SOT23
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.4A (Ta)
Rds On (Max) @ Id, Vgs: 220mOhm @ 1.6A, 10V
Power Dissipation (Max): 1.3W (Ta)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 8.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 401 pF @ 25 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 20V 9A X1-DFN1616-6
Packaging: Cut Tape (CT)
Package / Case: 6-PowerUFDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 9A (Ta)
Rds On (Max) @ Id, Vgs: 14mOhm @ 9A, 4.5V
Power Dissipation (Max): 610mW (Ta)
Vgs(th) (Max) @ Id: 900mV @ 250µA
Supplier Device Package: X1-DFN1616-6 (Type E)
Drive Voltage (Max Rds On, Min Rds On): 1.8V, 4.5V
Vgs (Max): ±10V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 21.5 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 1788 pF @ 10 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 20V 250MA 3DFN
Packaging: Cut Tape (CT)
Package / Case: 3-XFDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 250mA (Ta)
Rds On (Max) @ Id, Vgs: 990mOhm @ 100mA, 4.5V
Power Dissipation (Max): 320mW (Ta)
Vgs(th) (Max) @ Id: 1V @ 250µA
Supplier Device Package: X2-DFN0606-3
Drive Voltage (Max Rds On, Min Rds On): 1.2V, 4.5V
Vgs (Max): ±8V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 0.5 nC @ 4.5 V
Input Capacitance (Ciss) (Max) @ Vds: 55.2 pF @ 16 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 300V 250MA SOT23
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 250mA (Ta)
Rds On (Max) @ Id, Vgs: 4Ohm @ 300mA, 10V
Power Dissipation (Max): 310mW (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-23-3
Drive Voltage (Max Rds On, Min Rds On): 2.7V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 300 V
Gate Charge (Qg) (Max) @ Vgs: 7.6 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 187.3 pF @ 25 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 60V 1.6A SOT-23
Packaging: Cut Tape (CT)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.6A (Ta)
Rds On (Max) @ Id, Vgs: 140mOhm @ 1.8A, 10V
Power Dissipation (Max): 700mW (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 8.6 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 315 pF @ 40 V

Hersteller: Diodes Incorporated
Description: IC AUDIO AMP D 16-SO
Features: Depop, Short-Circuit and Thermal Protection, Shutdown
Packaging: Cut Tape (CT)
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Output Type: 2-Channel (Stereo)
Mounting Type: Surface Mount
Type: Class D
Operating Temperature: -40°C ~ 85°C (TA)
Voltage - Supply: 2.5V ~ 6V
Max Output Power x Channels @ Load: 2.4W x 2 @ 4Ohm
Supplier Device Package: 16-SO
Part Status: Active

Hersteller: Diodes Incorporated
Description: DIODE SBR 60V 8A POWERDI5
Packaging: Cut Tape (CT)
Package / Case: PowerDI™ 5
Mounting Type: Surface Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Super Barrier
Current - Average Rectified (Io): 8A
Supplier Device Package: PowerDI™ 5
Operating Temperature - Junction: -65°C ~ 150°C
Part Status: Active
Voltage - DC Reverse (Vr) (Max): 60 V
Voltage - Forward (Vf) (Max) @ If: 530 mV @ 8 A
Current - Reverse Leakage @ Vr: 600 µA @ 60 V

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJUSTABLE 4A 8SO

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJ 5A SYNC 8-SO

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 60V 1.6A SOT-23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.6A (Ta)
Rds On (Max) @ Id, Vgs: 140mOhm @ 1.8A, 10V
Power Dissipation (Max): 700mW (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 8.6 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 315 pF @ 40 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 100V 1.4A SOT23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.4A (Ta)
Rds On (Max) @ Id, Vgs: 220mOhm @ 1.6A, 10V
Power Dissipation (Max): 1.3W (Ta)
Vgs(th) (Max) @ Id: 2.5V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 100 V
Gate Charge (Qg) (Max) @ Vgs: 8.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 401 pF @ 25 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 60V 1.6A SOT23
Packaging: Tape & Reel (TR)
Package / Case: TO-236-3, SC-59, SOT-23-3
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 1.6A (Ta)
Rds On (Max) @ Id, Vgs: 140mOhm @ 1.8A, 10V
Power Dissipation (Max): 700mW (Ta)
Vgs(th) (Max) @ Id: 3V @ 250µA
Supplier Device Package: SOT-23-3
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 8.6 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 315 pF @ 40 V

Hersteller: Diodes Incorporated
Description: EVAL BOARD FOR AL5811
Packaging: Box
Voltage - Output: 1V ~ 60V
Voltage - Input: 3.5V ~ 60V
Contents: Board(s)
Current - Output / Channel: 75mA
Utilized IC / Part: AL5811
Outputs and Type: 1 Non-Isolated Output

Hersteller: Diodes Incorporated
Description: EVAL BOARD FOR AL5812
Packaging: Box
Voltage - Output: 1V ~ 60V
Voltage - Input: 3.5V ~ 60V
Current - Output / Channel: 150mA
Utilized IC / Part: AL5812
Supplied Contents: Board(s)
Outputs and Type: 1, Non-Isolated
Part Status: Active

Hersteller: Diodes Incorporated
Description: EVAL BRD LED DRIVER ADJ LINEAR

Hersteller: Diodes Incorporated
Description: EVAL BOARD FOR AL8807
Features: Dimmable
Packaging: Box
Voltage - Input: 6V ~ 36V
Contents: Board(s)
Current - Output / Channel: 1A
Utilized IC / Part: AL8807
Supplied Contents: Board(s)
Outputs and Type: 1 Non-Isolated Output
Part Status: Active

Hersteller: Diodes Incorporated
Description: EVAL BOARD FOR AL8807
Features: Dimmable
Packaging: Box
Voltage - Input: 6V ~ 36V
Contents: Board(s)
Current - Output / Channel: 1A
Utilized IC / Part: AL8807
Supplied Contents: Board(s)
Outputs and Type: 1 Non-Isolated Output

Hersteller: Diodes Incorporated
Description: EVAL BOARD FOR AL8807
Features: Dimmable
Packaging: Box
Voltage - Input: 6V ~ 36V
Contents: Board(s)
Current - Output / Channel: 1A
Utilized IC / Part: AL8807
Supplied Contents: Board(s)
Outputs and Type: 1 Non-Isolated Output

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJ 4A 16UQFN
Packaging: Tape & Reel (TR)
Package / Case: 16-UFQFN Exposed Pad
Output Type: Adjustable
Mounting Type: Surface Mount
Number of Outputs: 1
Function: Step-Down
Current - Output: 4A
Operating Temperature: -40°C ~ 85°C (TA)
Output Configuration: Positive
Frequency - Switching: 200kHz ~ 2MHz
Voltage - Input (Max): 5.5V
Topology: Buck
Supplier Device Package: U-QFN3030-16 (Type B)
Synchronous Rectifier: Yes
Voltage - Output (Max): 5.5V
Voltage - Input (Min): 2.95V
Voltage - Output (Min/Fixed): 0.803V
Part Status: Obsolete

Hersteller: Diodes Incorporated
Description: IC REG LINEAR POS ADJ 3A 10UDFN
Packaging: Tape & Reel (TR)
Package / Case: 10-UFDFN Exposed Pad
Output Type: Adjustable
Mounting Type: Surface Mount
Current - Output: 3A
Operating Temperature: -40°C ~ 85°C
Output Configuration: Positive
Current - Quiescent (Iq): 1.5 mA
Voltage - Input (Max): 3.65V
Number of Regulators: 1
Supplier Device Package: U-DFN3030-10
Voltage - Output (Max): 3.12V
Voltage - Output (Min/Fixed): 0.8V
Control Features: Enable, Power Good
Voltage Dropout (Max): 0.53V @ 3A
Protection Features: Over Current, Over Temperature, Power On Reset (POR), Short Circuit, Soft Start

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 20V 11.7A 6UDFN
Packaging: Tape & Reel (TR)
Package / Case: 6-PowerUDFN
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 11.7A (Ta)
Rds On (Max) @ Id, Vgs: 9.5mOhm @ 7A, 4.5V
Power Dissipation (Max): 610mW (Ta)
Vgs(th) (Max) @ Id: 1V @ 250µA
Supplier Device Package: U-DFN2020-6 (Type E)
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V
Vgs (Max): ±12V
Drain to Source Voltage (Vdss): 20 V
Gate Charge (Qg) (Max) @ Vgs: 56 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2248 pF @ 10 V

Hersteller: Diodes Incorporated
Description: MOSFET N-CH 30V 4A SOT323
Packaging: Tape & Reel (TR)
Package / Case: SC-70, SOT-323
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 4A (Ta)
Rds On (Max) @ Id, Vgs: 52mOhm @ 4A, 10V
Power Dissipation (Max): 770mW (Ta)
Vgs(th) (Max) @ Id: 1.5V @ 250µA
Supplier Device Package: SOT-323
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 2.5V, 10V
Vgs (Max): ±12V
Drain to Source Voltage (Vdss): 30 V
Gate Charge (Qg) (Max) @ Vgs: 11.7 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 465 pF @ 15 V

Hersteller: Diodes Incorporated
Description: MOSFET P-CH 12V 9.5A 6UDFN
Packaging: Tape & Reel (TR)
Package / Case: 6-UDFN Exposed Pad
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 150°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: P-Channel
Current - Continuous Drain (Id) @ 25°C: 9.5A (Ta)
Rds On (Max) @ Id, Vgs: 15.3mOhm @ 4A, 4.5V
Power Dissipation (Max): 730mW (Ta)
Vgs(th) (Max) @ Id: 800mV @ 250µA
Supplier Device Package: U-DFN2020-6 (Type F)
Drive Voltage (Max Rds On, Min Rds On): 1.5V, 4.5V
Vgs (Max): ±8V
Drain to Source Voltage (Vdss): 12 V
Gate Charge (Qg) (Max) @ Vgs: 48.3 nC @ 8 V
Input Capacitance (Ciss) (Max) @ Vds: 2712 pF @ 10 V

Hersteller: Diodes Incorporated
Description: DIODE SBR 80V 25A POWERDI5060-8
Packaging: Tape & Reel (TR)
Package / Case: 8-PowerTDFN
Mounting Type: Surface Mount
Speed: Fast Recovery =< 500ns, > 200mA (Io)
Technology: Super Barrier
Current - Average Rectified (Io): 25A
Supplier Device Package: PowerDI5060-8
Operating Temperature - Junction: -55°C ~ 150°C
Voltage - DC Reverse (Vr) (Max): 80 V
Voltage - Forward (Vf) (Max) @ If: 610 mV @ 25 A
Current - Reverse Leakage @ Vr: 500 µA @ 80 V

Hersteller: Diodes Incorporated
Description: IC REG BUCK ADJ 4A 8SO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
Output Type: Adjustable
Mounting Type: Surface Mount
Number of Outputs: 1
Function: Step-Down
Current - Output: 4A
Operating Temperature: -40°C ~ 85°C (TA)
Output Configuration: Positive
Frequency - Switching: 750kHz
Voltage - Input (Max): 17V
Topology: Buck
Supplier Device Package: 8-SO-EP
Synchronous Rectifier: Yes
Voltage - Output (Max): 12V
Voltage - Input (Min): 4.75V
Voltage - Output (Min/Fixed): 2.5V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 10V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 10 V
Impedance (Max) (Zzt): 10 Ohms
Supplier Device Package: SOD-523
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 200 nA @ 7 V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 12V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 12 V
Impedance (Max) (Zzt): 10 Ohms
Supplier Device Package: SOD-523
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 100 nA @ 8 V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 13V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 13 V
Impedance (Max) (Zzt): 10 Ohms
Supplier Device Package: SOD-523
Grade: Automotive
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 100 nA @ 8 V
Qualification: AEC-Q101

Hersteller: Diodes Incorporated
Description: DIODE ZENER 15V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 15 V
Impedance (Max) (Zzt): 15 Ohms
Supplier Device Package: SOD-523
Part Status: Active
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 50 nA @ 10.5 V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 16V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 16 V
Impedance (Max) (Zzt): 40 Ohms
Supplier Device Package: SOD-523
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 50 nA @ 11.2 V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 18V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 18 V
Impedance (Max) (Zzt): 45 Ohms
Supplier Device Package: SOD-523
Part Status: Active
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 50 nA @ 12.6 V

Hersteller: Diodes Incorporated
Description: DIODE ZENER 20V 350MW SOD523
Tolerance: ±2%
Packaging: Tape & Reel (TR)
Package / Case: SC-79, SOD-523
Mounting Type: Surface Mount
Operating Temperature: -65°C ~ 150°C
Voltage - Zener (Nom) (Vz): 20 V
Impedance (Max) (Zzt): 55 Ohms
Supplier Device Package: SOD-523
Power - Max: 350 mW
Voltage - Forward (Vf) (Max) @ If: 1.1 V @ 100 mA
Current - Reverse Leakage @ Vr: 50 nA @ 14 V
