IPD50N06S4L12ATMA2 IPD50N06S4L12ATMA2 Infineon Technologies Infineon-IPD50N06S4L_12-DS-v01_00-en.pdf?fileId=db3a30431ff9881501203885cc580ca0 Description: MOSFET N-CH 60V 50A TO252-31
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 50A (Tc)
Rds On (Max) @ Id, Vgs: 12mOhm @ 50A, 10V
Power Dissipation (Max): 50W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 20µA
Supplier Device Package: PG-TO252-3-11
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 40 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2890 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
auf Bestellung 10837 Stücke:
Lieferzeit 10-14 Tag (e)
8+2.20 EUR
13+1.40 EUR
100+0.96 EUR
500+0.77 EUR
1000+0.70 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
IPD25N06S4L30ATMA2 IPD25N06S4L30ATMA2 Infineon Technologies Infineon-IPD25N06S4L_30-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038898f7b0caa Description: MOSFET N-CH 60V 25A TO252-31
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 25A (Tc)
Rds On (Max) @ Id, Vgs: 30mOhm @ 25A, 10V
Power Dissipation (Max): 29W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 8µA
Supplier Device Package: PG-TO252-3-11
Grade: Automotive
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 16.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 25 V
Qualification: AEC-Q101
auf Bestellung 12500 Stücke:
Lieferzeit 10-14 Tag (e)
2500+0.52 EUR
5000+0.50 EUR
7500+0.49 EUR
12500+0.48 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IPI80N06S407AKSA2 IPI80N06S407AKSA2 Infineon Technologies Infineon-I80N06S4_07-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038dc68c00cf5 Description: MOSFET N-CH 60V 80A TO262-3
Packaging: Tube
Package / Case: TO-262-3 Long Leads, I2PAK, TO-262AA
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 7.4mOhm @ 80A, 10V
Power Dissipation (Max): 79W (Tc)
Vgs(th) (Max) @ Id: 4V @ 40µA
Supplier Device Package: PG-TO262-3-1
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 56 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4500 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
auf Bestellung 675 Stücke:
Lieferzeit 10-14 Tag (e)
5+3.77 EUR
50+1.95 EUR
100+1.81 EUR
500+1.45 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
IPP120N06S4H1AKSA2 IPP120N06S4H1AKSA2 Infineon Technologies IPx120N06S4-H1.pdf Description: MOSFET N-CH 60V 120A TO220-3
Packaging: Tube
Package / Case: TO-220-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 120A (Tc)
Rds On (Max) @ Id, Vgs: 2.4mOhm @ 100A, 10V
Power Dissipation (Max): 250W (Tc)
Vgs(th) (Max) @ Id: 4V @ 200µA
Supplier Device Package: PG-TO220-3-1
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 270 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 21900 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IPP80N06S407AKSA2 IPP80N06S407AKSA2 Infineon Technologies Infineon-I80N06S4_07-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038dc68c00cf5 Description: MOSFET N-CH 60V 80A TO220-3
Packaging: Tube
Package / Case: TO-220-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 7.4mOhm @ 80A, 10V
Power Dissipation (Max): 79W (Tc)
Vgs(th) (Max) @ Id: 4V @ 40µA
Supplier Device Package: PG-TO220-3-1
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 56 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4500 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE72422GXUMA2 TLE72422GXUMA2 Infineon Technologies Infineon-TLE7242_2G-DS-v01_01-en.pdf?folderId=db3a30431400ef68011421b54e2e0564&fileId=db3a30431ed1d7b2011eee8d146f5480&ack=t Description: IC CURRENT SOURCE DSO28
Packaging: Tape & Reel (TR)
Package / Case: 28-SOIC (0.295", 7.50mm Width)
Sensing Method: Low-Side
Mounting Type: Surface Mount
Function: Current Source
Voltage - Input: 5.5V ~ 42V
Current - Output: 30mA
Operating Temperature: -40°C ~ 150°C
Supplier Device Package: PG-DSO-28
Part Status: Last Time Buy
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
AUIRS2012STR AUIRS2012STR Infineon Technologies AUIRS2012S.pdf Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C (TA)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: PG-DSO-8
Rise / Fall Time (Typ): 22ns, 15ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.7V, 2.5V
Current - Peak Output (Source, Sink): 2A, 2A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Grade: Automotive
Qualification: AEC-Q100
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE72422GXUMA2 TLE72422GXUMA2 Infineon Technologies Infineon-TLE7242_2G-DS-v01_01-en.pdf?folderId=db3a30431400ef68011421b54e2e0564&fileId=db3a30431ed1d7b2011eee8d146f5480&ack=t Description: IC CURRENT SOURCE DSO28
Packaging: Cut Tape (CT)
Package / Case: 28-SOIC (0.295", 7.50mm Width)
Sensing Method: Low-Side
Mounting Type: Surface Mount
Function: Current Source
Voltage - Input: 5.5V ~ 42V
Current - Output: 30mA
Operating Temperature: -40°C ~ 150°C
Supplier Device Package: PG-DSO-28
Part Status: Last Time Buy
auf Bestellung 500 Stücke:
Lieferzeit 10-14 Tag (e)
1+19.76 EUR
10+17.86 EUR
25+17.03 EUR
100+14.78 EUR
250+14.12 EUR
500+12.87 EUR
Im Einkaufswagen  Stück im Wert von  UAH
IDC04S60CEX1SA1 Infineon Technologies IDC04S60CE.pdf Description: DIODE SIC 600V 4A SAWN WAFER
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC04S60CEX7SA1 Infineon Technologies IDC04S60CE.pdf Description: DIODE GEN PURPOSE SAWN WAFER
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX1SA2 Infineon Technologies IDC08S60CE.pdf Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX1SA3 Infineon Technologies IDC08S60CE.pdf Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX7SA1 Infineon Technologies IDC08S60CE.pdf Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PTFB211803ELV1R0XTMA1 Infineon Technologies PTFB211803EL,FL.pdf Description: IC AMP RF LDMOS H-33288-6
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE2PCS03GXT ICE2PCS03GXT Infineon Technologies ICE2PCS03_G.pdf Description: IC PFC CTRLR CCM 100KHZ 8DSO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C
Voltage - Supply: 11V ~ 25V
Frequency - Switching: 100kHz
Mode: Continuous Conduction (CCM)
Supplier Device Package: PG-DSO-8
Current - Startup: 450 µA
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE2PCS04GXT ICE2PCS04GXT Infineon Technologies ICE2PCS04_G.pdf Description: IC PFC CTRLR CCM 133KHZ 8DSO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C
Voltage - Supply: 11V ~ 25V
Frequency - Switching: 133kHz
Mode: Continuous Conduction (CCM)
Supplier Device Package: PG-DSO-8
Current - Startup: 450 µA
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9831QVXUMA1 TLE9831QVXUMA1 Infineon Technologies Part_Number_Guide_Web.pdf Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QX TLE9832QX Infineon Technologies TLE9832.pdf Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QXXUMA2 TLE9832QXXUMA2 Infineon Technologies TLE9832.pdf Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 3.25K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 27V
Program Memory Type: FLASH (36kB)
Core Processor: XC800
Supplier Device Package: PG-VQFN-48-31
Grade: Automotive
Number of I/O: 11
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QXXUMA3 TLE9832QXXUMA3 Infineon Technologies TLE9832.pdf Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 3.25K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 27V
Program Memory Type: FLASH (36kB)
Applications: Automotive
Core Processor: XC800
Supplier Device Package: PG-VQFN-48-31
Number of I/O: 11
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9833QXXUMA2 TLE9833QXXUMA2 Infineon Technologies TLE9833QX.pdf Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9834QXXUMA1 TLE9834QXXUMA1 Infineon Technologies TLE9834QX.pdf Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE98442QXXUMA1 TLE98442QXXUMA1 Infineon Technologies Infineon-TLE9844-2QX-DS-v01_00-EN.pdf?fileId=5546d46259d9a4bf015a84a1d6e97509 Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 28V
Program Memory Type: FLASH (64kB)
Core Processor: ARM® Cortex®-M0
Supplier Device Package: PG-VQFN-48-31
Part Status: Active
Number of I/O: 10
DigiKey Programmable: Not Verified
Grade: Automotive
Qualification: AEC-Q100
auf Bestellung 2500 Stücke:
Lieferzeit 10-14 Tag (e)
2500+4.19 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
DD1200S33KL2CB5NOSA1 DD1200S33KL2CB5NOSA1 Infineon Technologies DD1200S33KL2C_B5.pdf Description: DIODE MOD GP 3300V 1200A MOD
Packaging: Tray
Package / Case: Block, 4 Lead
Mounting Type: Chassis Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Standard
Diode Configuration: 2 Independent
Current - Average Rectified (Io) (per Diode): 1200A (DC)
Supplier Device Package: Module
Operating Temperature - Junction: -40°C ~ 125°C
Voltage - DC Reverse (Vr) (Max): 3300 V
Voltage - Forward (Vf) (Max) @ If: 3.5 V @ 1200 A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE3BR1065JXKLA1 ICE3BR1065JXKLA1 Infineon Technologies ICE3BR1065J.pdf Description: IC OFFLINE SWITCH FLYBACK 8DIP
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Duty Cycle: 75%
Frequency - Switching: 65kHz
Internal Switch(s): Yes
Voltage - Breakdown: 650V
Output Isolation: Isolated
Topology: Flyback
Voltage - Supply (Vcc/Vdd): 10.5V ~ 25V
Supplier Device Package: PG-DIP-8
Fault Protection: Over Load, Over Temperature, Over Voltage
Voltage - Start Up: 18 V
Part Status: Obsolete
Power (Watts): 62 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
BGS18GA14E6327XTSA1 BGS18GA14E6327XTSA1 Infineon Technologies Infineon-BGS18GA14-DS-v03_00-EN.pdf?fileId=5546d46253f6505701543e060bd6475b Description: IC RF SWITCH SP8T 3.8GHZ ATSLP14
Packaging: Tape & Reel (TR)
Package / Case: 14-UFQFN Exposed Pad
Impedance: 50Ohm
Mounting Type: Surface Mount
Circuit: SP8T
Operating Temperature: -30°C ~ 85°C
Voltage - Supply: 3V
Insertion Loss: 0.7dB
Frequency Range: 100MHz ~ 3.8GHz
Test Frequency: 3.5GHz
Isolation: 33dB
Supplier Device Package: ATSLP-14-4
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD119B1W01005E6327XTSA1 ESD119B1W01005E6327XTSA1 Infineon Technologies Infineon-ESD119-B1-W01005-DS-v01_02-EN.pdf?fileId=5546d462503812bb0150854d53764ca0 Description: TVS DIODE 5.5VWM 14VC P/PGWLL22
Packaging: Tape & Reel (TR)
Package / Case: 01005 (0402 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 0.2pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: P/PG-WLL-2-2
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 14V
Power - Peak Pulse: 35W
Power Line Protection: No
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD128B1W0201E6327XTSA1 ESD128B1W0201E6327XTSA1 Infineon Technologies Infineon-ESD128-B1-W0201-DS-v01_03-EN.pdf?fileId=5546d462503812bb0150854d5b4e4ca3 Description: TVS DIODE 13VWM 18.5VC WLL-2-1
Packaging: Tape & Reel (TR)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: RF Antenna
Capacitance @ Frequency: 0.3pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2A (8/20µs)
Voltage - Reverse Standoff (Typ): 13V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 20V
Voltage - Clamping (Max) @ Ipp: 18.5V
Power - Peak Pulse: 53W
Power Line Protection: No
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
15000+0.04 EUR
Mindestbestellmenge: 15000
Im Einkaufswagen  Stück im Wert von  UAH
ESD231B1W0201E6327XTSA1 ESD231B1W0201E6327XTSA1 Infineon Technologies Infineon-ESD231-B1-W0201-DS-v01_01-EN.pdf?fileId=5546d462503812bb0150854d4bac4c9d Description: TVS DIODE 5.5VWM 10VC WLL-2-1
Packaging: Tape & Reel (TR)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 3.5pF @ 1MHz
Current - Peak Pulse (10/1000µs): 9A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 10V (Typ)
Power - Peak Pulse: 132W
Power Line Protection: No
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
15000+0.04 EUR
Mindestbestellmenge: 15000
Im Einkaufswagen  Stück im Wert von  UAH
IKD03N60RFATMA1 IKD03N60RFATMA1 Infineon Technologies Infineon-IKD03N60RF-DS-v02_06-EN.pdf?fileId=db3a30433c5c92fb013c5d3978350068 Description: IGBT TRENCH/FS 600V 6.5A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 31 ns
Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 2.5A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 10ns/128ns
Switching Energy: 50µJ (on), 40µJ (off)
Test Condition: 400V, 2.5A, 68Ohm, 15V
Gate Charge: 17.1 nC
Part Status: Active
Current - Collector (Ic) (Max): 6.5 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 7.5 A
Power - Max: 53.6 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD04N60RATMA1 IKD04N60RATMA1 Infineon Technologies Infineon-IKD04N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5d927b3e01a0 Description: IGBT TRENCH FS 600V 8A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 43 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 4A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/146ns
Switching Energy: 90µJ (on), 150µJ (off)
Test Condition: 400V, 4A, 43Ohm, 15V
Gate Charge: 27 nC
Part Status: Active
Current - Collector (Ic) (Max): 8 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 12 A
Power - Max: 75 W
auf Bestellung 2500 Stücke:
Lieferzeit 10-14 Tag (e)
2500+0.56 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IKD06N60RATMA1 IKD06N60RATMA1 Infineon Technologies Infineon-IKD06N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5dd406a402d6 Description: IGBT TRENCH FS 600V 12A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 68 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 6A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 12ns/127ns
Switching Energy: 110µJ (on), 220µJ (off)
Test Condition: 400V, 6A, 23Ohm, 15V
Gate Charge: 48 nC
Part Status: Active
Current - Collector (Ic) (Max): 12 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 18 A
Power - Max: 100 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD10N60RATMA1 IKD10N60RATMA1 Infineon Technologies Infineon-IKD10N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5df8088c02fd Description: IGBT TRENCH FS 600V 20A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 10A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/192ns
Switching Energy: 210µJ (on), 380µJ (off)
Test Condition: 400V, 10A, 23Ohm, 15V
Gate Charge: 64 nC
Part Status: Active
Current - Collector (Ic) (Max): 20 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 30 A
Power - Max: 150 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD15N60RATMA1 IKD15N60RATMA1 Infineon Technologies Infineon-IKD15N60R-DS-v02_04-en.pdf?fileId=db3a30433c5c92fb013c5e03026003b2 Description: IGBT TRENCH FS 600V 30A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 15A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 16ns/183ns
Switching Energy: 370µJ (on), 530µJ (off)
Test Condition: 400V, 15A, 15Ohm, 15V
Gate Charge: 90 nC
Part Status: Active
Current - Collector (Ic) (Max): 30 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 45 A
Power - Max: 250 W
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
2500+0.96 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IR44252LTRPBF IR44252LTRPBF Infineon Technologies ir44252l.pdf?fileId=5546d462533600a4015364c51e8e2a38 Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 85ns, 40ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 300mA, 550mA
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44272LTRPBF IR44272LTRPBF Infineon Technologies ir44272l.pdf?fileId=5546d462533600a4015364c5269d2a3b Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44273LTRPBF IR44273LTRPBF Infineon Technologies ir44273l.pdf?fileId=5546d462533600a4015364c52dae2a3d Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 20V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005MTRPBF IRS2005MTRPBF Infineon Technologies irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1 Description: IC GATE DRVR HALF-BRIDGE 14MLPQ
Packaging: Tape & Reel (TR)
Package / Case: 14-VFQFN Exposed Pad
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 14-MLPQ (4x4)
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
3000+0.80 EUR
Mindestbestellmenge: 3000
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005STRPBF IRS2005STRPBF Infineon Technologies irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1 Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 8-SOIC
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 32500 Stücke:
Lieferzeit 10-14 Tag (e)
2500+0.61 EUR
5000+0.59 EUR
12500+0.58 EUR
17500+0.57 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IRSM505-065PATR IRSM505-065PATR Infineon Technologies irsm505-065.pdf?fileId=5546d462533600a40153567bfeae2882 Description: IC HALF BRIDGE DRIVER 2.6A 23SOP
Packaging: Tape & Reel (TR)
Features: Bootstrap Circuit
Package / Case: 23-PowerSMD Module
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 13.5V ~ 16.5V
Rds On (Typ): 1Ohm
Applications: AC Motors
Current - Output / Channel: 2.6A
Current - Peak Output: 15A
Technology: UMOS
Voltage - Load: 400V (Max)
Supplier Device Package: 23-SOP
Fault Protection: UVLO
Load Type: Inductive
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRSM836-084MA IRSM836-084MA Infineon Technologies irsm836-084ma.pdf?fileId=5546d462533600a40153567f2ba0289c Description: IC HALF BRIDGE DRIVER 7A 36QFN
Packaging: Tray
Features: Bootstrap Circuit
Package / Case: 36-PowerVQFN
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 10V ~ 20V
Rds On (Typ): 310mOhm
Applications: AC Motors
Current - Output / Channel: 7A
Current - Peak Output: 27A
Technology: UMOS
Voltage - Load: 200V (Max)
Supplier Device Package: 36-PQFN (12x12)
Fault Protection: UVLO
Load Type: Inductive
Part Status: Active
auf Bestellung 864 Stücke:
Lieferzeit 10-14 Tag (e)
2+12.23 EUR
10+9.45 EUR
25+8.75 EUR
160+7.78 EUR
320+7.53 EUR
480+7.40 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
IGW30N60TPXKSA1 IGW30N60TPXKSA1 Infineon Technologies Infineon-IGW30N60TP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbb9952d7cae Description: IGBT TRENCH FS 600V 53A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 30A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 15ns/179ns
Switching Energy: 710µJ (on), 420µJ (off)
Test Condition: 400V, 30A, 10.5Ohm, 15V
Gate Charge: 130 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 53 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 90 A
Power - Max: 200 W
auf Bestellung 3248 Stücke:
Lieferzeit 10-14 Tag (e)
5+4.17 EUR
30+2.26 EUR
120+1.83 EUR
510+1.53 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
IGW40N60TPXKSA1 IGW40N60TPXKSA1 Infineon Technologies Infineon-IGW40N60TP-DS-v02_01-EN.pdf?fileId=5546d46269e1c019016a495a2ae24852 Description: IGBT TRENCH FS 600V 67A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 40A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 18ns/222ns
Switching Energy: 1.06mJ (on), 610µJ (off)
Test Condition: 400V, 40A, 10.1Ohm, 15V
Gate Charge: 177 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 67 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 120 A
Power - Max: 246 W
auf Bestellung 359 Stücke:
Lieferzeit 10-14 Tag (e)
4+5.40 EUR
30+2.94 EUR
120+2.40 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
IGW50N60TPXKSA1 IGW50N60TPXKSA1 Infineon Technologies Infineon-IGW50N60TP-DS-v02_01-EN.pdf?fileId=5546d46269bda8df0169c912513c1b5b Description: IGBT TRENCH FS 600V 80A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 50A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 20ns/215ns
Switching Energy: 1.53mJ (on), 850µJ (off)
Test Condition: 400V, 50A, 7Ohm, 15V
Gate Charge: 249 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 80 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 150 A
Power - Max: 319.2 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKW40N60DTPXKSA1 IKW40N60DTPXKSA1 Infineon Technologies Infineon-IKW40N60DTP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbc2c3c17cc3 Description: IGBT TRENCH FS 600V 67A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 87 ns
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 40A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 18ns/222ns
Switching Energy: 1.06mJ (on), 610µJ (off)
Test Condition: 400V, 40A, 10.1Ohm, 15V
Gate Charge: 177 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 67 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 120 A
Power - Max: 246 W
auf Bestellung 240 Stücke:
Lieferzeit 10-14 Tag (e)
3+6.20 EUR
30+3.40 EUR
120+2.79 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
IKW50N60DTPXKSA1 IKW50N60DTPXKSA1 Infineon Technologies Infineon-IKW50N60DTP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbc2c1c17cc1 Description: IGBT TRENCH FS 600V 80A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 115 ns
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 50A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 20ns/215ns
Switching Energy: 1.53mJ (on), 850µJ (off)
Test Condition: 400V, 50A, 7Ohm, 15V
Gate Charge: 249 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 80 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 150 A
Power - Max: 319.2 W
auf Bestellung 75 Stücke:
Lieferzeit 10-14 Tag (e)
3+7.04 EUR
30+3.91 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
BGS18GA14E6327XTSA1 BGS18GA14E6327XTSA1 Infineon Technologies Infineon-BGS18GA14-DS-v03_00-EN.pdf?fileId=5546d46253f6505701543e060bd6475b Description: IC RF SWITCH SP8T 3.8GHZ ATSLP14
Packaging: Cut Tape (CT)
Package / Case: 14-UFQFN Exposed Pad
Impedance: 50Ohm
Mounting Type: Surface Mount
Circuit: SP8T
Operating Temperature: -30°C ~ 85°C
Voltage - Supply: 3V
Insertion Loss: 0.7dB
Frequency Range: 100MHz ~ 3.8GHz
Test Frequency: 3.5GHz
Isolation: 33dB
Supplier Device Package: ATSLP-14-4
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD119B1W01005E6327XTSA1 ESD119B1W01005E6327XTSA1 Infineon Technologies Infineon-ESD119-B1-W01005-DS-v01_02-EN.pdf?fileId=5546d462503812bb0150854d53764ca0 Description: TVS DIODE 5.5VWM 14VC P/PGWLL22
Packaging: Cut Tape (CT)
Package / Case: 01005 (0402 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 0.2pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: P/PG-WLL-2-2
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 14V
Power - Peak Pulse: 35W
Power Line Protection: No
auf Bestellung 8090 Stücke:
Lieferzeit 10-14 Tag (e)
84+0.21 EUR
127+0.14 EUR
274+0.06 EUR
500+0.06 EUR
1000+0.05 EUR
2000+0.05 EUR
5000+0.05 EUR
Mindestbestellmenge: 84
Im Einkaufswagen  Stück im Wert von  UAH
ESD128B1W0201E6327XTSA1 ESD128B1W0201E6327XTSA1 Infineon Technologies Infineon-ESD128-B1-W0201-DS-v01_03-EN.pdf?fileId=5546d462503812bb0150854d5b4e4ca3 Description: TVS DIODE 13VWM 18.5VC WLL-2-1
Packaging: Cut Tape (CT)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: RF Antenna
Capacitance @ Frequency: 0.3pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2A (8/20µs)
Voltage - Reverse Standoff (Typ): 13V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 20V
Voltage - Clamping (Max) @ Ipp: 18.5V
Power - Peak Pulse: 53W
Power Line Protection: No
auf Bestellung 21226 Stücke:
Lieferzeit 10-14 Tag (e)
77+0.23 EUR
113+0.16 EUR
278+0.06 EUR
500+0.06 EUR
1000+0.06 EUR
2000+0.06 EUR
5000+0.05 EUR
Mindestbestellmenge: 77
Im Einkaufswagen  Stück im Wert von  UAH
ESD231B1W0201E6327XTSA1 ESD231B1W0201E6327XTSA1 Infineon Technologies Infineon-ESD231-B1-W0201-DS-v01_01-EN.pdf?fileId=5546d462503812bb0150854d4bac4c9d Description: TVS DIODE 5.5VWM 10VC WLL-2-1
Packaging: Cut Tape (CT)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 3.5pF @ 1MHz
Current - Peak Pulse (10/1000µs): 9A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 10V (Typ)
Power - Peak Pulse: 132W
Power Line Protection: No
auf Bestellung 18884 Stücke:
Lieferzeit 10-14 Tag (e)
112+0.16 EUR
179+0.10 EUR
339+0.05 EUR
500+0.05 EUR
1000+0.05 EUR
2000+0.05 EUR
5000+0.05 EUR
Mindestbestellmenge: 112
Im Einkaufswagen  Stück im Wert von  UAH
IKD04N60RATMA1 IKD04N60RATMA1 Infineon Technologies Infineon-IKD04N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5d927b3e01a0 Description: IGBT TRENCH FS 600V 8A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 43 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 4A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/146ns
Switching Energy: 90µJ (on), 150µJ (off)
Test Condition: 400V, 4A, 43Ohm, 15V
Gate Charge: 27 nC
Part Status: Active
Current - Collector (Ic) (Max): 8 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 12 A
Power - Max: 75 W
auf Bestellung 4985 Stücke:
Lieferzeit 10-14 Tag (e)
9+2.11 EUR
14+1.34 EUR
100+0.88 EUR
500+0.69 EUR
1000+0.63 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
IKD06N60RATMA1 IKD06N60RATMA1 Infineon Technologies Infineon-IKD06N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5dd406a402d6 Description: IGBT TRENCH FS 600V 12A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 68 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 6A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 12ns/127ns
Switching Energy: 110µJ (on), 220µJ (off)
Test Condition: 400V, 6A, 23Ohm, 15V
Gate Charge: 48 nC
Part Status: Active
Current - Collector (Ic) (Max): 12 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 18 A
Power - Max: 100 W
auf Bestellung 1463 Stücke:
Lieferzeit 10-14 Tag (e)
8+2.36 EUR
12+1.48 EUR
100+0.99 EUR
500+0.77 EUR
1000+0.71 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
IKD10N60RATMA1 IKD10N60RATMA1 Infineon Technologies Infineon-IKD10N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5df8088c02fd Description: IGBT TRENCH FS 600V 20A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 10A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/192ns
Switching Energy: 210µJ (on), 380µJ (off)
Test Condition: 400V, 10A, 23Ohm, 15V
Gate Charge: 64 nC
Part Status: Active
Current - Collector (Ic) (Max): 20 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 30 A
Power - Max: 150 W
auf Bestellung 1570 Stücke:
Lieferzeit 10-14 Tag (e)
7+2.83 EUR
10+1.81 EUR
100+1.21 EUR
500+0.96 EUR
1000+0.88 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
IKD15N60RATMA1 IKD15N60RATMA1 Infineon Technologies Infineon-IKD15N60R-DS-v02_04-en.pdf?fileId=db3a30433c5c92fb013c5e03026003b2 Description: IGBT TRENCH FS 600V 30A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 15A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 16ns/183ns
Switching Energy: 370µJ (on), 530µJ (off)
Test Condition: 400V, 15A, 15Ohm, 15V
Gate Charge: 90 nC
Part Status: Active
Current - Collector (Ic) (Max): 30 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 45 A
Power - Max: 250 W
auf Bestellung 18611 Stücke:
Lieferzeit 10-14 Tag (e)
6+3.48 EUR
10+2.23 EUR
100+1.52 EUR
500+1.21 EUR
1000+1.17 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
IR44252LTRPBF IR44252LTRPBF Infineon Technologies ir44252l.pdf?fileId=5546d462533600a4015364c51e8e2a38 Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 85ns, 40ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 300mA, 550mA
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44272LTRPBF IR44272LTRPBF Infineon Technologies ir44272l.pdf?fileId=5546d462533600a4015364c5269d2a3b Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44273LTRPBF IR44273LTRPBF Infineon Technologies ir44273l.pdf?fileId=5546d462533600a4015364c52dae2a3d Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 20V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005MTRPBF IRS2005MTRPBF Infineon Technologies irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1 Description: IC GATE DRVR HALF-BRIDGE 14MLPQ
Packaging: Cut Tape (CT)
Package / Case: 14-VFQFN Exposed Pad
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 14-MLPQ (4x4)
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 4765 Stücke:
Lieferzeit 10-14 Tag (e)
11+1.69 EUR
15+1.22 EUR
25+1.10 EUR
100+0.97 EUR
250+0.91 EUR
500+0.87 EUR
1000+0.84 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005STRPBF IRS2005STRPBF Infineon Technologies irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1 Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 8-SOIC
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 33136 Stücke:
Lieferzeit 10-14 Tag (e)
14+1.30 EUR
19+0.93 EUR
25+0.84 EUR
100+0.74 EUR
250+0.69 EUR
500+0.66 EUR
1000+0.64 EUR
Mindestbestellmenge: 14
Im Einkaufswagen  Stück im Wert von  UAH
IRSM505-065PATR IRSM505-065PATR Infineon Technologies irsm505-065.pdf?fileId=5546d462533600a40153567bfeae2882 Description: IC HALF BRIDGE DRIVER 2.6A 23SOP
Features: Bootstrap Circuit
Packaging: Cut Tape (CT)
Package / Case: 23-PowerSMD Module
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 13.5V ~ 16.5V
Rds On (Typ): 1Ohm
Applications: AC Motors
Current - Output / Channel: 2.6A
Current - Peak Output: 15A
Technology: UMOS
Voltage - Load: 400V (Max)
Supplier Device Package: 23-SOP
Fault Protection: UVLO
Load Type: Inductive
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IPD50N06S4L12ATMA2 Infineon-IPD50N06S4L_12-DS-v01_00-en.pdf?fileId=db3a30431ff9881501203885cc580ca0
IPD50N06S4L12ATMA2
Hersteller: Infineon Technologies
Description: MOSFET N-CH 60V 50A TO252-31
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 50A (Tc)
Rds On (Max) @ Id, Vgs: 12mOhm @ 50A, 10V
Power Dissipation (Max): 50W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 20µA
Supplier Device Package: PG-TO252-3-11
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 40 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 2890 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
auf Bestellung 10837 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
8+2.20 EUR
13+1.40 EUR
100+0.96 EUR
500+0.77 EUR
1000+0.70 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
IPD25N06S4L30ATMA2 Infineon-IPD25N06S4L_30-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038898f7b0caa
IPD25N06S4L30ATMA2
Hersteller: Infineon Technologies
Description: MOSFET N-CH 60V 25A TO252-31
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 25A (Tc)
Rds On (Max) @ Id, Vgs: 30mOhm @ 25A, 10V
Power Dissipation (Max): 29W (Tc)
Vgs(th) (Max) @ Id: 2.2V @ 8µA
Supplier Device Package: PG-TO252-3-11
Grade: Automotive
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Vgs (Max): ±16V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 16.3 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 1220 pF @ 25 V
Qualification: AEC-Q101
auf Bestellung 12500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2500+0.52 EUR
5000+0.50 EUR
7500+0.49 EUR
12500+0.48 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IPI80N06S407AKSA2 Infineon-I80N06S4_07-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038dc68c00cf5
IPI80N06S407AKSA2
Hersteller: Infineon Technologies
Description: MOSFET N-CH 60V 80A TO262-3
Packaging: Tube
Package / Case: TO-262-3 Long Leads, I2PAK, TO-262AA
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 7.4mOhm @ 80A, 10V
Power Dissipation (Max): 79W (Tc)
Vgs(th) (Max) @ Id: 4V @ 40µA
Supplier Device Package: PG-TO262-3-1
Part Status: Active
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 56 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4500 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
auf Bestellung 675 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5+3.77 EUR
50+1.95 EUR
100+1.81 EUR
500+1.45 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
IPP120N06S4H1AKSA2 IPx120N06S4-H1.pdf
IPP120N06S4H1AKSA2
Hersteller: Infineon Technologies
Description: MOSFET N-CH 60V 120A TO220-3
Packaging: Tube
Package / Case: TO-220-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 120A (Tc)
Rds On (Max) @ Id, Vgs: 2.4mOhm @ 100A, 10V
Power Dissipation (Max): 250W (Tc)
Vgs(th) (Max) @ Id: 4V @ 200µA
Supplier Device Package: PG-TO220-3-1
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 270 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 21900 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IPP80N06S407AKSA2 Infineon-I80N06S4_07-DS-v01_00-en.pdf?fileId=db3a30431ff98815012038dc68c00cf5
IPP80N06S407AKSA2
Hersteller: Infineon Technologies
Description: MOSFET N-CH 60V 80A TO220-3
Packaging: Tube
Package / Case: TO-220-3
Mounting Type: Through Hole
Operating Temperature: -55°C ~ 175°C (TJ)
Technology: MOSFET (Metal Oxide)
FET Type: N-Channel
Current - Continuous Drain (Id) @ 25°C: 80A (Tc)
Rds On (Max) @ Id, Vgs: 7.4mOhm @ 80A, 10V
Power Dissipation (Max): 79W (Tc)
Vgs(th) (Max) @ Id: 4V @ 40µA
Supplier Device Package: PG-TO220-3-1
Part Status: Obsolete
Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V
Drain to Source Voltage (Vdss): 60 V
Gate Charge (Qg) (Max) @ Vgs: 56 nC @ 10 V
Input Capacitance (Ciss) (Max) @ Vds: 4500 pF @ 25 V
Grade: Automotive
Qualification: AEC-Q101
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE72422GXUMA2 Infineon-TLE7242_2G-DS-v01_01-en.pdf?folderId=db3a30431400ef68011421b54e2e0564&fileId=db3a30431ed1d7b2011eee8d146f5480&ack=t
TLE72422GXUMA2
Hersteller: Infineon Technologies
Description: IC CURRENT SOURCE DSO28
Packaging: Tape & Reel (TR)
Package / Case: 28-SOIC (0.295", 7.50mm Width)
Sensing Method: Low-Side
Mounting Type: Surface Mount
Function: Current Source
Voltage - Input: 5.5V ~ 42V
Current - Output: 30mA
Operating Temperature: -40°C ~ 150°C
Supplier Device Package: PG-DSO-28
Part Status: Last Time Buy
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
AUIRS2012STR AUIRS2012S.pdf
AUIRS2012STR
Hersteller: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C (TA)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: PG-DSO-8
Rise / Fall Time (Typ): 22ns, 15ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.7V, 2.5V
Current - Peak Output (Source, Sink): 2A, 2A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Grade: Automotive
Qualification: AEC-Q100
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE72422GXUMA2 Infineon-TLE7242_2G-DS-v01_01-en.pdf?folderId=db3a30431400ef68011421b54e2e0564&fileId=db3a30431ed1d7b2011eee8d146f5480&ack=t
TLE72422GXUMA2
Hersteller: Infineon Technologies
Description: IC CURRENT SOURCE DSO28
Packaging: Cut Tape (CT)
Package / Case: 28-SOIC (0.295", 7.50mm Width)
Sensing Method: Low-Side
Mounting Type: Surface Mount
Function: Current Source
Voltage - Input: 5.5V ~ 42V
Current - Output: 30mA
Operating Temperature: -40°C ~ 150°C
Supplier Device Package: PG-DSO-28
Part Status: Last Time Buy
auf Bestellung 500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
1+19.76 EUR
10+17.86 EUR
25+17.03 EUR
100+14.78 EUR
250+14.12 EUR
500+12.87 EUR
Im Einkaufswagen  Stück im Wert von  UAH
IDC04S60CEX1SA1 IDC04S60CE.pdf
Hersteller: Infineon Technologies
Description: DIODE SIC 600V 4A SAWN WAFER
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC04S60CEX7SA1 IDC04S60CE.pdf
Hersteller: Infineon Technologies
Description: DIODE GEN PURPOSE SAWN WAFER
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX1SA2 IDC08S60CE.pdf
Hersteller: Infineon Technologies
Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX1SA3 IDC08S60CE.pdf
Hersteller: Infineon Technologies
Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IDC08S60CEX7SA1 IDC08S60CE.pdf
Hersteller: Infineon Technologies
Description: DIODE SIL CARBIDE 600V 8A DIE
Packaging: Bulk
Package / Case: Die
Mounting Type: Surface Mount
Speed: No Recovery Time > 500mA (Io)
Reverse Recovery Time (trr): 0 ns
Technology: SiC (Silicon Carbide) Schottky
Capacitance @ Vr, F: 310pF @ 1V, 1MHz
Current - Average Rectified (Io): 8A
Supplier Device Package: Die
Operating Temperature - Junction: -55°C ~ 175°C
Part Status: Obsolete
Voltage - DC Reverse (Vr) (Max): 600 V
Voltage - Forward (Vf) (Max) @ If: 1.7 V @ 8 A
Current - Reverse Leakage @ Vr: 100 µA @ 600 V
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
PTFB211803ELV1R0XTMA1 PTFB211803EL,FL.pdf
Hersteller: Infineon Technologies
Description: IC AMP RF LDMOS H-33288-6
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE2PCS03GXT ICE2PCS03_G.pdf
ICE2PCS03GXT
Hersteller: Infineon Technologies
Description: IC PFC CTRLR CCM 100KHZ 8DSO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C
Voltage - Supply: 11V ~ 25V
Frequency - Switching: 100kHz
Mode: Continuous Conduction (CCM)
Supplier Device Package: PG-DSO-8
Current - Startup: 450 µA
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE2PCS04GXT ICE2PCS04_G.pdf
ICE2PCS04GXT
Hersteller: Infineon Technologies
Description: IC PFC CTRLR CCM 133KHZ 8DSO
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 125°C
Voltage - Supply: 11V ~ 25V
Frequency - Switching: 133kHz
Mode: Continuous Conduction (CCM)
Supplier Device Package: PG-DSO-8
Current - Startup: 450 µA
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9831QVXUMA1 Part_Number_Guide_Web.pdf
TLE9831QVXUMA1
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QX TLE9832.pdf
TLE9832QX
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QXXUMA2 TLE9832.pdf
TLE9832QXXUMA2
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 3.25K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 27V
Program Memory Type: FLASH (36kB)
Core Processor: XC800
Supplier Device Package: PG-VQFN-48-31
Grade: Automotive
Number of I/O: 11
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9832QXXUMA3 TLE9832.pdf
TLE9832QXXUMA3
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 3.25K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 27V
Program Memory Type: FLASH (36kB)
Applications: Automotive
Core Processor: XC800
Supplier Device Package: PG-VQFN-48-31
Number of I/O: 11
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9833QXXUMA2 TLE9833QX.pdf
TLE9833QXXUMA2
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE9834QXXUMA1 TLE9834QX.pdf
TLE9834QXXUMA1
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
TLE98442QXXUMA1 Infineon-TLE9844-2QX-DS-v01_00-EN.pdf?fileId=5546d46259d9a4bf015a84a1d6e97509
TLE98442QXXUMA1
Hersteller: Infineon Technologies
Description: IC MOTOR DRIVER 48VQFN
Packaging: Tape & Reel (TR)
Package / Case: 48-VFQFN Exposed Pad
Mounting Type: Surface Mount
Interface: LIN, SSI, UART
RAM Size: 4K x 8
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 3V ~ 28V
Program Memory Type: FLASH (64kB)
Core Processor: ARM® Cortex®-M0
Supplier Device Package: PG-VQFN-48-31
Part Status: Active
Number of I/O: 10
DigiKey Programmable: Not Verified
Grade: Automotive
Qualification: AEC-Q100
auf Bestellung 2500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2500+4.19 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
DD1200S33KL2CB5NOSA1 DD1200S33KL2C_B5.pdf
DD1200S33KL2CB5NOSA1
Hersteller: Infineon Technologies
Description: DIODE MOD GP 3300V 1200A MOD
Packaging: Tray
Package / Case: Block, 4 Lead
Mounting Type: Chassis Mount
Speed: Standard Recovery >500ns, > 200mA (Io)
Technology: Standard
Diode Configuration: 2 Independent
Current - Average Rectified (Io) (per Diode): 1200A (DC)
Supplier Device Package: Module
Operating Temperature - Junction: -40°C ~ 125°C
Voltage - DC Reverse (Vr) (Max): 3300 V
Voltage - Forward (Vf) (Max) @ If: 3.5 V @ 1200 A
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ICE3BR1065JXKLA1 ICE3BR1065J.pdf
ICE3BR1065JXKLA1
Hersteller: Infineon Technologies
Description: IC OFFLINE SWITCH FLYBACK 8DIP
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 150°C (TJ)
Duty Cycle: 75%
Frequency - Switching: 65kHz
Internal Switch(s): Yes
Voltage - Breakdown: 650V
Output Isolation: Isolated
Topology: Flyback
Voltage - Supply (Vcc/Vdd): 10.5V ~ 25V
Supplier Device Package: PG-DIP-8
Fault Protection: Over Load, Over Temperature, Over Voltage
Voltage - Start Up: 18 V
Part Status: Obsolete
Power (Watts): 62 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
BGS18GA14E6327XTSA1 Infineon-BGS18GA14-DS-v03_00-EN.pdf?fileId=5546d46253f6505701543e060bd6475b
BGS18GA14E6327XTSA1
Hersteller: Infineon Technologies
Description: IC RF SWITCH SP8T 3.8GHZ ATSLP14
Packaging: Tape & Reel (TR)
Package / Case: 14-UFQFN Exposed Pad
Impedance: 50Ohm
Mounting Type: Surface Mount
Circuit: SP8T
Operating Temperature: -30°C ~ 85°C
Voltage - Supply: 3V
Insertion Loss: 0.7dB
Frequency Range: 100MHz ~ 3.8GHz
Test Frequency: 3.5GHz
Isolation: 33dB
Supplier Device Package: ATSLP-14-4
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD119B1W01005E6327XTSA1 Infineon-ESD119-B1-W01005-DS-v01_02-EN.pdf?fileId=5546d462503812bb0150854d53764ca0
ESD119B1W01005E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 5.5VWM 14VC P/PGWLL22
Packaging: Tape & Reel (TR)
Package / Case: 01005 (0402 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 0.2pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: P/PG-WLL-2-2
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 14V
Power - Peak Pulse: 35W
Power Line Protection: No
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD128B1W0201E6327XTSA1 Infineon-ESD128-B1-W0201-DS-v01_03-EN.pdf?fileId=5546d462503812bb0150854d5b4e4ca3
ESD128B1W0201E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 13VWM 18.5VC WLL-2-1
Packaging: Tape & Reel (TR)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: RF Antenna
Capacitance @ Frequency: 0.3pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2A (8/20µs)
Voltage - Reverse Standoff (Typ): 13V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 20V
Voltage - Clamping (Max) @ Ipp: 18.5V
Power - Peak Pulse: 53W
Power Line Protection: No
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
15000+0.04 EUR
Mindestbestellmenge: 15000
Im Einkaufswagen  Stück im Wert von  UAH
ESD231B1W0201E6327XTSA1 Infineon-ESD231-B1-W0201-DS-v01_01-EN.pdf?fileId=5546d462503812bb0150854d4bac4c9d
ESD231B1W0201E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 5.5VWM 10VC WLL-2-1
Packaging: Tape & Reel (TR)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 3.5pF @ 1MHz
Current - Peak Pulse (10/1000µs): 9A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 10V (Typ)
Power - Peak Pulse: 132W
Power Line Protection: No
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
15000+0.04 EUR
Mindestbestellmenge: 15000
Im Einkaufswagen  Stück im Wert von  UAH
IKD03N60RFATMA1 Infineon-IKD03N60RF-DS-v02_06-EN.pdf?fileId=db3a30433c5c92fb013c5d3978350068
IKD03N60RFATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH/FS 600V 6.5A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 31 ns
Vce(on) (Max) @ Vge, Ic: 2.5V @ 15V, 2.5A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 10ns/128ns
Switching Energy: 50µJ (on), 40µJ (off)
Test Condition: 400V, 2.5A, 68Ohm, 15V
Gate Charge: 17.1 nC
Part Status: Active
Current - Collector (Ic) (Max): 6.5 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 7.5 A
Power - Max: 53.6 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD04N60RATMA1 Infineon-IKD04N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5d927b3e01a0
IKD04N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 8A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 43 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 4A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/146ns
Switching Energy: 90µJ (on), 150µJ (off)
Test Condition: 400V, 4A, 43Ohm, 15V
Gate Charge: 27 nC
Part Status: Active
Current - Collector (Ic) (Max): 8 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 12 A
Power - Max: 75 W
auf Bestellung 2500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2500+0.56 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IKD06N60RATMA1 Infineon-IKD06N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5dd406a402d6
IKD06N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 12A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 68 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 6A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 12ns/127ns
Switching Energy: 110µJ (on), 220µJ (off)
Test Condition: 400V, 6A, 23Ohm, 15V
Gate Charge: 48 nC
Part Status: Active
Current - Collector (Ic) (Max): 12 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 18 A
Power - Max: 100 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD10N60RATMA1 Infineon-IKD10N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5df8088c02fd
IKD10N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 20A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 10A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/192ns
Switching Energy: 210µJ (on), 380µJ (off)
Test Condition: 400V, 10A, 23Ohm, 15V
Gate Charge: 64 nC
Part Status: Active
Current - Collector (Ic) (Max): 20 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 30 A
Power - Max: 150 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKD15N60RATMA1 Infineon-IKD15N60R-DS-v02_04-en.pdf?fileId=db3a30433c5c92fb013c5e03026003b2
IKD15N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 30A TO252-3
Packaging: Tape & Reel (TR)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 15A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 16ns/183ns
Switching Energy: 370µJ (on), 530µJ (off)
Test Condition: 400V, 15A, 15Ohm, 15V
Gate Charge: 90 nC
Part Status: Active
Current - Collector (Ic) (Max): 30 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 45 A
Power - Max: 250 W
auf Bestellung 15000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2500+0.96 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IR44252LTRPBF ir44252l.pdf?fileId=5546d462533600a4015364c51e8e2a38
IR44252LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 85ns, 40ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 300mA, 550mA
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44272LTRPBF ir44272l.pdf?fileId=5546d462533600a4015364c5269d2a3b
IR44272LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44273LTRPBF ir44273l.pdf?fileId=5546d462533600a4015364c52dae2a3d
IR44273LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Tape & Reel (TR)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 20V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005MTRPBF irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1
IRS2005MTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 14MLPQ
Packaging: Tape & Reel (TR)
Package / Case: 14-VFQFN Exposed Pad
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 14-MLPQ (4x4)
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 3000 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
3000+0.80 EUR
Mindestbestellmenge: 3000
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005STRPBF irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1
IRS2005STRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Tape & Reel (TR)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 8-SOIC
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 32500 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2500+0.61 EUR
5000+0.59 EUR
12500+0.58 EUR
17500+0.57 EUR
Mindestbestellmenge: 2500
Im Einkaufswagen  Stück im Wert von  UAH
IRSM505-065PATR irsm505-065.pdf?fileId=5546d462533600a40153567bfeae2882
IRSM505-065PATR
Hersteller: Infineon Technologies
Description: IC HALF BRIDGE DRIVER 2.6A 23SOP
Packaging: Tape & Reel (TR)
Features: Bootstrap Circuit
Package / Case: 23-PowerSMD Module
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 13.5V ~ 16.5V
Rds On (Typ): 1Ohm
Applications: AC Motors
Current - Output / Channel: 2.6A
Current - Peak Output: 15A
Technology: UMOS
Voltage - Load: 400V (Max)
Supplier Device Package: 23-SOP
Fault Protection: UVLO
Load Type: Inductive
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRSM836-084MA irsm836-084ma.pdf?fileId=5546d462533600a40153567f2ba0289c
IRSM836-084MA
Hersteller: Infineon Technologies
Description: IC HALF BRIDGE DRIVER 7A 36QFN
Packaging: Tray
Features: Bootstrap Circuit
Package / Case: 36-PowerVQFN
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 10V ~ 20V
Rds On (Typ): 310mOhm
Applications: AC Motors
Current - Output / Channel: 7A
Current - Peak Output: 27A
Technology: UMOS
Voltage - Load: 200V (Max)
Supplier Device Package: 36-PQFN (12x12)
Fault Protection: UVLO
Load Type: Inductive
Part Status: Active
auf Bestellung 864 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
2+12.23 EUR
10+9.45 EUR
25+8.75 EUR
160+7.78 EUR
320+7.53 EUR
480+7.40 EUR
Mindestbestellmenge: 2
Im Einkaufswagen  Stück im Wert von  UAH
IGW30N60TPXKSA1 Infineon-IGW30N60TP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbb9952d7cae
IGW30N60TPXKSA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 53A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 30A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 15ns/179ns
Switching Energy: 710µJ (on), 420µJ (off)
Test Condition: 400V, 30A, 10.5Ohm, 15V
Gate Charge: 130 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 53 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 90 A
Power - Max: 200 W
auf Bestellung 3248 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
5+4.17 EUR
30+2.26 EUR
120+1.83 EUR
510+1.53 EUR
Mindestbestellmenge: 5
Im Einkaufswagen  Stück im Wert von  UAH
IGW40N60TPXKSA1 Infineon-IGW40N60TP-DS-v02_01-EN.pdf?fileId=5546d46269e1c019016a495a2ae24852
IGW40N60TPXKSA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 67A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 40A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 18ns/222ns
Switching Energy: 1.06mJ (on), 610µJ (off)
Test Condition: 400V, 40A, 10.1Ohm, 15V
Gate Charge: 177 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 67 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 120 A
Power - Max: 246 W
auf Bestellung 359 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
4+5.40 EUR
30+2.94 EUR
120+2.40 EUR
Mindestbestellmenge: 4
Im Einkaufswagen  Stück im Wert von  UAH
IGW50N60TPXKSA1 Infineon-IGW50N60TP-DS-v02_01-EN.pdf?fileId=5546d46269bda8df0169c912513c1b5b
IGW50N60TPXKSA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 80A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 50A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 20ns/215ns
Switching Energy: 1.53mJ (on), 850µJ (off)
Test Condition: 400V, 50A, 7Ohm, 15V
Gate Charge: 249 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 80 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 150 A
Power - Max: 319.2 W
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IKW40N60DTPXKSA1 Infineon-IKW40N60DTP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbc2c3c17cc3
IKW40N60DTPXKSA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 67A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 87 ns
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 40A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 18ns/222ns
Switching Energy: 1.06mJ (on), 610µJ (off)
Test Condition: 400V, 40A, 10.1Ohm, 15V
Gate Charge: 177 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 67 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 120 A
Power - Max: 246 W
auf Bestellung 240 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
3+6.20 EUR
30+3.40 EUR
120+2.79 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
IKW50N60DTPXKSA1 Infineon-IKW50N60DTP-DS-v02_01-EN.pdf?fileId=5546d46253a864fe0153cbc2c1c17cc1
IKW50N60DTPXKSA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 80A TO247-3
Packaging: Tube
Package / Case: TO-247-3
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 115 ns
Vce(on) (Max) @ Vge, Ic: 1.8V @ 15V, 50A
Supplier Device Package: PG-TO247-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 20ns/215ns
Switching Energy: 1.53mJ (on), 850µJ (off)
Test Condition: 400V, 50A, 7Ohm, 15V
Gate Charge: 249 nC
Part Status: Not For New Designs
Current - Collector (Ic) (Max): 80 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 150 A
Power - Max: 319.2 W
auf Bestellung 75 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
3+7.04 EUR
30+3.91 EUR
Mindestbestellmenge: 3
Im Einkaufswagen  Stück im Wert von  UAH
BGS18GA14E6327XTSA1 Infineon-BGS18GA14-DS-v03_00-EN.pdf?fileId=5546d46253f6505701543e060bd6475b
BGS18GA14E6327XTSA1
Hersteller: Infineon Technologies
Description: IC RF SWITCH SP8T 3.8GHZ ATSLP14
Packaging: Cut Tape (CT)
Package / Case: 14-UFQFN Exposed Pad
Impedance: 50Ohm
Mounting Type: Surface Mount
Circuit: SP8T
Operating Temperature: -30°C ~ 85°C
Voltage - Supply: 3V
Insertion Loss: 0.7dB
Frequency Range: 100MHz ~ 3.8GHz
Test Frequency: 3.5GHz
Isolation: 33dB
Supplier Device Package: ATSLP-14-4
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
ESD119B1W01005E6327XTSA1 Infineon-ESD119-B1-W01005-DS-v01_02-EN.pdf?fileId=5546d462503812bb0150854d53764ca0
ESD119B1W01005E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 5.5VWM 14VC P/PGWLL22
Packaging: Cut Tape (CT)
Package / Case: 01005 (0402 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 0.2pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: P/PG-WLL-2-2
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 14V
Power - Peak Pulse: 35W
Power Line Protection: No
auf Bestellung 8090 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
84+0.21 EUR
127+0.14 EUR
274+0.06 EUR
500+0.06 EUR
1000+0.05 EUR
2000+0.05 EUR
5000+0.05 EUR
Mindestbestellmenge: 84
Im Einkaufswagen  Stück im Wert von  UAH
ESD128B1W0201E6327XTSA1 Infineon-ESD128-B1-W0201-DS-v01_03-EN.pdf?fileId=5546d462503812bb0150854d5b4e4ca3
ESD128B1W0201E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 13VWM 18.5VC WLL-2-1
Packaging: Cut Tape (CT)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: RF Antenna
Capacitance @ Frequency: 0.3pF @ 1MHz
Current - Peak Pulse (10/1000µs): 2A (8/20µs)
Voltage - Reverse Standoff (Typ): 13V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 20V
Voltage - Clamping (Max) @ Ipp: 18.5V
Power - Peak Pulse: 53W
Power Line Protection: No
auf Bestellung 21226 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
77+0.23 EUR
113+0.16 EUR
278+0.06 EUR
500+0.06 EUR
1000+0.06 EUR
2000+0.06 EUR
5000+0.05 EUR
Mindestbestellmenge: 77
Im Einkaufswagen  Stück im Wert von  UAH
ESD231B1W0201E6327XTSA1 Infineon-ESD231-B1-W0201-DS-v01_01-EN.pdf?fileId=5546d462503812bb0150854d4bac4c9d
ESD231B1W0201E6327XTSA1
Hersteller: Infineon Technologies
Description: TVS DIODE 5.5VWM 10VC WLL-2-1
Packaging: Cut Tape (CT)
Package / Case: 0201 (0603 Metric)
Mounting Type: Surface Mount
Type: Zener
Operating Temperature: -55°C ~ 125°C (TJ)
Applications: HDMI
Capacitance @ Frequency: 3.5pF @ 1MHz
Current - Peak Pulse (10/1000µs): 9A (8/20µs)
Voltage - Reverse Standoff (Typ): 5.5V (Max)
Supplier Device Package: WLL-2-1
Bidirectional Channels: 1
Voltage - Breakdown (Min): 6.1V
Voltage - Clamping (Max) @ Ipp: 10V (Typ)
Power - Peak Pulse: 132W
Power Line Protection: No
auf Bestellung 18884 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
112+0.16 EUR
179+0.10 EUR
339+0.05 EUR
500+0.05 EUR
1000+0.05 EUR
2000+0.05 EUR
5000+0.05 EUR
Mindestbestellmenge: 112
Im Einkaufswagen  Stück im Wert von  UAH
IKD04N60RATMA1 Infineon-IKD04N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5d927b3e01a0
IKD04N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 8A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 43 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 4A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/146ns
Switching Energy: 90µJ (on), 150µJ (off)
Test Condition: 400V, 4A, 43Ohm, 15V
Gate Charge: 27 nC
Part Status: Active
Current - Collector (Ic) (Max): 8 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 12 A
Power - Max: 75 W
auf Bestellung 4985 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
9+2.11 EUR
14+1.34 EUR
100+0.88 EUR
500+0.69 EUR
1000+0.63 EUR
Mindestbestellmenge: 9
Im Einkaufswagen  Stück im Wert von  UAH
IKD06N60RATMA1 Infineon-IKD06N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5dd406a402d6
IKD06N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 12A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Reverse Recovery Time (trr): 68 ns
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 6A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 12ns/127ns
Switching Energy: 110µJ (on), 220µJ (off)
Test Condition: 400V, 6A, 23Ohm, 15V
Gate Charge: 48 nC
Part Status: Active
Current - Collector (Ic) (Max): 12 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 18 A
Power - Max: 100 W
auf Bestellung 1463 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
8+2.36 EUR
12+1.48 EUR
100+0.99 EUR
500+0.77 EUR
1000+0.71 EUR
Mindestbestellmenge: 8
Im Einkaufswagen  Stück im Wert von  UAH
IKD10N60RATMA1 Infineon-IKD10N60R-DS-v02_05-en.pdf?fileId=db3a30433c5c92fb013c5df8088c02fd
IKD10N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 20A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 10A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 14ns/192ns
Switching Energy: 210µJ (on), 380µJ (off)
Test Condition: 400V, 10A, 23Ohm, 15V
Gate Charge: 64 nC
Part Status: Active
Current - Collector (Ic) (Max): 20 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 30 A
Power - Max: 150 W
auf Bestellung 1570 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
7+2.83 EUR
10+1.81 EUR
100+1.21 EUR
500+0.96 EUR
1000+0.88 EUR
Mindestbestellmenge: 7
Im Einkaufswagen  Stück im Wert von  UAH
IKD15N60RATMA1 Infineon-IKD15N60R-DS-v02_04-en.pdf?fileId=db3a30433c5c92fb013c5e03026003b2
IKD15N60RATMA1
Hersteller: Infineon Technologies
Description: IGBT TRENCH FS 600V 30A TO252-3
Packaging: Cut Tape (CT)
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 175°C (TJ)
Input Type: Standard
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 15A
Supplier Device Package: PG-TO252-3
IGBT Type: Trench Field Stop
Td (on/off) @ 25°C: 16ns/183ns
Switching Energy: 370µJ (on), 530µJ (off)
Test Condition: 400V, 15A, 15Ohm, 15V
Gate Charge: 90 nC
Part Status: Active
Current - Collector (Ic) (Max): 30 A
Voltage - Collector Emitter Breakdown (Max): 600 V
Current - Collector Pulsed (Icm): 45 A
Power - Max: 250 W
auf Bestellung 18611 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
6+3.48 EUR
10+2.23 EUR
100+1.52 EUR
500+1.21 EUR
1000+1.17 EUR
Mindestbestellmenge: 6
Im Einkaufswagen  Stück im Wert von  UAH
IR44252LTRPBF ir44252l.pdf?fileId=5546d462533600a4015364c51e8e2a38
IR44252LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 85ns, 40ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 300mA, 550mA
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44272LTRPBF ir44272l.pdf?fileId=5546d462533600a4015364c5269d2a3b
IR44272LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 18V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IR44273LTRPBF ir44273l.pdf?fileId=5546d462533600a4015364c52dae2a3d
IR44273LTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR LOW-SIDE SOT23-5
Packaging: Cut Tape (CT)
Package / Case: SC-74A, SOT-753
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 5V ~ 20V
Input Type: Non-Inverting
Supplier Device Package: PG-SOT23-5
Rise / Fall Time (Typ): 10ns, 10ns
Channel Type: Single
Driven Configuration: Low-Side
Number of Drivers: 1
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.6V, 2.7V
Current - Peak Output (Source, Sink): 1.5A, 1.5A
Part Status: Obsolete
DigiKey Programmable: Not Verified
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005MTRPBF irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1
IRS2005MTRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 14MLPQ
Packaging: Cut Tape (CT)
Package / Case: 14-VFQFN Exposed Pad
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 14-MLPQ (4x4)
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 4765 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
11+1.69 EUR
15+1.22 EUR
25+1.10 EUR
100+0.97 EUR
250+0.91 EUR
500+0.87 EUR
1000+0.84 EUR
Mindestbestellmenge: 11
Im Einkaufswagen  Stück im Wert von  UAH
IRS2005STRPBF irs2005s.pdf?fileId=5546d462533600a4015364c4246229e1
IRS2005STRPBF
Hersteller: Infineon Technologies
Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Packaging: Cut Tape (CT)
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 150°C (TJ)
Voltage - Supply: 10V ~ 20V
Input Type: Non-Inverting
High Side Voltage - Max (Bootstrap): 200 V
Supplier Device Package: 8-SOIC
Rise / Fall Time (Typ): 70ns, 30ns
Channel Type: Independent
Driven Configuration: Half-Bridge
Number of Drivers: 2
Gate Type: IGBT, MOSFET (N-Channel)
Logic Voltage - VIL, VIH: 0.8V, 2.5V
Current - Peak Output (Source, Sink): 290mA, 600mA
Part Status: Active
DigiKey Programmable: Not Verified
auf Bestellung 33136 Stücke:
Lieferzeit 10-14 Tag (e)
Anzahl Preis
14+1.30 EUR
19+0.93 EUR
25+0.84 EUR
100+0.74 EUR
250+0.69 EUR
500+0.66 EUR
1000+0.64 EUR
Mindestbestellmenge: 14
Im Einkaufswagen  Stück im Wert von  UAH
IRSM505-065PATR irsm505-065.pdf?fileId=5546d462533600a40153567bfeae2882
IRSM505-065PATR
Hersteller: Infineon Technologies
Description: IC HALF BRIDGE DRIVER 2.6A 23SOP
Features: Bootstrap Circuit
Packaging: Cut Tape (CT)
Package / Case: 23-PowerSMD Module
Mounting Type: Surface Mount
Interface: Logic
Operating Temperature: -40°C ~ 150°C (TJ)
Output Configuration: Half Bridge (3)
Voltage - Supply: 13.5V ~ 16.5V
Rds On (Typ): 1Ohm
Applications: AC Motors
Current - Output / Channel: 2.6A
Current - Peak Output: 15A
Technology: UMOS
Voltage - Load: 400V (Max)
Supplier Device Package: 23-SOP
Fault Protection: UVLO
Load Type: Inductive
Part Status: Obsolete
Produkt ist nicht verfügbar
Im Einkaufswagen  Stück im Wert von  UAH
Wählen Sie Seite:   [  << Vorherige Seite ]  1 247 275 276 277 278 279 280 281 282 283 284 285 494 741 988 1235 1482 1729 1976 2223 2470 2478  [ Nächste Seite >> ]
